I have be playing with light animations, see this thread:
However I wanted to be able to have AI generate animations factoring in:
- The 3D positions of the lights.
- The differences in color mappings between manufactures.
- The difference in brightness between Kevin Temps and XY colors.
So I threw together a 3D model of the room in Godot and then placed the light bulbs in 3D space.
My Godot “Bulb” class supports:
- Kelvin Temps.
- XY color space
- Transitioning between colors and/or modes (XY vs Kelvin)
- The two types of bulb I am using Aqara and Philips Hue.
- Aqara bulbs brightness in XY mode is only about 60% of Kelvin mode.
- Philips bulbs do not have that issue.
- I have separate lookup table to map between Kevin and XY for each bulb type.
I had Claude create three “whole room” animations.
When I look at these locally (in Godot) they are hi-res running at > 60 FPS, but I have shrunk them down into slow animated gifs to upload them (about 15MB each).
Finally I told Claude to translate the Godot animations into the script format I used in the linked thread so that I could see the animations for real.
The translation into HA script has worked pretty well, but the real world brightness is not 1-to-1 with the animation - I am going to need to do some additional work to figure out how to map the brightness correctly so that:
- The color is still vibrant (when needed).
- That there are good transitions between light and dark.
A few other technical details:
- My bulbs are all Zigbee so both the simulations and real world make use of transitions - a max of 1 update per second is sent to each bulb to avoid overloading Zigbee.
- The prompt I gave to the AI was to: Favor Kelvin Colors at the end of the animation on Aqara bulbs - this leaves them in a significantly brighter state.
UPDATE: Applying a gamma (of 1.8) to the brightness has boosted the middle of the brightness range which has more or less resolved the issues - the simulation is still more vibrant than reality but there is only so much you can do …
