ESP32 with CC1101 - RF Proxy stays unknown in HA

mdehaas · May 11, 2026, 9:01am

Hi all,

I've been trying to get an RF Proxy working using Googling and asking supposedly intelligent algorithms and I think I'm close but cannot get the last step to work. I have seen data popping up when using the remote_receiver. The entry "RF Proxy" shows up in Home Assistant but the state always end up being unknown and trying to onboard the Novy Cooker Hood results in the message "No radio frequency transmitters are available. Please set up a transmitter first."

Can someone please help me point out where I'm going wrong?

Pinout ESP32 and CC1101. First two columns are on the RF Module.

| CC1101 | PIN | ESP32  | Color  |
| ------ | --- | ------ | ------ |
| VCC    | 2   | 3.3V   | Red    |
| GND    | 1   | GND    | Black  |
| SCK    | 5   | GPIO18 | Orange |
| MISO   | 7   | GPIO19 | Yellow |
| MOSI   | 6   | GPIO23 | Purple |
| CSN    | 4   | GPIO21 | Green  |
| GDO0   | 3   | GPIO16 | Blue   |
| GDO2   | 8   | GPIO22 | Brown  |

Relevant part of my configuration:

# SPI bus
spi:
 clk_pin: GPIO18
 miso_pin: GPIO19
 mosi_pin: GPIO23

# CC1101
cc1101:
 cs_pin: GPIO21
 gdo0_pin: GPIO16
 frequency: 433.92MHz
 modulation_type: ASK/OOK
 output_power: 10
 symbol_rate: 5000

# RF transmitter
remote_transmitter:
 id: rf_tx
 pin: GPIO16  # Changed from GPIO17 to match CC1101 GDO0 (table)
 carrier_duty_percent: 100%
 non_blocking: true

# RF receiver
# remote_receiver:
#   id: rf_rx
#   pin: GPIO22  # Uncommented to match CC1101 GDO2 (table)
#   dump: all
#   tolerance: 25%
#   filter: 250us
#   idle: 4ms
#   buffer_size: 2kb

# Infrared
infrared:
 - platform: ir_rf_proxy
   id: rf_proxy
   name: RF Proxy
   frequency: 433.92MHz  #Docs state: frequency: 433 MHz
   remote_transmitter_id: rf_tx

Karosm · May 11, 2026, 9:56am

Why are you using infrared instead of RF?
Also, remove the gdo0_pin from cc1101:

mdehaas · May 11, 2026, 10:30am

As far as I worked out reading the documentation (IR/RF Proxy - ESPHome - Smart Home Made Simple) this is the way to create the proxy element.

Removing that line does not change the state of the RF Proxy

Karosm · May 11, 2026, 10:38am

Edit: I had a look at the component api and you are right, it's configured as infrared:
Doesnt make sense, but it's on experimental state so...

Didgeridrew · May 11, 2026, 7:20pm

There is an example config for the M5 Stack device that uses radio_frequency not infrared...

github.com/esphome/rf-proxies

m5stack-atom-echo/m5stack-atom-echo.yaml

3c5fb1dcf



              disabled_by_default: true
              icon: "mdi:restart"

          # M5Stack RF433T (433 MHz transmitter) connected to the Atom Echo's
          # Grove port. GPIO26 is the data pin.
          remote_transmitter:
            id: rf_tx
            pin: GPIO26
            carrier_duty_percent: 100%

          radio_frequency:
            # RF transmitter instance
            - platform: ir_rf_proxy
              name: RF Proxy Transmitter
              id: rf_proxy_tx
              remote_transmitter_id: rf_tx
              frequency: 433.92MHz

mdehaas · May 11, 2026, 7:27pm

Yeah, I found that to but that component cannot be found. So maybe this is something that will appear in the next release but for now infrared seems to be the correct component. I could not find any usable information searching GitHub repostories...

Karosm · May 11, 2026, 7:40pm

Interesting. I can't find it on docs, neither on api. Do you have further info about that?

Didgeridrew · May 11, 2026, 7:44pm

Unfortunately, no. I found that while trying to help on an earlier post... it seems like maybe there's been a miscommunication between either HA v. ESPHome or the docs v. API.

mdehaas · May 11, 2026, 8:00pm

I see this in the web interface of the ESP. Do I need to investigate ESP any further or is the issue in HA?

