Floor3D Pro Card – Game Engine Backbone Edition
Your Home Digital Twin for Home Assistant (3D Lovelace Card)
Floor3D Pro Card (source & documentation):
Original concept and vision:
floor3d-cardby @andyHA – with full respect and acknowledgment of the foundational work.
Original card (source & documentation):
https://github.com/adizanni/floor3d-card
Important:
This is not a feature expansion of the original Project.
For feature requests or development inquiries, please contact the original author.
Context
The original floor3d-card works exceptionally well and introduced a powerful idea: a true digital twin inside Home Assistant.
However, as models grow large and entity counts increase, natural performance and lifecycle limits emerge — not due to poor design, but because UI‑driven architectures do not scale like engines.
This Project focuses on scaling and stabilization, not on rewriting the core idea.
Overview
Floor3D Pro Card is a Lovelace card for Home Assistant that enables the creation of a 3D digital twin of a home based on its physical structure, Providing an interactive 3D floor plan. The card represents device and sensor data from Home Assistant through a three-dimensional home model in a visual and interactive manner.
- The card associates Home Assistant entities such as lights, switches, doors, windows, shutters, and sensors with objects within the 3D model, allowing the current state of the home to be observed within a single scene.
- For example, when a room light is turned on, the corresponding area is illuminated in the model; door, window, and shutter objects visually reflect their open–close states, while sensors display their associated states directly within the scene.
Floor3D Pro Card, unlike apProaches based on 2D images or image-based floor plans, builds the scene using real 3D geometry.
This allows the entire home to be monitored and interactively managed through a single 3D scene, particularly in large or multi-story environments.
Technically, the card uses a home model created with 3D modeling tools such as Sweet Home 3D, Rhino, 3ds Max, Blender, SketchUp, and similar software, exported in obj or glb format.
The model is uploaded to Home Assistant and defined through the card configuration.
The 3D scene is generated using a JavaScript-based 3D rendering infrastructure and is synchronized with Home Assistant entity states in real time.
Project Vision
Floor3D Pro Card is part of a future 3-module ecosystem:
- Floor3D Pro Card → 3D Scene Engine
- Overlay Pro Card → UI Overlay Engine
- Scene3D → Full Interactive 3D Dashboard Platform
Built on a Real Game-Engine Backbone
Release 1.5.3-Pro.Faz.0
Shaped by architectural discipline — not just code.
Not a game engine, but engineered to behave like one.
This card implements a deterministic game-engine architecture for both rendering and asset management.
Determinism as the Primary Goal
This isn’t a performance hack — it’s determinism as a foundation.
Deterministic rendering. Deterministic assets. Isolated instances. Stable behavior.
Deterministic Render Scheduler
Floor3D Pro routes every render trigger through a single, predictable scheduler.
This ensures 100 triggers result in only 1 render, eliminating jitter, lag, and random redraws for a consistently smooth experience on any device.
Deterministic Asset Backbone
All models load once, and each card receives its own isolated clone.
This prevents duplicate fetches, parse storms, and UI‑driven chaos, delivering a stable and efficient asset pipeline that behaves like a real game engine.
Deterministic Transactional Editor
All edits stay in a draft state until you intentionally commit them.
This removes rebuild storms, preview resets, and accidental refresh loops, resulting in a clean, predictable editing workflow even in large, complex setups.
Deterministic Engine Core Overview
Detailed explanation in ENGINE.md
Deterministic Correction: (Fix)
Repairs the original behavior through a clean, deterministic game‑engine backbone…
- Overlay is display‑only — must not block clicks on level/zoom controls
- Touchstart listener marked passive — prevents scroll‑blocking violations
- Canvas obscurity logic corrected — animation stops only when a real dialog/overlay is present, not when root containers appear
- Edit-Card preview guard added — unsafe DOM traversal no longer crashes the card
- Raycasting concat pressure eliminated — deterministic rebuild without array growth
- Cover/Index alignment restored — _states and _position now map deterministically, including valid 0 positions
- Editor lifecycle guard added — early render() calls no longer risk undefined-access crashes
- Edit‑Card fallback template enabled — hostile lifecycle states no longer break the editor
- DOM custom‑element isolation added — original and Pro cards can run side‑by‑side without conflict.
