ET-Bus (ElectronicsTech Bus)
ET-Bus is a local-first, real-time device bus designed for ESP32-based automation systems and Home Assistant.
It is built for speed, reliability, and deterministic control on a local LAN — without MQTT brokers, without cloud dependencies, and without retained-message complexity.
ET-Bus is not a replacement for MQTT, Zigbee, or ESPHome.
It is a complementary protocol for always-on, mains-powered, low-latency devices.
Why ET-Bus Exists
Home Assistant users regularly encounter real-world problems such as:
- MQTT broker failures stopping all automation
- Retained messages causing state desynchronisation
- Devices appearing online when physically offline
- Slow or unpredictable command response
- Devices failing to recover after Home Assistant restarts
These are architectural issues, not misconfiguration.
ET-Bus was created to eliminate these failure modes by moving to a device-owned, UDP-based state model.
Key Features
- Ultra-low latency (UDP on LAN)
- No broker required
- Device-owned state (no retained lies)
- Automatic resync after reconnect
- Multicast discovery
- Local-only by default
- Human-readable JSON (Wireshark friendly)
- Designed specifically for Home Assistant
What ET-Bus Is (and Is Not)
Designed for
- Relays and switches
- WS2812 / RGB lighting
- Fans and motors
- Pumps and valves
- Industrial & hydroponics controllers
- Server rack & homelab automation
Not designed for
- Battery-powered sensors
- Sleepy devices
- Cloud-first IoT
- Internet-scale messaging
Use Zigbee / LoRa / BLE for battery devices.
Use ET-Bus for fast, deterministic, always-on control.
Architecture Overview
- Devices communicate with Home Assistant using UDP
- Multicast is used for discovery and health checks
- Unicast is used for commands once the device IP is known
- Devices send periodic
pongheartbeats - Home Assistant tracks true online/offline state
No broker.
No retained messages.
No single point of failure.
Protocol Summary
All messages are JSON over UDP.
Common message envelope
{ “v”: 1, “type”: “state | command | discover | ping | pong”, “id”: “device_id”, “class”: “switch.relay | light.rgb | fan.speed”, “payload”: {} }
Message Types
| Type | Purpose |
|---|---|
| discover | Device announces itself |
| state | Device publishes current state |
| command | Home Assistant sends a command |
| ping | Health check from Home Assistant |
| pong | Device heartbeat |
Device Lifecycle
- Device boots
- Sends
discover(multicast) - Home Assistant registers device
- Device sends initial
state - Device sends periodic
pong - Home Assistant marks device online/offline
If Home Assistant restarts:
- Devices re-announce automatically
- State is rebuilt from live devices
- No stale or ghost entities remain
Command Flow
Home Assistant UI
↓
command
↓
ESP32 device
↓
apply action
↓
state confirmation
↓
Home Assistant updates entity
State is never assumed — only confirmed.
Reliability Model
ET-Bus follows an industrial reliability model:
- No heartbeat → offline
- No device → no state
- No confirmation → no assumption
Explicit failure is preferred over silent failure.
Why ET-Bus Avoids Retained Messages
MQTT retained failure
- Broker retains relay = ON
- Device loses power
- Home Assistant still shows ON
- Automations behave incorrectly
ET-Bus behaviour
- Device loses power
- Heartbeats stop
- Device marked offline
- State becomes unknown
ET-Bus refuses to lie about physical reality.
Failure Scenarios
MQTT Broker Restart
- Broker goes down
- Devices disconnect
- Home Assistant shows old retained state
- Automations misfire
ET-Bus Controller Restart
- Home Assistant restarts
- Devices re-announce
- State rebuilt automatically
- System stabilises cleanly
Security Model (current state – important)
ET-Bus currently operates as plaintext UDP and is intended for use on trusted local networks only.
Current reality
- No protocol-level encryption
- No authentication
- No cryptographic integrity checking
- Any device on the same network could observe or inject packets
This is intentional and documented, not accidental.
ET-Bus prioritises deterministic latency, simple failure modes, broker-less operation, easy packet inspection, and fast recovery after Home Assistant restarts over protocol-level security.
Intended deployment model
Trusted LAN or VLAN → ET-Bus
Remote access → VPN (WireGuard / OpenVPN) → LAN → ET-Bus
Security is enforced at the network layer, not the protocol layer.
ESP32 Example Behaviour
Relay
void onCommand(JsonObject payload) { if (payload.containsKey(“on”)) { bool on = payload[“on”]; digitalWrite(RELAY_PIN, on ? HIGH : LOW); sendState(on); } }
WS2812 / RGB Light
void onCommand(JsonObject payload) { setColor(payload[“r”], payload[“g”], payload[“b”]); setBrightness(payload[“brightness”]); sendState(); }
Fan Speed Control
void onCommand(JsonObject payload) { setFanSpeed(payload[“speed”]); // 0–100 sendState(); }
ESPHome vs MQTT vs ET-Bus
ESPHome
Strengths
- YAML-based configuration
- Native Home Assistant API
- OTA updates
Limitations
- Firmware-centric
- Less suitable for complex distributed systems
MQTT
Strengths
- Huge ecosystem
- Flexible pub/sub model
- Cross-platform support
Limitations
- Requires a broker
- Retained message state issues
- Single point of failure
ET-Bus
Strengths
- No broker
- No retained state
- Deterministic latency
- True device presence tracking
- Automatic recovery after restarts
Trade-offs
- LAN-only by design
- Always-on devices only
Comparison Table
| Feature | ESPHome | MQTT | ET-Bus |
|---|---|---|---|
| Broker required | No | Yes | No |
| Local-first | Yes | Optional | Yes |
| Deterministic latency | Medium | Low | High |
| Retained state risk | No | Yes | No |
| Device-owned state | Partial | No | Yes |
| Best for battery devices | Sometimes | Sometimes | No |
| Best for always-on control | Yes | Yes | Yes (best) |
Networking Notes
- UDP must be allowed through firewalls
- Multicast must be permitted on the LAN
- VLANs must pass multicast or use unicast mode
ET-Bus is intentionally LAN-first.
Troubleshooting
Devices appear then disappear
- Heartbeat interval too long
- Home Assistant timeout too short
- Multicast blocked
Fix
- Reduce heartbeat interval
- Increase HA timeout
- Verify multicast routing
Commands sent but nothing happens
- Device does not parse command
- Device does not send state confirmation
- ID or class mismatch
Fix
- Log received packets on device
- Confirm state is sent after applying command
Roadmap
- Protocol versioning rules
- Device profile definitions
- WS2812 effect schema
- Protocol-level security (future work)
- Robust reconnect logic
- Rate limiting
- Stable device registry
- HACS support
- Example ESP32 firmwares
Contributing
Contributions should prioritise:
- Correctness over convenience
- Explicit failure over hidden failure
- Simple, inspectable protocols
License
MIT License
Author
ElectronicsTech
Built for real-world automation — not demos.
Security (highest priority for v1.1)
Hard-coded Wi-Fi credentials
UDP port 5555
Packet size / MTU concerns
IPv6
“Flooding” / keep-alives scaling
Versioning placement
Multi-relay boards / more complex devices
Dropped packets / reliability
Light sync / effects syncing (extra feature)
Speed / latency (explicit design goal)
