Analog Barometer Card – a simple SVG gauge for Home Assistant

Share your Projects! Dashboards & Frontend
1

I've just released my first custom Home Assistant card:

Analog Barometer Card

It's a lightweight SVG-based Lovelace card that displays atmospheric pressure using a traditional analogue barometer style gauge.

I originally built it because I wanted something that looked a bit more like a real barometer than the existing options I could find. Rather than trying to recreate a full physical instrument, the aim was to create a clean, responsive card that fits naturally into modern Home Assistant dashboards.

Features

  • Fully SVG based (crisp at any size)
  • Smooth animated needle
  • Configurable pressure range
  • Configurable warning/normal zones
  • Supports any pressure sensor
  • Lightweight with no external dependencies

Example configuration is included in the repository, along with installation instructions.

I'd really appreciate any feedback, feature requests or bug reports. If there are improvements that would make it more useful for other dashboards, let me know.

GitHub:

Hopefully someone else finds it useful!

1 Like
Analog Cards – a family of analogue-style Lovelace cards for Home Assistant
2

Just installed it. Exactly what I was looking for. Many thanks.

1 Like
3

I’m looking to increase the size of the pressure tendency text (steady etc). Is that possible? TIA

4

Ill take a look at this, it should be easy to do. I will see how a small increase and maybe make it configurable

5

I started making some new cards and instead of having one repo per card I have consolidated into one new repo.

See - GitHub - gramtech/homeassistant-analog-cards · GitHub

hope you find these useful

6

I have done this now, default is slightly larger but its adjustable in the card settings.
However I have made all these changes in a new repo which has this card and more.

See - Analog Cards – a family of analogue-style Lovelace cards for Home Assistant
