Tuya / eWeLink Zigbee PC Power Switch [ZHA]

XxmArKxX · June 16, 2025, 7:00am

Hi,

I’m considering buying this PC power switch card with Zigbee support.
I guess it’s pretty new as there’s nothing about ZHA support, just some people who use it with MQTT. Is there anyone here who has this card or a similar one and can confirm it’s possible to use it with ZHA?

https://de.aliexpress.com/item/1005006090821609.html

Thanks

tom_l · June 16, 2025, 7:50am

Is there any reason a WoL switch wont do?

XxmArKxX · June 16, 2025, 11:59am

Yes, WOL is not option for my usecase.

tom_l · June 16, 2025, 12:55pm

Why not?

XxmArKxX · June 16, 2025, 2:30pm

Because its an Server that will be online on demand. And some applications that tries to reach this server would wake it up even if you not want to. (for example when the application is just launchend in background)
So i disabled WOL and switched to an eWelink wifi PCI Card, but now want to switch to the zigbee version to get rid of the cloud.

TheLord · July 1, 2025, 9:41am

I have one. I can pair it with ZHA but the device is recognized as a light bulb…

It seems to work with zigbee2mqtt (didnt test)

github.com/Koenkk/zigbee2mqtt

[New device support]: Zigbee Computer Power - model 'TS0601' and manufacturer name '_TZE204_6fk3gewc'

opened 12:33AM - 03 Oct 23 UTC

closed 12:03AM - 02 Oct 24 UTC

LuizizM

new device support stale

### Link https://vi.aliexpress.com/item/1005002776442806.html?spm=a2g0o.order…_list.order_list_main.11.6daccaa4F9lIDH&gatewayAdapt=glo2vnm ### Database entry {"id":17,"type":"Router","ieeeAddr":"0xa4c1382e33144c13","nwkAddr":22241,"manufId":4417,"manufName":"_TZE204_6fk3gewc","powerSource":"Mains (single phase)","modelId":"TS0601","epList":[1,242],"endpoints":{"1":{"profId":260,"epId":1,"devId":81,"inClusterList":[4,5,61184,0],"outClusterList":[25,10],"clusters":{"genBasic":{"attributes":{"65503":"\u000e\u0000\u0000\u0000e\u000f\u0000\u0000\u0000\u0012#` ,\u0017$` ,\u0013h\u0007\u0000\u0000ei\u0007\u0000\u0000\u0012 ,f ,\u0012","65506":56,"65508":0,"stackVersion":0,"dateCode":"","appVersion":74}}},"binds":[{"cluster":61184,"type":"endpoint","deviceIeeeAddress":"0x040d84fffe512f0c","endpointID":1},{"cluster":6,"type":"endpoint","deviceIeeeAddress":"0x040d84fffe512f0c","endpointID":1},{"cluster":7,"type":"endpoint","deviceIeeeAddress":"0x040d84fffe512f0c","endpointID":1}],"configuredReportings":[],"meta":{}},"242":{"profId":41440,"epId":242,"devId":97,"inClusterList":[],"outClusterList":[33],"clusters":{},"binds":[],"configuredReportings":[],"meta":{}}},"appVersion":74,"stackVersion":0,"hwVersion":1,"dateCode":"","zclVersion":3,"intervewCompleted":true,"meta":{},"lastSeen":1696294086650,"defaultSendRequestWhen":"immediate"} ### Comments i tried to add this Zigbee adapter but im new and dont know how to get the data from the device and need help with it , is a power switch that allows you to turn on you PC remotely using zigbee, has child lock that dont allow it to be turned on/off from the computer switch only allowing to be turned remotely, also has a feature to bind a 433mhz remote to turn on and off the computer by pressing the remote as well. ### External converter _No response_ ### Supported color modes _No response_ ### Color temperature range _No response_

XxmArKxX · July 4, 2025, 1:06pm

I have bought one too and realised just in this moment the same issue
Do you still use the card even if its detected as an lightbulb?

francisp · July 4, 2025, 1:15pm

You can change it to a switch

in configuration.yaml

zha:
  device_config:
    00:12:4b:00:22:ed:55:37-1:
      type: "switch"
    00:12:4b:00:22:ed:55:37-2:
      type: "switch"`

XxmArKxX · July 4, 2025, 2:02pm

ah, i see. i guess i have to check if the card is proper working until i only need on and off function…big question if its correctly recognize the state of the pc and set the switch properly. we will see.

if not, i need to setup a second network and work in mqtt or i write a custom quirk. (got python experience but never wrote a quik by myself, maybe the is something like a guide?)
