Trigger action when Tasmoto flashed Sonoff RF Bridge reads a RF command from a KAKU remote

SuperR1902 · July 3, 2025, 7:42pm

I have a Tasmoto flashed Sonoff RF Bridge configured in HA. With some thinkering I can turn on and off my KlikAanKlikUit RF switches based on a question I had in the past:

github.com/Portisch/RF-Bridge-EFM8BB1

Reading Klik Aan Klik Uit (KAKU) devices

opened 06:12AM - 05 Nov 21 UTC

SuperR1902

### Latest firmware used? RF-Bridge-EFM8BB1-20190220.hex ### Information Kl…ik aan klik uit, KAKU ### Sniffed data 07:41:03.284 CMD: rfraw 177 07:41:03.293 MQT: stat/rf-bridge/RESULT = {"RfRaw":"ON"} 07:41:03.378 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:03","RfRaw":{"Data":"AAA055"}} 07:41:05.311 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:05","RfRaw":{"Data":"AA B1 04 0140 04B0 00C8 049C 3818281828 55"}} 07:41:05.338 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:05","RfRaw":{"Data":"AA B1 04 0136 00D2 0492 04C4 381828 55"}} 07:41:05.560 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:05","RfRaw":{"Data":"AA B1 05 0140 099C 04A6 00D2 2A9E 481828383828382828383828382838283828382838283828283828382838283828383828382828382838382828383828382828380828082828383828382808282838 55"}} 07:41:05.577 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:05","RfRaw":{"Data":"AA B1 04 014A 00C8 04B0 04A6 381828 55"}} 07:41:05.846 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:05","RfRaw":{"Data":"AA B1 05 0168 0974 0488 00AA 2A9E 481828383828382828383828382838283828382838283828283828382838283828383828382828382838382828383828382828383828382828383828382838282838 55"}} 07:41:05.858 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:05","RfRaw":{"Data":"AA B1 04 014A 00C8 04A6 049C 381828 55"}} 07:41:06.892 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:06","RfRaw":{"Data":"AA B1 04 0136 00DC 04BA 04BA 381828 55"}} 07:41:07.112 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:07","RfRaw":{"Data":"AA B1 05 014A 0992 04A6 00C8 2A94 481828383828382828383828382838283828382838283828283828382838283828383828382828382838382828383828382828383828382828383828382838282838 55"}} 07:41:07.134 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:07","RfRaw":{"Data":"AA B1 04 0140 00D2 04B0 04A6 381828 55"}} 07:41:07.355 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:07","RfRaw":{"Data":"AA B1 05 0168 097E 0488 00AA 2A9E 481828383828382828383828382838283828382838283828283828382838283828383828382828382838382828383828382828383828382828383828382838282838 55"}} 07:41:07.373 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:07","RfRaw":{"Data":"AA B1 04 0154 00C8 04A6 049C 381828 55"}} 07:41:11.449 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:11","RfRaw":{"Data":"AA B1 04 0140 00DC 04BA 04B0 381828 55"}} 07:41:11.669 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:11","RfRaw":{"Data":"AA B1 05 0140 09A6 04B0 00C8 2AA8 481828383828382828383828382838283828382838283828283828382838283828383828382828382838382828383828382828383828382828080828382838282808 55"}} 07:41:11.687 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:11","RfRaw":{"Data":"AA B1 04 0140 00C8 04B0 04B0 381828 55"}} 07:41:11.909 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:11","RfRaw":{"Data":"AA B1 05 015E 0974 0488 00A0 2AA8 481828383828382828383828382838283828382838283828283828382838283828383828382828382838382828383828382828383828382828383828382838282838 55"}} 07:41:11.927 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:41:11","RfRaw":{"Data":"AA B1 04 014A 00BE 04B0 049C 381828 55"}} This is the output from RFRAW 166 07:46:59.043 CMD: rfraw 166 07:46:59.052 MQT: stat/rf-bridge/RESULT = {"RfRaw":"ON"} 07:46:59.154 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:46:59","RfRaw":{"Data":"AAA055"}} 07:47:01.762 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:47:01","RfRaw":{"Data":"AAA6050D6FE0CB6E55"}} 07:47:06.584 MQT: tele/rf-bridge/RESULT = {"Time":"2021-11-05T07:47:06","RfRaw":{"Data":"AAA6050D6FE0CB6E55"}} How to identify the actual code from the rest? In another app, the 'remote code' is identified as 02407CD201. In other words, how to identify what line to convert in https://bbconv.hrbl.pl/ ?

