Sonoff seems to have a meat thermometer that is viewable in Ewelink app.
I acnnot find out what communication it has, but since they promise >180*2h on 2 AAA batteries, I would assume BLE.
Has anyone tried to connect it to HA yet?
I just received one. The eWeLink add-on says it is an unsupported device. It is BLE and I can see it if I scan, but not connect to it.
Actually, after stopping the eWeLink app (duh,) I was able to connect to it with LightBlue and got some information. Now if I can figure out what to do with it…
Fri Dec 06 12:34:20 CST 2024: LightBlue® app launched
Fri Dec 06 12:34:20 CST 2024: App foregrounded
Fri Dec 06 12:34:33 CST 2024: Connecting to 12:F1:0A:04:27:D0 (ck_10024a18a0)
Fri Dec 06 12:34:34 CST 2024: Connected to 12:F1:0A:04:27:D0 (ck_10024a18a0)
Fri Dec 06 12:34:34 CST 2024: Discovering services for 12:F1:0A:04:27:D0 (ck_10024a18a0)
Fri Dec 06 12:34:35 CST 2024: Discovered 3 services for 12:F1:0A:04:27:D0.
Fri Dec 06 12:34:35 CST 2024:
Service 00001800-0000-1000-8000-00805f9b34fb
Characteristics:
|--00002a04-0000-1000-8000-00805f9b34fb: Properties: Read
Fri Dec 06 12:34:35 CST 2024:
Service 00001801-0000-1000-8000-00805f9b34fb
Characteristics:
|--00002a05-0000-1000-8000-00805f9b34fb: Properties: Indicate
|------00002902-0000-1000-8000-00805f9b34fb: <EMPTY>
Fri Dec 06 12:34:35 CST 2024:
Service 0000aaaa-0000-1000-8000-00805f9b34fb
Characteristics:
|--0000bbb1-0000-1000-8000-00805f9b34fb: Properties: Read, Notify
|------00002902-0000-1000-8000-00805f9b34fb: <EMPTY>
|--0000bbb0-0000-1000-8000-00805f9b34fb: Properties: Write
|--0000bbb3-0000-1000-8000-00805f9b34fb: Properties: Read, Notify
|------00002902-0000-1000-8000-00805f9b34fb: <EMPTY>
|--0000bbb2-0000-1000-8000-00805f9b34fb: Properties: Write
Hey, look at me replying over and over
I’m thinking building upon the Bluetooth Trash Day Beacon will be the easiest way to get this working:
I have this set up successfully, and then added the MAC address for my thermometer (above 12:F1:0A:04:27:D0)
So I now receive MQTT messages from the thermometer.
bluecharm/publish/BC57290B0DA0 {"msg":"advData","gmac":"BC57290B0DA0","obj":[{"type":4,"dmac":"DD34020A41C8","uuid":"1B6295D54F744C58A2D8CD83CA26BDF4","majorID":3838,"minorID":4949,"refpower":-59,"rssi":-52,"time":"2024-12-07 00:03:06.272"},{"type":32,"dmac":"12F10A0427D0","data1":"0201050E09636B5F31303032346131386130","rssi":-24,"time":"2024-12-07 00:03:06.552"}]}
Using this, and copying the trash bin beacon template, so far I get the RSSI. Battery shows up as unknown, but here are my sensors:
- state_topic: "bluecharm/publish/BC57290B0DA0"
name: "BMT01 RSSI"
unique_id: "bmt01_rssi"
device_class: signal_strength
# Assume the sensor is too far away after 300 seconds of no updates
expire_after: 300
unit_of_measurement: "dBm"
# Home Assistant ignores an empty value ('') and will not update the state of the entity.
value_template: >-
{% set targetUuidFound = namespace(found=False) %}
{% for i in range(value_json.obj|count) -%}
{% if value_json.obj[i].uuid == "1B6295D54F744C58A2D8CD83CA26BDF6" and targetUuidFound.found == False %}
{{ value_json.obj[i].rssi }}
{% set targetUuidFound.found = True %}
{%- endif %}
{%- endfor %}
{% set targetUuidFound = namespace(found=False) %}
- state_topic: "bluecharm/publish/BC57290B0DA0"
name: "BMT01 battery"
unique_id: "bmt01_battery"
device_class: battery
state_class: measurement
unit_of_measurement: "%"