- Layout‑timing gap stabilized — model_loaded events could fire while the parent size was still 0×0; rendering is now deferred until valid layout dimensions exist, preventing first‑frame stretch and aspect‑ratio artifacts
Additional Pro Features
Release 1.5.3-Pro.Faz.1
Activation (All Pro features are opt-in and disabled by default.)
Engine Diagnostics (optional)
Pro_log: engine
Feature Skills (optional)
Pro_skill: [level, editor, mobile]
Enables selected Pro skill modules.
level→ Pro Skill:levelkeeps entity‑heavy multi‑floor models fast and responsiveeditor→ Pro Skill:editorstable editing without auto‑commit chaosmobile→ Pro Skill:mobilesmoother experience on tablets/phones
You can enable one or multiple skills:
Pro_skill: level
or
Pro_skill: [level, editor]
To disable all skills (default):
Pro_skill: []
Engine Behavior Tracing
Optional detailed logging for debugging engine behavior.
Allows tracing render scheduling, asset cache and lifecycle decisions without polluting normal logs.
Activation (This feature is opt-in and disabled by default.)
Pro_log: engine
LEVEL-Based Entity Filtering Pro Skill: level
Release 1.5.3-Pro.Faz.1.A
The level skill adds a performance‑focused execution filter for entity‑heavy multi‑floor models.
Each entity defines its level in the YAML configuration, where -1 entities are always active (security, climate, exterior lights, alarms, etc.) and never paused.
All other entities activate only when their YAML‑defined level matches the highest visible floor; non‑matching levels become inactive to reduce update and render load.
Inactive entities stop receiving HA updates, are skipped in render/update cycles, and ignore interactions and service calls, improving responsiveness on large setups without changing what is visually shown.
Activation (This feature is opt-in and disabled by default.)
Pro_skill: level
Usage
# Always-active entity (security, exterior, climate, etc.)
- entity: <your_entity>
object_id: <your_object_id>
level: -1 # always active, never paused
# Floor-specific entity (active only when this floor is visible)
- entity: <your_entity>
object_id: <your_object_id>
level: 3 # active only when floor 3 is the highest visible level
EDITOR‑User Driven Cycle Pro Skill: editor
Release: 1.5.3‑Pro.Faz.1.B
The editor skill replaces Home Assistant’s auto‑saving behavior with a deterministic manual‑commit editing model.
It changes how edits are applied — not what can be edited — and affects only the visual editor UI (not YAML).
When enabled, all edits stay local:
no auto‑commit, no preview‑triggered commits, no lifecycle commits, no debounce, no background updates, no config-changed spam.
Editing becomes free, but applying changes becomes intentional.
A dedicated Commit Changes button appears and becomes the only valid way to save configuration updates.
One click = one deterministic commit, enforcing a clean draft → commit → apply workflow.
This prevents preview rebuild storms, model reload loops, editor flicker, accidental partial saves, and keeps editing responsive on weaker devices.
All changes remain local until manually committed.
Activation (This feature is opt-in and disabled by default.)
Pro_skill: editor
Mobile-Optimized Runtime Profile Pro Skill: mobile
Release: 1.5.3‑Pro.Faz.1.C
The mobile skill enables a dedicated renderer profile optimized for tablets, phones, and other low‑power devices.
It does not change the UI; it simply activates a lighter, deterministic render‑cost tier that improves smoothness, responsiveness, thermal balance, and stability on heavy models.
When enabled, the renderer switches to mobile‑friendly settings:
- Pixel ratio clamp → forces
pixelRatio = 1to reduce GPU load - Shadow tier reduction → uses
BasicShadowMapinstead of PCF soft shadows - Antialias control → disables expensive multisample antialiasing
These adjustments apply only to rendering.
