Aqara T2 for curtain/shutter

JPT123 · June 25, 2025, 12:59pm

Hi,
I would like to automate my new window shutter with the aqara T2 relay.
When you use it with the aqara hub, you can set it to shutter mode which interlocks the relays so both cannot be active at the same time.

in Homeassist I cannot find any of this.
Should I just define this in the automation?
Is this enough so the magic smoke doesn’t come out?

thanks

ShadowFist · June 25, 2025, 7:09pm

I’m guessing you’re using the native HomeAssistant zigbee integration called ZHA. If that’s the case, I don’t believe this has been implemented yet.

You might want to consider moving to Zigbee2MQTT instead of attempting to let out the magic smoke. It has built-in support for interlock on the T2 relay.

JPT123 · July 6, 2025, 11:44am

Ah, ok. Yes I seem to be using ZHA.
Since the aqara was borrowed only, i switched to the MOES curtain module instead (which isn’t without any problems either - separate thread)

JPT123 · July 6, 2025, 1:24pm

I found a solution for the interlock.

github.com/zigpy/zha-device-handlers

[Device Support Request] Aqara T2 Dual Relay (LLKZMK12LM / acn047) - Interlock support

opened 10:21PM - 02 Dec 23 UTC

closed 04:37PM - 27 Dec 23 UTC

pilot51

Xiaomi

### Problem description I bought two Aqara T2's to control two roller shades.… I thought I'd be able to toggle interlock mode (prevents both switches being on at the same time) through ZHA in Home Assistant, but so far I've been unable to find a way to do it even in the clusters/attributes under Manage Zigbee Device. I see no "interlock" attribute or anything that looks similar. ### Solution description Interlock mode available for the Aqara T2 through ZHA in Home Assistant. ### Screenshots/Video _No response_ ### Device signature <details><summary>Device signature</summary> ```json { "node_descriptor": "NodeDescriptor(logical_type=<LogicalType.Router: 1>, complex_descriptor_available=0, user_descriptor_available=0, reserved=0, aps_flags=0, frequency_band=<FrequencyBand.Freq2400MHz: 8>, mac_capability_flags=<MACCapabilityFlags.FullFunctionDevice|MainsPowered|RxOnWhenIdle|AllocateAddress: 142>, manufacturer_code=4447, maximum_buffer_size=82, maximum_incoming_transfer_size=82, server_mask=11264, maximum_outgoing_transfer_size=82, descriptor_capability_field=<DescriptorCapability.NONE: 0>, *allocate_address=True, *is_alternate_pan_coordinator=False, *is_coordinator=False, *is_end_device=False, *is_full_function_device=True, *is_mains_powered=True, *is_receiver_on_when_idle=True, *is_router=True, *is_security_capable=False)", "endpoints": { "1": { "profile_id": "0x0104", "device_type": "0x0000", "input_clusters": [ "0x0000", "0x0003", "0x0004", "0x0005", "0x0006", "0x0012", "0x0702", "0x0b04", "0xfcc0" ], "output_clusters": [ "0x000a", "0x0019" ] }, "2": { "profile_id": "0x0104", "device_type": "0x0000", "input_clusters": [ "0x0003", "0x0004", "0x0005", "0x0006", "0x0012", "0xfcc0" ], "output_clusters": [] }, "21": { "profile_id": "0x0104", "device_type": "0x0000", "input_clusters": [ "0x000c" ], "output_clusters": [] } }, "manufacturer": "Aqara", "model": "lumi.switch.acn047", "class": "zigpy.device.Device" } ``` </details> ### Diagnostic information <details><summary>Diagnostic information</summary> ```json { "home_assistant": { "installation_type": "Home Assistant Container", "version": "2023.11.3", "dev": false, "hassio": false, "virtualenv": false, "python_version": "3.11.6", "docker": true, "arch": "x86_64", "timezone": "America/New_York", "os_name": "Linux", "os_version": "6.1.0-12-amd64", "run_as_root": true }, "custom_components": {}, "integration_manifest": { "domain": "zha", "name": "Zigbee Home Automation", "after_dependencies": [ "onboarding", "usb" ], "codeowners": [ "@dmulcahey", "@adminiuga", "@puddly" ], "config_flow": true, "dependencies": [ "file_upload" ], "documentation": "https://www.home-assistant.io/integrations/zha", "iot_class": "local_polling", "loggers": [ "aiosqlite", "bellows", "crccheck", "pure_pcapy3", "zhaquirks", "zigpy", "zigpy_deconz", "zigpy_xbee", "zigpy_zigate", "zigpy_znp", "universal_silabs_flasher" ], "requirements": [ "bellows==0.36.8", "pyserial==3.5", "pyserial-asyncio==0.6", "zha-quirks==0.0.106", "zigpy-deconz==0.21.1", "zigpy==0.59.0", "zigpy-xbee==0.19.0", "zigpy-zigate==0.11.0", "zigpy-znp==0.11.6", "universal-silabs-flasher==0.0.14", "pyserial-asyncio-fast==0.11" ], "usb": [ { "vid": "10C4", "pid": "EA60", "description": "*2652*", "known_devices": [ "slae.sh cc2652rb stick" ] }, { "vid": "1A86", "pid": "55D4", "description": "*sonoff*plus*", "known_devices": [ "sonoff zigbee dongle plus v2" ] }, { "vid": "10C4", "pid": "EA60", "description": "*sonoff*plus*", "known_devices": [ "sonoff zigbee dongle plus" ] }, { "vid": "10C4", "pid": "EA60", "description": "*tubeszb*", "known_devices": [ "TubesZB Coordinator" ] }, { "vid": "1A86", "pid": "7523", "description": "*tubeszb*", "known_devices": [ "TubesZB Coordinator" ] }, { "vid": "1A86", "pid": "7523", "description": "*zigstar*", "known_devices": [ "ZigStar Coordinators" ] }, { "vid": "1CF1", "pid": "0030", "description": "*conbee*", "known_devices": [ "Conbee II" ] }, { "vid": "10C4", "pid": "8A2A", "description": "*zigbee*", "known_devices": [ "Nortek HUSBZB-1" ] }, { "vid": "0403", "pid": "6015", "description": "*zigate*", "known_devices": [ "ZiGate+" ] }, { "vid": "10C4", "pid": "EA60", "description": "*zigate*", "known_devices": [ "ZiGate" ] }, { "vid": "10C4", "pid": "8B34", "description": "*bv 2010/10*", "known_devices": [ "Bitron Video AV2010/10" ] } ], "zeroconf": [ { "type": "_esphomelib._tcp.local.", "name": "tube*" }, { "type": "_zigate-zigbee-gateway._tcp.local.", "name": "*zigate*" }, { "type": "_zigstar_gw._tcp.local.", "name": "*zigstar*" }, { "type": "_uzg-01._tcp.local.", "name": "uzg-01*" }, { "type": "_slzb-06._tcp.local.", "name": "slzb-06*" } ], "is_built_in": true }, "data": { "ieee": "**REDACTED**", "nwk": 44333, "manufacturer": "Aqara", "model": "lumi.switch.acn047", "name": "Aqara lumi.switch.acn047", "quirk_applied": false, "quirk_class": "zigpy.device.Device", "quirk_id": null, "manufacturer_code": 4447, "power_source": "Mains", "lqi": 208, "rssi": -48, "last_seen": "2023-12-02T16:31:24", "available": true, "device_type": "Router", "signature": { "node_descriptor": "NodeDescriptor(logical_type=<LogicalType.Router: 1>, complex_descriptor_available=0, user_descriptor_available=0, reserved=0, aps_flags=0, frequency_band=<FrequencyBand.Freq2400MHz: 8>, mac_capability_flags=<MACCapabilityFlags.FullFunctionDevice|MainsPowered|RxOnWhenIdle|AllocateAddress: 142>, manufacturer_code=4447, maximum_buffer_size=82, maximum_incoming_transfer_size=82, server_mask=11264, maximum_outgoing_transfer_size=82, descriptor_capability_field=<DescriptorCapability.NONE: 0>, *allocate_address=True, *is_alternate_pan_coordinator=False, *is_coordinator=False, *is_end_device=False, *is_full_function_device=True, *is_mains_powered=True, *is_receiver_on_when_idle=True, *is_router=True, *is_security_capable=False)", "endpoints": { "21": { "profile_id": "0x0104", "device_type": "0x0000", "input_clusters": [ "0x000c" ], "output_clusters": [] }, "2": { "profile_id": "0x0104", "device_type": "0x0000", "input_clusters": [ "0x0003", "0x0004", "0x0005", "0x0006", "0x0012", "0xfcc0" ], "output_clusters": [] }, "1": { "profile_id": "0x0104", "device_type": "0x0000", "input_clusters": [ "0x0000", "0x0003", "0x0004", "0x0005", "0x0006", "0x0012", "0x0702", "0x0b04", "0xfcc0" ], "output_clusters": [ "0x000a", "0x0019" ] } }, "manufacturer": "Aqara", "model": "lumi.switch.acn047" }, "active_coordinator": false, "entities": [ { "entity_id": "button.aqara_double_relay_1_identify", "name": "Aqara lumi.switch.acn047" }, { "entity_id": "sensor.aqara_double_relay_1_power", "name": "Aqara lumi.switch.acn047" }, { "entity_id": "sensor.aqara_double_relay_1_summation_delivered", "name": "Aqara lumi.switch.acn047" }, { "entity_id": "switch.aqara_double_relay_1_switch", "name": "Aqara lumi.switch.acn047" }, { "entity_id": "switch.aqara_double_relay_1_switch_2", "name": "Aqara lumi.switch.acn047" } ], "neighbors": [], "routes": [], "endpoint_names": [ { "name": "ON_OFF_SWITCH" }, { "name": "ON_OFF_SWITCH" }, { "name": "ON_OFF_SWITCH" } ], "user_given_name": "Aqara Double Relay 1", "device_reg_id": "d7a0cd6d520fb635ba0ba7e88258281a", "area_id": null, "cluster_details": { "21": { "device_type": { "name": "ON_OFF_SWITCH", "id": 0 }, "profile_id": 260, "in_clusters": { "0x000c": { "endpoint_attribute": "analog_input", "attributes": { "0x0055": { "attribute_name": "present_value", "value": 0.0 }, "0x006f": { "attribute_name": "status_flags", "value": 0 } }, "unsupported_attributes": { "0x0100": { "attribute_name": "application_type" }, "0x0041": { "attribute_name": "max_present_value" }, "0x006a": { "attribute_name": "resolution" } } } }, "out_clusters": {} }, "2": { "device_type": { "name": "ON_OFF_SWITCH", "id": 0 }, "profile_id": 260, "in_clusters": { "0x0005": { "endpoint_attribute": "scenes", "attributes": { "0xfffd": { "attribute_name": "cluster_revision", "value": 2 } }, "unsupported_attributes": {} }, "0x0004": { "endpoint_attribute": "groups", "attributes": {}, "unsupported_attributes": {} }, "0x0003": { "endpoint_attribute": "identify", "attributes": {}, "unsupported_attributes": {} }, "0x0012": { "endpoint_attribute": "multistate_input", "attributes": {}, "unsupported_attributes": {} }, "0x0006": { "endpoint_attribute": "on_off", "attributes": { "0x0000": { "attribute_name": "on_off", "value": 0 } }, "unsupported_attributes": { "0x4003": { "attribute_name": "start_up_on_off" } } }, "0xfcc0": { "endpoint_attribute": "manufacturer_specific", "attributes": {}, "unsupported_attributes": {} } }, "out_clusters": {} }, "1": { "device_type": { "name": "ON_OFF_SWITCH", "id": 0 }, "profile_id": 260, "in_clusters": { "0x0b04": { "endpoint_attribute": "electrical_measurement", "attributes": { "0x0605": { "attribute_name": "ac_power_divisor", "value": 10 }, "0x0604": { "attribute_name": "ac_power_multiplier", "value": 1 }, "0x050b": { "attribute_name": "active_power", "value": 0 }, "0x0000": { "attribute_name": "measurement_type", "value": 1 } }, "unsupported_attributes": { "0x0300": { "attribute_name": "ac_frequency" }, "0x0601": { "attribute_name": "ac_voltage_divisor" }, "0x0302": { "attribute_name": "ac_frequency_max" }, "0x0603": { "attribute_name": "ac_current_divisor" }, "0x0602": { "attribute_name": "ac_current_multiplier" }, "0x0505": { "attribute_name": "rms_voltage" }, "0x0507": { "attribute_name": "rms_voltage_max" }, "0x0508": { "attribute_name": "rms_current" }, "0x0600": { "attribute_name": "ac_voltage_multiplier" }, "0x050a": { "attribute_name": "rms_current_max" }, "0x0403": { "attribute_name": "power_divisor" }, "0x050d": { "attribute_name": "active_power_max" }, "0x050f": { "attribute_name": "apparent_power" }, "0x0401": { "attribute_name": "ac_frequency_divisor" }, "0x0510": { "attribute_name": "power_factor" }, "0x0400": { "attribute_name": "ac_frequency_multiplier" }, "0x0402": { "attribute_name": "power_multiplier" } } }, "0x0702": { "endpoint_attribute": "smartenergy_metering", "attributes": { "0x0000": { "attribute_name": "current_summ_delivered", "value": 