# Home Assistant ignores an empty value ('') and will not update the state of the entity.
# Sensor with CR2477 stops operating around is 2450 mV
# Battery starts at 3.3V. Anything over 3.0V is considered 100%.
# Assumes discharge curve is linear
# Type 8 message is (Eddystone) TLM, which contains the battery information as mV
value_template: >-
{% set targetDmacFound = namespace(found=False) %}
{% for i in range(value_json.obj|count) -%}
{% if value_json.obj[i].dmac == "DD34020A491D" and value_json.obj[i].type == 8 and targetDmacFound.found == False %}
{% set stock_voltage = 3000 %}
{% set voltage_range = 550 %}
{% set current_voltage = value_json.obj[i].vbatt %}
{% set remaining_life = 0 %}
{% if current_voltage >= stock_voltage %}
{% set remaining_life = 100 %}
{% elif current_voltage > (stock_voltage - voltage_range) %}
{% set remaining_life = int((current_voltage - (stock_voltage - voltage_range)) / voltage_range * 100) %}
{% else %}
{% set remaining_life = 0 %}
{% endif %}
{{ remaining_life | int }}
{% set targetDmacFound.found = True %}
{%- endif %}
{%- endfor %}
{% set targetDmacFound = namespace(found=False) %}
Since the BMT01 uses two AAA this will need to be adjusted once the measurement is figured out.
Hopefully someone else with one of these can pitch in and help decode the messages
Thank you for replying to yourself! We really appreciate it.
I’ve messed around some more, but not made any progress. I set up a Bluetooth sniffer and see it advertising, but I guess it switches to full bluetooth after connecting?
I did get the battery voltage working; I used the wrong DMAC in the sensor.
I just wanted to drop a note and say “Thank You” for looking into getting the BMT01 hooked up to Home Assistant. I just got one myself and would love to see it working in Home Assistant! I’ve done no BLE hacking so I don’t know that I’ll be any help getting it working, but if you need a tester, let me know.
Happy Holidays!
I started on an ESPhome project, but have not gotten too far. I’ve put what I have so far up on Github:
I welcome anyone that wants to work on it
Hi everyone, has anyone had any luck pairing this device (or something similar) with Home Assistant recently?
I currently use a Meater+ (1st gen) with my smoker, but it has only one probe and I have to use my old smartphone as the “transmitter” device. This Sonoff device looks promising, but without Home Assistant integration it doesn’t make sense for me.
After numerous attempts and using AI, unfortunately, nothing worked. I’ve written to Sonoff asking for communication details. I suggest you do the same. There will be more of us.
Sonoff email address: [email protected]
Here’s my message:
Dear Sonoff Team,
I am writing to you as a smart home enthusiast and a user of Sonoff products. I recently purchased your Sonoff BMT01 BBQ thermometer and am very impressed with its capabilities.
My goal is to integrate the BMT01 with my Home Assistant smart home system, utilizing the ESPHome platform on an ESP32 microcontroller. This integration would allow me to fully leverage the device’s potential and create advanced automations.
I have already attempted the integration by analyzing the device’s BLE communication. I successfully established a connection, discovered services (UUID 0xAAAA) and characteristics (0xBBB0, 0xBBB1, 0xBBB2, 0xBBB3), and enabled notifications for characteristics 0xBBB1 and 0xBBB3. However, despite these actions, the device does not transmit temperature data to ESPHome, whereas communication with the official eWeLink app or tools like nRF Connect works flawlessly.
I suspect that the BMT01 requires a specific initialization sequence, authorization, or key exchange that is not publicly documented.
I kindly request your assistance in providing technical documentation or guidance regarding the BLE communication protocol for the Sonoff BMT01 thermometer. Information such as:
- The complete sequence of commands (write commands) and their values that need to be sent to characteristics 0xBBB0 and 0xBBB2 (or others) to initiate data transmission.
