Hi everyone, I would like to interface esp32 wRover with an Nvr system and then configure it. In addition to this nvr on home Assistant, can anyone give me some feedback?
What do you want to do with your ESP in relation to your NVR, exactly?
I would like to connect with RTSP protocol to be able to see the images and then use it as a streaming video camera
Still unclear who connects to what and why, but have you seen
1 Like
Esphome does not create an RTSP stream. The thread linked by @koying shows you how to use the esp32 camera with frigate, but RTSP it is not.
To be clear, RTSP it is not for sure, but ESPHome allows to stream MJPEG from, e.g, an ESPcam through
But yeah, unclear whether OP wants to connect an ESP camera to his NVR or …
Hi everyone I managed to make esp32 rover work with the web in HA . But I have a problem with the light saturation that always appears purple.
esphome:
name: esphome-web-f2a12c
friendly_name: esp32camera
min_version: 2024.11.0
name_add_mac_suffix: false
esp32:
board: esp-wrover-kit
framework:
type: arduino
version: recommended
# Enable logging
logger:
# Enable Home Assistant API
api:
# Allow Over-The-Air updates
ota:
- platform: esphome
wifi:
# Set up a wifi access point
ap: {}
ssid: !secret wifi_ssid
password: !secret wifi_password
web_server:
port: 80
esp32_camera:
name: "ESP32 Camera"
external_clock:
pin: GPIO21
frequency: 8MHz
i2c_pins:
sda: GPIO26
scl: GPIO27
data_pins: [GPIO4, GPIO5, GPIO18, GPIO19, GPIO36, GPIO39, GPIO34, GPIO35]
vsync_pin: GPIO25
href_pin: GPIO23
pixel_clock_pin: GPIO22
#brightness: 0 # Regola la luminosità (-2 a 2, 0 è neutro)
#contrast: 0 # Migliora la definizione dell'immagine (-2 a 2)
saturation: 0 # Intensifica i colori (-2 a 2)
# Image Quality
resolution: UXGA
jpeg_quality: 10
agc_gain_ceiling: 16X
wb_mode: CLOUDY # Bilancia per luci artificiali
# aec2: True
# aec_mode: AUTO
# max_framerate: 6 fps
# idle_framerate: 0.1 fps
# wb_mode: home
# agc_gain_ceiling: 8x
# vertical_flip: False
# horizontal_mirror: False
esp32_camera_web_server:
- port: 8080
mode: Stream
- port: 8081
mode: snapshot
switch:
- platform: restart
name: "Riavvia ESP32 camera"
button:
- platform: template
name: "Reboot ESP32 camera"
on_press:
- lambda: ESP.restart();
sensor :
- platform: wifi_signal
name: "ESP32 WiFi Strength"
update_interval: 60s
- platform: uptime
name: Uptime Sensor
There are plenty of variables to try
Perhaps saturation or white balance.
Very good of you to share how you solved it.
1 Like
esphome:
name: esphome-web-f2a12c
friendly_name: esp32camera
min_version: 2024.11.0
name_add_mac_suffix: false
esp32:
board: esp-wrover-kit
framework:
type: arduino
version: recommended
# Enable logging
logger:
# Enable Home Assistant API
api:
# Allow Over-The-Air updates
ota:
- platform: esphome
wifi:
# Set up a wifi access point
ap: {}
ssid: !secret wifi_ssid
password: !secret wifi_password
web_server:
port: 80
esp32_camera:
name: "ESP32 Camera"
external_clock:
pin: GPIO21
frequency: 8MHz
i2c_pins:
sda: GPIO26
scl: GPIO27
data_pins: [GPIO4, GPIO5, GPIO18, GPIO19, GPIO36, GPIO39, GPIO34, GPIO35]
vsync_pin: GPIO25
href_pin: GPIO23
pixel_clock_pin: GPIO22
brightness: 2 # Regola la luminosità (-2 a 2, 0 è neutro)
contrast: 1 # Migliora la definizione dell'immagine (-2 a 2)
saturation: 0 # Intensifica i colori (-2 a 2)
# Image Quality
resolution: SXGA
jpeg_quality: 10
agc_gain_ceiling: 2X
wb_mode: HOME # Bilancia per luci artificiali
# aec2: True
# aec_mode: AUTO
# max_framerate: 6 fps
# idle_framerate: 0.1 fps
# wb_mode: home
# agc_gain_ceiling: 8x
vertical_flip: true
horizontal_mirror: false
esp32_camera_web_server:
- port: 8080
mode: Stream
- port: 8081
mode: snapshot
switch:
- platform: restart
name: "Riavvia ESP32 camera"
button:
- platform: template
name: "Reboot ESP32 camera"
on_press:
- lambda: ESP.restart();
sensor :
- platform: wifi_signal
name: "ESP32 WiFi Strength"
update_interval: 60s
- platform: uptime
name: Uptime Sensor
filters:
- lambda: return x / 3600.0;
unit_of_measurement: "hours"
accuracy_decimals: 2
