How big are the images you’re including?
2 Likes
Not so many but maybe they were too big…
I just didn’t think a sec to this point.
It’s OK now, thank you… forced a resize to 120x120px, as this is just for testing.
- id: img_startup
file: m5dial_files/cs_smiley.png
type: RGBA
resize: 120x120 #added to save flash memory
So, after lot of digging in this post and espHome documentation: here’s my code.
Just a base for what i want to do, i only achieved the welcome page.
Code
wifi:
ssid: !secret wifi_ssid
password: !secret wifi_password
manual_ip:
static_ip: !secret ip_m5stack_dial
gateway: !secret wifi_gtw
subnet: !secret wifi_sub
ap:
ssid: "m5stack-dial-fallback"
password: !secret wifi_ap_password
ota:
password: !secret ota_password
logger:
level: DEBUG
api:
encryption:
key: !secret api_encryption_key
esp32:
board: esp32-s3-devkitc-1
framework:
type: arduino
esphome:
name: ${name}
friendly_name: ${friendly_name}
on_boot:
then:
- light.turn_on: backlight
- delay: 3s
- display.page.show: page_01
- pcf8563.read_time: my_time
external_components:
- source: github://dgaust/esphome@gc9a01
components: [ gc9a01, ft3267 ]
refresh: 0s
<<: !include m5dial_files/colors_and_fonts.yaml
<<: !include m5dial_files/images.yaml
spi: #required by display.ili9xxx
mosi_pin: GPIO5
clk_pin: GPIO6
i2c:
- id: bus_internal #required by touchscreen.ft3267
sda: GPIO11
scl: GPIO12
scan: false
rc522_i2c: # RFiD
i2c_id: bus_internal
address: 0x28
on_tag:
then:
- rtttl.play: 'two_short:d=4,o=5,b=100:16e6,16e6'
- homeassistant.tag_scanned: !lambda 'return x;'
rtttl: # buzzer
output: rtttl_out
id: my_rtttl
output:
- id: lcdbacklight # screen backlight
platform: ledc
pin: GPIO9
min_power: 0
max_power: 1
- platform: ledc # buzzer
pin: GPIO3
id: rtttl_out
substitutions:
name: tab-m5stack-dial
friendly_name: M5Stack Dial
lux_sensor_id: sensor.ip030_mmw_aqara_living_luminance
alarm_panel_id: alarm_control_panel.alarme_maison
gate_sensor_id: binary_sensor.tplt_gate_open_too_long
windows_group_id: binary_sensor.windows_upstairs
# ======================================================================================
# ======================================================================================
# ================================================================================= time
time:
- platform: pcf8563
id: my_time
address: 0x38
update_interval: never # repeated synchronization is not necessary unless the external RTC is much more accurate than the internal clock
- platform: homeassistant
on_time_sync: # instead try to synchronize via network repeatedly ...
then:
- pcf8563.write_time: my_time # ... and update the RTC when the synchronization was successful
- logger.log: "time synced"
# ======================================================================================
# ======================================================================================
# =============================================================================== lights
light:
# ------------------------------------------------------------------ backlight
- platform: monochromatic
id: backlight
name: "Backlight"
output: lcdbacklight
default_transition_length: 500ms
# ======================================================================================
# ======================================================================================
# ============================================================================== selects
select:
- platform: template
name: Page Selector
id: page_selector
options:
- "page_off" # index 0
- "page_00" # index 1
- "page_01" # index 2
- "page_a1" # index 3
- "page_b1" # index 4
- "page_c1" # index 5
- "page_d1" # index 6
initial_option: "page_00"
optimistic: true
on_value:
- if:
condition:
- lambda: 'return id(page_selector).state == "page_off";'
then:
- light.turn_off: backlight
else:
- if:
condition:
- light.is_off: backlight
then:
- light.turn_on: backlight
- display.page.show: page_01
- if:
condition:
- lambda: 'return id(page_selector).state == "page_00";'
then:
- display.page.show: page_00
- if:
condition:
- lambda: 'return id(page_selector).state == "page_01";'
then:
- display.page.show: page_01
- if:
condition:
- lambda: 'return id(page_selector).state == "page_a1";'
then:
- display.page.show: page_a1
- if:
condition:
- lambda: 'return id(page_selector).state == "page_b1";'
then:
- display.page.show: page_b1
- if:
condition:
- lambda: 'return id(page_selector).state == "page_c1";'
then:
- display.page.show: page_c1
- if:
condition:
- lambda: 'return id(page_selector).state == "page_d1";'
then:
- display.page.show: page_d1
# ======================================================================================
# ======================================================================================
# ====================================================================== display + pages
touchscreen:
platform: ft3267
on_touch:
then:
- logger.log:
format: 'Touch ID: %d at _____________________ (%d, %d)'
args: [touch.id, touch.x, touch.y]
- if:
condition:
- light.is_off: backlight
then:
- light.turn_on: backlight
display:
- platform: ili9xxx
model: gc9a01a
reset_pin: GPIO8
id: screen
cs_pin: GPIO7
dc_pin: GPIO4
dimensions:
height: 240
width: 240
on_page_change:
- to: page_00
then:
- select.set:
id: page_selector
option: page_00
- to: page_01
then:
- select.set:
id: page_selector
option: page_01
- to: page_a1
then:
- select.set:
id: page_selector
option: page_a1
- to: page_b1
then:
- select.set:
id: page_selector
option: page_b1
- to: page_c1
then:
- select.set:
id: page_selector
option: page_c1
- to: page_d1
then:
- select.set:
id: page_selector
option: page_d1
pages:
# _____________________________________________________ startup page
- id: page_00
lambda: |-
it.image(120, 120, img_00, ImageAlign::CENTER);
# ___________________________________________________ welcome page
- id: page_01
lambda: |-
// variables =========================================================
float screenheight = it.get_height();
float screenwidth = it.get_width();
float halfscreenheight = screenheight / 2;
float halfscreenwidth = screenwidth /2;
// background draws ==================================================
it.filled_rectangle(0, 0, halfscreenwidth, halfscreenheight, pri_color);
it.filled_rectangle(halfscreenwidth, halfscreenheight, 155, 155, pri_color);
it.filled_rectangle(0, halfscreenheight, halfscreenwidth, 155, pri_color);
it.filled_rectangle(halfscreenwidth, 0, 155, halfscreenheight, pri_color);
it.line(0, halfscreenheight, screenwidth, halfscreenheight, off_color);
it.line(halfscreenwidth, 0, halfscreenwidth, screenheight, off_color);
// icons =============================================================
// alarm icon ----------------------------------------------------
if (id(alarm_text).state == "armed_away") {
it.image(65, 75, mdi_shield_lock, ImageAlign::CENTER, nova_color);
} else if (id(alarm_text).state == "armed_night") {
it.image(65, 75, mdi_shield_moon, ImageAlign::CENTER, nova_color);
} else if (id(alarm_text).state == "armed_home") {
it.image(65, 75, mdi_shield_account, ImageAlign::CENTER, blue_color);
} else if (id(alarm_text).state == "arming") {
it.image(65, 75, mdi_shield_sync, ImageAlign::CENTER, text_color);
} else if (id(alarm_text).state == "pending") {
it.image(65, 75, mdi_shield_lock_open, ImageAlign::CENTER, yellow_color);
} else if (id(alarm_text).state == "triggered") {
it.image(65, 75, mdi_shield_alert, ImageAlign::CENTER, red_color);
} else {
it.image(65, 75, mdi_shield_off, ImageAlign::CENTER, off_color);
}
// gate icon -----------------------------------------------------
if (id(gate_text).state == "closed") {
it.image(175, 75, mdi_gate_closed, ImageAlign::CENTER, text_color);
} else if (id(gate_text).state == "open") {
it.image(175, 75, mdi_gate_open, ImageAlign::CENTER, blue_color);
} else {
it.image(175, 75, mdi_gate_alert, ImageAlign::CENTER, yellow_color);
}
// thermostat icon -----------------------------------------------
it.image(65, 165, mdi_thermostat, ImageAlign::CENTER, text_color);
// other icon ----------------------------------------------------
if (id(windows_text).state == "off") {