- Details regarding the data format transmitted in notifications from characteristics 0xBBB1 and 0xBBB3.
- Any requirements for BLE pairing (bonding) or authorization.
Providing this information would significantly facilitate the integration of the BMT01 with open platforms like Home Assistant, which would undoubtedly be highly appreciated by the user community and enhance the appeal of your products.
Thank you in advance for considering my request and for any assistance you can provide.
AHi, just stumbled upon this topic as I am considering to buy one.
Have got any answer from Sonoff? Thanks for reaching out to them!
Unfortunately, there is no good news at the moment. This is the response I received:
Summary
Regarding your request, we would like to clarify that the Sonoff BMT01 BBQ Thermometer is not an open device intended for third-party or open-source platform development.
The BLE communication protocol, initialization process, authorization mechanism, and data format used by the BMT01 are proprietary and not publicly documented or released.
At present, the BMT01 is designed to work exclusively with the eWeLink app, and its normal operation (including BLE pairing, data transmission, and device management) is only supported within the eWeLink ecosystem.
BMT01 BLE Authentication
The BMT01 thermometer uses a challenge-response auth over BLE before it will send temperature data. Here’s the flow:
Setup The device has a pre-shared key (sourced from eWeLink local storage). An MD5 hash of that key is used as the AES-128 CBC encryption key, with a static all-zero IV.
Handshake (3 steps)
- Client → Device: The app generates a random UUID (
app_uuid), encrypts it with AES, and sends it as the first BLE packet (header byte0x00). - Device → Client (challenge): The device responds with a packet starting with
0x01 0x00, containing its own AES-encrypted UUID (device_uuid). The client decrypts this to get the device’s UUID. - Client → Device (confirm): The client concatenates
app_uuid + "_" + device_uuid, encrypts the combined string, and sends it back (header byte0x02). - Device → Client (accepted): If the confirm packet checks out, the device responds with
0x03, signaling auth success. The client then sends a sync command (0x21 0x00 0x00 0x00) to start receiving temperature data.
Packets are split into 20-byte BLE chunks with a 4-byte header (type byte, padding, 16-bit little-endian length).
Temperature frames are identified by a leading 0x04 byte and contain probe readings at bytes 4 and 6, where 0x88 means “no probe connected.”
How to identify the device key via a rooted android phone
A) Copy the database from the android device
adb pull /data/data/com.coolkit/databases/ ./coolkit_db/
B) Output some values from the database
for db in coolkit_db/*.db coolkit_db/RKStorage; do
echo "=== $db ==="
sqlite3 "$db" "SELECT key, value FROM catalystLocalStorage WHERE key LIKE '%secret%' OR key LIKE '%device%';" 2>/dev/null
done
C) Copy the device key
Try this code (don’t forget to change to your MAC address and your device key) and you will start receiving data
import asyncio
import uuid
import hashlib
import base64
from cryptography.hazmat.primitives.ciphers import Cipher, algorithms, modes
from bleak import BleakClient
MAC = "XX:XX:XX:XX:XX:XX"
DEVICE_KEY = "XXXXXXXX-XXXX-XXXX-XXXX-XXXXXXXXXXXX"
NOTIFY_UUID = "0000bbb1-0000-1000-8000-00805f9b34fb"
