Frient Electricity Meter Interface2 (EMIZB-141)

Hi HA community,

in my setup ZHA is running with the Conbee II. I managed to pair the device well and a power sensor is created. But the values are completely wrong because my electricity meter works with 10000 imp/kWh. And I can not find the value pulse configuration unfortunately.

Does anyone know how to change the pulse rate?

      "manufacturer": "frient A/S",
      "model": "EMIZB-141"
    },
    "active_coordinator": false,
    "entities": [
      {
        "entity_id": "sensor.powermeter1_battery",
        "name": "frient A/S EMIZB-141"
      },
      {
        "entity_id": "button.powermeter1_identify",
        "name": "frient A/S EMIZB-141"
      },
      {
        "entity_id": "sensor.powermeter1_instantaneous_demand",
        "name": "frient A/S EMIZB-141"
      },
      {
        "entity_id": "sensor.powermeter1_summation_delivered",
        "name": "frient A/S EMIZB-141"
      },
      {
        "entity_id": "switch.powermeter1_switch",
        "name": "frient A/S EMIZB-141"
      }
    ],
    "neighbors": [],
    "routes": [],
    "endpoint_names": [
      {
        "name": "unknown 1 device_type of 0xc0c9 profile id"
      },
      {
        "name": "METER_INTERFACE"
      }
    ],
    "user_given_name": "Powermeter1",
    "device_reg_id": "*******************6088",
    "area_id": "keller",
    "cluster_details": {
      "1": {
        "device_type": {
          "name": "unknown",
          "id": 1
        },
        "profile_id": 49353,
        "in_clusters": {
          "0x0005": {
            "endpoint_attribute": "scenes",
            "attributes": {},
            "unsupported_attributes": {}
          },
          "0x0006": {
            "endpoint_attribute": "on_off",
            "attributes": {},
            "unsupported_attributes": {}
          }
        },
        "out_clusters": {}
      },
      "2": {
        "device_type": {
          "name": "METER_INTERFACE",
          "id": 83
        },
        "profile_id": 260,
        "in_clusters": {
          "0x0000": {
            "endpoint_attribute": "basic",
            "attributes": {
              "0x0004": {
                "attribute_name": "manufacturer",
                "value": "frient A/S"
              },
              "0x0005": {
                "attribute_name": "model",
                "value": "EMIZB-141"
              }
            },
            "unsupported_attributes": {}
          },
          "0x0001": {
            "endpoint_attribute": "power",
            "attributes": {
              "0x003e": {
                "attribute_name": "battery_alarm_state",
                "value": 0
              },
              "0x0021": {
                "attribute_name": "battery_percentage_remaining",
                "value": 200
              },
              "0x0033": {
                "attribute_name": "battery_quantity",
                "value": 2
              },
              "0x0031": {
                "attribute_name": "battery_size",
                "value": 3
              },
              "0x0020": {
                "attribute_name": "battery_voltage",
                "value": 30
              }
            },
            "unsupported_attributes": {}
          },
          "0x0003": {
            "endpoint_attribute": "identify",
            "attributes": {},
            "unsupported_attributes": {}
          },
          "0x0020": {
            "endpoint_attribute": "poll_control",
            "attributes": {
              "0x0000": {
                "attribute_name": "checkin_interval",
                "value": 13200
              }
            },
            "unsupported_attributes": {}
          },
          "0x0702": {
            "endpoint_attribute": "smartenergy_metering",
            "attributes": {
              "0x0000": {
                "attribute_name": "current_summ_delivered",
                "value": 90956
              },
              "0x0304": {
                "attribute_name": "demand_formatting",
                "value": 248
              },
              "0x0302": {
                "attribute_name": "divisor",
                "value": 1000
              },
              "0x0400": {
                "attribute_name": "instantaneous_demand",
                "value": 4826
              },
              "0x0306": {
                "attribute_name": "metering_device_type",
                "value": 0
              },
              "0x0301": {
                "attribute_name": "multiplier",
                "value": 1
              },
              "0x0200": {
                "attribute_name": "status",
                "value": 0
              },
              "0x0303": {
                "attribute_name": "summation_formatting",
                "value": 248
              },
              "0x0300": {
                "attribute_name": "unit_of_measure",
                "value": 0
              }
            },
            "unsupported_attributes": {
              "0x0100": {
                "attribute_name": "current_tier1_summ_delivered"
              },
              "0x0102": {
                "attribute_name": "current_tier2_summ_delivered"
              },
              "0x0104": {
                "attribute_name": "current_tier3_summ_delivered"
              },
              "0x0106": {
                "attribute_name": "current_tier4_summ_delivered"
              },
              "0x0108": {
                "attribute_name": "current_tier5_summ_delivered"
              },
              "0x010a": {
                "attribute_name": "current_tier6_summ_delivered"
              }
            }
          },
          "0x0b01": {
            "endpoint_attribute": "meter_id",
            "attributes": {},
            "unsupported_attributes": {}
          },
          "0x0b05": {
            "endpoint_attribute": "diagnostic",
            "attributes": {},
            "unsupported_attributes": {}
          }
        },
        "out_clusters": {
          "0x0003": {
            "endpoint_attribute": "identify",
            "attributes": {},
            "unsupported_attributes": {}
          },
          "0x000a": {
            "endpoint_attribute": "time",
            "attributes": {},
            "unsupported_attributes": {}
          },
          "0x0019": {
            "endpoint_attribute": "ota",
            "attributes": {},
            "unsupported_attributes": {}
          }
        }
      }
    }
  }
}
{
  "node_descriptor": "NodeDescriptor(logical_type=<LogicalType.EndDevice: 2>, complex_descriptor_available=0, user_descriptor_available=0, reserved=0, aps_flags=0, frequency_band=<FrequencyBand.Freq2400MHz: 8>, mac_capability_flags=<MACCapabilityFlags.AllocateAddress: 128>, manufacturer_code=4117, maximum_buffer_size=82, maximum_incoming_transfer_size=1500, server_mask=11264, maximum_outgoing_transfer_size=1500, descriptor_capability_field=<DescriptorCapability.NONE: 0>, *allocate_address=True, *is_alternate_pan_coordinator=False, *is_coordinator=False, *is_end_device=True, *is_full_function_device=False, *is_mains_powered=False, *is_receiver_on_when_idle=False, *is_router=False, *is_security_capable=False)",
  "endpoints": {
    "1": {
      "profile_id": "0xc0c9",
      "device_type": "0x0001",
      "input_clusters": [
        "0x0005",
        "0x0006"
      ],
      "output_clusters": []
    },
    "2": {
      "profile_id": "0x0104",
      "device_type": "0x0053",
      "input_clusters": [
        "0x0000",
        "0x0001",
        "0x0003",
        "0x0020",
        "0x0702",
        "0x0b01",
        "0x0b05"
      ],
      "output_clusters": [
        "0x0003",
        "0x000a",
        "0x0019"
      ]
    }
  },
  "manufacturer": "frient A/S",
  "model": "EMIZB-141",
  "class": "zigpy.device.Device"
}