it.image(175, 165, mdi_window_closed, ImageAlign::CENTER, text_color);
} else {
it.image(175, 165, mdi_window_open, ImageAlign::CENTER, blue_color);
}
// foreground draws ==================================================
it.filled_regular_polygon(halfscreenwidth, halfscreenheight -220, 144, EDGES_OCTAGON, VARIATION_FLAT_TOP, sec_color);
it.filled_regular_polygon(halfscreenwidth, halfscreenheight +220, 144, EDGES_OCTAGON, VARIATION_FLAT_TOP, sec_color);
it.regular_polygon(halfscreenwidth, halfscreenheight -220, 145, EDGES_OCTAGON, VARIATION_FLAT_TOP, off_color);
it.regular_polygon(halfscreenwidth, halfscreenheight +220, 145, EDGES_OCTAGON, VARIATION_FLAT_TOP, off_color);
// top text draw =====================================================
it.strftime(halfscreenwidth, 20, id(roboto_16_with_icons), orange_color, TextAlign::CENTER, "%d/%m %X", id(my_time).now());
// bottom text draw ==================================================
it.print(halfscreenwidth, screenheight -20, id(roboto_16_with_icons), orange_color, TextAlign::CENTER, "\U000F0046 ETEINDRE");
# ___________________________________________________ alarm page
- id: page_a1
lambda: |-
// variables ======================================================
float screenheight = it.get_height();
float screenwidth = it.get_width();
float halfscreenheight = screenheight / 2;
float halfscreenwidth = screenwidth /2;
// text draw ==================================================
it.print(halfscreenwidth, halfscreenheight, id(roboto_16_with_icons), orange_color, TextAlign::CENTER, "A1 PAGE");
# ___________________________________________________ gate page
- id: page_b1
lambda: |-
// variables ======================================================
float screenheight = it.get_height();
float screenwidth = it.get_width();
float halfscreenheight = screenheight / 2;
float halfscreenwidth = screenwidth /2;
// text draw ==================================================
it.print(halfscreenwidth, halfscreenheight, id(roboto_16_with_icons), orange_color, TextAlign::CENTER, "B1 PAGE");
# ___________________________________________________ thermostat page
- id: page_c1
lambda: |-
// variables ======================================================
float screenheight = it.get_height();
float screenwidth = it.get_width();
float halfscreenheight = screenheight / 2;
float halfscreenwidth = screenwidth /2;
// text draw ==================================================
it.print(halfscreenwidth, halfscreenheight, id(roboto_16_with_icons), orange_color, TextAlign::CENTER, "C1 PAGE");
# ___________________________________________________ windows page
- id: page_d1
lambda: |-
// variables ======================================================
float screenheight = it.get_height();
float screenwidth = it.get_width();
float halfscreenheight = screenheight / 2;
float halfscreenwidth = screenwidth /2;
// text draw ==================================================
it.print(halfscreenwidth, halfscreenheight, id(roboto_16_with_icons), orange_color, TextAlign::CENTER, "D1 PAGE");
# ======================================================================================
# ======================================================================================
# ============================================================================== sensors
sensor:
# ----------------------------------------------------------------- lux sensor
- platform: homeassistant
entity_id: $lux_sensor_id
name: "Lux Sensor"
id: sensor_lux
accuracy_decimals: 0
on_value:
- logger.log:
format: "$lux_sensor_id: %.0f"
args: [ 'id(sensor_lux).state' ]
- if:
condition:
- light.is_on: backlight
then:
- lambda: |-
float lux = id(sensor_lux).state;
if (lux < 10) {
id(lcdbacklight).set_level(0.1);
}
else if (lux < 40) {
id(lcdbacklight).set_level(0.3);
}
else if (lux < 80) {
id(lcdbacklight).set_level(0.5);
}
else {
id(lcdbacklight).set_level(0.7);
}
# ------------------------------------------------------------- rotary encoder
- platform: rotary_encoder
name: Rotary Encoder
id: rotaryencoder
resolution: 1
pin_a:
number: GPIO40
mode:
input: true
pullup: true
pin_b:
number: GPIO41
mode:
input: true
pullup: true
accuracy_decimals: 0
# accuracy_decimals: 1
on_clockwise:
- logger.log: "rotary_encoder : _____________________ turned_clockwise"
- if:
<<: &select_off
condition:
- lambda: 'return id(page_selector).state == "page_off";'
then:
- select.set:
id: page_selector
option: page_01
on_anticlockwise:
- logger.log: "rotary_encoder : _____________________ turned_ANTIclockwise"
- if:
<<: *select_off
# ======================================================================================
# ======================================================================================
# ======================================================================= binary sensors
binary_sensor:
# --------------------------------------------------------------------- button
- platform: gpio
pin:
number: GPIO42
inverted: true
name: M5 Button
on_press:
- logger.log: "button_pushed _____________________ button_pushed"
- if:
condition:
- lambda: 'return id(page_selector).state == "page_00";'
then:
- select.set:
id: page_selector
option: page_off
else:
- if:
condition:
- lambda: 'return id(page_selector).state == "page_01";'
then:
- select.set:
id: page_selector
option: page_00
else:
- select.set:
id: page_selector
option: page_01
# ================================================================= touch inputs
# -------------------------------------------------------------- startup
- platform: touchscreen
id: touch_00
internal: true
x_min: 0
x_max: 240
y_min: 0
y_max: 240
page_id: page_00
on_press:
- logger.log: "touch_input OVER page_00 : _____________________ startup"
on_release:
- if:
condition:
- light.is_on: backlight
then:
- display.page.show: page_01
# -------------------------------------------------------------- welcome
- platform: touchscreen
id: touch_01_tl
internal: true
x_min: 0
x_max: 118
y_min: 0
y_max: 118
page_id: page_01
on_press:
- logger.log: "touch_input OVER page_01 : _____________________ top_left"
on_release:
- if:
condition:
- light.is_on: backlight
then:
- display.page.show: page_a1
- platform: touchscreen
id: touch_01_tr
internal: true
x_min: 122
x_max: 240
y_min: 0
y_max: 118
page_id: page_01
on_press:
- logger.log: "touch_input OVER page_01 : _____________________ top_right"
on_release:
- if:
condition:
- light.is_on: backlight
then:
- display.page.show: page_b1
- platform: touchscreen
id: touch_01_bl
internal: true
x_min: 0
x_max: 118
y_min: 122
y_max: 240
page_id: page_01
on_press:
- logger.log: "touch_input OVER page_01 : _____________________ bottom_left"
on_release:
- if:
condition:
- light.is_on: backlight
then:
- display.page.show: page_c1
- platform: touchscreen
id: touch_01_br
internal: true
x_min: 122
x_max: 240
y_min: 122
y_max: 240
page_id: page_01
on_press:
- logger.log: "touch_input OVER page_01 : _____________________ bottom_right"
on_release:
- if:
condition:
- light.is_on: backlight
then:
- display.page.show: page_d1
# ======================================================================================
# ======================================================================================
# ============================================================================== numbers
number:
- platform: template
id: color_hue
initial_value: 0
min_value: 0
max_value: 359.9
step: 0.1
optimistic: True
- platform: template
id: color_saturation
initial_value: 0
min_value: 0
max_value: 100
step: 0.1
optimistic: True
- platform: template
id: dimmer_value
initial_value: 0
min_value: 0
max_value: 1
step: 0.001
optimistic: True
# ======================================================================================
# ======================================================================================
# ============================================================================== scripts
script:
- id: update_touch_script
mode: restart
parameters:
x: int
y: int
then:
- lambda: |-
// adjust center or coordinate plane to (120, 120)
float polar_x = x - 120;
float polar_y = 120 - y; // Screen y is opposite of cartesian.