WRITE_UUID = "0000bbb0-0000-1000-8000-00805f9b34fb"
SECRET_KEY = hashlib.md5(DEVICE_KEY.encode()).hexdigest()
IV = b'0000000000000000'
APP_UUID = str(uuid.uuid4())
def aes_encrypt(plaintext: str) -> str:
key = bytes.fromhex(SECRET_KEY)
pad_len = 16 - (len(plaintext) % 16)
padded = plaintext.encode() + bytes([pad_len] * pad_len)
cipher = Cipher(algorithms.AES(key), modes.CBC(IV))
enc = cipher.encryptor()
return base64.b64encode(enc.update(padded) + enc.finalize()).decode()
def aes_decrypt(b64_data: str) -> str:
key = bytes.fromhex(SECRET_KEY)
ct = base64.b64decode(b64_data)
cipher = Cipher(algorithms.AES(key), modes.CBC(IV))
dec = cipher.decryptor()
raw = dec.update(ct) + dec.finalize()
return raw[:-raw[-1]].decode()
async def send_chunks(client, data_bytes, msg_type):
header = bytes([msg_type, 0x00, len(data_bytes) & 0xFF, (len(data_bytes) >> 8) & 0xFF])
full = header + data_bytes
for i in range(0, len(full), 20):
await client.write_gatt_char(WRITE_UUID, full[i:i+20], response=False)
await asyncio.sleep(0.05)
async def notification_handler(sender, data):
print(f"RX Raw: {data.hex().upper()}")
# Auth Challenge handling
if len(data) >= 2 and data[0] == 0x01 and data[1] == 0x00:
try:
device_code = data[4:].decode('ascii', errors='ignore').strip('\x00')
device_uuid = aes_decrypt(device_code)
confirm_payload = aes_encrypt(f"{APP_UUID}_{device_uuid}").encode()
await send_chunks(sender_client, confirm_payload, 0x02)
except:
pass
# Auth Accepted -> Send Sync
elif len(data) >= 1 and data[0] == 0x03:
await sender_client.write_gatt_char(WRITE_UUID, bytes([0x21, 0x00, 0x00, 0x00]), response=False)
async def main():
global sender_client
async with BleakClient(MAC, timeout=20) as client:
sender_client = client
await client.start_notify(NOTIFY_UUID, notification_handler)
# Initial Auth Request
app_code = aes_encrypt(APP_UUID).encode()
await send_chunks(client, app_code, 0x00)
print("Authenticated. Monitoring raw traffic...")
while True:
await asyncio.sleep(1)
if __name__ == "__main__":
asyncio.run(main())
What’s next
- Understand how to decode the data
- Add the ability to send target temperature commands
- Add the ability to acknowledge an alarm
I have got these target temperature send commands
20 C: 05010e00369d38a244ada96f0d7672c11597
25 C: 05010e00369f38a249ada06f00767bc11597
32 C: 05010e00369c38a270adb76f39766cc11597
60 C: 05010e00369f38a26cad616f2576bac11597
61 C: 05010e00369c38a26dad636f2476b8c11597
62 C: 05010e00369b38a26ead7d6f2776a6c11597
63 C: 05010e00369838a26fad7c6f2676a7c11597
64 C: 05010e00369938a210ad7e6f5976a5c11597
65 C: 05010e00368638a211ad786f5876a3c11597
66 C: 05010e00368738a212ad7a6f5b76a1c11597
67 C: 05010e00368438a213ad746f5a76afc11597
68 C: 05010e00368538a214ad776f5d76acc11597
69 C: 05010e00368238a215ad716f5c76aac11597
70 C: 05010e00368338a216ad736f5f76a8c11597
71 C: 05010e00369c38a217ad4d6f5e7696c11597
72 C: 05010e00368038a218ad4f6f517694c11597
73 C: 05010e00368138a219ad4e6f507695c11597
74 C: 05010e00369d38a21aad486f537693c11597
And this sequence was sent to acknowledge an alarm
1c010200369a
Goddamnit you were faster than me few days. Almost cracked this one…
At least I can share this below that I came up with.
BLE temperature payload for a 4-probe thermometer.
The useful simplification is that all probes seem to use the same temperature decoder. Probes 2–4 are just XOR-scrambled first.