https://www.develcoproducts.com/media/5110/emizb-141-technical-manual.pdf

Mine is working correctly (1000 pulses pr. kWh). But I had a look around, and if you go to Manage Zigbee Device, select “Clusters”, then “Metering” in the first drop-down, there’s an attribute called “divisor”. It’s 1000 on mine. It seems you can change it there.

thank you for your support but unfortunately i already tried that and i can’t change the attribute. if i set the value to 10000 it returns to 1000 after reopening to check the value.

I have found the following detailed data sheet: https://www.develcoproducts.com/media/5110/emizb-141-technical-manual.pdf. According to this data sheet, the pulse configuration is done in manufacturer specific attributes.

With zha_toolkit, I managed to read and edit the pulse configuration.

read:

service: zha_toolkit.attr_read
data:
  ieee: <your address>
  cluster: 0x0702
  attribute: 0x0300
  manf: 0x1015

write (to 500):

service: zha_toolkit.attr_write
data:
  ieee: <your address>
  cluster: 0x0702
  attribute: 0x0300
  attr_type: 0x21
  manf: 0x1015
  attr_val: 500

But now the meter is always sending 0 as instantaneous demand…

The solution I settled for is to have some template sensors which calculate the correct values. I have to multiply by two, since I get 500 pulses/kWh. This sensors can then be integrated into energy dashboard and wherever else you want to have it.

Adapt and add to your configuration.yaml

template:
  - sensor:
    - name: "Instantaneous demand fixed"
      state_class: "measurement"
      device_class: "power"
      unit_of_measurement: "W"
      state: "{{ states('sensor.original_power_meter_instantaneous_demand')|float * 2 }}"
      availability: "{{ is_number(states('sensor.original_power_meter_instantaneous_demand')) }}"
  - sensor:
    - name: "Summation fixed"
      device_class: "energy"
      state_class: "total_increasing"
      unit_of_measurement: "kWh"
      state: "{{ states('sensor.original_power_meter_summation_delivered')|float * 2 }}"
      availability: "{{ is_number(states('sensor.original_power_meter_summation_delivered')) }}"

