Huawei Power Meter DTSU-666-H Modbus

EVH4ever · July 14, 2024, 12:31am

Some devices ,may require a login in order to change certain registers.

pela222 · August 1, 2024, 7:18am

Hi,
have you manage to solve problem with total energy 0 value?

cristitttt · October 3, 2024, 8:51am

please help me with integration i try a lot and don"t work
i try with modbus seriel i see the sensor but no value
i try with esp 32 and don<t work .

cristitttt · October 3, 2024, 9:08am

vinceg0267:

###
uart:
  id: mod_bus
  tx_pin: 03
  rx_pin: 01
  baud_rate: 9600
  stop_bits: 1

modbus:
  flow_control_pin: 5
  id: modbus1

modbus_controller:
    address: 0x001
    modbus_id: modbus1
    update_interval: 1s
    setup_priority: -10

sensor:
 - platform: modbus_controller
   id: chint_voltage
   name: "Chint Tensione"
   address: 0x2000
   unit_of_measurement: "V" ## for any other unit the value is returned in minutes
   register_type: holding
   value_type: FP32
   accuracy_decimals: 2
   filters:
     - multiply: 1

 - platform: modbus_controller
   id: chint_current
   name: "Chint Corrente"
   address: 0x2002
   unit_of_measurement: "A" ## for any other unit the value is returned in minutes
   register_type: read
   value_type: FP32
   accuracy_decimals: 2
   filters:
     - multiply: 1

 - platform: modbus_controller
   id: chint_power
   name: "Chint Potenza istantanea"
   address: 0x2004
   unit_of_measurement: "W" ## for any other unit the value is returned in minutes
   state_class: "measurement"
   register_type: read
   value_type: FP32
   accuracy_decimals: 2
   filters:
     - multiply: 1000

 - platform: modbus_controller
   id: chint_frequency
   name: "Chint Frequenza Rete"
   address: 0x200E
   unit_of_measurement: "Hz" ## for any other unit the value is returned in minutes
   register_type: read
   value_type: FP32
   accuracy_decimals: 2
   filters:
     - multiply: 1

 - platform: modbus_controller
   id: chint_energy_sold
   name: "Chint Energia ceduta"
   address: 0x4000
   unit_of_measurement: "KWh" ## for any other unit the value is returned in minutes
   state_class: total_increasing
   device_class: "energy"
   register_type: read
   value_type: FP32
   accuracy_decimals: 2
   filters:
     - multiply: 1

 - platform: modbus_controller
   id: chint_energy_purchased
   name: "Chint Energia acquistata"
   address: 0x400A
   unit_of_measurement: "KWh" ## for any other unit the value is returned in minutes
   state_class: total_increasing
   device_class: "energy"
   register_type: read
   value_type: FP32
   accuracy_decimals: 2
   filters:
     - multiply: 1

 - platform: modbus_controller
   id: chint_reactive_power
   name: "Chint Potenza reattiva"
   address: 0x2004
   unit_of_measurement: "Var" ## for any other unit the value is returned in minutes
   register_type: read
   value_type: FP32
   accuracy_decimals: 2
   filters:
     - multiply: 1000

my configuration yaml
please tell my what are wrong ?
modbus:

name: meter
type: serial
baudrate: 9600
bytesize: 8
method: rtu
parity: N
port: /dev/serial/by-id/usb-1a86_USB_Serial-if00-port0
stopbits: 1
sensors:
- name: sdm630_energy
  address: 1
  input_type: input
  slave: 1
  precision: 2
  data_type: float32
  unit_of_measurement: kWh
  device_class: energy
  state_class: total_increasing
- name: sdm630_p1
  slave: 1
  address: 2
  input_type: input
  precision: 2
  data_type: float32
  unit_of_measurement: V
  device_class: voltage
- name: sdm630_p2
  slave: 1
  address: 3
  input_type: input
  precision: 2
  data_type: float32
  unit_of_measurement: V
  device_class: voltage
- name: sdm630_p3
  slave: 1
  address: 4
  input_type: input
  precision: 2
  data_type: float32
  unit_of_measurement: V
  device_class: voltage
- name: sdm630_p1_current
  slave: 1
  address: 6
  input_type: input
  precision: 3
  data_type: float32
  unit_of_measurement: A
  device_class: current
- name: sdm630_p2_current
  slave: 1
  address: 8
  input_type: input
  precision: 3
  data_type: float32
  unit_of_measurement: A
  device_class: current
- name: sdm630_p3_current
  slave: 1
  address: 10
  input_type: input
  precision: 3
  data_type: float32
  unit_of_measurement: A
  device_class: current
- name: sdm630_p1
  slave: 1
  address: 12
  input_type: input
  precision: 3
  scale: 0.001
  data_type: float32
  unit_of_measurement: kW
  device_class: power
- name: sdm630_p2
  slave: 1
  address: 14
  input_type: input
  precision: 3
  scale: 0.001
  data_type: float32
  unit_of_measurement: kW
  device_class: power
- name: sdm630_p3
  slave: 1
  address: 16
  input_type: input
  precision: 3
  scale: 0.001
  data_type: float32
  unit_of_measurement: kW
  device_class: power
- name: sdm630_current
  slave: 1
  address: 48
  input_type: input
  precision: 3
  data_type: float32
  unit_of_measurement: A
  device_class: current
- name: sdm630_power
  slave: 1
  address: 52
  input_type: input
  precision: 3
  scale: 0.001
  data_type: float32
  unit_of_measurement: kW
  device_class: power
- name: sdm630__power
  slave: 1
  address: 56
  input_type: input
  precision: 2
  data_type: float32
  unit_of_measurement: VA
  device_class: power
- name: sdm630_reactive_power
  slave: 1
  address: 60
  input_type: input
  precision: 2
  data_type: float32
  unit_of_measurement: VAr
  device_class: power
- name: sdm630_sum_pf
  slave: 1
  address: 62
  input_type: input
  precision: 2
  data_type: float32
  unit_of_measurement: cosф
  device_class: power_factor