Probe masks
PROBE_RAW_MASK = {
1: 0x00,
2: 0xC3,
3: 0x73,
4: 0xBB,
}
PROBE_STATUS_MASK = {
1: 0x00,
2: 0x11,
3: 0xAF,
4: 0x62,
}
First convert the probe byte to the common/canonical format:
canonical_raw = raw ^ PROBE_RAW_MASK[probe]
canonical_status = status_raw ^ PROBE_STATUS_MASK[probe]
Temperature decoding
The low 5 bits are the temperature code:
code = canonical_raw & 0x1F
def decode_canonical_temp(canonical_raw, canonical_status=0x28):
# Over-range / HHH seen on the device display
if canonical_raw == 0xF1 and canonical_status == 0xD7:
return "HHH"
if canonical_status not in (0x28, 0x29):
return None
code = canonical_raw & 0x1F
effective_raw = canonical_raw
if canonical_status == 0x29:
effective_raw += 0x100
if effective_raw < 0x30:
base = 47
else:
bank = (effective_raw - 0x30) // 0x20
base = 79 + bank * 32
temp_c = base - code
if temp_c >= 300:
return "HHH"
return temp_c
Full probe decoder
def decode_probe(raw, probe, status_raw=0x28):
canonical_raw = raw ^ PROBE_RAW_MASK[probe]
canonical_status = status_raw ^ PROBE_STATUS_MASK[probe]
return decode_canonical_temp(canonical_raw, canonical_status)
Temperature packet depending on probe decoder
def decode_temp_packet(data):
if len(data) != 14:
return None
if not (data[0] == 0x04 and data[1] == 0x01 and data[2] == 0x0A and data[3] == 0x00 and data[4] == 0x82):
return None
body = data[4:]
probes = {}
for probe in range(1, 5):
idx = 2 + (probe - 1) * 2
raw = body[idx]
status = body[idx + 1]
probes[probe] = decode_probe(raw, probe, status)
return probes
To check with above method of connecting - modify notification handler with
async def notification_handler(sender, data):
print(f"RX Raw: {data.hex().upper()}")
probes = decode_temp_packet(data)
if probes is not None:
for probe, temp in probes.items():
if temp is None:
continue
if isinstance(temp, str):
print(f"probe={probe}, temperature={temp}")
else:
print(f"probe={probe}, temperature={temp}C")
return
if len(data) >= 2 and data[0] == 0x01 and data[1] == 0x00:
try:
device_code = data[4:].decode('ascii', errors='ignore').strip('\x00')
device_uuid = aes_decrypt(device_code)
confirm_payload = aes_encrypt(f"{APP_UUID}_{device_uuid}").encode()
await send_chunks(sender_client, confirm_payload, 0x02)
except:
pass
elif len(data) >= 1 and data[0] == 0x03:
await sender_client.write_gatt_char(WRITE_UUID, bytes([0x21, 0x00, 0x00, 0x00]), response=False)
Notes
- Probe 1 uses the raw/status bytes directly.
- Probes 2–4 appear to require XOR normalization before decoding.
- After normalization, all probes appear to use the same temperature decoder.
0x28is the normal status in my captures.0x29appears to indicate a higher temperature bank, so0x100is added before bank calculation.- (canonical_raw, canonical_status) == (
0xF1,0xD7) appears to map to the device’sHHHover-range display state. - Works for me, but this is still reverse-engineered, so your mileage may vary.
Good work! I fill in with some news too. I decompiled the index.android.bundle file (inside the bundled apk file). That file includes all logic, but still not found exactly how to decode… but maybe this could be helpful anyway
class CommonCommand:
