Bosch Light Shutter Control II not working after update to 2025.4.3

stylefish · April 20, 2025, 11:20pm

hi,

since the update to 2025.4.3 my bosch shutter control does not work anymore.
its not officially supported, but i’m using this quirk:

gist.github.com

https://gist.github.com/sopelt/26c6fcddc91953d4fa64655c487b24e5

light_shutter_control_ii.py

"""Device handler for Bosch Light/shutter control II (BMCT-SLZ aka RBSH-MMS-ZB-EU)."""
from zigpy.profiles import zha
from zigpy.quirks import CustomCluster, CustomDevice
from zigpy.zcl.clusters.general import Basic, Identify, Ota, PollControl
from zigpy.zcl.clusters.homeautomation import Diagnostic
from zigpy.zcl.clusters.measurement import TemperatureMeasurement
from zigpy.zcl.clusters.security import IasZone

import zigpy.types as t

This file has been truncated. show original

thats also mentioned here:

github.com/zigpy/zha-device-handlers

[Device Support Request] Bosch Light/shutter control II (BMCT-SLZ)

opened 09:42AM - 09 Aug 23 UTC

closed 07:14PM - 25 Nov 24 UTC

sopelt

stale

### Problem description [This device](https://www.bosch-smarthome.com/uk/en/p…roducts/devices/shutter-control/) looks like an interesting choice for roller/shutter control. After pairing it via code (as it needs this route to succeed) it is detected as `RBSH-MMS-ZB-EU`. The issue is that the device has to modes: lights (2 separate relays for switching lights) or shutter (the firmware prevents both relays being switched on at the same time and allows for shutter-specific settings like timings). Without setting this mode both options (a cover and two lights) are detected but seem non-functional. ### Solution description Looking at [this code](https://github.com/Koenkk/zigbee-herdsman-converters/commit/54ce782cdc89c6cdc515285766d28cc2bc35f956) I have a basic idea of what value needs to be written to the manufacturer specific cluster to set the mode I am interested in but I have no experience writing quirks. If someone could point me to a quirk with a similar use case (most stuff looks quite okay out of the box but a man. spec. cluster needs to be mapped to two specific settable values) I would love to see what I manage to get together. ### Device signature <details><summary>Device signature</summary> ```json { "node_descriptor": "NodeDescriptor(logical_type=<LogicalType.Router: 1>, complex_descriptor_available=0, user_descriptor_available=0, reserved=0, aps_flags=0, frequency_band=<FrequencyBand.Freq2400MHz: 8>, mac_capability_flags=<MACCapabilityFlags.FullFunctionDevice|MainsPowered|RxOnWhenIdle|AllocateAddress: 142>, manufacturer_code=4617, maximum_buffer_size=82, maximum_incoming_transfer_size=82, server_mask=11264, maximum_outgoing_transfer_size=82, descriptor_capability_field=<DescriptorCapability.NONE: 0>, *allocate_address=True, *is_alternate_pan_coordinator=False, *is_coordinator=False, *is_end_device=False, *is_full_function_device=True, *is_mains_powered=True, *is_receiver_on_when_idle=True, *is_router=True, *is_security_capable=False)", "endpoints": { "1": { "profile_id": "0x0104", "device_type": "0x0202", "input_clusters": [ "0x0000", "0x0003", "0x0004", "0x0005", "0x0102", "0x0702", "0x0b04", "0x0b05", "0xfca0" ], "output_clusters": [ "0x000a", "0x0019" ] }, "2": { "profile_id": "0x0104", "device_type": "0x0100", "input_clusters": [ "0x0003", "0x0004", "0x0005", "0x0006", "0xfca0" ], "output_clusters": [] }, "3": { "profile_id": "0x0104", "device_type": "0x0100", "input_clusters": [ "0x0003", "0x0004", "0x0005", "0x0006", "0xfca0" ], "output_clusters": [] } }, "manufacturer": "Bosch", "model": "RBSH-MMS-ZB-EU", "class": "zigpy.device.Device" } ``` </details> ### Diagnostic information <details><summary>Diagnostic information</summary> ```json { "home_assistant": { "installation_type": "Home Assistant OS", "version": "2023.8.1", "dev": false, "hassio": true, "virtualenv": false, "python_version": "3.11.4", "docker": true, "arch": "aarch64", "timezone": "Europe/Vienna", "os_name": "Linux", "os_version": "6.1.21-v8", "supervisor": "2023.08.1", "host_os": "Home Assistant OS 10.4", "docker_version": "23.0.6", "chassis": "embedded", "run_as_root": true }, "custom_components": {}, "integration_manifest": { "domain": "zha", "name": "Zigbee Home Automation", "after_dependencies": [ "onboarding", "usb" ], "codeowners": [ "@dmulcahey", "@adminiuga", "@puddly" ], "config_flow": true, "dependencies": [ "file_upload" ], "documentation": "https://www.home-assistant.io/integrations/zha", "iot_class": "local_polling", "loggers": [ "aiosqlite", "bellows", "crccheck", "pure_pcapy3", "zhaquirks", "zigpy", "zigpy_deconz", "zigpy_xbee", "zigpy_zigate", "zigpy_znp" ], "requirements": [ "bellows==0.35.8", "pyserial==3.5", "pyserial-asyncio==0.6", "zha-quirks==0.0.102", "zigpy-deconz==0.21.0", "zigpy==0.56.4", "zigpy-xbee==0.18.1", "zigpy-zigate==0.11.0", "zigpy-znp==0.11.4" ], "usb": [{ "vid": "10C4", "pid": "EA60", "description": "*2652*", "known_devices": [ "slae.sh cc2652rb stick" ] }, { "vid": "1A86", "pid": "55D4", "description": "*sonoff*plus*", "known_devices": [ "sonoff zigbee dongle plus v2" ] }, { "vid": "10C4", "pid": "EA60", "description": "*sonoff*plus*", "known_devices": [ "sonoff zigbee dongle plus" ] }, { "vid": "10C4", "pid": "EA60", "description": "*tubeszb*", "known_devices": [ "TubesZB Coordinator" ] }, { "vid": "1A86", "pid": "7523", "description": "*tubeszb*", "known_devices": [ "TubesZB Coordinator" ] }, { "vid": "1A86", "pid": "7523", "description": "*zigstar*", "known_devices": [ "ZigStar Coordinators" ] }, { "vid": "1CF1", "pid": "0030", "description": "*conbee*", "known_devices": [ "Conbee II" ] }, { "vid": "10C4", "pid": "8A2A", "description": "*zigbee*", "known_devices": [ "Nortek HUSBZB-1" ] }, { "vid": "0403", "pid": "6015", "description": "*zigate*", "known_devices": [ "ZiGate+" ] }, { "vid": "10C4", "pid": "EA60", "description": "*zigate*", "known_devices": [ "ZiGate" ] }, { "vid": "10C4", "pid": "8B34", "description": "*bv 2010/10*", "known_devices": [ "Bitron Video AV2010/10" ] } ], "zeroconf": [{ "type": "_esphomelib._tcp.local.", "name": "tube*" }, { "type": "_zigate-zigbee-gateway._tcp.local.", "name": "*zigate*" }, { "type": "_zigstar_gw._tcp.local.", "name": "*zigstar*" }, { "type": "_slzb-06._tcp.local.", "name": "slzb-06*" } ], "is_built_in": true }, "data": { "ieee": "**REDACTED**", "nwk": 57174, "manufacturer": "Bosch", "model": "RBSH-MMS-ZB-EU", "name": "Bosch RBSH-MMS-ZB-EU", "quirk_applied": false, "quirk_class": "zigpy.device.Device", "manufacturer_code": 4617, "power_source": "Mains", "lqi": 188, "rssi": -53, "last_seen": "2023-08-09T11:27:24", "available": true, "device_type": "Router", "signature": { "node_descriptor": "NodeDescriptor(logical_type=<LogicalType.Router: 1>, complex_descriptor_available=0, user_descriptor_available=0, reserved=0, aps_flags=0, frequency_band=<FrequencyBand.Freq2400MHz: 8>, mac_capability_flags=<MACCapabilityFlags.FullFunctionDevice|MainsPowered|RxOnWhenIdle|AllocateAddress: 142>, manufacturer_code=4617, maximum_buffer_size=82, maximum_incoming_transfer_size=82, server_mask=11264, maximum_outgoing_transfer_size=82, descriptor_capability_field=<DescriptorCapability.NONE: 0>, *allocate_address=True, *is_alternate_pan_coordinator=False, *is_coordinator=False, *is_end_device=False, *is_full_function_device=True, *is_mains_powered=True, *is_receiver_on_when_idle=True, *is_router=True, *is_security_capable=False)", "endpoints": { "1": { "profile_id": "0x0104", "device_type": "0x0202", "input_clusters": [ "0x0000", "0x0003", "0x0004", "0x0005", "0x0102", "0x0702", "0x0b04", "0x0b05", "0xfca0" ], "output_clusters": [ "0x000a", "0x0019" ] }, "2": { "profile_id": "0x0104", "device_type": "0x0100", "input_clusters": [ "0x0003", "0x0004", "0x0005", "0x0006", "0xfca0" ], "output_clusters": [] }, "3": { "profile_id": "0x0104", "device_type": "0x0100", "input_clusters": [ "0x0003", "0x0004", "0x0005", "0x0006", "0xfca0" ], "output_clusters": [] } }, "manufacturer": "Bosch", "model": "RBSH-MMS-ZB-EU" }, "active_coordinator": false, "entities": [{ "entity_id": "light.bosch_rbsh_mms_zb_eu_light", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "light.bosch_rbsh_mms_zb_eu_light_2", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "sensor.bosch_rbsh_mms_zb_eu_power_factor", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "sensor.bosch_rbsh_mms_zb_eu_active_power", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "sensor.bosch_rbsh_mms_zb_eu_instantaneous_demand", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "sensor.bosch_rbsh_mms_zb_eu_summation_delivered", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "cover.bosch_rbsh_mms_zb_eu_cover", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "select.bosch_rbsh_mms_zb_eu_start_up_behavior", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "select.bosch_rbsh_mms_zb_eu_start_up_behavior_2", "name": "Bosch RBSH-MMS-ZB-EU" }, { "entity_id": "button.bosch_rbsh_mms_zb_eu_identify", "name": "Bosch RBSH-MMS-ZB-EU" } ], "neighbors": [ ], "routes": [ ], "endpoint_names": [{ "name": "WINDOW_COVERING_DEVICE" }, { "name": "ON_OFF_LIGHT" }, { "name": "ON_OFF_LIGHT" } ], "user_given_name": null, "device_reg_id": "", "area_id": null, "cluster_details": { "1": { "device_type": { "name": "WINDOW_COVERING_DEVICE", "id": 514 }, "profile_id": 260, "in_clusters": { "0x0000": { "endpoint_attribute": "basic", "attributes": { "0x0009": { "attribute_name": "generic_device_type", "value": 255 }, "0x0004": { "attribute_name": "manufacturer", "value": "Bosch" }, "0x0005": { "attribute_name": "model", "value": "RBSH-MMS-ZB-EU" } }, "unsupported_attributes": {} }, "0x0003": { "endpoint_attribute": "identify", "attributes": {}, "unsupported_attributes": {} }, "0x0004": { "endpoint_attribute": "groups", "attributes": {}, "unsupported_attributes": {} }, "0x0005": { "endpoint_attribute": "scenes", "attributes": {}, "unsupported_attributes": {} }, "0x0102": { "endpoint_attribute": "window_covering", "attributes": { "0x0007": { "attribute_name": "config_status", "value": 3 }, "0x0008": { "attribute_name": "current_position_lift_percentage", "value": 0 }, "0x0009": { "attribute_name": "current_position_tilt_percentage", "value": 0 }, "0x0017": { "attribute_name": "window_covering_mode", "value": 0 } }, "unsupported_attributes": { "0x0015": { "attribute_name": "acceleration_time_lift" } } }, "0x0702": { "endpoint_attribute": "smartenergy_metering", "attributes": { "0x0000": { "attribute_name": "current_summ_delivered", "value": 0 }, "0x0302": { "attribute_name": "divisor", "value": 100 }, "0x0400": { "attribute_name": "instantaneous_demand", "value": 0 }, "0x0306": { "attribute_name": "metering_device_type", "value": 0 }, "0x0301": { "attribute_name": "multiplier", "value": 1 }, "0x0200": { "attribute_name": "status", "value": 0 }, "0x0303": { "attribute_name": "summation_formatting", "value": 42 }, "0x0300": { "attribute_name": "unit_of_measure", "value": 0 } }, "unsupported_attributes": { "0x0100": { "attribute_name": "current_tier1_summ_delivered" }, "0x0102": { "attribute_name": "current_tier2_summ_delivered" }, "0x0104": { "attribute_name": "current_tier3_summ_delivered" }, "0x0304": { "attribute_name": "demand_formatting" }, "0x0106": { "attribute_name": "current_tier4_summ_delivered" }, "0x0108": { "attribute_name": "current_tier5_summ_delivered" }, "0x010a": { "attribute_name": "current_tier6_summ_delivered" } } }, "0x0b04": { "endpoint_attribute": "electrical_measurement", "attributes": { "0x0605": { "attribute_name": "ac_power_divisor", "value": 