Karosm · May 12, 2026, 9:18am

Interesting how it offers you 38kHz carrier even if you set all up as RF transmitter.
Did you try if it works?

makai · May 12, 2026, 11:10am

You need to wait for the next major release of esphome (2026.5.0) to get radio_frequency to work with CC1101:

github.com/esphome/esphome

[ir_rf_proxy] Add CC1101 support to radio_frequency platform

dev ← 20260511-cc1101-rf-proxy

opened 05:59AM - 12 May 26 UTC

kbx81

+281 -24

# What does this implement/fix? Adds optional CC1101 integration to the `ir_r…f_proxy` radio_frequency platform, allowing a CC1101 sub-GHz transceiver to be used as a **programmable** RF front-end for raw-timing transmission and reception. Compared to cheap fixed-frequency 433 MHz modules, this gives users: - Tunable carrier frequency anywhere in 300-928 MHz (runtime-changeable via `cc1101.set_frequency`, **and via the API on every transmit** — see "Runtime frequency override" below) - Programmable output power (-30 to +11 dBm) - Significantly better RX sensitivity and selectivity - Runtime access to AGC, RSSI, LQI, filter bandwidth, etc. - **Combined half-duplex TX + RX on a single CC1101 + single shared GPIO pin** — see "Combined TX + RX" below The CC1101 already supports an "async transparent" OOK mode where GDO0 directly modulates the carrier — this PR wires that mode into the existing `ir_rf_proxy` + `remote_transmitter`/`remote_receiver` stack so the chip becomes a drop-in replacement at the radio layer without any new transmit/receive infrastructure. ### How it works Adding `cc1101_id` to a `radio_frequency: - platform: ir_rf_proxy` entry: 1. At setup, `RfProxy` defers a call to `cc1101_->begin_rx()` (chip's default idle state) 2. CC1101 is told to stop touching the shared GDO0 pin (see "Pin-sharing fix" below) 3. `remote_transmitter`/`remote_receiver` continue to own GDO0's direction and RMT peripheral routing as usual 4. On TX, the chip is briefly switched to TX state and back to RX after the transmission completes ### Combined TX + RX on a single CC1101 Users can wire one CC1101 to one GPIO pin and configure **two** `radio_frequency` entities — one TX and one RX — both pointing at the same `cc1101_id`. The platform handles half-duplex turnaround transparently: 1. CC1101 sits in RX state (continuously listening for incoming RF) 2. When a transmit request arrives, `RfProxy::control()`: - Marks `cc1101_->set_tx_busy(true)` so the sibling RX entity drops ghost events generated by the MCU driving the shared pin - Calls `cc1101_->begin_tx()` to switch the chip into TX state - Hands off to `remote_transmitter` via the existing transmit helper - Sums the raw timings × repeat count to compute the in-flight transmission duration - Schedules a named `set_timeout` to return the chip to RX state once RMT is done playing out the symbols 3. Named timeout auto-cancels if a new TX arrives before the timer fires (overlapping transmits are handled correctly) This works on a single shared GPIO pin (`gdo0_pin` on the CC1101, `pin` on both `remote_transmitter` and `remote_receiver`, all with `allow_other_uses: true`) — a single-pin design is friendlier to GPIO-constrained boards. ### Runtime frequency override `InfraredRFTransmitRawTimingsRequest.carrier_frequency` is honored when the entity is backed by a CC1101. If the API client sends a transmit request with a non-zero carrier frequency that differs from the chip's current tuning, `RfProxy::control()` retunes the CC1101 before transmitting. Subsequent transmits at the same frequency skip the retune (each one costs ~1.5 ms in PLL calibration). The "last-set" value is initialized from the entity's configured `frequency:` (if any) so the first matching transmit doesn't retune unnecessarily. This means a single ESPHome device with one CC1101 can transmit on different carrier frequencies (e.g., 315 MHz and 433.92 MHz) just by varying the `carrier_frequency` field in successive API requests — no extra YAML or automations required. ### Pin-sharing fix in CC1101 ESP32's GPIO matrix routes