Mobile mode does not modify entity logic, interactions, editor behavior, UI layout, or logging features.
Desktop behavior remains unchanged when the skill is disabled.
Activation (This feature is opt-in and disabled by default.)
Pro_skill: mobile
From this point onward, the content is sourced from the original
floor3d-cardby @andyHA and has been adapted, condensed, and reformatted for this documentation.
3D Model Preparation
Recommended Workflow (Easy Method)
- Sweet Home 3D is recommended because it Provides the simplest workflow for designing your home model with furniture and objects.
- After modeling, export using the ExportToHASS plugin (original author @andyHA):
https://github.com/adizanni/ExportToHASS - This plugin generates an OBJ model with correct object groups for the Floor3D card.
Use GLB Instead of OBJ
- OBJ exports create many files and are often large in size.
- GLB is faster, lighter, and more efficient for the card.
To convert OBJ → GLB, install Node.js and run:
npm install -g obj2gltf
obj2gltf -i home.obj -o home.glb --checkTransparency
To optimize your GLB using Draco compression, install Node.js and run:
npm install -g gltf-pipeline
gltf-pipeline -i home.glb -o home_compressed.glb --dracoCompression
Copy the resulting .glb file into your Home Assistant /config/www/community/floor3dPro-card/ folder.
Advanced Workflow (Professional Tools: Rhino, 3ds Max, Blender, SketchUp)
- The card can support models created in Sweet Home 3D, Rhino, 3ds Max, Blender, SketchUp, and similar tools, exported as OBJ or GLB.
Importing OBJ for Editing
When importing the OBJ generated by ExportToHASS into a Professional 3D tool:
- Import OBJ groups as: layers
- Import OBJ objects as: none / nothing
This preserves the grouping logic required by the Floor3D card.
Exporting Back to OBJ
When exporting your edited model back to OBJ:
- Do NOT export object names
- Export layers as OBJ groups
This ensures compatibility with the card’s object‑group structure.
Critical Rule: Layer = Object Group
- Every layer must have a unique name.
- Professional 3D tools treat layers the same way Sweet Home 3D treats object groups.
Example Mapping
- SweetHome3D OBJ:
Group (door) → wing + frame + handle
g lvl001Door_1 - Professional App:
Layer (door) → wing + frame + handle
Layer lvl001Door_1
Level Naming Convention (original author’s format)
Use layer names like:
lvl000Flowers_18_3lvl001...lvl002...
These represent floors/levels, and if you don’t follow this naming convention, the level buttons will not work.
When exporting, layer names become OBJ groups.
Key Principle: OBJ group = layer
This is the shared logic across all Professional 3D modeling applications.
Installation
Method 1: HACS (Recommended)
- Open HACS in Home Assistant.
- Search for: Floor3D Pro Card.
- Select the repository and click Download.
- Restart Home Assistant.
After installation, HACS will automatically register the card as a Lovelace resource.
Method 2: Manual Installation
-
Download the latest
floor3dpro-card.jsfrom the Releases page:
https://github.com/levonisyas/floor3dpro-card/releases -
Place the file in:
/config/www/community/floor3dpro-card/ -
Add it as a Lovelace resource:
resources:
- url: /local/community/floor3dpro-card/floor3dpro-card.js
type: module
Notes
- No custom repository setup is required anymore, since Floor3D Pro is now included in the official HACS Default Repository Store.
- Manual installation is only recommended for advanced or offline setups.
Build Chain Floor3D Pro Card
Supported / Verified Environment
- OS: Windows
- Node.js: v16.20.2
- npm: 8.19.4
Locked Tool Versions (Stable Build)
These versions are confirmed to build successfully:
- TypeScript: 4.3.5
- Rollup: 2.62.0 (2.62.x)
- rollup‑plugin‑typescript2 (rpt2): 0.30.0
- tslib: 2.6.2 (TS helper — resolves
tslib cannot be founderrors)
Configuration
north
north defines the north direction on the X‑Z plane.
