Tapo Cameras with Frigate

Thanks for the PTZ settings, I was using wrong ONVIF port number :slight_smile:

With regards to your 2-way audio issue, I have 2-way audio working with Tapo C220 camera. Under your go2rtc settings add the following:

streams:
    EundE_EINGANG-Innen:
      - rtsp://USER:[email protected]:554/stream1
      - tapo://[email protected]

( # insert your tplink cloud password without username)

Hopefully that will enable 2-way audio for you too :slight_smile:

THX, but No 2way Audio Icon to talk in fregate when I click in the picture of the cam.
Where do you see the icon.
I have these on Top richt corner:

And The PTZ in the middle down on the Video screen

Can you provide a screenshot of the 2 Way-Audio Icon, Pls.
And also the camera section, Maybe I have a problem there.

Does the C220 work fluently? I have just bought a Tapo C220 and the image is not stable and frigate throws lot of errors from ffmpeg. I think I’m going to return this shit.

Are you accessing Frigate UI over https? It must be https for 2 way audio to work.

It’s working great for me. Here are my go2rtc settings in my Frigate config.yml:

go2rtc:
  streams:
    kitchen_tapo:
      - ffmpeg:rtsp://user:[email protected]/stream1#video=copy#audio=copy#audio=aac
      - tapo://[email protected]

I have that configuration, but PTZ is not working.

Frigate says “No appropriate Onvif profiles found for camera: camara-cocina.”

I have RTSP video in Frigate but has that problem.

Onvif is working with an Onvif software and I can control the PTZ with it.

Do you have ONVIF configured in Frigate under that specific camera?

Here’s my tapo camera Frigate config for reference:

  kitchen_tapo:
    ffmpeg:
      retry_interval: 60
      inputs:
        - path: rtsp://127.0.0.1:8554/kitchen_tapo?video=copy&audio=aac
          input_args: preset-rtsp-restream
          roles:
            - record
            - audio
            - detect
    audio:
      enabled: true
      listen:
        - bark
        - scream
        - yell
        - glass
        - smash
        - speech
        - fire_alarm
        - smoke_detector
      filters:
        speech:
          threshold: 0.6
        glass:
          threshold: 0.5
        fire_alarm:
          threshold: 0.5
        smoke_detector:
          threshold: 0.5
    snapshots:
      enabled: false
      timestamp: false
    record:
      enabled: true
      retain:
        # Optional: Number of days to retain recordings regardless of events (default: shown below)
        # NOTE: This should be set to 0 and retention should be defined in events section below
        #       if you only want to retain recordings of events.
        days: 1
        # Optional: Mode for retention. Available options are: all, motion, and active_objects
        #   all - save all recording segments regardless of activity
        #   motion - save all recordings segments with any detected motion
        #   active_objects - save all recording segments with active/moving objects
        # NOTE: this mode only applies when the days setting above is greater than 0
        mode: all
    detect:
      enabled: false
      fps: 1
    onvif:
      # Required: host of the camera being connected to.
      host: 192.168.0.14
      # Optional: ONVIF port for device (default: shown below).
      port: 2020
      # Optional: username for login.
      # NOTE: Some devices require admin to access ONVIF.
      user: username
      # Optional: password for login.
      password: mypassword1
      # Optional: PTZ camera object autotracking. Keeps a moving object in
      # the center of the frame by automatically moving the PTZ camera.
      autotracking:
        # Optional: enable/disable object autotracking. (default: shown below)
        enabled: false
        # Optional: list of objects to track from labelmap.txt (default: shown below)
        track:
          - person
        # Required: Begin automatically tracking an object when it enters any of the listed zones.
        #required_zones:
        #  - all
        # Required: Name of ONVIF preset in camera's firmware to return to when tracking is over. (default: shown below)
        return_preset: '3'
        # Optional: Seconds to delay before returning to preset. (default: shown below)

Hello,

This is my configuration.

camara-cocina:
ffmpeg:
inputs:
- path: rtsp://127.0.0.1:8554/camara-cocina
input_args: preset-rtsp-restream
roles:
- record
output_args:
record: preset-record-generic-audio-aac
onvif:
host: 192.168.1.136
port: 2020
user: “usercamera”
password: “r532mtE8camera”

detect:
  enabled: False
record:
  enabled: True
snapshots:
  enabled: False

On the other hand, I have the camera set to 20fps. Sometimes the video runs smoothly, but other times the image becomes choppy or freezes and then suddenly speeds up to catch up to real-time.
This happens both in Frigate and in the Tapo app. The camera is located next to the router, and the RSSI is good (-24dB).