BLEWIFI_REQ_AUTH = 0x00
AUTH_RESPONSE = 0x01
BLEWIFI_AUTH_TOKEN = 0x02
BLEWIFI_TOKEN_RESPONSE = 0x03
HEARTBEAT = 0x1D # device-initiated keepalive, no pong needed
OTA_VERSION_REQUEST = 0x21 # also used as sync/ping after auth
OTA_VERSION_RESPONSE = 0x22 # also received as keepalive/ack
OTA_CONFIRM_REQUEST = 0x23
OTA_CONFIRM_RESPONSE = 0x24
OTA_FINISH_REQUEST = 0x25
OTA_FINISH_RESPONSE = 0x26
# High byte shared by all ControlCommands — used as packet type in framing.
CONTROL_CMD_HIGH = 0x01
class ControlCommand:
BATTERY_LEVEL_REQUEST = 0x0101
BATTERY_LEVEL_RESPONSE = 0x0102
PROBE_TEMPERATURE_REQUEST = 0x0103
PROBE_TEMPERATURE_RESPONSE = 0x0104 # inbound 0x04 packets
PROBE_PRESET_SETTING = 0x0105
ALARM_NOTIFY = 0x0106
HISTORY_REQUEST = 0x0107
HISTORY_RESPONSE = 0x0108 # inbound 0x08 packets
CLEAR_HISTORY = 0x0109
TEMPERATURE_CALIBRATION_SETTING = 0x0111
TEMPERATURE_CALIBRATION_REQUEST = 0x0113
TEMPERATURE_CALIBRATION_RESPONSE = 0x0114
ADVANCE_ALARM_REQUEST = 0x0115
ADVANCE_ALARM_RESPONSE = 0x0116
ADVANCE_ALARM_SETTING = 0x0117
TEMPERATURE_UNIT_REQUEST = 0x0119
TEMPERATURE_UNIT_RESPONSE = 0x011A
TEMPERATURE_UNIT_SETTING = 0x011B
CANCEL_ALARM_REQUEST = 0x011C
CANCEL_ALARM_RESPONSE = 0x011D
COMMON_RESPONSE = 0xFFFF
class CommonStatusCode:
SUCCESS = 0
FAILURE = 1
NOT_AUTHORIZED = 2
TIMEOUT = 3
SEND_FAIL = 4
class TemperatureUnit:
CELSIUS = 0
FAHRENHEIT = 1
class ProbePresetType:
EMPTY = 0
UPPER_TEMP = 1
RANGE = 2
class AlarmType:
REACH = 0
ADVANCE = 1
BEYOND = 2
# Probe sentinel values (ProbeTemperature enum from official protocol)
PROBE_SENTINELS = {
0xFFFF: 'not_connected',
0xFFFE: 'too_high',
0xFFFD: 'too_low',
0x0FFF: 'invalid',
}
The device does not accept plain commands like:
01 01 00 00
Even though the APK names the command as 0x0101 for battery, the real BLE command needs a small rolling “permission byte” taken from the device’s live telemetry.
The normal flow is:
1. Connect
2. Enable notifications on bbb1 / bbb3
3. Authenticate
4. Send sync: 21 00 00 00
5. Device starts sending live probe/temperature telemetry
A live telemetry packet looks like this:
04 01 0A 00 82 XX ...
The important byte is XX.
To send a command, you reuse that XX like this:
<command_low> 01 <payload_len> 00 89 XX ...
So for battery, command 0x0101, it becomes:
01 01 02 00 89 XX
The response comes back with the same XX, but 89 becomes 8E:
02 01 03 00 8E XX <battery_byte>
So the command exchange is basically:
Device telemetry: 04 01 0A 00 82 XX ...
Client command: 01 01 02 00 89 XX
Device response: 02 01 03 00 8E XX ...
The catch: the XX byte is single-use. If you reuse the same XX, the device often ignores the command.
So the client should do this:
Wait for next live telemetry packet.
Read the byte after 82.
Use it once in a command.
Wait for the matching response with 8E and the same byte.
For the next command, wait for another telemetry packet and use a new byte.
The client should not use history packets as the token source. History packets also contain 82 XX, but they can confuse the command pipeline. The reliable source is the live probe/temperature telemetry:
04 01 0A 00 82 XX ...
Example commands:
Battery request:01 01 02 00 89 XX
Probe/temperature request:03 01 02 00 89 XX
Calibration request:13 01 02 00 89 XX
Advance alarm request:15 01 02 00 89 XX
Temperature unit request:19 01 02 00 89 XX
I did only test battery and temp unit setup. Others possibly need extra payload byte, like temperature unit setting below:
Set Fahrenheit:
1B 01 03 00 89 XX 0E
Set Celsius:
1B 01 03 00 89 XX 0F
A successful setting command returns a common response:
FF FF 04 00 8E XX ...
A practical way to describe it:
The thermometer broadcasts a fresh ticket every couple of seconds in its temperature notification.
To ask it for battery, unit, calibration, etc., the client must include the latest unused ticket in the request.
Once a ticket is used, throw it away and wait for the next one.