JoeBeu · March 21, 2025, 6:58am

The integration

doesn`t work anymore as modbus seems to be outdated. Several unanswered issues opened at Github since January 2025

E.Antonsson · May 14, 2025, 7:43pm

Hi, do you get it to work? The communication thru Modbus TCP between Smartlogger and home assist?

mryndak · October 22, 2025, 5:30pm

My version: GitHub - mryndak/ha_chint_pm: homeassistant Chint power meter integration

triboi1st1982-collab · April 9, 2026, 1:09pm

(post deleted by author)

triboi1st1982-collab · April 10, 2026, 3:24pm

my config for DTSU666-H

# packages/dtsu666_modbus.yaml
# Подключение счётчика CHNT DTSU666 через RS485 (USB-конвертер)
# Параметры счётчика: Modbus RTU, адрес 11, 9600 бод, n.2 (No parity, 2 stop bits)

modbus:
  - name: "dtsu666"
    type: serial
    method: rtu
    port: /dev/ttyUSB1
    baudrate: 9600
    stopbits: 2
    bytesize: 8
    parity: N
    timeout: 5
    sensors:
# ========== НОВЫЕ СЕНСОРЫ ИЗ АЛЬТЕРНАТИВНОЙ ДОКУМЕНТАЦИИ ==========
# packages/dtsu666_modbus.yaml
# Подключение счётчика CHNT DTSU666 через RS485 (USB-конвертер)
# Параметры счётчика: Modbus RTU, адрес 11, 9600 бод, n.2 (No parity, 2 stop bits)
      # ========== НАПРЯЖЕНИЯ (фазные) ==========
      - name: dtsu666_ua
        unique_id: dtsu666_ua
        slave: 11
        address: 0x2006          # регистр фазного напряжения A
        data_type: float32
        unit_of_measurement: "V"
        input_type: holding
        precision: 1
        device_class: voltage
        state_class: measurement

      - name: dtsu666_ub
        unique_id: dtsu666_ub
        slave: 11
        address: 0x2008
        data_type: float32
        unit_of_measurement: "V"
        input_type: holding
        precision: 1
        device_class: voltage
        state_class: measurement

      - name: dtsu666_uc
        unique_id: dtsu666_uc
        slave: 11
        address: 0x200A
        data_type: float32
        unit_of_measurement: "V"
        input_type: holding
        precision: 1
        device_class: voltage
        state_class: measurement

      # ========== НАПРЯЖЕНИЯ (линейные) ==========
      - name: dtsu666_uab
        unique_id: dtsu666_uab
        slave: 11
        address: 0x2000
        data_type: float32
        unit_of_measurement: "V"
        input_type: holding
        precision: 1
        device_class: voltage
        state_class: measurement

      - name: dtsu666_ubc
        unique_id: dtsu666_ubc
        slave: 11
        address: 0x2002
        data_type: float32
        unit_of_measurement: "V"
        input_type: holding
        precision: 1
        device_class: voltage
        state_class: measurement

      - name: dtsu666_uca
        unique_id: dtsu666_uca
        slave: 11
        address: 0x2004
        data_type: float32
        unit_of_measurement: "V"
        input_type: holding
        precision: 1
        device_class: voltage
        state_class: measurement