What I now want to do is have my Home Assistent trigger an action when a certain RF signal is read/received.

These are the commands I use to generate the particular signals, but I now want trigger an action when these are read/received.

      woonkamerlicht:
        turn_on:
          service: mqtt.publish
          data:
            topic: 'cmnd/rf-bridge/RfRaw'
            payload: 'AAA8050DDFADB22F55'
        turn_off:
          service: mqtt.publish
          data:
            topic: 'cmnd/rf-bridge/RfRaw'
            payload: 'AAA8050DDFADB23F55'

This is the console reponse for Off and then On

20:43:21.059 CMD: rfraw 177
20:43:21.068 MQT: stat/rf-bridge/RESULT = {“RfRaw”:“ON”}
20:43:21.143 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:21”,“RfRaw”:{“Data”:“AAA055”}}
20:43:29.347 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:29”,“RfRaw”:{“Data”:“AA B1 04 0122 00D2 04BA 04BA 381828 55”}}
20:43:29.585 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:29”,“RfRaw”:{“Data”:“AA B1 05 0122 09D8 00D2 04CE 285A 481828382838382828382838283828382838283838080838380808380838380808380838380808380838380838080838380838083808083808380838083808380838 55”}}
20:43:29.820 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:29”,“RfRaw”:{“Data”:“AA B1 05 014A 09B0 00AA 04A6 2832 481828382838382828382838283828382838283838282838382828382838382828382838382828382838382838282838382838283828283828382838283828382838 55”}}
20:43:30.766 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:30”,“RfRaw”:{“Data”:“AA B1 05 014A 09B0 00AA 04A6 283C 481828382838382828382838283828382838283838282838382828382838382828382838382828382838382838282838382838283828283828382838283828382838 55”}}
20:43:32.370 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:32”,“RfRaw”:{“Data”:“AA B1 04 0122 00D2 04CE 04BA 381828 55”}}
20:43:32.460 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:32”,“RfRaw”:{“Data”:“AA B1 03 010E 04CE 04C4 281808 55”}}
20:43:32.921 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:32”,“RfRaw”:{“Data”:“AA B1 05 0140 09B0 00AA 04A6 283C 481828382838382828382838283828382838283838282838382828382838382828382838382828382838382838282838382838283828283838282838283828382838 55”}}
20:43:33.866 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:43:33”,“RfRaw”:{“Data”:“AA B1 05 014A 09B0 00AA 04A6 283C 481828382838382828382838283828382838283838282838382828382838382828382838382828382838382838282838382838283828283838282838283828382838 55”}}

And the same for a different RFRaw command

20:44:27.882 CMD: rfraw 166
20:44:27.891 MQT: stat/rf-bridge/RESULT = {“RfRaw”:“ON”}
20:44:27.986 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:44:27”,“RfRaw”:{“Data”:“AAA055”}}
20:44:34.124 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:44:34”,“RfRaw”:{“Data”:“AAA6050DDFADB23F55”}}
20:44:34.990 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:44:34”,“RfRaw”:{“Data”:“AAA6050DDFADB23F55”}}
20:44:37.540 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:44:37”,“RfRaw”:{“Data”:“AAA6050DDFADB22F55”}}
20:44:38.406 MQT: tele/rf-bridge/RESULT = {“Time”:“2025-07-03T20:44:38”,“RfRaw”:{“Data”:“AAA6050DDFADB22F55”}}

WarLion · July 3, 2025, 8:47pm

something like this?

alias: RF KlikAanKlikUit Handler
description: "Handles multiple RF codes from the RF Bridge"
trigger:
  - platform: mqtt
    topic: tele/rf-bridge/RESULT

condition: []

action:
  - choose:
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfRaw.Data == 'AAA6050DDFADB22F55' }}"
        sequence:
          - service: light.turn_on
            target:
              entity_id: light.woonkamer

      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfRaw.Data == 'AAA6050DDFADB23F55' }}"
        sequence:
          - service: light.turn_off
            target:
              entity_id: light.woonkamer

mode: queued

Just copy a - conditions: block under choose: for each new RF code and target entity. This way, you can manage all RF signal responses in a single automation.