For example, {x: 0, z: 1} (the default) represents north pointing in the positive Z direction.
Used together with sky: yes for correct orientation.
north:
x: 0
z: -1
Camera Rotation, Camera Position and Camera Direction
In edit mode, double‑clicking on an empty area of the model retrieves the current camera position and rotation. A Prompt box appears showing two sets of coordinates, which you can copy and paste into the card configuration in code editor mode. This allows you to manually define the new default camera position.
camera_position:
x: 609.3072605703628
"y": 905.5330092468828
z: 376.66437610591277
camera_rotate:
x: -1.0930244719682243
"y": 0.5200808414019678
z: 0.7648717152512469
camera_target:
x: 37.36890424945437
"y": 18.64464320782064
z: -82.55051697031719
3D Model
| 3D Model | Description |
|---|---|
| Name | Defines the name assigned to the 3D model. |
| Path | Specifies the directory path where the 3D model files are located. |
| Obj / Glb file | Defines the 3D model file to be used (.glb or .obj). |
| Mtl Wavefront file | Specifies the .mtl material file required for .obj models. |
| Object list JSON | Defines the JSON file mapping model objects to HA entities. |
Appearance
| Appearance | Description |
|---|---|
| Style | Defines the general style applied to the card’s canvas element. |
| Lock Camera | Locks camera zoom/rotation when set to yes. |
| Selection Mode | Enables object selection mode for console listing. |
| Edit Mode PopUp | Enables popup notifications in edit mode. |
| Header | Defines whether the card header is displayed. |
| Click | Enables single‑click interaction. |
| Overlay | Enables the overlay panel for object‑related data. |
| Background Color | Defines the canvas background color. |
| Hide Levels Menu | Hides the level selection menu. |
| Global Scene Light | Defines global light intensity (0…1). |
| Shadow | Enables shadow casting for lights. |
| + Lights - Perf | Enables extra‑light performance mode. |
| Show Axes | Displays 3D axes in the scene. |
| Sky | Enables sky, ground, and sun environment. |
Overlay and Action
When you enable overlay in the card’s Appearance settings, additional customization options appear, such as alignment, size, fonts, and colors. This creates a panel displayed on top of the model canvas. You must also enable the click option for it to function. Each entity has an action parameter that defines what happens when its associated object is clicked. If action is set to “overlay,” clicking the object displays the entity’s name and state inside the overlay panel.
Entities
| Entity | Description |
|---|---|
| Entity | Defines the Home Assistant entity to attach to the card, using either a direct entity_id or an object_group reference (not applicable for text and gesture). |
| Type & Object | Defines the binding between the entity and the 3D object, specifying the object_id of the model element to link with the entity. |
| Template | Defines a dynamic JavaScript template in the format [[[ template ]]] that reacts to the entity’s state using variables such as $entity. |
| Action | Defines the on‑click behavior for the entity, supporting ‘more-info’, ‘overlay’, or ‘default’ actions. |
| 3D Type | Defines how the entity is represented in the 3D scene, using types such as light, hide, color, text, gesture, door, or rotate. |
| Object | Specifies the object_id of the 3D model element that the entity will be bound to. |
3D Type — Light
Light behavior is straightforward: the light object illuminates when the linked Home Assistant entity is turned on, and turns off when the entity is off. If the light entity has color or brightness attributes, they are used to render the light. Double‑clicking the light object toggles it.