I do have local client rolling for this, but I need to take a break. Been focused too much on this. But your commands were helpful, so no worries.
Small update: you don’t need to disassemble the APK or pull the local eWeLink database just to get the auth key for an already paired BMT01.
For now, I’m using my own small local wrapper that logs into eWeLink with my own credentials, checks whether the account has a paired BMT01, and then prints the account apikey. I don’t have a clean, shareable version of that wrapper yet, so I’m not publishing it right now.
The general flow is:
- Pair the BMT01 normally in the eWeLink app.
- Get your eWeLink account
apikey. - Use that
apikeyin the scripts above.
For getting the apikey, you can use other existing options, for example:
- eWeLink OAuth demo:
https://github.com/nocmt/eWeLinkOAuthLoginDemo - AlexxIT SonoffLAN, which already talks to the eWeLink cloud and stores synced device/account data locally:
https://github.com/AlexxIT/SonoffLAN
I’ll try to clean up my wrapper into something safer and easier to share later.
Here's an updated code (expect some bugs; what's not working reliable: using °F, calibration command, temperature alarm after pressing the button on device). Would be nice with a persistent pairing (to avoid paring at each run, you need to hold the button for 7 sec on the device each time now) and a Home Assistant extension. Don't forget to change to your MAC address and your device id in the code before you run it
"""
eWeLink BMT01 BLE BBQ Thermometer Client version 2026-05-06
===========================================================
Re-implemented from the eWeLink JS bundle (output.js, Hermes bytecode).
Auth channel:
AES-128-CBC, key=MD5(apikey).hexdigest() → bytes, IV=b'0000000000000000'
Control channel:
Inbound/outbound frame format:
[cmd_lo, cmd_hi, len_lo, len_hi, ...XOR-encrypted-payload...]
XOR key: MD5(apikey) as 16 raw bytes, applied per 16-byte block
→ encryptUtils.encrypt/decrypt in output.js (line 5384648)
→ convertMD5ToBytes(MD5(apikey).toString()) in output.js
Payload: [flags_byte, rx_tsn, ...payloadContent...]
flags byte: bit0 = source (0=APP, 1=DEVICE)
bit1 = needResponse (0=False, 1=True)
(byteToBits LSB-first, output.js line 638586)
Temperature (PUSH, source=DEVICE, byte5=0xD4):
payload_content = [lo1,hi1, lo2,hi2, lo3,hi3, lo4,hi4]
uint16 LE = °C directly. Sentinels: 0xFFFF NOT_ACTIVE, 0xFFFE TOO_HIGH,
0xFFFD TOO_LOW, 0x0FFF INVALID.
Temperature (RESP, source=APP, byte5=0x3D):
Same uint16-LE °C values but each probe's two bytes are XOR'd with a
per-probe 2-byte mask before embedding in the payload. Masks are
device-specific: mask[i] = MD5(apikey)[2+i*2:4+i*2] XOR secondary_key[i*2:i*2+2]
where secondary_key = 38 A3 50 AD ED 6F 19 76 (firmware constant).
For this device: P1=BD 72 P2=1E 02 P3=13 DE P4=6A 94.
The same masks apply to PROBE_PRESET_SETTING outbound payloads.
GATT:
bbb0 = WRITE (TX) bbb1 = NOTIFY (RX) bbb3 = NOTIFY2 (RX, secondary)
Source bit semantics:
source=DEVICE (bit0=1) → autonomous periodic push (byte5=0xD4)
source=APP (bit0=0) → device response after button press (byte5=0x3D)
New in v8:
Temperature unit (TEMPERATURE_UNIT_SETTING = 283):
payload = [0=Celsius | 1=Fahrenheit]
Range alarm (ADVANCE_ALARM_SETTING = 279):
payload = [wire_probe (0-based), lower_c_lo, lower_c_hi, upper_c_lo, upper_c_hi]
Use 0xFFFF for disabled bounds.
Battery (BATTERY_LEVEL_REQUEST = 257):
No payload; response byte[0] = battery %.