// convert to polar coords
float r = sqrt(pow(polar_x, 2) + pow(polar_y, 2));
float theta = atan(polar_y / polar_x);
if (polar_x < 0) {
theta += M_PI; // Adjust atan for quadrants 2 & 3.
} else if (polar_y < 0) {
theta += 2 * M_PI; // Make quadrant 4 value positive.
}
// Update dimmer value.
float min_theta = M_PI * 310 / 180;
float max_theta = M_PI * 590 / 180;
// Normalize the relative positioning of the values.
float test_theta = theta;
if (test_theta < min_theta) {
test_theta += M_PI * 2;
}
ESP_LOGD("THETA", "%f < %f < %f", min_theta, test_theta, max_theta);
// page interactions
if (id(screen).get_active_page() == id(page_00)) {
id(color_hue).publish_state(360 - theta / M_PI * 180);
id(color_saturation).publish_state(min(r, (float)100));
}
if (id(screen).get_active_page() == id(page_01)) {
id(color_hue).publish_state(360 - theta / M_PI * 180);
id(color_saturation).publish_state(min(r, (float)100));
}
# - component.update: screen
# ======================================================================================
# ======================================================================================
# ============================================================================== text sensors
text_sensor:
- platform: homeassistant
id: alarm_text
entity_id: $alarm_panel_id
- platform: homeassistant
id: gate_text
entity_id: $gate_sensor_id
attribute: esphome_text_sensor
- platform: homeassistant
id: windows_text
entity_id: $windows_group_id
I didn’t find the way to reduce those parts with lambdas… Any guess?
Select component
on_value:
- if:
condition:
- lambda: 'return id(page_selector).state == "page_off";'
then:
- light.turn_off: backlight
else:
- if:
condition:
- light.is_off: backlight
then:
- light.turn_on: backlight
- display.page.show: page_01
- if:
condition:
- lambda: 'return id(page_selector).state == "page_00";'
then:
- display.page.show: page_00
- if:
condition:
- lambda: 'return id(page_selector)....... etc etc etc
Display component:
on_page_change:
- to: page_00
then:
- select.set:
id: page_selector
option: page_00
- to: page_01
then:
- select.set:
id: page_selector
option: page_01
- to: page_a1....... etc etc etc
2 Likes
In the video I shared a few posts up, the guy ‘Volos Projects’ has made not only a nice looking, but very responsive UI. I am not sure how he implemented it, but I am pretty sure he shares his code somewhere, maybe you could look at it and see?
This videos are only in German but the github repo is in english:
SmartHome-yourself/m5-dial-for-esphome
But has added touch switch between entities (swiping left and right) and switch between modes (swiping up and down)
https://www.youtube.com/watch?v=4dE7YONEYVk <= lights
https://www.youtube.com/watch?v=7TZfAWmYNzo <= update with more entities
2 Likes
Hello, has anyone already managed to operate the NFC tag via the M5Stack dial? I would like to perform this option with him. Thanks in advance
I’ve now started looking at the lvgl component that is in development for esphome
It’s only early days of bringing things across, but it’s a lot faster than the lambda display method that we needed to use
edit: updated with a loading screen and a little more visible due to colour changes (still can’t work out how to change the blue colour for the arc
)
edit 2: I figured out how to change the blue colour 32s after posting the initial edit
)
4 Likes
Yeah… Look at post #48!
that’s awesome ! could you share the code ? i have been looking on how to implement a squareline studio ui to the M5 for so long and feel like you have found the way !
You didn’t reply to anyone specific, but some of the code I use in this thread is here
The dial_lvgl is essentially what is in the video above.
1 Like
Do you have something to share from Squareline?
Hey all. I’m very close to finishing up programming my first Dial. I have pages working with the dial, etc. I am basically setting up a timer that is “supposed” to buzz when it expires. For whatever reason, the buzzer isn’t making any sound. I went back to the default firmware and I can hear it beep when I click on things, so I don’t think it’s a hardware issue.
output:
- platform: ledc
pin: GPIO3
id: buzzer
sensor:
- platform: rotary_encoder
id: encoder
pin_a: GPIO40
pin_b: GPIO41
on_clockwise:
then:
- output.turn_on: buzzer
- logger.log: "Next page"
on_anticlockwise:
then:
- output.turn_off: buzzer
- logger.log: "Previous page"
I tried the above code just to simply test the buzzer, but nothing happens. In the past, I’ve used ESP dev boards and attached passive buzzers to pins and that is how I turned them on/off. Does anyone have any experiences with the buzzer on the Dial? Any thoughts/tips?
The buzzer needs to be controlled with rtttl
https://esphome.io/components/rtttl.html
on_clockwise:
- rtttl.play: quick_e:d=4,o=5,b=100:16e6
Unfortunately, there is a fair bit of blocking code so it doesn’t work perfectly.
Gotcha. I was hoping to use it without rttl. I need something that will continue to make noise until a user interacts with it. I’ll play with it though. Thanks for the response.
Any idea if there is a way to start rtttl from inside a lambda? With my countdown, it tests for the end of the countdown and takes actions inside lambdas. Oddly, Google isn’t helping me much.
