ESPHome Warning ESPTouch November Release

agengr1293 · November 26, 2025, 3:05pm

After compiling for the last couple of times for the November Release of ESPHome, I noticed that I continue to get this warning.

In file included from src/esphome/components/esp32_touch/esp32_touch.h:11,
                 from src/esphome/components/esp32_touch/esp32_touch_common.cpp:3:
/data/cache/platformio/packages/framework-espidf/components/driver/touch_sensor/esp32/include/driver/touch_sensor.h:13:2: warning: #warning "This set of Touch APIs has been deprecated, please include 'driver/touch_sens.h' instead. if you want to keep using the old APIs and ignore this warning, you can enable 'Suppress legacy driver deprecated warning' option under 'Touch Configuration' menu in Kconfig" [-Wcpp]
   13 | #warning "This set of Touch APIs has been deprecated, \
      |  ^~~~~~~
Compiling .pioenvs/f

Any work around on this? Will it get updated automatically?

agengr1293 · November 30, 2025, 2:38pm

Anyone else have this issue?

kcr · December 1, 2025, 3:24pm

Yes, I just encountered this warning while rebuilding a device today.
Also “The legacy RMT driver is deprecated, please use driver/rmt_tx.h and/or driver/rmt_rx.h”

agengr1293 · December 2, 2025, 1:40pm

Does anyone know if this is going to be resolved in future ESPhome updates or is this something manually we need to change?