Additionally, Frigate keeps logging errors related to this camera, like the following:

[segment @ 0x62c0ebffcd40] Non-monotonous DTS in output stream 0:0; previous: 3446867, current: 304128; changing to 3446868. This may result in incorrect timestamps in the output file.

Does anything similar happen to you?

I used it with local IP!
Many THX conorlap!
That is the " Magic" nowhere mentioned! :magic_wand: :sunglasses:

1 Like

Here are my full Tapo related settings, have a look at my config and try to copy it to see if your camera works better.

I’ve put my rtsp feed through ffmpeg in go2rtc and specified video copy, audio copy and audio aac for full compatibility with Frigate and Home Assistant. I use ‘input_args: preset-rtsp-restream’ and ‘output_args: preset-record-generic-audio-copy’.

go2rtc:
  streams:
    kitchen_tapo:
      - ffmpeg:rtsp://username:[email protected]/stream1#video=copy#audio=copy#audio=aac
      - tapo://[email protected]
  webrtc:
    candidates:
      - stun:8555
  api:
    origin: '*'


cameras:
  kitchen_tapo:
    ffmpeg:
      retry_interval: 60
      inputs:
        - path: rtsp://127.0.0.1:8554/kitchen_tapo?video=copy&audio=aac
          input_args: preset-rtsp-restream
          roles:
            - record
            - audio
            - detect
    #Audio detection settings:
    audio:
      enabled: true
      listen:
        - bark
        - scream
        - yell
        - glass
        - smash
        - speech
        - fire_alarm
        - smoke_detector
      filters:
        speech:
          threshold: 0.6
        glass:
          threshold: 0.5
        fire_alarm:
          threshold: 0.5
        smoke_detector:
          threshold: 0.5
    snapshots:
      enabled: false
      timestamp: false
    record:
      enabled: true
      retain:
        # Optional: Number of days to retain recordings regardless of events (default: shown below)
        # NOTE: This should be set to 0 and retention should be defined in events section below
        #       if you only want to retain recordings of events.
        days: 1
        # Optional: Mode for retention. Available options are: all, motion, and active_objects
        #   all - save all recording segments regardless of activity
        #   motion - save all recordings segments with any detected motion
        #   active_objects - save all recording segments with active/moving objects
        # NOTE: this mode only applies when the days setting above is greater than 0
        mode: all
    detect:
      enabled: false
      fps: 1
    onvif:
      # Required: host of the camera being connected to.
      host: 192.168.0.14
      # Optional: ONVIF port for device (default: shown below).
      port: 2020
      # Optional: username for login.
      # NOTE: Some devices require admin to access ONVIF.
      user: username
      # Optional: password for login.
      password: password
      # Optional: PTZ camera object autotracking. Keeps a moving object in
      # the center of the frame by automatically moving the PTZ camera.
      autotracking:
        # Optional: enable/disable object autotracking. (default: shown below)
        enabled: false
        # Optional: list of objects to track from labelmap.txt (default: shown below)
        track:
          - person
        # Required: Begin automatically tracking an object when it enters any of the listed zones.
        #required_zones:
        #  - all
        # Required: Name of ONVIF preset in camera's firmware to return to when tracking is over. (default: shown below)
        return_preset: '3'
        # Optional: Seconds to delay before returning to preset. (default: shown below)

ffmpeg:
  hwaccel_args: preset-vaapi #or, depending on your CPU use preset-intel-qsv-h264 / preset-intel-qsv-h265
  output_args:
    record: preset-record-generic-audio-copy

Will u share your frigate.yaml?

It’s something with FW version of the camera.

I bought two camera.

The first one updated to 1.2.2 and it’s not working PTZ.

The second one I desactivad automatic updates and it’s on 1.1.13. It’s working right!