Here is the section of yaml. I commented where I need the rtttl to start (and hopefully continue non-stop until the user presses a button).
lambda: |-
int mins = 0;
int secs = 0;
if (id(esptime).now().day_of_week == 1) { // it's Sunday, do nothing.
it.fill(id(Color::WHITE));
it.image(120, 60, id(cfa_logo), ImageAlign::CENTER);
it.print(120, 120, id(roboto20), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "It's a day of rest!");
it.print(120, 160, id(roboto20), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "No alarms until tomorrow.");
id(backlight_output).set_level(0.2);
} else if (id(esptime).now().hour < id(starttime) || id(esptime).now().hour > id(endtime)) { // After Hours
it.fill(id(Color::WHITE));
it.image(120, 60, id(cfa_logo), ImageAlign::CENTER);
it.print(120, 120, id(roboto20), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "Good night!");
it.print(120, 160, id(roboto20), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "No alarms");
it.print(120, 180, id(roboto20), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "until tomorrow.");
id(countdown) = ${countdown_length};
id(backlight_output).set_level(0.2);
} else if (id(countdown) > 0) { // Countdown is active
id(countdown)--;
secs = id(countdown) % 60;
mins = (id(countdown) - secs) / 60;
it.fill(id(Color::WHITE));
it.image(120, 60, id(cfa_logo), ImageAlign::CENTER);
it.printf(120, 120, id(roboto32), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "%2d:%02d", mins, secs);
it.print(120, 175, id(roboto20), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "Current Time");
it.strftime(120, 200, id(roboto20), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "%I:%M %p", id(esptime).now());
id(backlight_output).set_level(0.6);
} else { // Countdown has expired. Let's make some noise!
id(alarming) = "true";
// start rtttl
it.fill(id(Color::WHITE));
it.image(120, 60, id(cfa_logo), ImageAlign::CENTER);
it.print(120, 120, id(roboto32), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "Time to clean!");
it.print(120, 195, id(roboto16), id(cfa_black), TextAlign::CENTER_HORIZONTAL, "Rotate for tasks");
id(backlight_output).set_level(1.0);
}
Without going through all that code, I would think something like
id(my_rtttl).play("success:d=24,o=5,b=100:c,g,b");
Replace my_rtttl with whatever the id of your rtttl component is, and the string is the audio that is played
That should work, but if I was thinking about doing it, I’d create a script that plays the rtttl (and anything else I needed to do at the expiry of the countdown) and then just put
id(my_script).execute();
in the lambda.
Hi there,
is someone managed to reproduce or approach the sound that rotary encoder do on stock M5dial firmware.
I’m using this one for my tests, but it sounds like the 80’s …
rtttl.play: 'one_short:d=32,o=4,b=900:a'
I made some progress on LVGL component, and this is FASTEEEEEEEEEER than lambdas, and even look better to me!
Here's the LVGL code part (WIP):
lvgl:
# -------------------------------------------------------------------- general
displays:
- my_display
touchscreens:
- my_touchscreen
rotary_encoders:
sensor: rotaryencoder
enter_button: m5_button
theme:
obj:
scrollbar_mode: "OFF"
scrollable: false
bg_color: pri_color
border_width: 0
border_color: orange_color
radius: 10
arc:
arc_color: pri_color
knob:
bg_color: nova_color
indicator:
arc_color: dark_nova_color
btn:
bg_color: pri_color
checked:
bg_color: nova_color
label:
align: CENTER
text_font: montserrat_18
text_color: text_color
clickable: false
on_idle:
timeout: !lambda "return (id(backlight_timeout).state * 1000);"
then:
- logger.log: "LVGL is idle"
- light.turn_off: backlight
- lvgl.pause:
# ------------------------------------------------------------------ top layer
top_layer:
widgets:
- obj:
id: boot_screen
width: SIZE_CONTENT
height: SIZE_CONTENT
bg_color: 0x000000
bg_opa: COVER
radius: 0
pad_all: 0
border_width: 0
on_press:
- lvgl.widget.hide: boot_screen
widgets:
- img:
align: CENTER
src: boot_logo
y: -30
- spinner:
align: CENTER
y: 70
height: 50
width: 50
spin_time: 2s
arc_length: 60deg
arc_rounded: true
arc_color: sec_color
arc_width: 7
indicator:
arc_color: blue_color
arc_width: 7
# ---------------------------------------------------------------------- pages
pages:
# _____________________________________________________ page welcome
- id: page_welcome
<<: &page_config
bg_color: sec_color
scrollbar_mode: "OFF"
scrollable: false
widgets:
# time
- label:
id: label_rtc_time
align: TOP_MID
text: "Heure"
y: 5
# date
- label:
id: label_rtc_date
align: TOP_MID
text_font: montserrat_16
text: "Date"
y: 28
# MIDDLE_CONTAINER
- obj:
id: object_alarm_state
align: BOTTOM_MID
x: 0
y: -150
width: 250
height: 36
# clickable: true
# on_press:
# - lvgl.page.show: page_alarm
# - homeassistant.service:
# service: input_select.select_option
# data:
# entity_id: $ha_page_selector
# option: page_alarm
widgets:
- label:
id: label_alarm_text
text: "Alarme"
text_color: sec_color
# LEFT_CONTAINER_1
- obj:
width: 150
height: 95
align: TOP_RIGHT
x: -101
y: 98
widgets:
######################### COLUMN 01
# garage
- label:
id: icon_garage_state
<<: &icon_40_config
clickable: true
text_font: grandstander_40_regular
text: "x"
<<: &column_01
x: -60
<<: &row_01
align: TOP_RIGHT
y: -8
clickable: false
# on_long_press:
# - <<: &bip
# rtttl.play: 'one_short:d=32,o=4,b=900:a'
# cargate
- label:
id: icon_cargate_text
<<: *icon_40_config
<<: *column_01
<<: &row_02
align: BOTTOM_RIGHT
y: 2
clickable: false
# on_long_press:
# - <<: *bip
######################### COLUMN 02
# light
- label:
id: icon_light_cour
<<: *icon_40_config
<<: &column_02
x: 0
<<: *row_01
on_long_press:
- <<: &bip
rtttl.play: 'one_short:d=24,o=5,b=100:g'
- homeassistant.service:
service: light.toggle
data:
entity_id: $ha_light_cour
# handgate
- label:
id: icon_handgate_text
<<: *icon_40_config
<<: *column_02
<<: *row_02
y: 4 # SPE handgate
on_long_press:
- <<: *bip
- homeassistant.service:
service: lock.unlock
data_template:
entity_id: lock.gate
# LEFT_CONTAINER_2
- obj:
bg_opa: TRANSP
border_opa: TRANSP
width: 150
height: 45
align: TOP_RIGHT
x: -100
y: 195
widgets:
# outside temperature
- label:
id: label_outside_temperature
x: 41
text_font: montserrat_20
text: "Temp"
# meteo
- label:
id: icon_weather_sensor
x: 41
text_font: grandstander_36_regular
text: "x"
# RIGHT_1_CONTAINER
- obj:
bg_opa: TRANSP
border_opa: TRANSP
width: 110
height: 45
align: TOP_LEFT
x: 147
y: 98
widgets:
- label:
id: icon_front_door
<<: &icon_36_config
text_font: grandstander_36_regular
text: "x"
align: LEFT_MID
x: -5
- label:
id: icon_window_group
<<: *icon_36_config
align: LEFT_MID