robertklep · December 2, 2025, 3:15pm

github.com/esphome/esphome

NeoPixelBus generates warning on compile

opened 07:15AM - 19 Jul 25 UTC

closed 07:34AM - 19 Jul 25 UTC

briis

### The problem When compiling my project on ESPHome 2025.7.x it has started to… generate this warning when compiling `The legacy RMT driver is deprecated`. Even though it is only a warning, my project still stops working. ### Which version of ESPHome has the issue? 2025.7.x ### What type of installation are you using? Home Assistant Add-on ### What platform are you using? ESP32 ### Component causing the issue NeoPixelBus Light ### YAML Config ```yaml substitutions: device: "bedroom-clock" name: "Bedroom Clock" version: "1.0.0" data_pin: "GPIO14" # Data PIN for Display rotation_angle: "180°" # Set the rotation of the display. One of 0°, 90°, 180°, 270° font_large: "fonts/MatrixChunky8X.ttf" # 8 Pixel Font font_small: "fonts/MatrixChunky6X.ttf" # 6 Pixel Font weekDaysShort: "Søn,Man,Tir,Ons,Tor,Fre,Lør" # Danish translation for Weekdays temp_entity: "sensor.vindinge_sensor_temperature" # Home Assistant Entity ID for Temperature Sensor condition_entity: "sensor.vindinge_sensor_condition" # Home Assistant Entity ID for Weather Condition Sensor alarm_entity: "alarm_control_panel.alarm_toftebuen" # Home Assistant Entity ID for Alarm Status lock_entity: "lock.bryggersdor" # Home Assistant Entity ID for Lock Status door_entity: "sensor.dore_abne" # Home Assistant Entity ID for number of open doors bed_entity: "binary_sensor.beboere_i_seng" # Home Assistant Entity ID for Bed Status ############################################# ### CORE SETTINGS ### ############################################# esphome: name: "${device}" friendly_name: "${name}" min_version: 2025.6.0 name_add_mac_suffix: False project: name: "briis.${device}" version: "${version}" platformio_options: build_flags: - "-DBOARD_HAS_PSRAM" - "-DARDUINO_USB_CDC_ON_BOOT=1" board_build.arduino.memory_type: qio_opi esp32: board: esp32-s3-devkitc-1 variant: esp32s3 flash_size: 16MB framework: type: arduino psram: mode: octal speed: 80MHz # Enable logging logger: # Enable Home Assistant API api: encryption: key: "d3Js1auGoHGHbdjBSr+7cm8DQNkjekkwea0GmNzV3pA=" ota: - platform: esphome password: "a8eb4a01326f1778f039a6af4338a5bf" wifi: ssid: !secret wifi_iot_ssid password: !secret wifi_iot_password # Enable fallback hotspot (captive portal) in case wifi connection fails ap: ssid: "Bedroom-Clock" password: "12345678" captive_portal: ############################################# ### HARDWARE ### ############################################# display: - platform: addressable_light id: main_display addressable_light_id: main_display_light width: 32 height: 8 pixel_mapper: |- if (x % 2 == 0) { return (x * 8) + y; } return (x * 8) + (7 - y); rotation: ${rotation_angle} update_interval: 500ms lambda: |- id(display_text).execute(); light: - platform: neopixelbus id: main_display_light name: "${name} Light" type: GRB internal: true variant: ws2812 pin: ${data_pin} num_leds: 256 color_correct: [30%, 30%, 30%] gamma_correct: 2.0 restore_mode: ALWAYS_OFF ############################################# ### GENERAL SETTINGS ### ############################################# time: - platform: homeassistant id: device_time ############################################# ### BINARY SENSOR ### ############################################# binary_sensor: - platform: homeassistant entity_id: ${bed_entity} id: bed_sensor disabled_by_default: True trigger_on_initial_state: True ############################################# ### FONTS ### ############################################# font: - file: ${font_large} id: main_font size: 8 glyphs: '!"%()+=,-_.:&°/[]|<>?0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZÆØÅ abcdefghijklmnopqrstuvwxyzæøå' - file: ${font_small} id: small_font size: 6 glyphs: '!"%()+=,-_.:&°/[]|<>?0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZÆØÅ abcdefghijklmnopqrstuvwxyzæøå' ############################################# ### GLOBALS ### ############################################# globals: - id: display_brightness type: float restore_value: true initial_value: '0.4' # 40% brightness - id: night_brightness type: float restore_value: true initial_value: '0.2' # 20% brightness - id: current_page type: int restore_value: False initial_value: '0' - id: scroll_pos type: int restore_value: False initial_value: '0' - id: page_timer type: int restore_value: False initial_value: '0' - id: page_duration type: int restore_value: False initial_value: '20' ############################################# ### IMAGES ### ############################################# image: - file: "images/8x8/lock_locked.png" id: img_locked type: RGB565 resize: 8x8 - file: "images/8x8/lock_unlocked.png" id: img_unlocked type: RGB565 resize: 8x8 - file: "images/8x8/alarm_off.png" id: img_alarm_off type: RGB565 resize: 8x8 - file: "images/8x8/alarm_on.png" id: img_alarm_on type: RGB565 resize: 8x8 - file: "images/8x8/door_closed.png" id: img_door_closed type: RGB565 resize: 8x8 - file: "images/8x8/door_open.png" id: img_door_open type: RGB565 resize: 8x8 - file: "images/8x8/weather_clear_night.png" id: img_weather_clear_night type: RGB565 resize: 8x8 - file: "images/8x8/weather_cloudy.png" id: img_weather_cloudy type: RGB565 resize: 8x8 - file: "images/8x8/weather_fog.png" id: img_weather_fog type: RGB565 resize: 8x8 - file: "images/8x8/weather_hail.png" id: img_weather_hail type: RGB565 resize: 8x8 - file: "images/8x8/weather_lightning_rainy.png" id: img_weather_lightning_rainy type: RGB565 resize: 8x8 - file: "images/8x8/weather_lightning.png" id: img_weather_lightning type: RGB565 resize: 8x8 - file: "images/8x8/weather_partlycloudy_night.png" id: img_weather_partlycloudy_night type: RGB565 resize: 8x8 - file: "images/8x8/weather_partlycloudy.png" id: img_weather_partlycloudy type: RGB565 resize: 8x8 - file: "images/8x8/weather_pouring.png" id: img_weather_pouring type: RGB565 resize: 8x8 - file: "images/8x8/weather_rainy.png" id: img_weather_rainy type: RGB565 resize: 8x8 - file: "images/8x8/weather_snowy.png" id: img_weather_snowy type: RGB565 resize: 8x8 - file: "images/8x8/weather_snowy_rainy.png" id: img_weather_snowy_rainy type: RGB565 resize: 8x8 - file: "images/8x8/weather_sunny.png" id: img_weather_sunny type: RGB565 resize: 8x8 - file: "images/8x8/weather_windy.png" id: img_weather_windy type: RGB565 resize: 8x8 # DIMMED IMAGES - file: "images/8x8/dimmed/lock_locked_dimmed.png" id: img_locked_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/lock_unlocked_dimmed.png" id: img_unlocked_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/alarm_off_dimmed.png" id: img_alarm_off_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/alarm_on_dimmed.png" id: img_alarm_on_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/door_closed_dimmed.png" id: img_door_closed_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/door_open_dimmed.png" id: img_door_open_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_clear_night_dimmed.png" id: img_weather_clear_night_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_cloudy_dimmed.png" id: img_weather_cloudy_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_fog_dimmed.png" id: img_weather_fog_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_hail_dimmed.png" id: img_weather_hail_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_lightning_rainy_dimmed.png" id: img_weather_lightning_rainy_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_lightning_dimmed.png" id: img_weather_lightning_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_partlycloudy_night_dimmed.png" id: img_weather_partlycloudy_night_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_partlycloudy_dimmed.png" id: img_weather_partlycloudy_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_pouring_dimmed.png" id: img_weather_pouring_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_rainy_dimmed.png" id: img_weather_rainy_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_snowy_dimmed.png" id: img_weather_snowy_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_snowy_rainy_dimmed.png" id: img_weather_snowy_rainy_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_sunny_dimmed.png" id: img_weather_sunny_dimmed type: RGB565 resize: 8x8 - file: "images/8x8/dimmed/weather_windy_dimmed.png" id: img_weather_windy_dimmed type: RGB565 resize: 8x8 # DARK IMAGES - file: "images/8x8/dark/lock_locked_dark.png" id: img_locked_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/lock_unlocked_dark.png" id: img_unlocked_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/alarm_off_dark.png" id: img_alarm_off_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/alarm_on_dark.png" id: img_alarm_on_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/door_closed_dark.png" id: img_door_closed_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/door_open_dark.png" id: img_door_open_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_clear_night_dark.png" id: img_weather_clear_night_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_cloudy_dark.png" id: img_weather_cloudy_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_fog_dark.png" id: img_weather_fog_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_hail_dark.png" id: img_weather_hail_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_lightning_rainy_dark.png" id: img_weather_lightning_rainy_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_lightning_dark.png" id: img_weather_lightning_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_partlycloudy_night_dark.png" id: img_weather_partlycloudy_night_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_partlycloudy_dark.png" id: img_weather_partlycloudy_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_pouring_dark.png" id: