virtual_led_strip

An ESPHome light: platform with no pin. Your browser is the strip.

Point your effects at it instead of neopixelbus or esp32_rmt_led_strip, open
http://<ip>:8083/, and the strip appears in a tab — with a panel that names
whatever goes wrong. ESP8266 and ESP32. No LEDs, no data pin, no solder.

external_components:
  - source: github://kaboom748/virtual_led_strip
    components: [virtual_led_strip]
    refresh: 1d

light:
  - platform: virtual_led_strip
    id: strip
    name: "Shelf"
    num_leds: 188
    port: 8083
    max_refresh_rate: 32ms
    effects:
      - addressable_rainbow:
      - addressable_scan:

Three keys, and that is the whole point

num_leds, port, is_rgbw. There is no chipset:, no variant:, no
rgb_order: — those describe a wire we do not have. ESPColorView hands out
pointers into our own buffer, so the memory layout is ours; an effect writes
Color(255, 0, 0) and the view puts it where it likes. Byte order on the wire is
a property of the bus.

is_rgbw earns its place because it changes LightTraits, and therefore what
effects can express. Rehearsing an SK6812 RGBW is not rehearsing a WS2812 RGB.

Swapping to a real strip

Replace the light: block. Effects, automations, lambdas, id, name and
num_leds all carry over:

light:
  - platform: neopixelbus          # ESP8266
    variant: WS2812
    pin: GPIO2
    num_leds: 188

Wiring advice worth more than any option: use GPIO1, GPIO2 or GPIO3 on
ESP8266. neopixelbus picks its method from the pin — DMA on GPIO3, UART on
GPIO1/GPIO2, and bit-bang on anything else. Bit-bang means 188 × 30 µs =
5.6 ms of loop with interrupts off, every frame. The other three cost nothing.
On ESP32 it is always I2S or RMT — never blocking.

max_refresh_rate is a threshold, not a rate

Same semantics as esp32_rmt_led_strip, and the same trap. Writes leave from
LightState::loop(), one per pass, so the loop interval quantizes it:

you write you actually get
16ms 62.5 fps
32ms 31.2 fps
33ms 20.9 fps — 30 % below what you asked
48ms 20.9 fps

Only multiples of the 16 ms loop land where you meant. dump_config() prints the
resolved rate so you are not left guessing.

A bench pattern: 100 LEDs, ten tests, one image

example/bench-mire-100-esp8266.yaml and -esp32.yaml carry a test pattern
worth more than its size.

With 10 LEDs you are forced to code in time: each LED gets its rhythm and you
wait for the sequence to unfold. With 100 you code in space — ten decades, ten
diagnostics running in parallel. One image is a complete verdict, and there
is nothing to wait for.

decade LEDs what it proves
d0-d2 00-29 R, G, B ramps 25..255 — per-channel linearity, missing steps
d3 30-39 white ramp — do the three channels track together
d4 40-49 levels 1..10 of 255 — the quantization floor
d5 50-59 checkerboard at fs/2 — signal integrity, dropped frames
d6 60-69 pure R G B — channel order
d7 70-79 hue wheel — continuity, banding
d8 80-89 pure Y C M — two-channel mixing
d9 90-99 full white — reference, end of strip

You read a fault as decade + rank: “third LED of the blue ramp is dark” is
LED 22, blue channel. You get the index without counting the strip.

A white cursor walks one LED per frame, preceded by a black hole that shows the
direction. A dead LED is a fixed gap. One pass is 100 frames — time it and
you have your real frame rate without touching the log. 3.2 s is 31.25 fps; 4.8 s
is 20.8 fps, which means you landed on the 16 ms quantum described above.

gamma_correct: 0 is not optional on a bench: with the 2.8 default, d4 is
entirely black and your ramps stop being ramps. Set it back to 2.8 to see the
crushing — decade d4 vanishing is the same finding as the cliff below effect 28.

Decoded off the wire, d0 reads 25, 51, 76, 102, 127, 153, 178, 204, 229, 255
and d4 reads exactly 1..10. The encoder picks DELTA and spends 12 B/frame:
only the cursor moves.

The one fault this pattern cannot see is voltage drop — it needs all 100 LEDs at
full simultaneously, which is incompatible with a test pattern. That is what
the second effect, MUR, is for: a white ramp to 100 %. Watch the far end.
White turning yellow then orange is the 5 V collapsing; blue (Vf ~3.2 V) dies
before red (Vf ~2.0 V). The hue drift is the voltmeter. Note the percentage
where it starts: that is your supply limit, in a number.

MUR only means anything on real hardware. This platform has no wire and no
supply, and cannot simulate it.

Reading the panel

The heartbeat (10/s, always, playing or not) is the metronome. Every beat is
stamped on the ESP, before the network can touch it, which lets the panel
separate the only two things that can go wrong:

Line Means
Beat rate / target Must read 10.0 / 10.0. Any sag is real.
ESP loop worst Largest gap between beats as the ESP lived it.
Link jitter Arrival spread minus the ESP’s own period. The network, and nothing else.
Dropped frames A frame was superseded before it left. Your effect outruns the link.
Encoding / RAW / RLE / DELTA The three candidates and which won, per frame.
Late frames Play-out shorter than the link jitter. Raise the slider; Margin min says by how much.

Bandwidth is decided by the effect, not by num_leds

Measured on ESPHome’s own effects, on the wire:

effect 60 LEDs 300 LEDs 5000 LEDs
Scan 12 B 12 B 12 B
Twinkle 10 B 13 B 12 B
Fireworks 6 B 5 B 5 B
Rainbow 180 B 900 B 15000 B

Sparse effects are O(1) — delta sends only what moved, and what moves does
not grow with the strip. Only a full-length gradient is O(N). At 188 LEDs a
rainbow is 564 B/frame: 33 kB/s at 60 fps (over an ESP8266’s practical ~32 kB/s),
16.5 kB/s at 32ms (half the budget).

