Read Tibber Pulse Bridge data from your LAN (no external web API) directly in your HA

If you like to access the data of your Tibber Pulse directly (instead via the detour through the cloud), then there is quite a simple approach to read the data directly from the Tibber Pulse Bridge. Thanks to
@Prof.Dr.YoMan for providing the initial idea here in this post - https://community.home-assistant.io/t/query-the-tibber-pulse-bridge-locally-with-esphome-no-external-web-api - but I failed with the required ESP setup - so I created a separate integration that works stand-alone

Get all instructions & Info’s here:

7 Likes

Well, this was my final target if I ever would find enough time to get into HA custom addon programming. Now you did it. Thanks! Will try soon.

1 Like

One thing after quickly checking the code.

If you are polling often (e.g., all 1000 ms) the chance is very high that you get same data.

My ESP implementation checks for that (if the complete package is the same) and does not update the sensor values. This saves a reasonable amount of data in the DB.

I did not see the same in your implementation.

So far I do this kind of checks in none of my integrations that I have created (which actually does not mean anything) :slight_smile:

IMHO a value in the HA-DB only get’s updated if the value is actually changing to the previous one… So as data provider you do not have to care, if you provide the same data (or not) - the storage process should (&IMHO will) take care…

But again - this is just my “opinion” here - this opinion is based on the “last update” information that is shown when you open sensor details - e.g. in the case of the Net-Frequency the GUI will update the “last changed” & “last updated” dates, if the value has changed - so it can stick at 50.0 Hz for really a long time - while the other values will constantly be updated…

I haven’t looked into the actual DB in order to verify my assumption - might be cause I am running my HA installation on quite a decent hardware [i5, 6 TB SSD, 128GB RAM] together with plenty of other docker containers…

Ok, then it might be not needed. I don’t know either.

The integration is working for me, with update rate 1 second and is showing just slightly earlier as the Tibber API integration which is running in parallel.

If I rename the old energy counter entity and rename the new one to be same as the old one was, does the energy dashboard get this?

I don’t want to lose the old history in the energy dashboard. I don’t care about the Tibber API data.

this EnergyDashboard is some sort of mystery for me… I would not name entities that have different source with the “same” name…

We have some sort of similar problem with the SENEC Integration… where my recommendation is, to add the NEW entities just as additional source (and just remove the tibber original integration (if you don’t need the prices)…

Another way would be to hard-core hack the DB ids’s as it’s described here:

1 Like

Hey @marq24, great job, may I have you Tibber referral link? Would like to use it for registration to appreciate your work.

sorry for the late reply - here you go: Du wurdest eingeladen, bei Tibber mitzumachen!

Hallo Matthias,
vielen Dank fĂĽr die Anleitung um Tibber Lokal einzubinden.
Es hat ales bis zu dem Punkt funktioniert bei dem man unter HACS nach “Tibber Pule Local” suchen soll.
Hier konnte ich keinen Eintrag finden.
Kannst du mir weiter helfen?

Geht in HACS auf Integrationen (z.B. http://192.168.178.203:8123/hacs/integrations), dort oben rechts drei senkrechte Punkte > Benutzerdefinierte Repositories und dort folgendes “Integration”-Repository hinzufügen:

https://github.com/marq24/ha-tibber-pulse-local

Super, vielen Dank.
Ich bin nun einen Schritt weitergekommen.
Leider bekomme keine Verbindung. (siehe Anhang)
ich habe die IP Adresse(192.1xx.xxx.xx) eingetragen und das Passwort (xxxx-xxxx) Wenn ich im Browser die IP eigeben und unter “admin” das gleiche Passwort eintrage, komme ich auf die Seite von TibberBridge…
Was mache ich Falsch? Kannst dumir auch hier weiterhelfen?

Tibber Pulse is available in other countries than Germany, follow the guidelines and use English.

No attachment attached. But it sounds like a similar problem I had (and resolved):

Resolved here

Thank you for the tip to turn the reading head to 5h. So I actually have access to local access. :grinning:

Are there any more instructions on how to get the pulse in AP mode? I have tried everything but it doesn’t want change to a green light.

I cannot find any information about it online, it keeps sending me back to this page ;).

Do you plug/unplug using a micro usb of the ethernet? I have tried both but to no avail. Since the Tibber plugin from HA is becoming more unreliable by the day I would really like to get this working :slight_smile:

The bridge needs to be in AP (accesspoint) mode - and I am sorry - but there is only one way to plug/unplug the bridge-adapter - it’s directly plugged into the power supply?! [the bridge is the thing, with the colourful led ring]

Thanks, I totally misunderstood the fact that there is a separate bridge. I only have the pulse. I will have to look for a different approach. Thanks for the fast response! :slight_smile:

well - I was not ware that they are available seperatly?!

How about this one?

have fun with that - if you don’t find this Integration useful for you, if you are running MQTT and if the setup is also easier for you - that’s totally fine…