      # ========== ТОКИ ==========
      - name: dtsu666_ia
        unique_id: dtsu666_ia
        slave: 11
        address: 0x200C
        data_type: float32
        unit_of_measurement: "A"
        input_type: holding
        precision: 2
        device_class: current
        state_class: measurement

      - name: dtsu666_ib
        unique_id: dtsu666_ib
        slave: 11
        address: 0x200E
        data_type: float32
        unit_of_measurement: "A"
        input_type: holding
        precision: 2
        device_class: current
        state_class: measurement

      - name: dtsu666_ic
        unique_id: dtsu666_ic
        slave: 11
        address: 0x2010
        data_type: float32
        unit_of_measurement: "A"
        input_type: holding
        precision: 2
        device_class: current
        state_class: measurement

      # ========== АКТИВНАЯ МОЩНОСТЬ (Вт) ==========
      - name: dtsu666_pa
        unique_id: dtsu666_pa
        slave: 11
        address: 0x2014
        data_type: float32
        unit_of_measurement: "W"
        input_type: holding
        precision: 0
        device_class: power
        state_class: measurement

      - name: dtsu666_pb
        unique_id: dtsu666_pb
        slave: 11
        address: 0x2016
        data_type: float32
        unit_of_measurement: "W"
        input_type: holding
        precision: 0
        device_class: power
        state_class: measurement

      - name: dtsu666_pc
        unique_id: dtsu666_pc
        slave: 11
        address: 0x2018
        data_type: float32
        unit_of_measurement: "W"
        input_type: holding
        precision: 0
        device_class: power
        state_class: measurement

      - name: dtsu666_pt          # суммарная активная мощность
        unique_id: dtsu666_pt
        slave: 11
        address: 0x2012
        data_type: float32
        unit_of_measurement: "W"
        input_type: holding
        precision: 0
        device_class: power
        state_class: measurement

      # ========== РЕАКТИВНАЯ МОЩНОСТЬ (вар) ==========
      - name: dtsu666_qa
        unique_id: dtsu666_qa
        slave: 11
        address: 0x201C
        data_type: float32
        unit_of_measurement: "var"
        input_type: holding
        precision: 0
        device_class: reactive_power
        state_class: measurement

      - name: dtsu666_qb
        unique_id: dtsu666_qb
        slave: 11
        address: 0x201E
        data_type: float32
        unit_of_measurement: "var"
        input_type: holding
        precision: 0
        device_class: reactive_power
        state_class: measurement

      - name: dtsu666_qc
        unique_id: dtsu666_qc
        slave: 11
        address: 0x2020
        data_type: float32
        unit_of_measurement: "var"
        input_type: holding
        precision: 0
        device_class: reactive_power
        state_class: measurement

      - name: dtsu666_qt          # суммарная реактивная мощность
        unique_id: dtsu666_qt
        slave: 11
        address: 0x201A
        data_type: float32
        unit_of_measurement: "var"
        input_type: holding
        precision: 0
        device_class: reactive_power
        state_class: measurement

      # ========== КОЭФФИЦИЕНТЫ МОЩНОСТИ ==========
      - name: dtsu666_pft          # суммарный
        unique_id: dtsu666_pft
        slave: 11
        address: 0x202A
        data_type: float32
        input_type: holding
        precision: 3
        device_class: power_factor
        state_class: measurement

      - name: dtsu666_pfa          # фаза A
        unique_id: dtsu666_pfa
        slave: 11
        address: 0x202C
        data_type: float32
        input_type: holding
        precision: 3
        device_class: power_factor
        state_class: measurement

      - name: dtsu666_pfb          # фаза B
        unique_id: dtsu666_pfb
        slave: 11
        address: 0x202E
        data_type: float32
        input_type: holding
        precision: 3
        device_class: power_factor
        state_class: measurement

      - name: dtsu666_pfc          # фаза C
        unique_id: dtsu666_pfc
        slave: 11
        address: 0x2030
        data_type: float32
        input_type: holding
        precision: 3
        device_class: power_factor
        state_class: measurement

      # ========== ЧАСТОТА ==========
      - name: dtsu666_freq
        unique_id: dtsu666_freq
        slave: 11
        address: 0x2044
        data_type: float32
        unit_of_measurement: "Hz"
        input_type: holding
        precision: 2
        device_class: frequency
        state_class: measurement

      # ========== Total active power demand ==========
      - name: dtsu666_dmpt
        unique_id: dtsu666_dmpt
        slave: 11
        address: 0x2050
        data_type: float32
        unit_of_measurement: "W"
        input_type: holding
        precision: 2
        device_class: power
        state_class: measurement