x: 40
# RIGHT_2_CONTAINER
- obj:
width: 110
height: 100
align: TOP_LEFT
x: 147
y: 151
on_long_press:
- <<: *bip
- lvgl.page.show: page_thermostat
- homeassistant.service:
service: input_select.select_option
data:
entity_id: $ha_page_selector
option: page_thermostat
- homeassistant.service:
service: climate.set_hvac_mode
data:
entity_id: $ha_climate_heating
hvac_mode: heat
widgets:
# temp
- label:
id: label_climate_heating_current_0
y: -5
align: TOP_LEFT
text_font: montserrat_20
text: "Temp"
# climate icon
- label:
id: icon_climate_heating
align: TOP_LEFT
x: -3
y: 22
text_font: grandstander_32_regular
text: "x"
# __________________________________________________ page thermostat
- id: page_thermostat
<<: *page_config
widgets:
- meter:
id: meter_climate_heating_target
width: 210
height: 210
align: CENTER
bg_opa: TRANSP
border_width: 0
text_color: text_color
scales:
range_from: 16 # = template_sensor, and arc values
range_to: 24 # = template_sensor, and arc values
angle_range: 250
rotation: 145 # = arc start_angle
ticks:
count: 9
width: 1
length: 3
color: sec_color
major:
stride: 1
length: 1
color: dark_nova_color
label_gap: 18
- arc:
id: arc_climate_heating_target
width: 210
height: 210
align: CENTER
start_angle: 145 # = meter rotation value
end_angle: 35
min_value: 160 # idem meter range_from value * 10
max_value: 240 # idem meter range_to value * 10
adjustable: false
- obj:
id: button_climate_state_off
align: CENTER
width: 60
height: 60
radius: 60
on_long_press:
- <<: *bip
- lvgl.page.show: page_welcome
- homeassistant.service:
service: input_select.select_option
data:
entity_id: $ha_page_selector
option: page_welcome
- homeassistant.service:
service: climate.set_hvac_mode
data:
entity_id: $ha_climate_heating
hvac_mode: "off"
widgets:
- label:
<<: *icon_36_config
text: "\U000F0425" # mdi:power
- label:
id: label_climate_heating_current_1
text: ""
y: 70
text_font: montserrat_26
Have to work on the alarm page now.
EDIT : Done
4 Likes
Here’s the main part of the code (had to split code to post here):
Code
packages:
wifi: !include common/esp_common_wifi.yaml
device_base: !include common/esp_common_device_base.yaml
<<: !include m5dial_files/colors_and_fonts.yaml
# <<: !include m5dial_files/lvgl_images_and_icons.yaml
# ----------------------------------------------------------------------- images
image:
- id: boot_logo
file: m5dial_files/cs_smiley.png
type: RGB565
use_transparency: true
resize: 100x100
wifi:
manual_ip:
static_ip: 192.168.2.63
ap:
ssid: "ip063-tab-m5stack-dial-fallback"
esphome:
on_boot:
priority: 600
then:
- pcf8563.read_time: rtc_time
- light.turn_on: backlight
esp32:
board: esp32-s3-devkitc-1
framework:
type: arduino
api:
on_client_connected:
- if:
condition:
lambda: 'return (0 == client_info.find("Home Assistant "));'
then:
- delay: 1s
- lvgl.widget.hide: boot_screen
- lvgl.page.show: page_welcome
- homeassistant.service:
service: input_select.select_option
data:
entity_id: $ha_page_selector
option: page_welcome
on_client_disconnected:
- if:
condition:
lambda: 'return (0 == client_info.find("Home Assistant "));'
then:
- lvgl.widget.show: boot_screen
external_components:
- source: github://clydebarrow/esphome@lvgl
refresh: 10min
components: [ lvgl ]
# ======================================================================================
# ======================================================================================
# =========================================================================== components
i2c:
- id: bus_internal #required by touchscreen.ft5x06
sda: GPIO11
scl: GPIO12
scan: False
touchscreen:
platform: ft5x06
address: 0x38
id: my_touchscreen
on_release:
- if:
condition: lvgl.is_paused
then: &lvgl_resume
- logger.log: "LVGL resuming"
- lvgl.resume:
- lvgl.widget.redraw:
- light.turn_on: backlight
uart:
tx_pin: GPIO2
rx_pin: GPIO1
baud_rate: 256000
parity: NONE
stop_bits: 1
spi:
mosi_pin: GPIO5
clk_pin: GPIO6
display:
- platform: ili9xxx
model: gc9a01a
auto_clear_enabled: false
update_interval: never
reset_pin: GPIO8
id: my_display
cs_pin: GPIO7
dc_pin: GPIO4
dimensions:
height: 240
width: 240
output:
- platform: ledc
id: lcd_backlight
pin: GPIO9
min_power: 0
max_power: 1
- platform: ledc
id: rtttl_out
pin: GPIO3
light:
- platform: monochromatic
id: backlight
name: "Backlight"
output: lcd_backlight
default_transition_length: 250ms
rtttl:
output: rtttl_out
id: my_rtttl
# ======================================================================================
# ======================================================================================
# ============================================================================= specials
# -------------------------------------------------------------- substitutions
substitutions:
name: ip063_tab_m5stack_dial
friendly_name: M5Stack Dial
comment: M5stack Dial / esp32-s3 (lvgl)
log_level: DEBUG # NONE / ERROR / WARN / INFO / DEBUG (default) / VERBOSE / VERY_VERBOSE (not recommended)
ha_presence_sensor: binary_sensor.ip030_mmw_aqara_living_presence_sensor_6
ha_light_cour: light.shelly_one_cour
ha_climate_heating: climate.heatpump_sdgs_ebusd
ha_weather_sensor: weather.84_main_city
ha_outside_temperature: sensor.ebusd_bass2_displayedoutsidetemp_tempv
ha_page_selector: input_select.tab_m5stack_dial_page_selector
ha_alarm_text: sensor.tplt_alarmo
ha_alarm_state: alarm_control_panel.alarme_maison
ha_front_door: binary_sensor.magnet_aqara_front_door_contact
ha_window_group: binary_sensor.windows_upstairs_bedrooms
ha_handgate_text: binary_sensor.tplt_gate_open_too_long
ha_cargate_text: input_boolean.test
ha_garage_state: binary_sensor.io_frient_garage_09c6_input_1
# -------------------------------------------------------------------- globals
globals:
- id: lambda_nova_color
type: lv_color_t
restore_value: no
initial_value: 'lv_color_hex(0xe38de3)'
- id: lambda_blue_color
type: lv_color_t
restore_value: no
initial_value: 'lv_color_hex(0x6b93e3)'
- id: lambda_green_color
type: lv_color_t
restore_value: no
initial_value: 'lv_color_hex(0xa6da95)'
- id: lambda_yellow_color
type: lv_color_t
restore_value: no
initial_value: 'lv_color_hex(0xffd17a)'
- id: lambda_orange_color
type: lv_color_t
restore_value: no
initial_value: 'lv_color_hex(0xe0752b)'
- id: lambda_red_color
type: lv_color_t
restore_value: no
initial_value: 'lv_color_hex(0xede455c)'
- id: lambda_off_color
type: lv_color_t
restore_value: no
initial_value: 'lv_color_hex(0x85b6078)'
- id: lambda_text_color
type: lv_color_t
restore_value: no
initial_value: 'lv_color_hex(0xcad3f5)'
