web_i2c

An in-browser I2C bus console, monitor, and controller for ESPHome.

web_i2c turns an ESP8266 or ESP32 into a live I2C debugging tool you reach from
a browser. No logic analyzer, no extra hardware, no software to install: the ESP
serves a web page over WebSocket, runs the real I2C transactions on its own
SDA/SCL pins, and streams what it sees back to your browser as you watch.

It is not an electrical logic analyzer. It taps the bus at the
transaction/API level: the ESP is the bus master, and the component observes
and relays every transaction that passes through its own I2C driver. That makes
it a console + monitor + controller for the device that is already in your
circuit – uniquely able to reconstruct an SSD1306 screen image from the bus,
take over the bus to compose on a display, and monitor the host’s health while
it monitors traffic.

Highlights

  • Transparent tap / monitor – every transaction relayed by the ESP is
    logged live, with per-transaction microsecond timestamps and inter-transaction
    deltas.
  • Device-aware decoder – decodes I2C transactions with SSD1306/SH1106
    semantics (Set Column Address, Charge Pump, etc.), grouping ESPHome’s
    byte-by-byte command writes back into logical commands.
  • Framebuffer mirror – reconstructs the actual SSD1306 image from the pixel
    writes on the bus and draws it in the browser. No logic analyzer does this.
  • Bus takeover + composer – stop relaying device traffic and drive the bus
    yourself: draw or load an image, send it to the display, run test patterns.
  • Manual terminal – scan the bus, read/write registers, dump register maps.
  • Trigger → capture – arm on an address, error, or byte pattern; the log
    freezes on the match and highlights it, keeping the pre-trigger context.
  • Live cockpit – semicircle gauges (bus traffic, loop rate, free heap), a
    reactive wiring diagram, and a plain-language status banner.
  • Export – CSV (UTF-8, Excel-ready) and JSON, including the ESP-side
    timestamps and deltas.
  • Serial mirror – mirror the log to a UART/USB serial port (Chrome/Edge).
  • Health guardrails – dynamic CPU throttle, bounded buffers, boot
    protection, and a bus-recovery routine for a stuck line.

Requirements

  • ESPHome (2024.x or newer recommended).
  • An ESP8266 or ESP32 board on your network (Wi-Fi).
  • An i2c: bus defined in your YAML.

Works on both platforms. The ESP8266 (single core, ~80 KB RAM) handles the tool
comfortably; heavy continuous traffic is throttled to protect the loop. An ESP32
sustains much higher message rates.

Installation

Add the component from GitHub via external_components:

external_components:
  - source: github://kaboom748/web_i2c
    components: [web_i2c]

Then define an I2C bus and the terminal:

# the real I2C bus of the ESP (wire your SSD1306 / sensor here)
i2c:
  id: bus0
  sda: D2        # GPIO4 on a D1 mini
  scl: D1        # GPIO5 on a D1 mini
  scan: true     # log addresses found at boot

# the in-browser I2C console
web_i2c:
  id: i2c_debug
  i2c_id: bus0   # name the real bus (see note below)
  port: 8095     # open <esp-ip>:8095 in a browser

Complete, ready-to-flash examples are in example/ for both
ESP8266 and ESP32.

Configuration options

Option Required Description
id no Component ID (also usable as an i2c_id by other comps).
i2c_id yes The real i2c: bus to wrap (give that bus an id).
port yes TCP port of the embedded WebSocket server.

Why i2c_id is required: web_i2c is itself an i2c::I2CBus (a decorator),
so any config has at least two buses – the real one and web_i2c. ESPHome
cannot auto-pick which one web_i2c should wrap, so you must name the real bus
explicitly (i2c: { id: bus0, ... } then web_i2c: { i2c_id: bus0, ... }).

Monitoring other components’ traffic

web_i2c is also an i2c::I2CBus decorator. Point another component’s i2c_id
at it and every transaction that component makes is relayed to the real bus
and captured by the tap:

i2c:
  id: real_bus
  sda: D2
  scl: D1

web_i2c:
  id: i2c_debug
  i2c_id: real_bus
  port: 8095

display:
  - platform: ssd1306_i2c
    i2c_id: i2c_debug      # route the display through the tap
    address: 0x3C
    # ...

Now the display’s traffic shows up live in the browser, and you can mirror its
framebuffer or take over the bus.

Using the interface

Open <esp-ip>:<port> in a browser. The top status bar shows live pills: WebSocket,
real bus state, tap mode, device count, and a saturation alert.

Tabs

  • Commands – manual bus operations (scan, read, write, register access).
  • Display – SSD1306/SH1106 command helpers.
  • Init / Scroll – display init and scroll helpers.
  • Info – the cockpit: gauges, wiring diagram, and the tap Monitor & Control
    panel.
  • System – exact numeric readouts (bus config, monitor counters, bus lines,
    memory, device, server).

The composer (top of the page)

Draw on a virtual SSD1306, load a photo (converted to 1-bit with adjustable
threshold and dithering), or apply Fill / Checkerboard patterns. Nothing is sent
until you press Send to display – the composer fills the preview, you review
it, then send.

Manual command syntax

Type these in the terminal (or use the buttons):

Command Action
SCAN Scan the bus for devices.
W <addr> <b0> <b1> ... Write bytes to a device (hex).
R <addr> <len> Read len bytes.
WR <addr> <reg> <b0> ... Write to a register.
RR <addr> <reg> <len> Read len bytes from a register.

Addresses and bytes are hexadecimal (e.g. W 3C 00 AF). ACK/NACK is reported
per transaction.

