Sensor value as a part of path to image

Configuration Frontend
1

Hi, I need help with a simple configuration. I want to use a sensor to populate the path/filename of an image to show on my dashboard. Picture entity card or otherwise.

The sensor I have publishes an TitleId: for example “0100B7C00933A000”. I want to show a image with the path media-source://media_source/local/Server/TitleID.jpg
That would then translate to media-source://media_source/local/Server/0100B7C00933A000.jpg, or what ever that sensor value is.

I have tried a bunch of options but no luck, templating and such. Because the syntax has changed from a lot of the previous examples, I don’t know how to make this happen.

I appreciate any help with this basic config.
Thanks!

2

As far as a template goes this should work

# This concatenates the `media_content_id` string and sensor result in a template
media_content_id: "{{ 'media-source://media_source/local/your_media_directory/' ~ states('sensor.your_sensor_id') ~ '.jpg' }}"
# or, this inserts the template into the `media_content_id` string
media_content_id: "media-source://media_source/local/your_media_directory/{{ states('sensor.your_sensor_id') }}.jpg"
3

Thanks! Good advice I’m sure. I’ll read up on that.
Can I use this with a Picture Entity card? Or do I need to use some kind of media card?

I can solve it by using separate lines for each ID, but this is too much manual work:

show_state: true
show_name: true
camera_view: auto
fit_mode: cover
type: picture-entity
entity: sensor.nintendo_switch_k_current_game_title_id
state_image:
  0100d71004694000: >-
    media-source://media_source/local/Server/0100d71004694000.jpg
  01006e001823c000: >-
    media-source://media_source/local/Server/01006e001823c000.jpg
show_entity_picture: false

etc. etc.

4

The Picture Entity card does not have a media-source: option.

secondly it does not support templates. Not many core cards do.

Either use a third party card that does support templating or create a template image and display that entity in your dashboard.

5

Maybe you should give us a full picture of what you’re trying to do so that we can help you better, my advice is useless with the context you gave after my answer… See Rusty’s post.

6

I’ll read up more, for sure, thanks for your help. Super appreciated!
Gonna read up on your suggestions, but I’m not too familiar with yaml I’m afraid

I set up the integration Switch Assistant (GitHub - ErSeraph/switch-assistant: Switch Assistant connects your Nintendo Switch to Home Assistant through MQTT · GitHub)
And I have this sensor that provides the TitleID for the game that is currently being played. I want to show the Cover art for that game. I have scripted an export of all the images/covers for the games and named them the same as the ID that the sensor is presenting.
Now I need to show them whenever a game is played.

7

If you have any more pointers or maybe examples, I would love that. It makes learning way faster.

Thanks guys

8

What is the entity id of this sensor and in which directory are your images stored (e.g. config/lwww/titles/…)

9

The sensor is a MQTT sensor with entity id sensor.nintendo_switch_k_current_game_title_id
and the directory is a mapped network share. media-source://media_source/local/Server/

10

I’m almost certain that won’t work. They have to be stored locally.

11

The picture entity card can use media-source images (it’s there in the UI picker), but it doesn’t have the ability to use a templated ID.

A template image can generate a key from an ID, but I don’t believe template image have any access to media-source files, it can only generate a URL, and that will not have the appropriate authorization keys added.

So you might be stuck for the moment from the core side. It would probably be a good feature request to make though.

The closest you can get for now is to move all your images to the /www/ folder and reference them with template image.

12

I managed to solve all this using the Media-Source Image Card GitHub - luixal/lovelace-media-source-image-card: A Lovelace custom card for showing images stored in Media Source · GitHub

It supports media-Source and templating!

:smiley:

I find it kinda weird that templating isn’t supported everywhere. It should be a core feature.