2 Likes

I’m not the original poster, but I used the template above with minor changes and IT WORKS!
I’m very glad I can now track my consumption even though my meter LED is 10000 imp/kWh.
THANK YOU @charno.
Here’s the final code:

template:
  - sensor:
    - name: "Instantaneous demand fixed"
      unique_id: "ydwRwMattmg"
      state_class: "measurement"
      device_class: "power"
      unit_of_measurement: "W"
      state: "{{ states('sensor.frient_a_s_emizb_141_instantaneous_demand')|float / 10 }}"
      availability: "{{ is_number(states('sensor.frient_a_s_emizb_141_instantaneous_demand')) }}"
  - sensor:
    - name: "Summation fixed"
      unique_id: "aByI8S9eMlU"
      device_class: "energy"
      state_class: "total_increasing"
      unit_of_measurement: "kWh"
      state: "{{ states('sensor.frient_a_s_emizb_141_summation_delivered')|float / 10 }}"
      availability: "{{ is_number(states('sensor.frient_a_s_emizb_141_summation_delivered')) }}"

2 Likes

Hope I’m not necroposting here but if anyone’s interested in setting the appropriate pulse rate parameter you can do so using the services provided by zha_toolkit:

For example, to write the Pulse Configuration option:

service: zha_toolkit.attr_write
data:
  ieee: ZIGBEE_IEEE_ADDRESS_HERE
  manf: 4117
  endpoint: 2
  cluster: 1794
  attribute: 768
  attr_val: "4000"

Unfortunately this didn’t work, it messed up my data :frowning: I am getting only 1.00, 2.00,etc on Instantaneous demand.
Does anyone have setup 10 000 pulses running on ZHA?

Yes, I was able to set the pluse correctly as described with zha_toolkit. But at first my instantaneous wattage sensor showed only 0 and my total_increasing where skyrocketing by 2000+ kwh. I then went back to the ZHA integration and read the attributes once more from there, no luck. Finally a wrote the divisor again with zha_toolkit and restarted home assistant and took the batteries out of the frient and after that it shows now me correct values:

But if I read the divisor attribute again over zha integration it still shows “1000”. On the other hand on the zha_toolkit it its displayed correctly:

zha_toolkit_version: v1.1.8
zigpy_version: 0.62.3
zigpy_rf_version: 0.38.0
ieee_org: sensor.stromzahler_zusammenfassung_geliefert
ieee: 00:15:bc:XX:XX:XX:XX:X
command: attr_read
command_data: null
start_time: "2024-02-13T09:23:57.475612+00:00"
errors: []
params:
  endpoint_id: 2
  cluster_id: 1794
  attr_id: 768
  dir: 0
  manf: 4117
  tries: 1
  expect_reply: true
  args: []
  read_before_write: true
  read_after_write: true
attr_type: "0x21"
write_is_equal: false
result_read:
  - "768": 10000
  - {}
success: true

But for me its reboot safe and stable so far.

Hi Tim,
maybe you have a few more helpful ideas for me?
I have done everything as described above, unfortunately without success.
Now it says 0 all the time

service: zha_toolkit.attr_read
data:
  ieee: xx:xx:xx
  cluster: 0x0702
  attribute: 0x0300
  manf: 0x1015
</>
</>
zha_toolkit_version: v1.1.10
zigpy_version: 0.63.5
zigpy_rf_version: 0.12.1
ieee_org:
  - 183
  - 7
  - 16
  - 27
  - 0
  - 188
  - 21
  - 0
ieee: xx:xx:xx
command: attr_read
command_data: null
start_time: "2024-04-04T18:49:19.237413+00:00"
errors: []
params:
  cluster_id: 1794
  attr_id: 768
  dir: 0
  manf: 4117
  tries: 1
  expect_reply: true
  args: []
  read_before_write: true
  read_after_write: true
attr_type: "0x21"
write_is_equal: false
result_read:
  - "768": 10000
  - {}
success: true

Hello, so your ZHA Integration shows still 1000, but it gives you the correct value anyways, after you changed it to 10000 with zha_toolkit?

I’m planning to buy this device, but I need a working solution for the described issue.

Thank you!

Edit:
Bidirectional electricity meters are not supported, so the device is probably not for me.

Just so the solution is documented here:

  1. Do what @themainframe suggested above.
    It will now show just 0 like @rfahren85 had the issue with.
  2. Go back to manage zigbee device like here:
  3. Read the attribute. Now it should for some reason start working again with the new value. (ignore the value that is being read here)

Might also work with other attributes being read. I dont know why this consistently fixes it for me.

Do not re-read the value with zha_toolkit, btw. When I do that it stops working again.