| Light options | Description |
|---|---|
| Lumens | Defines the light’s brightness level (0–5000), with typical LED and bulb sources reaching up to 4000 lumens. |
| Color | Defines the emitted light color; ignored if the light entity Provides its own color/temperature attributes. |
| Decay | Controls how quickly the light intensity decreases over distance (0–2 typical). |
| Distance | Sets the maximum effective range of the light in centimeters. |
| Shadow | Determines whether the light casts shadows. |
| Target Object | Specifies the target object for spot lights. |
| Angle | Defines the beam angle of the spot light in degrees. |
| Vertical Alignment | Controls vertical alignment: top, middle, bottom. |
| Direction | Defines the direction vector of a spotlight using x, y, z coordinates. |
3D Type — Color
The object is painted with the defined color when the state of the linked entity matches the specified value.
| Color condition | Description |
|---|---|
| Color | Defines the color to apply (Hex, HTML, RGB). |
| State | Defines the entity state in which the color is applied. |
3D Type — Room
A parallelepiped is drawn to highlight the room. Works with all room objects whose names contain “room.” Non‑rectangular rooms are simplified. Supports color condition.
| Room options | Description |
|---|---|
| Transparency % | Defines the room’s transparency level. |
| Color | Defines the base color of the room. |
| Elevation (cm) | Sets the vertical position of the room. |
| Label | Controls label visibility. |
| Label text | Defines the text displayed on the label. |
| Label Width | Label width in scaled cm. |
| Label Height | Label height in scaled cm. |
| Attribute | Optional entity attribute to display. |
| Font | Font used for the label text. |
| Span percentage | Percentage of the plane the label spans. |
| Text Background Color | Background color of the label text. |
| Text Foreground Color | Foreground (text) color. |
| Color (Condition) | Color applied when condition is met. |
| State (Condition) | Entity state that triggers the conditional color. |
3D Type — Hide
The object is hidden when the entity matches the specified state.
| Hide options | Description |
|---|---|
| State | Defines the entity state that hides object. |
3D Type — Show
The object becomes visible when the entity matches the specified state.
| Show options | Description |
|---|---|
| State | Defines the entity state that shows object. |
3D Type — Text
The object displays the entity’s state text.
| Text options | Description |
|---|---|
| Transparency % | Defines transparency level. |
| Color | Defines base color. |
| Elevation (cm) | Vertical position. |
| Label | Label visibility. |
| Label text | Text displayed. |
| Label Width | Width in scaled cm. |
| Label Height | Height in scaled cm. |
| Attribute | Attribute used for text. |
| Font | Font used. |
| Span percentage | Percentage of plane used. |
| Text Background Color | Background color. |
| Text Foreground Color | Text color. |
| Color (Condition) | Conditional color. |
| State (Condition) | State that triggers conditional color. |
3D Type — Door
A door or window rotates or slides depending on type.
| Door options | Description |
|---|---|
| Door Type | Movement type: swing or slide. |
| Side | Hinge or sliding side. |
| Direction | Opening direction: inner or outer. |
| Degrees | Max opening angle (swing). |
| Percentage open | Opening percentage (slide). |
| Pane object | Moving pane object_id. |
| Hinge object | Hinge object_id. |
3D Type — Cover
| Cover options | Description |
|---|---|
| Pane object | Moving cover component. |
| Side | Opening direction: up or down. |
3D Type — Rotate
The object rotates when the entity is “on.”
| Rotate options | Description |
|---|---|
| Axis | Rotation axis: x, y, z. |
| Hinge-pivot object | Pivot object for grouped rotation. |
| Rounds per second | Rotation speed (negative reverses). |
3D Type — Gesture
Double‑click triggers a domain.service call.
| Gesture options | Description |
|---|---|
| Domain | Home Assistant service domain. |
| Service | Specific service to execute. |
3D Type — Camera
Double‑clicking opens a pop‑up showing the camera view.
Object Groups
| Object Groups | Description |
|---|---|
| Object Group | Name of the group. |
| Objects | List of 3D objects in the group. |
| Object Id | object_id of each object. |
Zoom Areas
| Zoom Areas | Description |
|---|---|
| Zoom | Name of the zoom area. |
| Object | Target 3D object. |
| Distance (cm) | Camera distance during zoom. |