0 }, "0x0302": { "attribute_name": "divisor", "value": 1000 }, "0x0306": { "attribute_name": "metering_device_type", "value": 0 }, "0x0301": { "attribute_name": "multiplier", "value": 1 }, "0x0303": { "attribute_name": "summation_formatting", "value": 159 }, "0x0300": { "attribute_name": "unit_of_measure", "value": 0 } }, "unsupported_attributes": { "0x0400": { "attribute_name": "instantaneous_demand" }, "0x0100": { "attribute_name": "current_tier1_summ_delivered" }, "0x0102": { "attribute_name": "current_tier2_summ_delivered" }, "0x0104": { "attribute_name": "current_tier3_summ_delivered" }, "0x0200": { "attribute_name": "status" }, "0x0106": { "attribute_name": "current_tier4_summ_delivered" }, "0x0108": { "attribute_name": "current_tier5_summ_delivered" }, "0x0304": { "attribute_name": "demand_formatting" }, "0x010a": { "attribute_name": "current_tier6_summ_delivered" } } }, "0x0005": { "endpoint_attribute": "scenes", "attributes": { "0xfffd": { "attribute_name": "cluster_revision", "value": 2 } }, "unsupported_attributes": {} }, "0x0004": { "endpoint_attribute": "groups", "attributes": {}, "unsupported_attributes": {} }, "0x0003": { "endpoint_attribute": "identify", "attributes": {}, "unsupported_attributes": {} }, "0x0012": { "endpoint_attribute": "multistate_input", "attributes": {}, "unsupported_attributes": {} }, "0x0000": { "endpoint_attribute": "basic", "attributes": { "0x0001": { "attribute_name": "app_version", "value": 27 }, "0x0006": { "attribute_name": "date_code", "value": "20230606" }, "0x0010": { "attribute_name": "location_desc", "value": "\u9ed8\u8ba4\u623f\u95f4" }, "0x0004": { "attribute_name": "manufacturer", "value": "Aqara" }, "0x0005": { "attribute_name": "model", "value": "lumi.switch.acn047" }, "0x000d": { "attribute_name": "serial_number", "value": "" }, "0x0002": { "attribute_name": "stack_version", "value": 27 }, "0x0000": { "attribute_name": "zcl_version", "value": 3 } }, "unsupported_attributes": { "0x0012": { "attribute_name": "device_enabled" }, "0x0008": { "attribute_name": "generic_device_class" }, "0x0013": { "attribute_name": "alarm_mask" }, "0xfffe": { "attribute_name": "reporting_status" } } }, "0x0006": { "endpoint_attribute": "on_off", "attributes": { "0x0000": { "attribute_name": "on_off", "value": 0 } }, "unsupported_attributes": { "0x4000": { "attribute_name": "global_scene_control" }, "0x4003": { "attribute_name": "start_up_on_off" } } }, "0xfcc0": { "endpoint_attribute": "manufacturer_specific", "attributes": {}, "unsupported_attributes": {} } }, "out_clusters": { "0x0019": { "endpoint_attribute": "ota", "attributes": {}, "unsupported_attributes": {} }, "0x000a": { "endpoint_attribute": "time", "attributes": {}, "unsupported_attributes": {} } } } } } } ``` </details> ### Logs _No response_ ### Custom quirk _No response_ ### Additional information This is almost identical to #639 for another Aqara relay. Interlock for the Aqara T2 is supported by Zigbee2MQTT: https://www.zigbee2mqtt.io/devices/LLKZMK12LM.html There are a lot of other options supported by Z2M that would be nice to have in ZHA, so this would be a good time to add those while you're at it, though interlock is the only critical one that I need before I can safely install the T2. I spent hours trying to set up Z2M on a separate system with another adapter so I could enable interlock before adding the T2 to my production network, but I just couldn't get Z2M to connect to the SkyConnect adapter. At best, I got a "Resource busy" error when there was no reason for it to be busy (new adapter never used before and no other processes accessing it).

But this still leaves shutter positioning.