img_weather_pouring_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_rainy_dark.png" id: img_weather_rainy_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_snowy_dark.png" id: img_weather_snowy_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_snowy_rainy_dark.png" id: img_weather_snowy_rainy_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_sunny_dark.png" id: img_weather_sunny_dark type: RGB565 resize: 8x8 - file: "images/8x8/dark/weather_windy_dark.png" id: img_weather_windy_dark type: RGB565 resize: 8x8 ############################################# ### INTERVAL ACTIONS ### ############################################# interval: - interval: 1s then: - lambda: |- id(page_timer)++; if (id(page_timer) >= id(page_duration)) { id(page_timer) = 0; id(scroll_pos) = 0; // Find next valid page do { id(current_page)++; if (id(current_page) > 5) id(current_page) = 0; // Skip page 1 if show_date is off if (id(current_page) == 1 && !id(show_date).state) { continue; } // Skip page 2 if show_weather is off if (id(current_page) == 2 && !id(show_weather).state) { continue; } // Skip page 3 if show_alarm is off if (id(current_page) == 3 && !id(show_alarm).state) { continue; } // Skip page 4 if show_locks is off if (id(current_page) == 4 && !id(show_locks).state) { continue; } // Skip page 5 if show_doors is off if (id(current_page) == 5 && !id(show_doors).state) { continue; } // Valid page found, break out of loop break; } while (true); // Set page duration based on current page if (id(current_page) == 0) { id(page_duration) = id(clock_duration).state; // Clock page timing } else if (id(current_page) == 1) { id(page_duration) = id(other_duration).state; // Date timing } else if (id(current_page) == 2) { id(page_duration) = id(other_duration).state; // Weather } else if (id(current_page) == 3) { id(page_duration) = id(other_duration).state; // Alarm page timing } else if (id(current_page) == 4) { id(page_duration) = id(other_duration).state; // Lock page timing } else if (id(current_page) == 5) { id(page_duration) = id(other_duration).state; // Door page timing } } - interval: 500ms then: - lambda: |- if (id(current_page) == 1) { id(scroll_pos)++; } ############################################# ### NUMBER ### ############################################# number: - platform: template name: "Brightness (%)" id: brightness_control icon: mdi:brightness-6 unit_of_measurement: "%" optimistic: true min_value: 20.0 max_value: 100.0 step: 5 initial_value: 45 restore_value: true on_value: then: - globals.set: id: display_brightness value: !lambda 'return x/100;' - platform: template name: "Night Brightness (%)" id: night_brightness_control icon: mdi:brightness-4 unit_of_measurement: "%" optimistic: true min_value: 20.0 max_value: 100.0 step: 5 initial_value: 25 restore_value: true on_value: then: - globals.set: id: night_brightness value: !lambda 'return x/100;' - platform: template id: clock_duration name: "Clock Duration (Sec)" icon: mdi:clock-fast min_value: 5 max_value: 60 step: 1 initial_value: 20 restore_value: True optimistic: True - platform: template id: other_duration name: "Other Page Duration (Sec)" icon: mdi:information-variant-box-outline min_value: 5 max_value: 60 step: 1 initial_value: 15 restore_value: True optimistic: True ############################################# ### SCRIPTS ### ############################################# script: ### DISPLAY TEXT ON SCREEN ### - id: display_text then: - lambda: |- // Set Screen Dimensions int s_width = 16; int s_height = 4; int display_width = s_width * 2; int display_height = s_height * 2; // Get current brightness float brightness = id(display_brightness); float n_brightness = id(night_brightness); // Create colors with brightness applied Color red = Color(245 * brightness, 67 * brightness, 54 * brightness); Color green = Color(76 * brightness, 175 * brightness, 80 * brightness); Color blue = Color(32 * brightness, 151 * brightness, 243 * brightness); Color amber = Color(255 * brightness, 193 * brightness, 8 * brightness); Color orange = Color(255 * brightness, 152 * brightness, 0); Color white = Color(240 * brightness, 240 * brightness, 240 * brightness); Color night_red = Color(245 * n_brightness, 67 * n_brightness, 54 * n_brightness); Color night_green = Color(76 * n_brightness, 175 * n_brightness, 80 * n_brightness); // Get Time auto time = id(device_time).now(); // PRINT BEDSTATUS IF ENABLED if (id(show_bed_status).state) { Color status_color = (!id(bed_sensor).state) ? night_green : night_red; if (!id(night_mode).state) { status_color = (!id(bed_sensor).state) ? green : red; } id(main_display).filled_rectangle(31, 0, 1, 2, status_color); id(main_display).filled_rectangle(30, 0, 1, 1, status_color); } // PRINT NIGHTMODE SCREEN AND EXIT LOOP if (time.is_valid() && id(night_mode).state) { char buf[16]; if (time.second % 2 == 0) { snprintf(buf, sizeof(buf), "%02d:%02d", time.hour, time.minute); } else { snprintf(buf, sizeof(buf), "%02d %02d", time.hour, time.minute); } id(main_display).print(s_width, s_height, main_font, night_red, TextAlign::CENTER, buf); return; } // PRINT CLOCK SCREEN if (id(current_page) == 0) { auto time = id(device_time).now(); if (!time.is_valid()) { id(main_display).print(s_width, s_height, main_font, amber, TextAlign::CENTER, "Waiting"); return; } else { // PRINT CLOCK SCREEN WITH DAY if (id(show_weekday).state) { char buf[16]; // Parse weekdays from substitution variable std::string weekdays_str = "${weekDaysShort}"; std::vector<std::string> weekdays_vec; size_t start = 0; size_t end = 0; while ((end = weekdays_str.find(',', start)) != std::string::npos) { weekdays_vec.push_back(weekdays_str.substr(start, end - start)); start = end + 1; } weekdays_vec.push_back(weekdays_str.substr(start)); // Last element // Ensure we have enough weekdays and valid day_of_week if (weekdays_vec.size() >= 7 && time.day_of_week >= 1 && time.day_of_week <= 7) { snprintf(buf, sizeof(buf), "%s", weekdays_vec[time.day_of_week - 1].c_str()); } else { snprintf(buf, sizeof(buf), "??"); } id(main_display).print(0, 0, main_font, white, buf); if (time.second % 2 == 0) { snprintf(buf, sizeof(buf), "%02d:%02d", time.hour, time.minute); } else { snprintf(buf, sizeof(buf), "%02d %02d", time.hour, time.minute); } id(main_display).print(32, 0, main_font, white, TextAlign::RIGHT, buf); // PRINT CLOCK SCREEN WITHOUT DAY } else { char buf[16]; if (time.second % 2 == 0) { snprintf(buf, sizeof(buf), "%02d:%02d", time.hour, time.minute); } else { snprintf(buf, sizeof(buf), "%02d %02d", time.hour, time.minute); } id(main_display).print(s_width, s_height, main_font, white, TextAlign::CENTER, buf); } } // END OF CLOCK SCREEN } else if (id(current_page) == 1) { // PRINT DATE SCREEN char buf[16]; snprintf(buf, sizeof(buf), "%02d-%02d", time.day_of_month, time.month); id(main_display).print(s_width, 0, small_font, white, TextAlign::TOP_CENTER, buf); // PRINT DAY MARKER int current_day = time.day_of_week; if (current_day == 1) current_day = 7; // Convert Sunday (1) to 7 else current_day = current_day - 1; // Convert Mon-Sat (2-7) to 1-6 // Draw 7 rectangles for days of the week for (int day = 1; day <= 7; day++) { int x = (day - 1) * 4 + 2; // Position: 2, 6, 10, 14, 18, 22, 26 int y = 7; // Bottom area of 8-pixel high display Color day_color = (day == current_day) ? orange : blue; id(main_display).filled_rectangle(x, y, 3, 1, day_color); } // END OF DATE SCREEN } else if (id(current_page) == 2) { // PRINT WEATHER SCREEN std::string weather_state = id(weather_condition).state; // Vælg og vis korrekt vejrikon baseret på tilstand og lysstyrke if (weather_state == "clear-night") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_clear_night)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_clear_night_dimmed)); else id(main_display).image(0, 0, id(img_weather_clear_night_dark)); } else if (weather_state == "cloudy") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_cloudy)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_cloudy_dimmed)); else id(main_display).image(0, 0, id(img_weather_cloudy_dark)); } else if (weather_state == "fog") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_fog)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_fog_dimmed)); else id(main_display).image(0, 0, id(img_weather_fog_dark)); } else if (weather_state == "hail") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_hail)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_hail_dimmed)); else id(main_display).image(0, 0, id(img_weather_hail_dark)); } else if (weather_state == "lightning-rainy") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_lightning_rainy)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_lightning_rainy_dimmed)); else id(main_display).image(0, 0, id(img_weather_lightning_rainy_dark)); } else if (weather_state == "lightning") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_lightning)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_lightning_dimmed)); else id(main_display).image(0, 0, id(img_weather_lightning_dark)); } else if (weather_state == "partlycloudy-night") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_partlycloudy_night)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_partlycloudy_night_dimmed)); else id(main_display).image(0, 0, id(img_weather_partlycloudy_night_dark)); } else if (weather_state == "partlycloudy") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_partlycloudy)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_partlycloudy_dimmed)); else id(main_display).image(0, 0, id(img_weather_partlycloudy_dark)); } else if (weather_state == "pouring") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_pouring)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_pouring_dimmed)); else id(main_display).image(0, 0, id(img_weather_pouring_dark)); } else if (weather_state == "rainy") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_rainy)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_rainy_dimmed)); else