Run HomeAssistant on FreeBSD using bhyve
Why?
Because it’s simple.
FreeBSD provides out of the box ZFS support, great documentation for the proper way of doing things, solid community and the OS is maintained by one group. Not like with Linux, where Linux is just the kernel, and we have zillion different distributions and confusion about how to do things.
FreeBSD is just better, simple as that.
And FreeBSD after installation uses 500MB ram, compared to 1500M of base Proxmox installation.
Basic Packages needed
pkg update
pkg install vm-bhyve
pkg install bhyve-firmware
pkg install qemu-tools
Setup and vm-bhyve and firmware for uefi
zfs create -o mountpoint=/vm zroot/vm
pkg install vm-bhyve
sysrc vm_enable="YES"
sysrc vm_dir="zfs:zroot/vm"
vm init
cp /usr/local/share/examples/vm-bhyve/* /vm/.templates/
pkg install bhyve-firmware
pkg install qemu-tools
Create switch if we don’t have a bridge already
if you have a bridge already, create a manual switch and add it to the bridge
I am using wlan0 (wifi network) for the switch. The idea is to passtrhough USB hub with NIC to the HomeAssistant VM and use that exlusively for HomeAssistant
vm switch create public
vm switch add public wlan0
Download latest hassos VM image
bhyve/vm-bhyve supports raw or qcow2 images, so we can use the VM images provided by HomeAssistant team directly
vm img https://github.com/home-assistant/operating-system/releases/download/14.2/haos_ova-14.2.qcow2.xz
Create and start the VM
vm create -t debian -c 2 -s 64G -m 2GB -i haos_ova-14.2.qcow2 hass
Before starting, edit the /vm/hass/hass.conf file and replace loader=“grub” with loader=“uefi”
Afterwards, start the vm and confirm it is up and running.
You can connect to the console of the vm now
vm start hass
vm list
vm console hass
Passtrhu
Passthru on FreeBSD is possible only on controller level. So, if you bave just one USB hub in your PC (laptop, like I did), you need to passthru whole controller.
Maybe this will change in the future, but for now, this is the only way to do it.
First, find the device you want to passthru.
vm passthru
In my case, it was
usb0 0/21/0 Yes Celeron/Pentium Silver Processor USB 3.0 xHCI Controller
Now, you need to detach the device from the host.
This is done by putting the appropriate line in /boot/loader.conf file.
This frees the 0/21/0 pci device to from host, and prepares it to be passed thru to the VM.
# VM
vmm_load="YES"
pptdevs="0/21/0"
Now, we are almost there.
Edit the /vm/hass/hass.conf file once again, and add
passthru0="0/21/0"
to it.
Reboot the machine to activate the changes.
After machine is back up, make sure the device is managed by ppt
vm passthru
ppt0 0/21/0 Yes Celeron/Pentium Silver Processor USB 3.0 xHCI Controller
and now, after you start the VM, you should see the usb contoller (with NIC and USB ports to attach your z-wave/zigbee usb sticks to).
HASSOS console
You can access the HASSOS console using
vm console hass
and configure basic networking from there.
Afterwards, you should be able to access the web gui of HomeAssistant and continue the installation as needed from there.