peripheral signals (RMT, in this case) to pins. Calling `gpio_set_direction()` on such a pin **silently detaches it from the peripheral** and reverts it to plain GPIO — meaning RMT generates waveforms internally but they never reach the pin. CC1101's existing `setup()`, `begin_tx()`, `begin_rx()`, and `set_packet_mode()` all called `pin_mode()` on GDO0, which broke RMT-based TX/RX on the shared pin. This PR adds a `set_gdo0_managed_externally(bool)` setter to CC1101. When set (automatically, by `ir_rf_proxy.radio_frequency`'s `to_code` when `cc1101_id` is configured), CC1101 skips all pin direction and interrupt operations on GDO0 and leaves that work to whichever component owns the pin matrix routing. A `tx_busy_` coordination flag (with `set_tx_busy()` / `is_tx_busy()`) is also added to CC1101. The CC1101 itself doesn't touch it — it's only read by `RfProxy::on_receive()` to drop ghost RX events during a transmission. ### Validation Configuration-time checks (`FINAL_VALIDATE_SCHEMA`): - CC1101's `packet_mode` must be `false` (the default, async transparent mode) — packet mode buffers bytes internally and is incompatible with raw-timing transmission - CC1101's `gdo0_pin` number must match the linked `remote_transmitter`/`remote_receiver` pin number - Both pin configurations must set `allow_other_uses: true` - `remote_transmitter`'s `carrier_duty_percent` must be `100%` (RF hardware handles modulation) ## Types of changes - [ ] Bugfix (non-breaking change which fixes an issue) - [x] New feature (non-breaking change which adds functionality) - [ ] Breaking change (fix or feature that would cause existing functionality to not work as expected) — [policy](https://developers.esphome.io/contributing/code/#what-constitutes-a-c-breaking-change) - [ ] Developer breaking change (an API change that could break external components) — [policy](https://developers.esphome.io/contributing/code/#what-is-considered-public-c-api) - [ ] Undocumented C++ API change (removal or change of undocumented public methods that lambda users may depend on) — [policy](https://developers.esphome.io/contributing/code/#c-user-expectations) - [ ] Code quality improvements to existing code or addition of tests - [ ] Other **Related issue or feature (if applicable):** - builds on the experimental `ir_rf_proxy` radio_frequency platform added in esphome/esphome#15744 **Pull request in [esphome-docs](https://github.com/esphome/esphome-docs) with documentation (if applicable):** - docs updated in the `ir_rf_proxy` page on the `20260511-cc1101-rf-proxy` branch (separate esphome-docs PR to follow) ## Test Environment - [x] ESP32 IDF (ESP32 + CC1101 board — confirmed transmission to a real RF target device; combined TX+RX scenario verified via `script/test_build_components -c ir_rf_proxy -t esp32-idf`) ## Example entry for `config.yaml`: ```yaml spi: clk_pin: GPIO15 mosi_pin: GPIO12 miso_pin: GPIO13 cc1101: id: cc1101_radio cs_pin: GPIO14 # Shared with remote_transmitter and remote_receiver — all three set allow_other_uses gdo0_pin: number: GPIO26 allow_other_uses: true frequency: 433.92MHz modulation_type: ASK/OOK output_power: 10 remote_transmitter: id: rf_tx pin: number: GPIO26 allow_other_uses: true carrier_duty_percent: 100% remote_receiver: id: rf_rx pin: number: GPIO26 allow_other_uses: true inverted: true # Two entities, one CC1101, one shared GPIO pin — full half-duplex TX + RX radio_frequency: - platform: ir_rf_proxy name: RF Transmitter frequency: 433.92MHz # default carrier — overridable per-transmit via the API remote_transmitter_id: rf_tx cc1101_id: cc1101_radio - platform: ir_rf_proxy name: RF Receiver frequency: 433.92MHz remote_receiver_id: rf_rx cc1101_id: cc1101_radio ``` ## Checklist: - [x] The code change is tested and works locally. - [x] Tests have been added to verify that the new code works (under `tests/` folder). If user exposed functionality or configuration variables are added/changed: - [ ] Documentation added/updated in [esphome-docs](https://github.com/esphome/esphome-docs).