The LOG panel

Every relayed transaction and manual result appears here, newest at the bottom,
each with a delta timestamp:

+118us   >> W 0x3C  cmd   00 21 00 7F  OK
+545us   >> W 0x3C  data  128 x 17 B   OK
+199ms   >> W 0x3C  cmd   00 22 00 07  OK

Each line is self-describing:

  • cmd – a command/register write (bytes shown when captured).
  • data – a bulk pixel stream to the display (control byte 0x40); shown as
    a readable size, not decoded (it would flood).
  • read – a read transaction.

Toolbar (left to right): Pause (freezes the display; a badge shows how many
lines were buffered while paused – nothing is lost), Errors (show only
NACK/TIMEOUT/… lines), Filter (substring), Trigger (see below),
CSV / JSON export, and Clear.

Timestamps and deltas

Timestamps are taken on the ESP with micros() at the moment the
transaction is observed – free of Wi-Fi/WebSocket jitter. The log shows the
delta from the previous transaction (+12.3ms), which reveals the rhythm of
the bus: polling intervals, refresh bursts, and abnormal gaps. The micros()
wrap (~71 minutes) is handled correctly. Exports include the raw esp_us and
delta_ms columns.

Trigger → capture

Type a condition in the trigger field (an address like 0x50, an error like
NACK, or any byte pattern) and arm it. When a matching line arrives, the log
auto-pauses, the triggering line is highlighted, and the pre-trigger
context stays visible. Click the trigger button again to re-arm. This catches
transient events you would otherwise miss as they scroll past.

The decoder

Click the arrow between the LOG and the Decoder to decode the current log.
Command transactions are broken down byte-by-byte with device semantics:

+118us
START
0x3C     ADDR . Write
00       CONTROL . command stream
21 00 7F Column address 0..127
22 00 07 Page address 0..7
STOP

Because ESPHome sends each SSD1306 command byte as its own I2C write, the decoder
merges consecutive command writes to reconstruct multi-byte commands – but
only when the capture is reliable. It is honest about its limits:

  • In Batch delivery the sequence is coalesced, so the decoder shows a note to
    switch to Live for exact decoding.
  • When the bus is flooded (transactions dropped by the throttle), the
    captured sequence has gaps; the decoder says so instead of inventing values.
  • For unknown (non-display) devices it shows the raw bytes without pretending
    to know the register meanings.

Capture modes (Monitor & Control panel)

  • Detail: Summary / Full – Summary logs only a byte count per transaction;
    Full streams the bytes of command writes (decodable). Pixel/bulk writes are
    always counted only.
  • Delivery: Live / Batch – Live sends one message per transaction (exact
    order, needed for precise decoding). Batch coalesces and de-duplicates to a few
    messages per second (much lighter, but scrambles command order).
  • Bus: Relay / Take over – Relay is normal operation. Take over stops
    relaying device traffic to the bus so your terminal commands own it – compose
    on the display without its component overwriting you.
  • Screen: Off / Mirror – Mirror reconstructs the display’s framebuffer from
    the pixel writes on the bus and draws it below.
  • Filter – restrict the tap to a single address (blank = all).

Serial mirror

Connect a USB/UART serial port (Chrome/Edge, Web Serial API) to mirror the log
lines to a terminal for external capture. The serial output matches the on-screen
log exactly, deltas included. The output is UTF-8; set your terminal to UTF-8.

Guardrails and recovery

  • Dynamic CPU throttle – the tap sends at most one log per a multiple of the
    smoothed loop period, so it always yields CPU to the web server and never
    starves the Wi-Fi handshake. On a flooded bus it drops log output (never bus
    data) and marks itself “skipping”. Log lines skipped is display throttling,
    not lost bus traffic.
  • Bounded buffers – fixed-size aggregation and output buffers; no dynamic
    allocation in the hot path.
  • Boot protection – heavy writes are deferred during the first seconds after
    boot so a slow transfer cannot block the loop during the Wi-Fi handshake.
  • Bus recovery – if a line is held low (stuck device, missing pull-up), the
    Recover bus button clocks SCL to release SDA.

Known limitations

web_i2c is a transaction-level tap, not an electrical analyzer. Being honest
about this is a feature:

  • No electrical view. It cannot see waveforms, glitches, rise/fall times, the
    true ACK bit (ACK is inferred from the driver’s return code), clock
    stretching, bus contention, or timing at the signal level. For those, use a
    logic analyzer.
  • Only its own bus. It sees traffic that passes through its own I2C driver
    (the ESP as master) or manual commands. It cannot passively sniff traffic
    between two other chips it is not part of.
  • Continuous display refresh on ESP8266. ~700 tx/s saturates the ESP8266; the
    throttle drops most transactions, so precise command decoding is not possible
    in either mode. Use the framebuffer mirror to see the screen, or capture a
    lighter/one-shot sequence (boot init, a manual command) for exact decoding. An
    ESP32 sustains far higher rates.
  • Serial mirror is Chrome/Edge only (Web Serial API).
  • Tested configuration. Developed and exercised on a Wemos D1 mini (ESP8266)
    and an ESP32 dev board with an SSD1306 at 0x3C. Other displays, sensors, and
    boards are supported structurally but not all exercised – feedback welcome.

Tuning

Compile-time constants (top of web_i2c.cpp / web_i2c.h) let you trade
responsiveness for CPU/RAM: tap backlog, throttle multiplier, batch interval and
slots, boot grace window, and the framebuffer refresh interval. Defaults are
conservative for the ESP8266.

How it works

The browser never speaks I2C. It sends command text over WebSocket; the ESP runs
the I2C and returns results. WebI2C is both the WebSocket server and an
i2c::I2CBus decorator: it overrides write_readv to observe and relay every
transaction, while manual terminal commands call the underlying bus directly.
The page (HTML + JS) is served from PROGMEM as a single document. See
docs/DEVELOPMENT_NOTES.md for the design decisions
and the pitfalls solved along the way.

License

MIT. See LICENSE.
