A blueprint that drives a light (or light group) through a gentle daily cycle:
- Sunset — fade gradually from 1% up to your target brightness
- Late evening — fade gradually back down to 1%
- Just after — hard-off
Color holds at a single configurable RGB value the whole time. Default is warm amber (255, 147, 41) — roughly 2200K, a candle / old sodium-streetlight feel that's easy on the eyes and good for outdoor accent lighting.
Import
Or paste this URL into Settings → Automations & Scenes → Blueprints → Import Blueprint:
https://magikh0e.pl/pubHomeAutomation/blueprints/outdoorLightsSunsetFade.yaml.txt
The HA quirk it solves
A transition: on a light that's currently off doesn't animate — it snaps straight to the target brightness. The blueprint works around it with a two-step turn-on:
- Call 1:
brightness_pct: 1, no transition → establishes the "on" state - 5-second settle
- Call 2:
brightness_pct: <target>with the full transition → the actual animated fade-in
The fade-out side doesn't need the trick (the light's already on, so a single transition from any non-off state works). If you've ever wondered why your sunrise/sunset fades "jump" instead of ramping, this is why.
What's configurable
Light
- Light or light group entity (use a
light: - platform: groupfor synchronised multi-bulb setups) - Color (RGB) — defaults to warm amber
- Target brightness — defaults to 50%
Sunset fade-in
- Sunset trigger offset (e.g.
-00:20:00= 20 min before astronomical sunset) - Fade-in duration — default 1800s (30 min)
- Optional "skip when the sky is still bright" gate — uses sun elevation, so high-summer evenings where astronomical sunset fires while it's still bright outside don't kick the lights on early. Configurable elevation threshold.
Late-evening fade-out
- Fade-out start time — default 23:30
- Fade-out duration — default 1800s (30 min)
- Hard-off time — default 00:00 (set to fade-out start + duration, or a touch later)
Sensible guards built in: the fade-out branch skips if the light's already off (so it doesn't turn a manually-off light back on at 1%), and the elevation gate has a | float(99) fallback so a momentary sun.sun attribute blip can't silently swallow the trigger.
Full blueprint YAML
blueprint:
name: Outdoor Lights — Sunset Fade-in / Overnight Fade-out
description: >
Drives a light or light group through a daily sunset-to-midnight cycle:
fade in at sunset, fade out at a configurable late-evening time, hard-off
at a configurable post-fade time. Configurable color, brightness, durations,
sunset offset, and an optional sun-elevation gate so high-summer evenings
don't kick the lights on while it's still bright outside.
domain: automation
source_url: https://magikh0e.pl/pubHomeAutomation/blueprints/outdoorLightsSunsetFade.yaml.txt
input:
light_section:
name: Light
icon: mdi:lightbulb-on-outline
input:
light_entity:
name: Light or light group
description: >
Single light entity, or a `light: - platform: group` that combines
multiple bulbs into one logical entity.
selector:
entity:
filter:
- domain: light
rgb_color:
name: Color (RGB)
description: >
Color used throughout the cycle. Default 255,147,41 = warm amber.
default: [255, 147, 41]
selector:
color_rgb:
target_brightness_pct:
name: Target brightness (%)
description: Brightness reached at the end of the fade-in.
default: 50
selector:
number:
min: 1
max: 100
step: 1
unit_of_measurement: "%"
mode: slider
fade_in_section:
name: Sunset fade-in
icon: mdi:weather-sunset-down
input:
sunset_offset:
name: Sunset trigger offset
description: "Negative = earlier, positive = later. Format HH:MM:SS."
default: "00:00:00"
selector:
text:
fade_in_seconds:
name: Fade-in duration (seconds)
description: "Ramp time from 1% to target. Default 1800 = 30 min."
default: 1800
selector:
number:
min: 1
max: 3600
step: 1
unit_of_measurement: "s"
mode: box
require_dark:
name: Skip when the sky is still bright
description: >
Optional gate: only run the fade-in if the sun's elevation is below
the threshold below.
default: false
selector:
boolean:
dark_elevation:
name: Dark-sky elevation threshold (degrees)
description: "Default 3°. Lower (-3° to 0°) waits for proper darkness."
default: 3
selector:
number:
min: -20
max: 20
step: 0.5
unit_of_measurement: "°"
mode: slider
fade_out_section:
name: Late-evening fade-out
icon: mdi:weather-night
input:
fade_out_time:
name: Fade-out start time
description: "When the lights start dimming down. Default 23:30."
default: "23:30:00"
selector:
time:
fade_out_seconds:
name: Fade-out duration (seconds)
description: "Ramp time back down to 1%. Default 1800 = 30 min."
default: 1800
selector:
number:
min: 1
max: 3600
step: 1
unit_of_measurement: "s"
mode: box
turn_off_time:
name: Hard-off time
description: >
Issues a hard light.turn_off after the fade-out. Default 00:00.
Set to fade-out time + duration, or slightly later.
default: "00:00:00"
selector:
time:
mode: single
max_exceeded: silent
trigger:
- platform: sun
event: sunset
offset: !input sunset_offset
id: sunset_fade_in
- platform: time
at: !input fade_out_time
id: fade_out_start
- platform: time
at: !input turn_off_time
id: turn_off
variables:
require_dark: !input require_dark
dark_elevation: !input dark_elevation
action:
- choose:
# Branch 1: SUNSET FADE-IN
- conditions:
- condition: trigger
id: sunset_fade_in
- condition: template
value_template: >-
{{ not require_dark
or is_state('sun.sun', 'below_horizon')
or (state_attr('sun.sun', 'elevation') | float(99) < dark_elevation) }}
sequence:
- action: light.turn_on
target:
entity_id: !input light_entity
data:
brightness_pct: 1
rgb_color: !input rgb_color
- delay:
seconds: 5
- action: light.turn_on
target:
entity_id: !input light_entity
data:
brightness_pct: !input target_brightness_pct
rgb_color: !input rgb_color
transition: !input fade_in_seconds
# Branch 2: LATE-EVENING FADE-OUT
- conditions:
- condition: trigger
id: fade_out_start
- condition: state
entity_id: !input light_entity
state: "on"
sequence:
- action: light.turn_on
target:
entity_id: !input light_entity
data:
brightness_pct: 1
transition: !input fade_out_seconds
# Branch 3: HARD-OFF AFTER FADE-OUT
- conditions:
- condition: trigger
id: turn_off
sequence:
- action: light.turn_off
target:
entity_id: !input light_entity
Companion guide
There's a longer write-up with a three-stage step-fade variant (20% → 60% → 100% across the first hour, instead of one smooth ramp), a color reference with RGB values for cool-white / coral / security-white / garden-green, and a troubleshooting table for the usual snags (location not set, transitions not honoured, bulbs that won't go below a brightness floor):
Feedback / improvements welcome — happy to fold fixes back in.
