Hello everyone,

I am currently trying to get a Nixie clock running with ESP-Home.

I have to admit to my shame the whole code is a combination of chatgpt and internet.
I have a bit of knowledge of coding, but really not much.

every time i change something i get another error.

would someone help me and look over the code?

many thanks

display_driver.h

#ifndef DISPLAY_DRIVER_H
#define DISPLAY_DRIVER_H

#include "esphome/core/component.h"
#include "esphome/components/output/output.h"

class DisplayDriver : public esphome::Component {
 public:
  DisplayDriver(esphome::output::OutputPin *data_pin, esphome::output::OutputPin *clock_pin, esphome::output::OutputPin *latch_pin);
  void setup();
  void loop();
  void update_time(int hours, int minutes);

 private:
  void shift_out(uint8_t value);
  esphome::output::OutputPin *data_pin_;
  esphome::output::OutputPin *clock_pin_;
  esphome::output::OutputPin *latch_pin_;
};

#endif

display_driver.cpp

#include "display_driver.h"

// Lookup-Tabelle: Adressen für jede Zahl (0-9) auf jeder Röhre (1-4)
const uint8_t NIXIE_ADDRESSES[4][10] = {
    {0b00000001, 0b00000010, 0b00000011, 0b00000100, 0b00000101, 0b00000110, 0b00000111, 0b00001000, 0b00001001, 0b00001010}, // Röhre 1
    {0b00010001, 0b00010010, 0b00010011, 0b00010100, 0b00010101, 0b00010110, 0b00010111, 0b00011000, 0b00011001, 0b00011010}, // Röhre 2
    {0b00100001, 0b00100010, 0b00100011, 0b00100100, 0b00100101, 0b00100110, 0b00100111, 0b00101000, 0b00101001, 0b00101010}, // Röhre 3
    {0b00110001, 0b00110010, 0b00110011, 0b00110100, 0b00110101, 0b00110110, 0b00110111, 0b00111000, 0b00111001, 0b00111010}  // Röhre 4
};

DisplayDriver::DisplayDriver(esphome::output::OutputPin *data_pin, esphome::output::OutputPin *clock_pin, esphome::output::OutputPin *latch_pin) {
  this->data_pin_ = data_pin;
  this->clock_pin_ = clock_pin;
  this->latch_pin_ = latch_pin;
}

void DisplayDriver::setup() {
  ESP_LOGD("DisplayDriver", "Setup completed");
}

void DisplayDriver::loop() {
  // Optional: Regelmäßiger Code
}

void DisplayDriver::update_time(int hours, int minutes) {
  ESP_LOGD("DisplayDriver", "Updating time: %02d:%02d", hours, minutes);

  // Stunden und Minuten aufsplitten
  int hour_tens = hours / 10;
  int hour_units = hours % 10;
  int minute_tens = minutes / 10;
  int minute_units = minutes % 10;

  // Zahlen in Adressen umwandeln
  uint8_t address_hour_tens = NIXIE_ADDRESSES[0][hour_tens];  // Zehnerstelle der Stunde, Röhre 1
  uint8_t address_hour_units = NIXIE_ADDRESSES[1][hour_units]; // Einerstelle der Stunde, Röhre 2
  uint8_t address_minute_tens = NIXIE_ADDRESSES[2][minute_tens]; // Zehnerstelle der Minute, Röhre 3
  uint8_t address_minute_units = NIXIE_ADDRESSES[3][minute_units]; // Einerstelle der Minute, Röhre 4

  // Adressen an Schieberegister senden
  shift_out(address_hour_tens);
  shift_out(address_hour_units);
  shift_out(address_minute_tens);
  shift_out(address_minute_units);

  // Latch-Pin aktivieren
  this->latch_pin_->digital_write(true);
  delayMicroseconds(1);
  this->latch_pin_->digital_write(false);
}

void DisplayDriver::shift_out(uint8_t value) {
  for (int i = 0; i < 8; i++) {
    this->clock_pin_->digital_write(false);
    this->data_pin_->digital_write((value >> (7 - i)) & 0x01); // Bit für Bit senden
    this->clock_pin_->digital_write(true);
  }
}


esphome:
  name: nixie_clock
  platform: ESP32
  board: esp32dev
  includes:
    - "display_driver.cpp"

wifi:
  ssid: !secret wifi_ssid
  password: !secret wifi_password

  # Wenn kein WLAN verfügbar ist, starte einen Access Point
  ap:
    ssid: "NixieClockSetup"
    password: "setup1234"

  # WLAN-Zugangsdaten über Weboberfläche einstellbar
captive_portal:

web_server:
  port: 80

# OTA-Updates
ota:
  platform: esphome

# Logging für Debugging
logger:

# GPIOs für das Schieberegister
output:
  - platform: gpio
    pin: GPIO23
    id: data_pin
  - platform: gpio
    pin: GPIO18
    id: latch_pin
  - platform: gpio
    pin: GPIO5
    id: clock_pin

# WS2812-LED-Steuerung
light:
  - platform: fastled_clockless
    chipset: WS2812
    pin: GPIO19
    num_leds: 4
    rgb_order: GRB
    name: "Nixie LEDs"

# Internetzeit abrufen
time:
  - platform: sntp
    id: sntp_time
    on_time:
      - seconds: 0
        minutes: /1
        then:
          - lambda: |-
              auto now = id(sntp_time).now();
              id(display_driver)->update_time(now.hour, now.minute);

custom_component:
  - id: display_driver
    lambda: |-
      auto *driver = new DisplayDriver(id(data_pin), id(clock_pin), id(latch_pin));
      App.register_component(driver);
      return driver;

binary_sensor:
  - platform: status
    name: "Nixie Clock Status"

sensor:
  - platform: uptime
    name: "Betriebsstunden"
    unit_of_measurement: "h"
    filters:
      - multiply: 0.00027778

text_sensor:
  - platform: wifi_info
    ip_address:
      name: "IP-Adresse"
    ssid:
      name: "WLAN-SSID"