1 }, "0x0604": { "attribute_name": "ac_power_multiplier", "value": 1 }, "0x050b": { "attribute_name": "active_power", "value": 0 }, "0x0000": { "attribute_name": "measurement_type", "value": 1 } }, "unsupported_attributes": { "0x0300": { "attribute_name": "ac_frequency" }, "0x0601": { "attribute_name": "ac_voltage_divisor" }, "0x0302": { "attribute_name": "ac_frequency_max" }, "0x0603": { "attribute_name": "ac_current_divisor" }, "0x0602": { "attribute_name": "ac_current_multiplier" }, "0x0505": { "attribute_name": "rms_voltage" }, "0x0600": { "attribute_name": "ac_voltage_multiplier" }, "0x0507": { "attribute_name": "rms_voltage_max" }, "0x0508": { "attribute_name": "rms_current" }, "0x050a": { "attribute_name": "rms_current_max" }, "0x0403": { "attribute_name": "power_divisor" }, "0x050d": { "attribute_name": "active_power_max" }, "0x050f": { "attribute_name": "apparent_power" }, "0x0400": { "attribute_name": "ac_frequency_multiplier" }, "0x0401": { "attribute_name": "ac_frequency_divisor" }, "0x0402": { "attribute_name": "power_multiplier" } } }, "0x0b05": { "endpoint_attribute": "diagnostic", "attributes": {}, "unsupported_attributes": {} }, "0xfca0": { "endpoint_attribute": "manufacturer_specific", "attributes": {}, "unsupported_attributes": {} } }, "out_clusters": { "0x000a": { "endpoint_attribute": "time", "attributes": {}, "unsupported_attributes": {} }, "0x0019": { "endpoint_attribute": "ota", "attributes": {}, "unsupported_attributes": {} } } }, "2": { "device_type": { "name": "ON_OFF_LIGHT", "id": 256 }, "profile_id": 260, "in_clusters": { "0x0003": { "endpoint_attribute": "identify", "attributes": {}, "unsupported_attributes": {} }, "0x0004": { "endpoint_attribute": "groups", "attributes": {}, "unsupported_attributes": {} }, "0x0005": { "endpoint_attribute": "scenes", "attributes": {}, "unsupported_attributes": {} }, "0x0006": { "endpoint_attribute": "on_off", "attributes": { "0x0000": { "attribute_name": "on_off", "value": 0 }, "0x4003": { "attribute_name": "start_up_on_off", "value": 0 } }, "unsupported_attributes": {} }, "0xfca0": { "endpoint_attribute": "manufacturer_specific", "attributes": {}, "unsupported_attributes": {} } }, "out_clusters": {} }, "3": { "device_type": { "name": "ON_OFF_LIGHT", "id": 256 }, "profile_id": 260, "in_clusters": { "0x0003": { "endpoint_attribute": "identify", "attributes": {}, "unsupported_attributes": {} }, "0x0004": { "endpoint_attribute": "groups", "attributes": {}, "unsupported_attributes": {} }, "0x0005": { "endpoint_attribute": "scenes", "attributes": {}, "unsupported_attributes": {} }, "0x0006": { "endpoint_attribute": "on_off", "attributes": { "0x0000": { "attribute_name": "on_off", "value": 0 }, "0x4003": { "attribute_name": "start_up_on_off", "value": 0 } }, "unsupported_attributes": {} }, "0xfca0": { "endpoint_attribute": "manufacturer_specific", "attributes": {}, "unsupported_attributes": {} } }, "out_clusters": {} } } } } ``` </details>

after the update the light shutter control II does not work anymore for my shutters, the error given is that “open / close” is not supported by this entity.

i’ve rolled back to 2025.4.2 and it is working again.

any suggestions what to do to keep my HA updated?

greetings

stylefish · April 28, 2025, 9:02am

nobody? issue still persists in 2025.4.4.

the entity does not have the “up/down” functions available:

the device is this:

BMCT-SLZ aka RBSH-MMS-ZB-EU

before the update there were up/down controls available.

any help would be greatly appreciated
