Solution to TS130F curtain switch

Configuration Zigbee
1

Hi,
My shutters are controlled by Tuya TS130F zigbee switches
unfortunately, unlike the documentation, the position is 100 when the shutter is closed and 0 when the shutter is open and motor_reversal does not work.
So I created virtual shutter like this:

cover:
  - platform: template
    covers:
      volet_salon:
        device_class: shutter
        friendly_name: "volet du salon"
        position_template: "{{ (100 - state_attr('cover.shutter_1, 'position')| float )|int }}"
        open_cover:
          service: cover.open_cover
          data:
          target:
            entity_id: cover.shutter_1
        close_cover:
          service: cover.close_cover
          data:
          target:
            entity_id: cover.shutter_1
        stop_cover:
          service: cover.stop_cover
          data:
          target:
            entity_id: cover.shutter_1
        set_cover_position:
          service: cover.set_cover_position
          data:
            position: "{{ ( 100 - position )| int  }}"
          target:
            entity_id: cover.shutter_1

This works fine :slight_smile:

I wanted to make a correction so that position 50 corresponds to a median physical position of the shutter.
So I defined a parabolic law.

to find it, I physically opened the shutter halfway, and I read the position exposed by zigbee. example 36.
I defined my law by 3 points:
X = 100 Y = 0
X = 36 Y = 50
X = 0 Y = 100
I used an internet solver to find the equation
y = 0.0060763888888889 x² -1.6076388888889 x + 100
I modified the lines

position_template: "{{ (0.0060763*state_attr('cover.shutter_1', 'position')*state_attr('cover.shutter_1', 'position')-1.60763*state_attr('cover.shutter_1', 'position')+100| float )|int }}"

and

position: "{{ ( 0.0060763*position*position -1.60763*position+100 | float )| int  }}"

:slight_smile:

2 Likes
2

Thanks Thierry, I’m in the same situation and I’m looking for a solution as yours!
Unfortunately it doesn’t seems to work for me when I copy this yaml in configuration.yaml : I’ve got an error as “data:” attributes are empty.

Is there any trick I’ve missed?

Thanks!

3

Indeed there is a writing error here is the real yaml

        open_cover:
          service: cover.open_cover
          data: {}
          target:
            entity_id: cover.shutter_1
        close_cover:
          service: cover.close_cover
          data: {}
          target:
            entity_id: cover.shutter_1
        stop_cover:
          service: cover.stop_cover
          data: {}
          target:
            entity_id: cover.shutter_1
```
1 Like
4

Hi @thierry-rhone
I have the same problem witch my loratap curtain switch.
Can you help me.
Apparement tu es français et moi aussi donc si on peut discuter en français.
Merci

5

Hello!

I’m facing the same situation and I need help?

is this still the best solution? if so, how do I apply this fix?

thanks

6

Bonjour, bien, merci de nous avoir donné une solution à l’interrupteur de rideau TS130F.Je voulais vous demander si le pourcentage est indiqué sur la carte, car le pourcentage est toujours nul pour moi, même si cela fonctionne très bien. Merci

7

Hi Thierry,

Thanks very much, actually after your fix, this cheap controller is working better than the most expensive z-wave I tried… really good work…

8

Tried to fix the issue with my wrong position reading on my TS130F (from Moes),
As for version HA 2024.5 with ZHA with the Quirk: zhaquirks.tuya.ts130f.TuyaTS130FTI2 it seems not necessary to create such a template.
But I couldn’t manage to enter the parameters to force the TS130F considering the time difference between up and down lift.

I did use the following params, which allows to see the percentages more or less correct:

calibration = first step I did
calibration_time = second step adding the value manually did make the thing work
acceleration_time_lift = tried, but not clear to me if related to the difference up/down

There is solution, but I seems to be a bit quirky to me. I think if someone knows, more about the different available parameter it should work with no additional template.
