Related issue:
Hi !
Can i somehow hide this panel? I would only need to clean the zone, because if I press this, a new cleaning will start and my map will be lost (gen1)
Thanks .
Iāve got this running with my Roborock S5 Max. But I have an issue. When I want to clean a specific room and select to make a double run (so 2 instead of the standard 1), it only does it once.
Known issue? Or should I configure something else?
Next to the play button you should have a button to change a number of cleanings, is it broken?
I can change that number. Thatās not the issue. But the robot will only clean once, no matter what that number is.
What integration do you use and whatās your card config?
configuration.yaml
camera:
- platform: xiaomi_cloud_map_extractor
host: !secret xiaomi_vacuum_host
token: !secret xiaomi_vacuum_token
username: !secret xiaomi_cloud_username
password: !secret xiaomi_cloud_password
draw: ['all']
attributes:
- calibration_points
I use the Xiaomi Miio integration
This is the card code:
type: custom:xiaomi-vacuum-map-card
entity: vacuum.roborock_s5_max
vacuum_platform: default
preset_name: Live map
map_source:
camera: camera.xiaomi_cloud_map_extractor
calibration_source:
camera: true
two_finger_pan: true
map_locked: true
template: vacuum_clean_zone
title: Roborock
map_modes:
- template: vacuum_goto
- template: vacuum_clean_zone
- template: vacuum_clean_segment
predefined_selections:
- id: 18
label:
text: Eetkamer
x: 26825
'y': 29450
offset_y: 35
icon:
name: mdi:broom
x: 26825
'y': 29450
- id: 16
label:
text: Woonkamer
x: 32025
'y': 29225
offset_y: 35
icon:
name: mdi:broom
x: 32025
'y': 29225
- id: 19
label:
text: Hal
x: 31475
'y': 34400
offset_y: 35
icon:
name: mdi:broom
x: 31475
'y': 34400
- id: 17
label:
text: Keuken
x: 26975
'y': 34600
offset_y: 35
icon:
name: mdi:broom
x: 26975
'y': 34600
- id: 20
label:
text: Bijkeuken
x: 25875
'y': 36525
offset_y: 35
icon:
name: mdi:broom
x: 25875
'y': 36525
- id: 25
label:
text: Achterkamer
x: 21475
'y': 37650
offset_y: 35
icon:
name: mdi:broom
x: 21475
'y': 37650
- id: 22
label:
text: WC
x: 33125
'y': 36000
offset_y: 35
icon:
name: mdi:broom
x: 33125
'y': 36000
- id: 26
label:
text: Badkamer
x: 25175
'y': 39225
offset_y: 35
icon:
name: mdi:broom
x: 25175
'y': 39225
Can you try manually calling this service and check if everything works?
Iām clueless on how to do that. Iāve never done an automation with homeassistant.
You can do it in dev tools:
service: xiaomi_miio.vacuum_clean_segment
data:
segments: [17,17]
target:
entity_id: vacuum.roborock_s5_max
I came up with this code, which cleans a certain room, but it only does it once. Is the code ok?
Also just found out, that a zoned cleanup works if I select 2x or 3x in your card. But with a room cleanup it only cleans once when I select 2x or 3x.
Ok, so it seems like a problem with your vacuum or HA Miio integration
Looks like it ;).
But how to solve this?
Thank you very much !
I already have a map card created using the xiaomi cloud map extractor.
I also have a 3D floor plan image which I would like to use as my map in a new card.
Iāve been reading through the documentation and have successfully added my image, but Iām having trouble calibrating it.
Using my existing card, Iāve collected the coordinates of the docked position, plus two more āpointsā that I have sent the vacuum to. Iāve then loaded my 3D floor plan image into GIMP and collected the coordinates of those same points in the image.
Iām a bit stuck getting those details into my card yaml. I am getting an error saying āduplicated mapping keyā.
Below is my card yaml:
type: custom:xiaomi-vacuum-map-card
map_source:
image: /local/images/2707-FP-8am.png
calibration_source:
camera: true
calibration_points:
vacuum:
x: 24557
'y': 26471
map:
x: 1115
'y': 714
vacuum:
x: 22571
'y': 29259
map:
x: 969
'y': 487
vacuum:
x: 19150
'y': 29301
map:
x: 687
'y': 474
entity: vacuum.robot_vacuum
vacuum_platform: default
What am I doing wrong?
Do I still need the ācamera: trueā line?
Iām assuming once I get it working I can overlay details such as rooms and paths over my 3D floor plan?
Here you have a fixed config:
type: custom:xiaomi-vacuum-map-card
map_source:
image: /local/images/2707-FP-8am.png
calibration_source:
calibration_points:
- vacuum:
x: 24557
'y': 26471
map:
x: 1115
'y': 714
- vacuum:
x: 22571
'y': 29259
map:
x: 969
'y': 487
- vacuum:
x: 19150
'y': 29301
map:
x: 687
'y': 474
entity: vacuum.robot_vacuum
vacuum_platform: default
Iām assuming once I get it working I can overlay details such as rooms and paths over my 3D floor plan?
Unfortunately thatās not exactly how it works. You can overlay your room controls (outlines, icons), but no live data from your vacuum will be overlayed
Thanks very much. Live data is not essential for me. What a great card!
1 Like
By the way, if your floorplan has perspective distortion you might want to add a fourth calibration point
