virtual_output

An ESPHome output: platform with no pin. Your browser is the buzzer.

Point rtttl: at it instead of esp8266_pwm or ledc, open port 8082 on the
ESP in a browser, and the ringtone plays in a tab — next to a scope showing
exactly what the pin would have been doing. ESP8266 and ESP32. No extra
hardware, no speaker, no wiring.

output:
  - platform: virtual_output
    id: buzzer
    port: 8082

rtttl:
  id: ringtone
  output: buzzer
  gain: 60%

Why

Because a buzzer is a rehearsal you cannot repeat at your desk. You solder,
flash, listen, and start again. This component moves the rehearsal into a
browser tab — and, importantly, it is as unforgiving as the real thing. If
your ESP stutters, this stutters. If gain: 100% is silent on the bench, it is
silent here. A rehearsal that only reproduced the successes would be worth
nothing.

What travels on the wire is not audio. It is a timestamped transition:

[0xAA][flags][ts uint32 LE][freq uint16 LE][duty uint8]   = 9 bytes

Roughly 100 bytes per second at peak. The timestamp is taken on the ESP,
inside update_frequency() / write_state(), before the network can add jitter
to it. The browser replays each transition on the Web Audio sample clock, so
network jitter shifts the whole melody instead of deforming its rhythm.

Install

external_components:
  - source: <repository source>
    components: [virtual_output]
    refresh: 1d

Then browse to your ESP’s address on port 8082.

Configuration

Option Default Notes
id required
port 8082 The only setting this component owns.
inverted false From FLOAT_OUTPUT_SCHEMA.
min_power / max_power From FLOAT_OUTPUT_SCHEMA.
zero_means_zero false From FLOAT_OUTPUT_SCHEMA.

Everything but port comes from the base schema for free, and
FloatOutput::set_level() applies it before write_state() is called. The
browser therefore receives the duty cycle the pin would carry, not the one
rtttl asked for.

An expected compile warning

WARNING Component rtttl is not known to work with the selected output type.

Harmless. rtttl/__init__.py carries a FINAL_VALIDATE_SCHEMA with an
allowlist, PWM_GOOD = ["esp8266_pwm", "ledc"]; anything else warns. Only an
upstream change removes it.

Reading the panel

The heartbeat (10/s, continuously, whether or not music is playing) is the
metronome. Every beat is stamped on the ESP, before the network can touch it,
which lets the panel separate the only two things that can go wrong instead of
blaming whichever is nearer to hand:

Line Means
Beat rate / target Must read 10.0 / 10.0. Any sag is real.
ESP loop worst Largest gap between beats as the ESP lived it. ~110 ms is healthy.
Link jitter Arrival spread minus the ESP’s own period. The network, and nothing else.
ESP repairs A transition overflowed the queue and was dropped. Must stay 0.
Resyncs Abnormal here; the ESP closes on a short write rather than shift a frame.
Late events Play-out shorter than the link jitter. Raise the slider; Margin min says by how much.
Duty / amplitude At gain: 100% you should read 100% / 0% and hear nothing.

“My notes are held too long”

Look at ESP loop worst before anything else. If it reads several hundred
milliseconds, your ESP’s main loop is freezing — a poor WiFi link is the usual
cause on ESP8266. rtttl derives its tempo from that same loop, so it freezes
too and holds the note.

A real buzzer on a GPIO does exactly the same thing. This component is not
adding the fault; it is showing it to you. Fixing it here would mean lying about
what the pin is doing.

Moving to real hardware

Replace the output: block. Nothing else changes — not rtttl:, not gain:,
not your automations:

output:
  - platform: esp8266_pwm     # or: ledc, on ESP32
    id: buzzer
    pin: D5                   # or: GPIO19

Moving to a real speaker (rtttl: speaker:) is not this migration. That is
rtttl’s other mode — 16 kHz PCM instead of a PWM square — and it drops ESP8266.
This component does not cover it.

Design notes

  • No undefined behaviour. output::FloatOutput is a public API, and this
    component owns its own state. Nothing is reached by casting to a class the
    object is not an instance of.
  • One socket path for both targets. ESPHome’s socket component covers
    ESP8266 through its lwip_tcp implementation, so there is no
    WiFiServer / socket::Socket split. The only #ifdef left picks a string for
    the X-Platform header. Note that on lwip_tcp, ListenSocket and Socket
    are distinct types: socket_ip() cannot listen() there.
  • A queue, not a coalesced state. For two identical consecutive notes,
    rtttl inserts a 10 ms gap with a blocking delay() between the two
    set_level() calls, so both land inside one of our loop() passes. Entries
    are fused only when they share a millisecond — which is exactly the
    update_frequency() + set_level() pair, and nothing else.
  • TCP_NODELAY on both sides. Every frame is 9 bytes, so all of them are
    sub-MSS; Nagle would hold each note until the previous ACK returned.
  • The browser is a delayed mirror, so its eyes ride the same delayed clock as
    its ears: the panel and the scope are scheduled at play-out time, not painted
    on arrival.

Browser autoplay

Browsers require a user gesture before audio can start. The page asks at load —
Chrome grants it once this origin’s Media Engagement Index has been crossed, and
Web Audio use feeds that index, so it earns itself with use. Until then, the
LISTEN button (or a click anywhere on the page) opens it. MUTE silences the
ear, not the instrument: the scope keeps scrolling and the panel keeps counting.

License

GPLv3 for the C++, MIT for the Python — ESPHome’s own model. GitHub will show
NOASSERTION; so does esphome/esphome.