# ======================================================================================
# ======================================================================================
# =============================================================================== number
number:
# __________________________________________________ backlight timeout
- platform: template
name: Backlight Timeout
optimistic: true
id: backlight_timeout
unit_of_measurement: "s"
initial_value: 30
restore_value: true
min_value: 10
max_value: 90
step: 10
mode: auto # auto / box / slider
# ======================================================================================
# ======================================================================================
# ================================================================================= time
switch:
- platform: template
id: switch_antiburn
icon: mdi:television-shimmer
optimistic: true
entity_category: "config"
turn_on_action:
- logger.log: "Starting Antiburn"
- if:
condition: lvgl.is_paused
then:
- lvgl.resume:
- lvgl.widget.redraw:
- delay: 1s
- lvgl.pause:
show_snow: true
turn_off_action:
- logger.log: "Stopping Antiburn"
- if:
condition: lvgl.is_paused
then:
- lvgl.resume:
- lvgl.widget.redraw:
- delay: 1s
- lvgl.pause:
# ======================================================================================
# ======================================================================================
# =============================================================================== switch
time:
- platform: homeassistant
on_time_sync:
then:
- pcf8563.write_time: rtc_time
- logger.log: "Time Synced"
- platform: pcf8563
id: rtc_time
address: 0x38
update_interval: never
on_time:
- minutes: '*'
seconds: 0
then:
- script.execute: time_update
- hours: 2,3,4,5
minutes: 5
seconds: 0
then:
- switch.turn_on: switch_antiburn
- hours: 2,3,4,5
minutes: 35
seconds: 0
then:
- switch.turn_off: switch_antiburn
- minutes: '*'
seconds: 0,10,20,30,40,50
then:
- lvgl.widget.hide: label_outside_temperature
- lvgl.widget.show: icon_weather_sensor
- minutes: '*'
seconds: 5,15,25,35,45,55
then:
- lvgl.widget.show: label_outside_temperature
- lvgl.widget.hide: icon_weather_sensor
# ======================================================================================
# ======================================================================================
# =============================================================================== script
script:
- id: time_update
then:
- lvgl.label.update:
id: label_rtc_time
text: !lambda |-
static char time_buf[10];
auto now = id(rtc_time).now();
int hour = now.hour;
int minute = now.minute;
snprintf(time_buf, sizeof(time_buf), "%02d:%02d", hour, minute);
return time_buf;
- lvgl.label.update:
id: label_rtc_date
text: !lambda |-
static const char * const month_names[] = {"Janvier", "Fevrier", "Mars", "Avril", "Mai", "Juin", "Juillet", "Aout", "Sept.", "Oct.", "Nov.", "Dec."};
static const char * const day_names[] = {"Dimanche", "Lundi", "Mardi", "Mercredi", "Jeudi", "Vendredi", "Samedi"};
static char combined_buf[20];
auto now = id(rtc_time).now();
snprintf(combined_buf, sizeof(combined_buf), "%s %2d %s", day_names[now.day_of_week - 1] , now.day_of_month , month_names[now.month-1]);
return combined_buf;
- id: climate_set_target_temperature
mode: restart
then:
- delay: 5s
- homeassistant.service:
service: climate.set_temperature
data:
entity_id: $ha_climate_heating
temperature: !lambda "return id(climate_heating_new_target).state;"
# ======================================================================================
# ======================================================================================
# ========================================================================== text sensor
text_sensor:
# ------------------------------------------------------------- home assistant
# ______________________________________________________ page selector
- platform: homeassistant
id: page_selector_state
entity_id: $ha_page_selector
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- if:
condition:
- lambda: 'return id(page_selector_state).state == "page_welcome";'
then:
- lvgl.page.show: page_welcome
- if:
condition:
- lambda: 'return id(page_selector_state).state == "page_thermostat";'
then:
- lvgl.page.show: page_thermostat
# ________________________________________________________ alarm state
- platform: homeassistant
id: alarm_state
entity_id: $ha_alarm_state
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.widget.update:
id: object_alarm_state
bg_color: !lambda |-
if (x == "armed_away") {
return id(lambda_nova_color);
} else if (x == "armed_home") {
return id(lambda_blue_color);
} else if (x == "armed_night") {
return id(lambda_nova_color);
} else if (x == "arming" or x == "pending") {
return id(lambda_yellow_color);
} else if (x == "triggered") {
return id(lambda_red_color);
} else if (x == "disarmed") {
return id(lambda_text_color);
} else {
return id(lambda_off_color);
}
# _________________________________________________________ alarm text
- platform: homeassistant
id: alarm_text
entity_id: $ha_alarm_text
on_value:
- lvgl.label.update:
id: label_alarm_text
text:
format: "%s"
args: [ 'x.c_str()' ]
# ___________________________________________________ front door state
- platform: homeassistant
id: front_door # off / on
entity_id: $ha_front_door
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.widget.update:
id: icon_front_door
text_color: !lambda |-
if (x == "off") {
return id(lambda_text_color);
} else if (x == "on") {
return id(lambda_blue_color);
} else {
return id(lambda_off_color);
}
- lvgl.label.update:
id: icon_front_door
text: !lambda |-
if (x == "off") {
return "\U000F10AF"; // mdi:door-closed-lock
} else if (x == "on") {
return "\U000F081C"; // mdi:door-open
} else {
return "x";
}
# _________________________________________________ window group state
- platform: homeassistant
id: window_group # off / on
entity_id: $ha_window_group
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.widget.update:
id: icon_window_group
text_color: !lambda |-
if (x == "off") {
return id(lambda_text_color);
} else if (x == "on") {
return id(lambda_yellow_color);
} else {
return id(lambda_off_color);
}
- lvgl.label.update:
id: icon_window_group
text: !lambda |-
if (x == "off") {
return "\U000F11DB"; // mdi:window-closed-variant
} else if (x == "on") {
return "\U000F11DC"; // mdi:window-open-variant
} else {
return "x";
}
# _______________________________________________________ garage state
- platform: homeassistant
id: garage_state # off / on
entity_id: $ha_garage_state
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.widget.update:
id: icon_garage_state
text_color: !lambda |-
