Custom Integration: Linksys Velop

Here’s my first ever integration. I’ve been running it for a while and all seems OK.

Installation can be done be adding the repository to HACS.

More information can be found in the readme on GitHub.

Entities provided

Binary Sensors

  • Mesh: Checking for Updates
  • Mesh: Speedtest state
    • current stage of the Speedtest, e.g. Detecting server, Checking latency
  • Mesh: WAN Status
    • IP, DNS, MAC
  • Node: Status
    • IP, MAC
  • Node: Update Available

Device Trackers

These are selectable and are presented as part of the configuration at both install time and from reconfiguring the integration.

Sensors

  • Mesh: Number of Offline Devices
    • list of device names that are offline
  • Mesh: Number of Online Devices
    • list of device names and IP addresses that are online
  • Mesh: Date of Latest Speedtest
    • Exit code, Latency, Download/Upload bandwidth, Result ID
  • Node: Number of Connected Devices
    • list of device names, IP addresses and adapter types that are connected
  • Node: Current Firmware Version
  • Node: Model Number
  • Node: Parent Name
    • IP address of the parent
  • Node: Serial Number
  • Node: Type of Node, e.g. Primary Secondary

Switches

  • Mesh: Guest Wi-Fi state
    • list of guest networks available
  • Mesh: Parental Control state

Services

Services are available for the following: -

  • Start a Speedtest
  • Initiate a check for firmware updates for the nodes
  • Delete a machine from the device list
2 Likes

I will give this a shot and see. This ‘could’ significantly reduce the size of my binary_sensors.yaml which is mostly ping sensors for devices on my network.

Looking at the README, I assume that primary node address is the ip address in standard xxx.xxx.xxx.xxx, is that correct?

Certainly is. It should be the address of the primary node as well. Whilstvwriting this I fell foul of accidently using a secondary node at one point and found that some of the calls I’m using required the primary - so I’ve made that a requirement now.

Installed it, but getting stumped by this screen.

I’m guessing primary mode address and pass?

You guess correctly. I’ve only seen that happen if the translations aren’t loaded correctly. A forced refresh of the browser normally diets that for me. Looks like you’re using the companion app, so maybe force closing it and reopening might do the trick.

1 Like

Looks good so far.
The ‘Mesh’ entity for location, I’m not sure about. I left it blank for now and put in the locations for the actual nodes.
I’ll work on my view and redoing some of my automations and see how it works.

I haven’t put an area against the mesh device either. The nodes have areas though. To be honest it doesn’t really make a difference for the way I use it either.

I felt like the mesh needed to be a device separate from the nodes mind you as it represents the majority of things that you’d interact with or have info about. I typically only use the nodes for status (to know if one dropped) or if one doesn’t have any connected devices at all.

I’m waiting for Linksys to release another firmware update so I can finalise the sensors for newest version and update available (I had those working with the pyscript integration previously so I know roughly what needs to be done).

Edit: unless you meant the device trackers… In which case, I find that useful in conjunction with the companion app. My phone will drop WiFi and show as not_home according to the consider home timing. The companion app will handle GPS. I was using the companion app and it’s WiFi connection sensor but found that occasionally took a while to update.

I’ve just pushed another update which adds a few more things. Most importantly it adds the ability to detect if a firmware update is required. However, whilst testing this I found that the Velop can sometimes get a little upset and have a node in the mesh that is fully connected, accepting connections, is not the primary but doesn’t report a parent node - in fact it reports that it is connected to parent 0.0.0.0 which clearly isn’t right. I’ve had to fix/workaround that in the underlying library as well.

I’m currently resetting the node in question to see if that brings it back to life.

I still need to update the README (mainly because I forgot) to bring it inline with the changes.

You’ll be pleased to know (or not bothered) that I’ve found what’s caused this. I’ll have it fixed in the next release.

1 Like

That’s brilliant. Well done, and very much appreciated.

Update pushed now. Should be in version 2021.10.2.

1 Like

Thanks for your excellent work. I do appreciate the effort that goes into this.

Thank you so very much!
I joined the Home Assistant world just a month ago (changing from SmartThings). I’ve been trying to get my Linksys AC2200 Smart Mesh Wi-Fi Router to connect. This works great! Even sees the Velop router I have meshed to the main router.
Most Excellent!

Linksys AC2200 Smart Mesh Wi-Fi Router
model: MR8300v1
firmware: 1.1.8.203202

Linksys Velop Mesh Router
model: WHW03Bv2
firmware: 2.1.18.206964

By way of thanks, I’ve opened a pull request to have linksys_velop added to home assistant brands here.

Brilliant. Thank you.

There might be a flurry of updates coming out as I had to do a full reset on the mesh the other day and found a few issues where responses weren’t quite as I expected (they were fine for a system that had been up and running for a while).

Pretty sure there’s nothing breaking though - most of it is guarding against responses being empty or not available.

Good news is that I now have a single node that can be used for testing and reset at will.

1 Like

Just a heads up. I’ve pushed a new release today. The only real things in there are preparing for the HASS 2021.11 release. They shouldn’t break anything mind you so just raise an issue on Github if you spot anything.

This is the new functionality added. Essentially I’ve made all binary sensors and sensors have the diagnostic category.
The Mesh device will also have the configuration_url set so that it’ll link to the primary node.

2 Likes

Another new version…

  • Add entity category for switches
  • Add UPnP Discovery Support
  • Set the API command timeout correctly on setup
  • Prevent duplicate config entries being created

You may have spotted that there’s a couple of big things hiding in there (UPnP support and preventing duplicates). You shouldn’t really notice these but they mean the following…

  1. For those that remove the integration, or are new users, the primary node should now be automatically discovered for you. When you configure you will still need to supply the password, timer details and select your device trackers.
  2. Existing users shouldn’t notice anything re: UPnP.

Switches have now been given the configuration category which should help with the layouts in Lovelace.

For those interested in what happens when adding the integration for new or existing users and when duplicates are prevented, I’ve written up what I’ve tested: -

  • New (manual) = created with unique_id
  • New (SSDP) = primary node automatically populated, created with unique_id
  • Existing (no unique_id, SSDP enabled) = unique_id populated when discovered
  • Existing (no unique_id, no SSDP) = no unique_id
  • Existing (no unique_id, no SSDP, try to add duplicate) = unique_id populated, duplicate aborted
  • Existing (unique_id, try to add duplicate) = duplicate aborted

The unique_id in each case is the serial number of the primary node. This was made more awkward by the fact that I missed adding the unique_id in the initial releases. Hopefully no-one should even notice a difference mind you. This essentially means that if you replace your primary node, then you’ll probably be safer removing the integration and re-adding (unless you fancy manually modifying the YAML file for config entries).

1 Like

Hello
I really liked your Lovelace layout and would like to use it, but when I copy the yaml and paste it in my lovelace I get all kinds of errors. I guess most of them are errors on intendations, but it is hard to see them all with so much code. Is there a way to just copy into the file and it works? I have installed all the cards you have used as well

Hi, whereabouts are you trying to paste the code?

In the editor for raw configuration. I tried pasting it at the end of my file