id(main_display).image(0, 0, id(img_weather_rainy_dark)); } else if (weather_state == "snowy-rainy") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_snowy_rainy)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_snowy_rainy_dimmed)); else id(main_display).image(0, 0, id(img_weather_snowy_rainy_dark)); } else if (weather_state == "snowy") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_snowy)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_snowy_dimmed)); else id(main_display).image(0, 0, id(img_weather_snowy_dark)); } else if (weather_state == "sunny") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_sunny)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_sunny_dimmed)); else id(main_display).image(0, 0, id(img_weather_sunny_dark)); } else if (weather_state == "windy") { if (brightness > 0.7f) id(main_display).image(0, 0, id(img_weather_windy)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_weather_windy_dimmed)); else id(main_display).image(0, 0, id(img_weather_windy_dark)); } else { // Fallback hvis ukendt tilstand id(main_display).print(0, 0, main_font, amber, TextAlign::CENTER, weather_state.c_str()); } char buf[16]; snprintf(buf, sizeof(buf), "%.1f°", id(temp_sensor).state); id(main_display).print(30, s_height, main_font, white ,TextAlign::CENTER_RIGHT, buf); // END OF WEATHER SCREEN } else if (id(current_page) == 3) { // PRINT ALARM SCREEN if (id(alarm_status).state == "disarmed") { if (brightness > 0.7f) id(main_display).image(0,0, id(img_alarm_off)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_alarm_off_dimmed)); else id(main_display).image(0, 0, id(img_alarm_off_dark)); } else { if (brightness > 0.7f) id(main_display).image(0,0, id(img_alarm_on)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_alarm_on_dimmed)); else id(main_display).image(0, 0, id(img_alarm_on_dark)); } id(main_display).print(31, s_height, main_font, white, TextAlign::CENTER_RIGHT, "Alarm"); // END OF ALARM SCREEN } else if (id(current_page) == 4) { // PRINT LOCK SCREEN if (id(lock_status).state == "unlocked") { if (brightness > 0.7f) id(main_display).image(0,0, id(img_unlocked)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_unlocked_dimmed)); else id(main_display).image(0, 0, id(img_unlocked_dark)); id(main_display).print(28, s_height, main_font, white, TextAlign::CENTER_RIGHT, "Ulåst"); } else { if (brightness > 0.7f) id(main_display).image(0,0, id(img_locked)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_locked_dimmed)); else id(main_display).image(0, 0, id(img_locked_dark)); id(main_display).print(28, s_height, main_font, white, TextAlign::CENTER_RIGHT, "Låst"); } // END OF LOCK SCREEN } else if (id(current_page) == 5) { // PRINT DOORS SCREEN if (id(door_sensor).state > 0) { if (brightness > 0.7f) id(main_display).image(0,0, id(img_door_open)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_door_open_dimmed)); else id(main_display).image(0, 0, id(img_door_open_dark)); } else { if (brightness > 0.7f) id(main_display).image(0,0, id(img_door_closed)); else if (brightness > 0.35f) id(main_display).image(0, 0, id(img_door_closed_dimmed)); else id(main_display).image(0, 0, id(img_door_closed_dark)); } id(main_display).print(30, s_height, main_font, white, TextAlign::CENTER_RIGHT, "Døre"); // END OF DOORS SCREEN } ############################################# ### SELECT ### ############################################# select: - platform: template id: operation_mode name: "Operation Mode" icon: mdi:form-dropdown optimistic: true options: - "Day" - "Night" - "Bedtime" initial_option: 'Day' restore_value: True on_value: then: - logger.log: format: "Operation mode changed to: %s" args: ['x.c_str()'] - if: condition: - lambda: 'return id(operation_mode).state == "Day";' then: - lambda: |- id(night_mode).turn_off(); id(show_date).turn_on(); id(show_weather).turn_on(); id(show_locks).turn_off(); id(show_alarm).turn_off(); id(show_doors).turn_off(); id(show_bed_status).turn_off(); - if: condition: - lambda: 'return id(operation_mode).state == "Night";' then: - lambda: |- id(night_mode).turn_on(); id(show_bed_status).turn_on(); - if: condition: - lambda: 'return id(operation_mode).state == "Bedtime";' then: - lambda: |- id(night_mode).turn_off(); id(show_weather).turn_on(); id(show_date).turn_off(); id(show_locks).turn_on(); id(show_alarm).turn_on(); id(show_doors).turn_on(); id(show_bed_status).turn_on(); ############################################# ### SENSORS ### ############################################# sensor: - platform: homeassistant entity_id: ${temp_entity} id: temp_sensor internal: False device_class: temperature state_class: measurement accuracy_decimals: 1 on_value: - logger.log: format: "Temp: %.1f" args: ['id(temp_sensor).state'] - platform: homeassistant entity_id: ${door_entity} id: door_sensor internal: False accuracy_decimals: 0 ############################################# ### SWITCHES ### ############################################# switch: - platform: template id: show_weekday name: "Show Weekday" icon: mdi:calendar-week optimistic: true restore_mode: RESTORE_DEFAULT_ON - platform: template id: show_date name: "Show Date" icon: mdi:calendar-month optimistic: true restore_mode: RESTORE_DEFAULT_ON - platform: template id: night_mode name: "Night Mode" icon: mdi:lightbulb-night optimistic: true restore_mode: RESTORE_DEFAULT_OFF - platform: template id: show_weather name: "Show Weather" icon: mdi:weather-partly-cloudy optimistic: true restore_mode: RESTORE_DEFAULT_ON - platform: template id: show_locks name: "Show Lock Status" icon: mdi:lock-check optimistic: true restore_mode: RESTORE_DEFAULT_OFF - platform: template id: show_alarm name: "Show Alarm Status" icon: mdi:lock-check optimistic: true restore_mode: RESTORE_DEFAULT_OFF - platform: template id: show_doors name: "Show Door Status" icon: mdi:door-closed-lock optimistic: true restore_mode: RESTORE_DEFAULT_OFF - platform: template id: show_bed_status name: "Show Bed Status" icon: mdi:bed optimistic: true restore_mode: RESTORE_DEFAULT_OFF ############################################# ### TEXT SENSOR ### ############################################# text_sensor: - platform: homeassistant entity_id: ${condition_entity} id: weather_condition disabled_by_default: true - platform: homeassistant entity_id: ${alarm_entity} id: alarm_status disabled_by_default: true - platform: homeassistant entity_id: ${lock_entity} id: lock_status disabled_by_default: true ` ``` ### Anything in the logs that might be useful for us? ```txt Here is an extract og the complete log, just picking out the warning messages: INFO ESPHome 2025.7.2 INFO Reading configuration /config/esphome/bedroom-clock.yaml... INFO Detected timezone 'Europe/Copenhagen' INFO Generating C++ source... INFO Compiling app... Processing bedroom-clock (board: esp32-s3-devkitc-1; framework: arduino; platform: https://github.com/pioarduino/platform-espressif32/releases/download/53.03.13/platform-espressif32.zip) -------------------------------------------------------------------------------- HARDWARE: ESP32S3 240MHz, 320KB RAM, 8MB Flash - framework-arduinoespressif32 @ 3.1.3 - framework-arduinoespressif32-libs @ 5.3.0+sha.489d7a2b3a - tool-esptoolpy @ 4.8.6 - tool-mklittlefs @ 3.2.0 - tool-riscv32-esp-elf-gdb @ 14.2.0+20240403 - tool-xtensa-esp-elf-gdb @ 14.2.0+20240403 - toolchain-riscv32-esp @ 13.2.0+20240530 - toolchain-xtensa-esp-elf @ 13.2.0+20240530 Dependency Graph |-- Networking @ 3.1.3 |-- AsyncTCP @ 3.4.5 |-- WiFi @ 3.1.3 |-- FS @ 3.1.3 |-- Update @ 3.1.3 |-- ESPAsyncWebServer @ 3.7.10 |-- ESP32 Async UDP @ 3.1.3 |-- DNSServer @ 3.1.3 |-- ESPmDNS @ 3.1.3 |-- noise-c @ 0.1.10 |-- NeoPixelBus @ 2.8.0 Creating esp32s3 image... Successfully created esp32s3 image. Generating partitions .pioenvs/bedroom-clock/partitions.bin In file included from .piolibdeps/bedroom-clock/NeoPixelBus/src/internal/methods/NeoEsp32RmtMethod.h:49, from .piolibdeps/bedroom-clock/NeoPixelBus/src/internal/NeoMethods.h:59, from .piolibdeps/bedroom-clock/NeoPixelBus/src/NeoPixelBus.h:43, from src/esphome/components/neopixelbus/neopixelbus_light.h:12, from src/esphome.h:59, from src/main.cpp:3: /data/cache/platformio/packages/framework-arduinoespressif32-libs/esp32s3/include/driver/deprecated/driver/rmt.h:18:2: warning: #warning "The legacy RMT driver is deprecated, please use driver/rmt_tx.h and/or driver/rmt_rx.h" [-Wcpp] 18 | #warning "The legacy RMT driver is deprecated, please use driver/rmt_tx.h and/or driver/rmt_rx.h" | ^~~~~~~ Compiling .pioenvs/bedroom-clock/lib6de/NeoPixelBus/internal/animations/NeoPixelAnimator.cpp.o In file included from .piolibdeps/bedroom-clock/NeoPixelBus/src/internal/methods/NeoEsp32RmtMethod.h:49, from .piolibdeps/bedroom-clock/NeoPixelBus/src/internal/NeoMethods.h:59, from .piolibdeps/bedroom-clock/NeoPixelBus/src/NeoPixelBus.h:43, from .piolibdeps/bedroom-clock/NeoPixelBus/src/internal/animations/NeoPixelAnimator.cpp:28: /data/cache/platformio/packages/framework-arduinoespressif32-libs/esp32s3/include/driver/deprecated/driver/rmt.h:18:2: warning: #warning "The legacy RMT driver is deprecated, please use driver/rmt_tx.h and/or driver/rmt_rx.h" [-Wcpp] 18 | #warning "The legacy RMT driver is deprecated, please use driver/rmt_tx.h and/or driver/rmt_rx.h" | ^~~~~~~ In file included from .piolibdeps/bedroom-clock/NeoPixelBus/src/internal/methods/NeoEsp32RmtMethod.h:49, from .piolibdeps/bedroom-clock/NeoPixelBus/src/internal/methods/NeoEsp32RmtMethod.cpp:36: /data/cache/platformio/packages/framework-arduinoespressif32-libs/esp32s3/include/driver/deprecated/driver/rmt.h:18:2: warning: #warning "The legacy RMT driver is deprecated, please use driver/rmt_tx.h and/or driver/rmt_rx.h" [-Wcpp] 18 | #warning "The legacy RMT driver is deprecated, please use driver/rmt_tx.h and/or driver/rmt_rx.h" | ^~~~~~~ ` ``` ### Additional information _No response_