50494554524F · May 12, 2026, 1:22pm

i was going crazy these days following the documentation, here to ask and found your reply... so, thank you!

dualtronic · May 12, 2026, 8:15pm

For those not wanting to build their own hardware interface, is there any off-the-shelf modules that can do the job?

The blogpost mentions Broadlink RM4 Pro, but that only works on 433MHz. The ESP32 world seemed unprepared for this feature release. I don't find much that doesn't require a breadboard and a solding iron except for M5Stack. A CoreS3 and Stack CC1101 modules snap together easily, cost $60 plus shipping and tax. It's expensive because it includes unnecessary features for a simple RF proxy solution.

M5Stack CC1101 Module (855-925MHz)– m5stack-store
M5Stack CoreS3 SE IoT Controller without Battery Bottom– m5stack-store

Am I missing another supplier that has an off-the-shelf solution offering multiple frequencies? Or best to wait until the market catches up and offers such a product?

Kral84 · May 17, 2026, 9:17am

@mdehaas can you post your full config pls, i have a problem

esphome:
  name: jarolift-cc1101
  friendly_name: jarolift-cc1101

web_server:
  port: 80

esp32:
  variant: ESP32C6
logger:

# Enable Home Assistant API
api:
  encryption:
    key: "xxxx"

ota:
  - platform: esphome
    password: "xxxxx0"

wifi:
  ssid: !secret wifi_ssid
  password: !secret wifi_password

spi:
  clk_pin: GPIO18
  mosi_pin: GPIO23
  miso_pin: GPIO19

cc1101:
  id: cc1101_radio
  cs_pin: GPIO5
  frequency: 433.92MHz
  modulation_type: ASK/OOK
  output_power: 10

remote_transmitter:
  id: rf_tx
  pin: GPIO21
  carrier_duty_percent: 100
  on_transmit:
    then:
      - cc1101.begin_tx: cc1101_radio
  on_complete:
    then:
      - cc1101.begin_rx: cc1101_radio

remote_receiver:
  id: rf_rx
  pin: GPIO22

radio_frequency:
  - platform: ir_rf_proxy
    id: rf_proxy_cc1101_tx
    name: "CC1101 RF Transmitter"
    frequency: 433.92MHz
    remote_transmitter_id: rf_tx
    # Optional: retune the CC1101 per-transmit when the API request specifies a
    # different carrier frequency.  Demonstrates the on_control trigger.
    on_control:
      then:
        - if:
            condition:
              lambda: "return x.get_frequency().has_value() && *x.get_frequency() > 0;"
            then:
              - cc1101.set_frequency:
                  id: cc1101_radio
                  value: !lambda "return *x.get_frequency();"
  - platform: ir_rf_proxy
    id: rf_proxy_cc1101_rx
    name: "CC1101 RF Receiver"
    frequency: 433.92MHz
    remote_receiver_id: rf_rx```

MichaelT · May 23, 2026, 8:32pm

I got it to work for my Novy hood, with this code (running ESPHome 2026.5)

esphome:
  name: dampkap
  friendly_name: dampkap

esp32:
  board: esp32dev
  framework:
    type: esp-idf

# Enable logging
logger:

# Enable Home Assistant API
api:
  encryption:
    key: "..."

ota:
  - platform: esphome
    password: "..."

wifi:
  ssid: !secret wifi_ssid
  password: !secret wifi_password

  # Enable fallback hotspot (captive portal) in case wifi connection fails
  ap:
    ssid: "Dampkap Fallback Hotspot"
    password: "..."

captive_portal:

spi:
  clk_pin: GPIO18
  miso_pin: GPIO19
  mosi_pin: GPIO23

cc1101:
  id: cc1101_radio
  cs_pin: GPIO21
  frequency: 433.92MHz
  modulation_type: ASK/OOK
  output_power: 10
  symbol_rate: 5000

remote_transmitter:
  id: rf_tx
  pin: GPIO17
  carrier_duty_percent: 100%
  non_blocking: true
  on_transmit:
    then:
      - cc1101.begin_tx: cc1101_radio
  on_complete:
    then:
      - cc1101.begin_rx: cc1101_radio

radio_frequency:
 - platform: ir_rf_proxy
   id: rf_proxy
   name: RF Proxy
   frequency: 433.92MHz
   remote_transmitter_id: rf_tx

mdehaas · June 2, 2026, 8:57pm

Hi all,

got it working now with the following code:

#-------------------------------
# Pinout ESP32 and CC1101
#-------------------------------
# CC1101 | PIN | ESP32  | Color
# -------+-----+--------+------
# VCC    | 2   | 3.3V   | Red
# GND    | 1   | GND    | Black
# SCK    | 5   | GPIO18 | Orange
# MISO   | 7   | GPIO19 | Yellow
# MOSI   | 6   | GPIO23 | Purple
# CSN    | 4   | GPIO21 | Green
# GDO0   | 3   | GPIO4  | Blue
# GDO2   | 8   | GPIO22 | Brown
#-------------------------------

spi:
  clk_pin: GPIO18
  miso_pin: GPIO19
  mosi_pin: GPIO23

cc1101:
  id: cc1101_radio
  cs_pin: GPIO21

# CC1101 GDO0 wired to one GPIO pin
remote_transmitter:
  id: rf_tx
  pin: GPIO4
  carrier_duty_percent: 100
  on_transmit:
    then:
      - cc1101.begin_tx: cc1101_radio
  on_complete:
    then:
      - cc1101.begin_rx: cc1101_radio

# CC1101 GDO2 wired to a second GPIO pin
remote_receiver:
  id: rf_rx
  pin: GPIO22

radio_frequency:
  - platform: ir_rf_proxy
    name: RF Proxy Transmitter
    frequency: 433.92MHz
    remote_transmitter_id: rf_tx
    # Optional: retune the CC1101 when an API request specifies a different
    # carrier frequency.  `x` is the radio_frequency call object.
    on_control:
      then:
        - if:
            condition:
              lambda: "return x.get_frequency().has_value() && *x.get_frequency() > 0;"
            then:
              - cc1101.set_frequency:
                  id: cc1101_radio
                  value: !lambda "return *x.get_frequency();"
  - platform: ir_rf_proxy
    name: RF Proxy Receiver
    frequency: 433.92MHz
    remote_receiver_id: rf_rx