The encoder picks the shortest per frame — and that is not a flourish. On a
rainbow, RLE (1199 B) and delta (955 B) both cost more than raw (900 B); on a
twinkle, delta collapses to 13 B. No single encoding wins.

The colour pipeline, and the bug it prevents

gamma_correct defaults to 2.8 on every ESPHome light, and
ESPColorView::set_red() applies it into our buffer. So what we stream is not
colour — it is PWM duty, which is linear light. Your screen wants sRGB.

effect writes buffer carries LED emits rgb(buffer) emits
128 37 14.5 % 1.43 % — 10× too dark
64 5 2.0 % 0.02 % — 112×
32 1 0.4 % 0.00 % — 772×

A naive render erases the bottom half of your range. This page converts
duty → linear → sRGB with the real piecewise curve (not a 2.2 power, whose linear
segment matters exactly where your fade lives).

Which means the page shows you something you would otherwise only find on the
shelf: below effect 28, the LED is simply off. Gamma 2.8 quantizes 0–27 to
buffer 0, and the last visible step is a jump of 21 sRGB levels. Your fade to
black does not fade — it snaps.

What this cannot rehearse

  • A wrong rgb_order. No wire, no order. Your rainbow will be right here and
    blue-green on the shelf.
  • Interrupt glitches on a bit-banged WS2812. No wire, no malformed bit.
  • Above 60 Hz the strip fuses — that is your monitor, and it is also your eye.
  • Rows, elbows and serpentine are assertions about your soldering. The ESP
    knows num_leds and nothing else. The browser lets you toggle them because
    picking the one where your comet snakes correctly is how you decide what to
    solder.

Design notes

  • setup_priority::HARDWARE, not AFTER_WIFI. LightState sits at
    HARDWARE - 1.0f, so it sets up after the output and immediately calls
    setup_state(), init_internal() on every effect, then restores saved state
    with a call.perform() — all of which reach into our buffer. At AFTER_WIFI
    (200) that buffer was still empty 599 priority levels earlier: a pointer into
    nothing, a crash, a boot loop, safe mode. Both real drivers are at HARDWARE
    for exactly this reason. The host bench cannot see it — it has no flash to
    restore from, so nothing touches the buffer early.
  • The listen socket opens on the first loop(), not in setup(). The buffer
    must exist at HARDWARE; the socket wants wifi’s setup() done (api is at
    AFTER_WIFI for that reason). You cannot be in both places, so the memory goes
    where LightState needs it and the socket waits for loop(), which follows
    every setup().
  • No undefined behaviour. AddressableLight is a public API and this
    component owns its buffer. Nothing is reached by casting to a class the object
    is not an instance of.
  • One socket path. ESPHome’s socket covers ESP8266 through lwip_tcp.
    Note that ListenSocket and Socket are distinct types there:
    socket_ip() cannot listen().
  • Drain the request, do not read once. socket.h states the contract, and
    the cost of ignoring it is not a slow read: closing a socket with received
    bytes still unread makes TCP send an RST instead of a FIN, and the RST discards
    the send buffer. The page arrived truncated mid-<script>, nothing ran, and
    the panel showed its hard-coded HTML defaults as if all were well. Invisible on
    loopback — everything is delivered before the close(). It takes a real
    browser.
  • read() == 0 is EOF. -1/EWOULDBLOCK is “wait”. They are not the same, and
    if (len <= 0) return; conflates them. Chrome opens speculative sockets it never
    uses; treated as “would block”, the first one holds the pending slot forever,
    accept() stops accepting, fetch('/events') never lands, and the strip stays
    black until reboot. lwip_raw_tcp_impl.cpp is explicit about which is which.
  • The panel’s HTML defaults declare failure, in red, and the script contradicts
    them on its first line. A panel that shows a plausible state while nothing runs
    is worse than an empty one.
  • A short write is not a failure. At 564 B every 32 ms an ESP8266’s send
    buffer fills in normal service. The frame is kept and retried; nothing is
    thrown away mid-stream.
  • prev_ only advances on a frame committed to the wire. Otherwise the
    client would rebuild deltas against a frame it never saw.
  • The heartbeat advances its phase (last_beat_ += 100, never = now). A
    metronome that cannot reach its own target measures nothing.
  • The heartbeat runs before the frame. Put promote_() first and the frame
    refills the send buffer every pass; the beat never finds it free, and
    Beat rate collapses precisely when you are reading the panel to find out why.
    The data starves the instrument.
  • No on / off branch in the renderer. Ambient and emission add; zero is
    not a special case. Two separate formulas do not meet at zero, and a comet’s
    tail rendered darker than an unlit strip — a darkness invented by the drawing,
    present nowhere in the buffer. It is checked, not intended: monotone across all
    256 levels.
  • Display counts requestAnimationFrame; Render counts frames painted.
    Conflating them made the panel blame the ESP for judder the renderer could have
    caused. Two gradients per lit dome is not free.
  • ESP loop worst is a 30 s window, with the lifetime max on its own line. A
    max that never decays welds a boot-time stall to the panel forever, and you
    cannot tell an old freeze from a live one.
  • The browser integrates over the display frame, in linear. Sampling the
    newest frame drops one at every beat between 16 ms and 16.7 ms — a 2.5 Hz
    stutter we would be adding. And averaging sRGB bytes would darken a 50/50
    strobe from 188 to 128.

License

GPLv3 for the C++, MIT for the Python — ESPHome’s own model. GitHub will show
NOASSERTION; so does esphome/esphome.