if (x == "off") {
return id(lambda_text_color);
} else if (x == "on") {
return id(lambda_yellow_color);
} else {
return id(lambda_off_color);
}
- lvgl.label.update:
id: icon_garage_state
text: !lambda |-
if (x == "off") {
return "\U000F12D3"; // mdi:garage-variant
} else if (x == "on") {
return "\U000F12D4"; // mdi:garage-open-variant
} else {
return "x";
}
# ______________________________________________________ cargate state
- platform: homeassistant
id: cargate_text # off / on
entity_id: $ha_cargate_text
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.widget.update:
id: icon_cargate_text
text_color: !lambda |-
if (x == "off") {
return id(lambda_text_color);
} else if (x == "on") {
return id(lambda_yellow_color);
} else {
return id(lambda_off_color);
}
- lvgl.label.update:
id: icon_cargate_text
text: !lambda |-
if (x == "off") {
return "\U000F0E8B"; // mdi:boom-gate-outline
} else if (x == "on") {
return "\U000F0E87"; // mdi:boom-gate-alert
} else {
return "x";
}
# ______________________________________________________ handgate text
- platform: homeassistant
id: handgate_text # closed / open / alert
entity_id: $ha_handgate_text
attribute: esphome_text_sensor
filters:
- map:
- closed -> Ferme
- open -> Ouvert
- alert -> Defaut
on_raw_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.label.update:
id: icon_handgate_text
text: !lambda |-
if (x == "closed") {
return "\U000F0299"; // mdi:gate
} else if (x == "open") {
return "\U000F116A"; // mdi:gate-open
} else if (x == "alert") {
return "\U000F17F8"; // mdi:gate-alert
} else {
return "x";
}
- lvgl.widget.update:
id: icon_handgate_text
text_color: !lambda |-
if (x == "closed") {
return id(lambda_text_color);
} else if (x == "open") {
return id(lambda_yellow_color);
} else if (x == "alert") {
return id(lambda_red_color);
} else {
return id(lambda_off_color);
}
# ______________________________________________________ climate state
- platform: homeassistant
id: climate_heating_state
entity_id: $ha_climate_heating
on_value:
- lvgl.label.update:
id: icon_climate_heating
text: !lambda |-
if (x == "auto") {
return "\U000F1B17"; // mdi:thermostat-auto
} else if (x == "heat") {
return "\U000F0238"; // mdi:fire
} else if (x == "off") {
return "\U000F0AD8"; // mdi:radiator-off
} else {
return "x";
}
- lvgl.widget.update:
id: icon_climate_heating
text_color: !lambda |-
if (x == "auto") {
return id(lambda_green_color);
} else if (x == "heat") {
return id(lambda_orange_color);
} else if (x == "off") {
return id(lambda_text_color);
} else {
return id(lambda_off_color);
}
# _____________________________________________________ weather sensor
- platform: homeassistant
id: weather_sensor
entity_id: $ha_weather_sensor
on_value:
- lvgl.label.update:
id: icon_weather_sensor
text: !lambda |-
if (x == "clear-night") {
return "\U000F0594";
} else if (x == "cloudy") {
return "\U000F0590";
} else if (x == "exceptional") {
return "\U000F0F2F";
} else if (x == "fog") {
return "\U000F0591";
} else if (x == "hail") {
return "\U000F0592";
} else if (x == "lightning") {
return "\U000F0593";
} else if (x == "lightning-rainy") {
return "\U000F067E";
} else if (x == "partlycloudy") {
return "\U000F0595";
} else if (x == "pouring") {
return "\U000F0596";
} else if (x == "rainy") {
return "\U000F0597";
} else if (x == "snowy") {
return "\U000F0598";
} else if (x == "snowy-rainy") {
return "\U000F067F";
} else if (x == "sunny") {
return "\U000F0599";
} else if (x == "windy") {
return "\U000F059D";
} else if (x == "windy-variant") {
return "\U000F059E";
} else if (x == "sunny-off") {
return "\U000F14E4";
} else {
return "x";
}
# _________________________________________________________ light cour
- platform: homeassistant
id: light_cour
entity_id: $ha_light_cour
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.label.update:
id: icon_light_cour
text: !lambda |-
if (x == "on") {
return "\U000F06E8"; // mdi:lightbulb-on
} else if (x == "off") {
return "\U000F0336"; // mdi:lightbulb-outline
} else {
return "x";
}
- lvgl.widget.update:
id: icon_light_cour
text_color: !lambda |-
if (x == "on") {
return id(lambda_yellow_color);
} else if (x == "off") {
return id(lambda_text_color);
} else {
return id(lambda_off_color);
}
# ======================================================================================
# ======================================================================================
# ======================================================================== binary sensor
binary_sensor:
# --------------------------------------------------------------------- button
- platform: gpio
pin:
number: GPIO42
inverted: true
id: m5_button
name: M5 Button
on_press:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.page.show: page_welcome
- homeassistant.service:
service: input_select.select_option
data:
entity_id: $ha_page_selector
option: page_welcome
# ------------------------------------------------------------- home assistant
# ____________________________________________________ presence sensor
- platform: homeassistant
id: presence_sensor
entity_id: $ha_presence_sensor
publish_initial_state: true
on_state:
- if:
condition:
- binary_sensor.is_on: presence_sensor
then:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lvgl.page.show: page_welcome
- homeassistant.service:
service: input_select.select_option
data:
entity_id: $ha_page_selector
option: page_welcome
# ======================================================================================
# ======================================================================================
# =============================================================================== sensor
sensor:
# ------------------------------------------------------------- rotary encoder
- platform: rotary_encoder
id: rotaryencoder
resolution: 1
pin_a:
number: GPIO40
mode:
input: true
pullup: true
pin_b:
number: GPIO41
mode:
input: true
pullup: true
accuracy_decimals: 0
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
# ________________________________________________________ clockwise
on_clockwise:
- if:
condition:
- lambda: 'return id(page_selector_state).state == "page_thermostat";'
then:
- lambda: |-
return id(climate_heating_new_target).publish_state(id(climate_heating_new_target).state + 0.5);
# ___________________________________________________ anti-clockwise
on_anticlockwise:
- if:
condition:
- lambda: 'return id(page_selector_state).state == "page_thermostat";'
then:
- lambda: |-
return id(climate_heating_new_target).publish_state(id(climate_heating_new_target).state - 0.5);