this one is what i use to recive data

alias: RF Control con múltiples botones lizzy
description: Automatización que reacciona a varios códigos RF del RF Bridge
triggers:
  - topic: tele/RF_Bridge2/RESULT
    trigger: mqtt
conditions:
  - condition: template
    value_template: "{{ trigger.payload_json.RfReceived is defined }}"
actions:
  - choose:
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfReceived.Data == '335208' }}"
        sequence:
          - target:
              entity_id: light.luz_cuarto
            data:
              brightness: 60
            action: light.toggle
        alias: boton 1 lizzy
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfReceived.Data == '33520C' }}"
        sequence:
          - target:
              entity_id: light.luces_cabecera
            action: light.toggle
            data: {}
        alias: boton 2 lizzy
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfReceived.Data == '335209' }}"
        sequence:
          - target:
              entity_id: light.luces_cabecera
            data:
              brightness: >
                {% set b = state_attr('light.luces_cabecera', 'brightness') |
                int(0) %} {{ [b + 70, 255] | min }}
            action: light.turn_on
        alias: boton 3 lizzy
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfReceived.Data == '335205' }}"
        sequence:
          - target:
              entity_id: light.luces_cabecera
            data:
              brightness: >
                {% set b = state_attr('light.luces_cabecera', 'brightness') |
                int(0) %} {{ [b - 70, 1] | max }}
            action: light.turn_on
        alias: boton 4 lizzy
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfReceived.Data == '335204' }}"
        sequence:
          - action: climate.turn_off
            metadata: {}
            data: {}
            target:
              entity_id: climate.clima_recamara
        alias: boton 5 lizzy
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfReceived.Data == '335202' }}"
        sequence:
          - data:
              name: RF Bridge
              message: Código 335202 recibido (reservado para acción futura).
            action: logbook.log
        alias: boton 6 lizzy
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfReceived.Data == '335201' }}"
        sequence:
          - data:
              name: RF Bridge
              message: Código 335201 recibido (reservado para acción futura).
            action: logbook.log
        alias: boton 7 lizzy
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfReceived.Data == '335203' }}"
        sequence:
          - data:
              name: RF Bridge
              message: Código 335203 recibido (reservado para acción futura).
            action: logbook.log
        alias: boton 8 lizzy
    default: []
mode: queued

SuperR1902 · July 8, 2025, 2:22pm

It works, it triggers a tbd action when the payload is received. I needed to make sure the automation would not run 2 times so I put the mode to single instead of qued and had it wait for a bit to make sure it would not trigger twice during the RF transmittal.

I needed to have a switch turn on and off quickly to tell a light dimmer to toggle between on/off.

Fun fact: When I have the RF bridge send the command via Home Assistant, it does not read the sent command during transmittal. Not a big deal and I can fix that in automation too, but when it is sending, it does not seem to be receiving too.

alias: Wandlamp schakelen op KaKu
description: Handles multiple RF codes from the RF Bridge
triggers:
  - topic: tele/rf-bridge/RESULT
    trigger: mqtt
conditions: []
actions:
  - choose:
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfRaw.Data == 'AAA6050DDFADB22F55' }}"
        sequence:
          - type: turn_on
            device_id: 665735e8bd847014112f2dd22e8e5a8a
            entity_id: 4eb7498cbdfb616ef2a361557ec08ac3
            domain: switch
          - delay:
              hours: 0
              minutes: 0
              seconds: 0
              milliseconds: 100
          - type: turn_off
            device_id: 665735e8bd847014112f2dd22e8e5a8a
            entity_id: 4eb7498cbdfb616ef2a361557ec08ac3
            domain: switch
      - conditions:
          - condition: template
            value_template: "{{ trigger.payload_json.RfRaw.Data == 'AAA6050DDFADB23F55' }}"
        sequence:
          - type: turn_on
            device_id: 665735e8bd847014112f2dd22e8e5a8a
            entity_id: 4eb7498cbdfb616ef2a361557ec08ac3
            domain: switch
          - delay:
              hours: 0
              minutes: 0
              seconds: 0
              milliseconds: 100
          - type: turn_off
            device_id: 665735e8bd847014112f2dd22e8e5a8a
            entity_id: 4eb7498cbdfb616ef2a361557ec08ac3
            domain: switch
  - delay:
      hours: 0
      minutes: 0
      seconds: 2
      milliseconds: 0
mode: single