      - name: dtsu666_apparent_power
        unique_id: dtsu666_apparent_power
        slave: 11
        address: 0x085E          # 2142 dec
        data_type: float32
        unit_of_measurement: "kVA"
        input_type: holding
        precision: 2
        device_class: apparent_power
        state_class: measurement

      - name: dtsu666_total_active_elec
        unique_id: dtsu666_total_active_elec
        slave: 11
        address: 0x086E          # 2158 dec
        data_type: float32
        unit_of_measurement: "kWh"
        input_type: holding
        precision: 2
        device_class: energy
        state_class: total_increasing


      - name: dtsu666_total_pos_active_elec
        unique_id: dtsu666_total_pos_active_elec
        slave: 11
        address: 0x0876          # 2166 dec
        data_type: float32
        unit_of_measurement: "kWh"
        input_type: holding
        precision: 2
        device_class: energy
        state_class: total_increasing

      - name: dtsu666_total_neg_active_elec
        unique_id: dtsu666_total_neg_active_elec
        slave: 11
        address: 0x087E          # 2174 dec
        data_type: float32
        unit_of_measurement: "kWh"
        input_type: holding
        precision: 2
        device_class: energy
        state_class: total_increasing

CARD =============

type: entities
title: 📊 DTSU666 – полный мониторинг
entities:
  - type: section
    label: ⚡ Напряжения фазные (В)
  - entity: sensor.dtsu666_ua
    icon: mdi:flash
    name: Фаза A
  - entity: sensor.dtsu666_ub
    icon: mdi:flash
    name: Фаза B
  - entity: sensor.dtsu666_uc
    icon: mdi:flash
    name: Фаза C

  - type: section
    label: 🔌 Напряжения линейные (В)
  - entity: sensor.dtsu666_uab
    icon: mdi:flash-triangle
    name: UAB
  - entity: sensor.dtsu666_ubc
    icon: mdi:flash-triangle
    name: UBC
  - entity: sensor.dtsu666_uca
    icon: mdi:flash-triangle
    name: UCA

  - type: section
    label: 🔁 Токи (А)
  - entity: sensor.dtsu666_ia
    icon: mdi:current-ac
    name: Фаза A
  - entity: sensor.dtsu666_ib
    icon: mdi:current-ac
    name: Фаза B
  - entity: sensor.dtsu666_ic
    icon: mdi:current-ac
    name: Фаза C

  - type: section
    label: 🔥 Активная мощность (Вт)
  - entity: sensor.dtsu666_pa
    icon: mdi:flash-outline
    name: Фаза A
  - entity: sensor.dtsu666_pb
    icon: mdi:flash-outline
    name: Фаза B
  - entity: sensor.dtsu666_pc
    icon: mdi:flash-outline
    name: Фаза C
  - entity: sensor.dtsu666_pt
    icon: mdi:flash
    name: Суммарная

  - type: section
    label: 🌀 Реактивная мощность (вар)
  - entity: sensor.dtsu666_qa
    icon: mdi:flash-circle
    name: Фаза A
  - entity: sensor.dtsu666_qb
    icon: mdi:flash-circle
    name: Фаза B
  - entity: sensor.dtsu666_qc
    icon: mdi:flash-circle
    name: Фаза C
  - entity: sensor.dtsu666_qt
    icon: mdi:flash-circle
    name: Суммарная

  - type: section
    label: 📐 Коэффициент мощности (PF)
  - entity: sensor.dtsu666_pft
    icon: mdi:cosine-wave
    name: Общий
  - entity: sensor.dtsu666_pfa
    icon: mdi:cosine-wave
    name: Фаза A
  - entity: sensor.dtsu666_pfb
    icon: mdi:cosine-wave
    name: Фаза B
  - entity: sensor.dtsu666_pfc
    icon: mdi:cosine-wave
    name: Фаза C

  - type: section
    label: 🎵 Частота и спрос
  - entity: sensor.dtsu666_freq
    icon: mdi:sine-wave
    name: Частота (Гц)
  - entity: sensor.dtsu666_dmpt
    icon: mdi:power-plug
    name: Спрос активной мощности (Вт)

  - type: section
    label: 📊 Полная мощность
  - entity: sensor.dtsu666_apparent_power
    icon: mdi:chart-bell-curve
    name: Полная мощность (кВА)

  - type: section
    label: 🔋 Энергия (активная, кВт·ч)
  - entity: sensor.dtsu666_total_active_elec
    icon: mdi:counter
    name: Общая активная (net?)
  - entity: sensor.dtsu666_total_pos_active_elec
    icon: mdi:arrow-up-bold
    name: Положительная (импорт)
  - entity: sensor.dtsu666_total_neg_active_elec
    icon: mdi:arrow-down-bold
    name: Отрицательная (экспорт)