# ------------------------------------------------------------- home assistant
# _____________________________________________ climate heating target
- platform: homeassistant
id: climate_heating_target
entity_id: $ha_climate_heating
attribute: temperature
on_value:
- if:
condition: lvgl.is_paused
then: *lvgl_resume
- lambda: |-
id(climate_heating_new_target).publish_state(x);
# ____________________________________________ climate new targetvalue
- platform: template
id: climate_heating_new_target
icon: mdi:thermometer-lines
filters:
- clamp:
min_value: 16 # idem meter range_from value
max_value: 24 # idem meter range_from value
on_value:
- lvgl.arc.update:
id: arc_climate_heating_target
value: !lambda return x * 10;
- script.execute: climate_set_target_temperature
# ____________________________________________ climate heating current
- platform: homeassistant
id: climate_heating_current
entity_id: $ha_climate_heating
attribute: current_temperature
on_value:
- lvgl.label.update:
id: label_climate_heating_current_0
text:
format: "%2.1f°C"
args: [ 'x' ]
- lvgl.label.update:
id: label_climate_heating_current_1
text:
format: "%2.1f°C"
args: [ 'x' ]
# ________________________________________________ outside temperature
- platform: homeassistant
id: outside_temperature
entity_id: $ha_outside_temperature
on_value:
- lvgl.label.update:
id: label_outside_temperature
text:
format: "%2.1f°C"
args: [ 'x' ]
<<: !include m5dial_files/colors_and_fonts.yaml
color:
# Nova Colors
- id: nova_color # pink
hex: "e38de3"
- id: dark_nova_color # pink
hex: "764a76"
- id: pri_color # light (mantle)
hex: "24273a"
- id: sec_color # dark (crust)
hex: "181926"
- id: text_color
hex: "cad3f5"
- id: off_color
hex: "5b6078"
# Color Colors
- id: blue_color
hex: "6b93e3"
- id: dark_blue_color
hex: "344b79"
- id: green_color
hex: "a6da95"
- id: dark_green_color
hex: "374825"
- id: yellow_color
hex: "ffd17a"
- id: orange_color
hex: "e0752b"
- id: dark_orange_color
hex: "5f3e25"
- id: red_color
hex: "de455c"
- id: dark_red_color
hex: "642b2b"
font:
- id: roboto_16_bold
file:
type: gfonts
family: Roboto
weight: bold
size: 16
<<: &extras
extras:
- file: "fonts/materialdesignicons-webfont.ttf"
glyphs: [
"\U000F1999", # mdi:rotate-360
"\U000F0741", # mdi:gesture-tap
"\U000F0046", # mdi:arrow-down-thick
"\U000F0594", # clear-night
"\U000F0590", # cloudy
"\U000F0F2F", # exceptional
"\U000F0591", # fog
"\U000F0592", # hail
"\U000F0593", # lightning
"\U000F067E", # lightning-rainy
"\U000F0595", # partlycloudy
"\U000F0596", # pouring
"\U000F0597", # rainy
"\U000F0598", # snowy
"\U000F067F", # snowy-rainy
"\U000F0599", # sunny
"\U000F059D", # windy
"\U000F059E", # windy-variant
"\U000F14E4", # sunny-off
"\U000F073A", # mdi:cancel
"\U000F0425", # mdi:power
"\U000F0238", # mdi:fire
"\U000F1B17", # mdi:thermostat-auto
"\U000F0AD8", # mdi:radiator-off
"\U000F0299", # mdi:gate
"\U000F116A", # mdi:gate-open
"\U000F17F8", # mdi:gate-alert
"\U000F0E8B", # mdi:boom-gate-outline
"\U000F0E87", # mdi:boom-gate-alert
"\U000F10AF", # mdi:door-closed-lock
"\U000F081C", # mdi:door-open
"\U000F11DB", # mdi:window-closed-variant
"\U000F11DC", # mdi:window-open-variant
"\U000F12D3", # mdi:garage-variant
"\U000F12D4", # mdi:garage-open-variant
"\U000F06E8", # mdi:lightbulb-on
"\U000F0336", # mdi:lightbulb-outline
]
- id: roboto_20_regular
file:
type: gfonts
family: Roboto
weight: regular
size: 20
<<: *extras
- id: roboto_20_bold
file:
type: gfonts
family: Roboto
weight: bold
size: 20
<<: *extras
- id: roboto_24_regular
file:
type: gfonts
family: Roboto
weight: regular
size: 24
<<: *extras
- id: roboto_24_bold
file:
type: gfonts
family: Roboto
weight: bold
size: 24
<<: *extras
- id: roboto_48_bold
file:
type: gfonts
family: Roboto
weight: bold
size: 48
<<: *extras
- id: grandstander_32_regular
file:
type: gfonts
family: Grandstander
weight: regular
size: 32
<<: *extras
- id: grandstander_36_regular
file:
type: gfonts
family: Grandstander
weight: regular
size: 36
<<: *extras
- id: grandstander_40_regular
file:
type: gfonts
family: Grandstander
weight: regular
size: 40
<<: *extras
2 Likes
Hello! I have this simplified code in which I need to use the internal bus and the A bus.
i2c:
- id: busi
sda: GPIO11
scl: GPIO12
scan: True
frequency: 400kHz
- id: busa
sda: GPIO13
scl: GPIO15
scan: True
frequency: 400kHz
sensor:
- platform: vl53l0x
i2c_id: busa
name: "VL53L0x Distance"
update_interval: 1s
touchscreen:
platform: ft5x06
i2c_id: busi
address: 0x38
spi:
mosi_pin: GPIO5
clk_pin: GPIO6
display:
- platform: ili9xxx
model: gc9a01a
reset_pin: GPIO8
cs_pin: GPIO7
dc_pin: GPIO4
When I run it and it reaches the device on the A bus, it restarts.
[14:12:28][I][app:029]: Running through setup()...
[14:12:28][I][i2c.arduino:218]: Performing I2C bus recovery
[14:12:28][I][i2c.arduino:218]: Performing I2C bus recovery
[14:12:28][D][spi:039]: Setting up SPI bus...
[14:12:28][D][ili9xxx:034]: Setting up ILI9xxx
[14:12:28][D][spi_device:379]: mode 0, data_rate 40000kHz
[14:12:28][D][ili9xxx:030]: Wrote MADCTL 0x48
[14:12:28][D][vl53l0x:034]: 'VL53L0x Distance' - setup BEGIN
[14:12:33]E (6003) task_wdt: Task watchdog got triggered. The following tasks did not reset the watchdog in time:
[14:12:33]E (6003) task_wdt: - loopTask (CPU 1)
[14:12:33]E (6003) task_wdt: Tasks currently running:
[14:12:33]E (6003) task_wdt: CPU 0: IDLE
[14:12:33]E (6003) task_wdt: CPU 1: IDLE
[14:12:33]E (6003) task_wdt: Aborting.
[14:12:33]ESP-ROM:esp32s3-20210327
[14:12:33]Build:Mar 27 2021
[14:12:33]rst:0xc (RTC_SW_CPU_RST),boot:0x2b (SPI_FAST_FLASH_BOOT)
[14:12:33]Saved PC:0x4037793c
WARNING Decoded 0x4037793c: esp_restart_noos at /Users/ficeto/Desktop/ESP32/ESP32S2/esp-idf-public/components/esp_system/port/soc/esp32s3/system_internal.c:143 (discriminator 1)
[14:12:33]SPIWP:0xee
[14:12:33]mode:DIO, clock div:1
[14:12:33]load:0x3fce3808,len:0x43c
[14:12:33]load:0x403c9700,len:0xbec
[14:12:33]load:0x403cc700,len:0x2a3c
[14:12:33]entry 0x403c98d8
[14:12:34]E (188) psram: PSRAM ID read error: 0x00ffffff
If I remove the touch, it doesn’t work. Then, if I remove the display, it doesn’t work. Finally, when I remove SPI, it works.
[14:22:54][I][app:029]: Running through setup()...
[14:22:54][I][i2c.arduino:218]: Performing I2C bus recovery
[14:22:54][I][i2c.arduino:218]: Performing I2C bus recovery
[14:22:54][D][vl53l0x:034]: 'VL53L0x Distance' - setup BEGIN
[14:22:54][D][vl53l0x:258]: 'VL53L0x Distance' - setup END
[14:22:54][D][vl53l0x:310]: 'VL53L0x Distance' - Got distance 0.054 m
[14:22:54][D][sensor:094]: 'VL53L0x Distance': Sending state 0.05400 m with 2 decimals of accuracy
[14:22:55][D][vl53l0x:310]: 'VL53L0x Distance' - Got distance 0.052 m
Please help, I don’t know what else to do.