agengr1293 · December 2, 2025, 4:52pm

Appreciate the feedback and yes that is for a light

The version I am getting is dealing with the touch sensor.

Here is my yaml:

binary_sensor:
  - platform: esp32_touch
    name: "Water Sensor Pin15"
    pin: 15
    threshold: 100

robertklep · December 2, 2025, 6:05pm

For now, it’s a warning, but eventually it’ll need to be fixed in the ESPHome code base. You can report it here if you’re up for it, I couldn’t find any existing issues for it.

agengr1293 · December 26, 2025, 5:06pm

Ok now it is at the point where the touch sensor is blocking the update for ESPHOME v2025.12.2 . Can anyone assist?

Here is error:

In file included from src/esphome/components/esp32_touch/esp32_touch.h:11,
                 from src/esphome.h:32,
                 from src/main.cpp:3:
/data/cache/platformio/packages/framework-espidf/components/driver/touch_sensor/esp32/include/driver/touch_sensor.h:13:2: warning: #warning "This set of Touch APIs has been deprecated, please include 'driver/touch_sens.h' instead. if you want to keep using the old APIs and ignore this warning, you can enable 'Suppress legacy driver deprecated warning' option under 'Touch Configuration' menu in Kconfig" [-Wcpp]
   13 | #warning "This set of Touch APIs has been deprecated, \
      |  ^~~~~~~
xtensa-esp-elf-g++: fatal error: Killed signal terminated program cc1plus
compilation terminated.
*** [.pioenvs/aquariumsensor/src/main.cpp.o] Error 1
======================== [FAILED] Took 1037.50 seconds ========================

I have posted it online here:
https://github.com/esphome/esphome/issues/12323

neel-m · December 26, 2025, 5:40pm

The warning is not an error, it is a warning (that at some point in the future will be an error, if not addressed before then).

The error you are seeing is not well described (by the message). It is likely because you are using an underpowered device to do the compilation. What are you running esphome on?

neel-m · December 26, 2025, 5:43pm

agengr1293 · December 26, 2025, 10:57pm

The help forum for ESPHome is saying that it is an error that I am running out of memory. Attempting to shorten the size of my install now.

neel-m · December 26, 2025, 11:39pm

Let me guess, a raspberry pi with only 1MB of RAM?

You can set the compile limit to one core and it will take longer but might actually work.

Or, you can install esphome on a more powerful computer.

agengr1293 · December 28, 2025, 4:06pm

While compiling, I have confirmed
HARDWARE: ESP32 240MHz, 320KB RAM, 4MB Flash

I will try your suggestion this morning.

neel-m · December 28, 2025, 5:22pm

The question was what is the hardware of the machine you are compiling on. You provided the specs of what you are compiling for (the target of the cross compilation).

I have not heard of anyone compiling esp32 code on an esp32 itself. Anything is possible with enough effort, but I certainly wouldn’t want to wait for it to finish.

agengr1293 · December 29, 2025, 11:14pm

Sounds good, I am assuming you are asking what device my home assistant is running off of. I have a home assistant yellow with 2GB of memory. It’s averaging around 1.3 GB of runtime (+/- 70%). I am hoping that is what you are asking for.

IOT7712 · December 29, 2025, 11:20pm

Post the full yaml code you are attempting to compile. Post the compile log. [Formatted for forum purposes </> please]

neel-m · December 29, 2025, 11:56pm

Well that has a CM4 in it, which is better than an rpi 3 (or 2). I found this benchmark

This not bad for its class with a multi core performance of 538.

But, I am using an old 1L size PC that has an Intel i7-9700T. This is a 5+ year old CPU. Its benchmark is here: https://browser.geekbench.com/processors/intel-core-i7-9700t
Its multi-core performance is 5204, almost 10X

This is why I run esphome on it instead of on my HA machine. It is running on a different (even older) PC that is probably still 5X the CM4.

If you want to keep running on the CM4, it is probably a good idea to limit the compile processes using:
compile_process_limit

agengr1293 · December 30, 2025, 3:23pm

I recently installed music assistant and I have a feeling it was bogging performance down. So I have un-installed that app and I am starting to get some of the devices to compile. There is one that I am having issues with that I will continue to work on. It is the one with the touch sensor above.

agengr1293 · December 30, 2025, 4:40pm

Since my system is growing steadily, I am going to upgrade to a Raspberry pi CM5 with 8 GB of memory. It seems to be the best available on the market at the moment for my Raspberry pi yellow. Appreciate your troubleshooting.

neel-m · December 30, 2025, 5:19pm

You might want to read this thread:
https://www.reddit.com/r/homeassistant/comments/15mi4tq/thoughts_on_home_assistant_yellow_vs_other/

The Raspberry Pi is great for things where you need a little bit of compute and more IO, especially GPIO. But, if you need more compute it gets more expensive quickly.

Used mini PCs have a much better cost for things that need more compute and can still have a low cost for power used.

If your major complaint is compiling for esphome, just do that on your PC/Mac and not on your HA machine. When you outgrow the CM4 for HA, move it to a VM or Docker container running on a decent mini PC from a few years ago.