Calibration (TEMPERATURE_CALIBRATION_SETTING = 273):
payload = 4 × [celsius_lo, celsius_hi_sign, fahrenheit_lo, fahrenheit_hi_sign]
Sign-magnitude: bit15=1 → positive, bit15=0 → negative.
Fahrenheit offset = celsius_offset × 9/5 (rounded to integer).
"""
import asyncio
import base64
import hashlib
import struct
import sys
import time
import uuid
import builtins
import threading
from datetime import datetime
from bleak import BleakClient, BleakError
from cryptography.hazmat.primitives.ciphers import Cipher, algorithms, modes
try:
import readline
except ImportError:
readline = None
_orig_print = builtins.print
_print_lock = threading.Lock()
_awaiting_input = False
def _coordinated_print(*args, **kwargs):
"""Print with coordination for terminal output, preserving user input."""
global _awaiting_input
if kwargs.get('file', sys.stdout) in (None, sys.stdout):
with _print_lock:
if _awaiting_input:
# Save current input buffer if readline is available
input_buffer = ""
if readline:
input_buffer = readline.get_line_buffer()
# Clear the current input line
sys.stdout.write('\r' + ' ' * 120 + '\r')
sys.stdout.flush()
_orig_print(*args, **kwargs)
if _awaiting_input:
# Restore prompt and input buffer
sys.stdout.write("cmd> " + input_buffer)
sys.stdout.flush()
else:
_orig_print(*args, **kwargs)
builtins.print = _coordinated_print
MAC = "XX:XX:XX:XX:XX:XX"
DEVICE_KEY = "XXXXXXXX-XXXX-XXXX-XXXX-XXXXXXXXXXXX"
NOTIFY_UUID = "0000bbb1-0000-1000-8000-00805f9b34fb"
NOTIFY_UUID2 = "0000bbb3-0000-1000-8000-00805f9b34fb"
WRITE_UUID = "0000bbb0-0000-1000-8000-00805f9b34fb"
POLL_INTERVAL = 3
_AES_KEY = bytes.fromhex(hashlib.md5(DEVICE_KEY.encode()).hexdigest())
_AES_IV = b'0000000000000000'
_XOR_KEY = hashlib.md5(DEVICE_KEY.encode()).digest()
APP_UUID = str(uuid.uuid4())
_tx_tsn = 0
def _next_tsn() -> int:
global _tx_tsn
tsn = _tx_tsn
_tx_tsn = (_tx_tsn + 1) % 256
return tsn
_last_push_probes: list[dict] | None = None
_ticket_queue: asyncio.Queue[int] | None = None
_last_ticket: int | None = None
_last_ticket_mono: float = 0.0
_pending_ticket_responses: dict[int, asyncio.Future[dict]] = {}
_client: BleakClient | None = None
_last_marker: int | None = None
_last_battery_pct: int | None = None
# Calibration offsets (°C) per probe, cached from last CALIBRATION_RESPONSE
_calibration_offsets: list[float] = [0.0, 0.0, 0.0, 0.0]
def _aes_encrypt(plaintext: str) -> str:
pad = 16 - (len(plaintext) % 16)
padded = plaintext.encode() + bytes([pad] * pad)
cipher = Cipher(algorithms.AES(_AES_KEY), modes.CBC(_AES_IV))
enc = cipher.encryptor()
return base64.b64encode(enc.update(padded) + enc.finalize()).decode()
def _aes_decrypt(b64: str) -> str:
ct = base64.b64decode(b64)
cipher = Cipher(algorithms.AES(_AES_KEY), modes.CBC(_AES_IV))
dec = cipher.decryptor()
raw = dec.update(ct) + dec.finalize()
return raw[:-raw[-1]].decode()
def _xor_crypt(data: bytes) -> bytes:
out = bytearray()
for start in range(0, len(data), 16):
block = data[start:start + 16]
for i, b in enumerate(block):
out.append(b ^ _XOR_KEY[i])
return bytes(out)
class CC:
BATTERY_LEVEL_REQUEST = 257
BATTERY_LEVEL_RESPONSE = 258
PROBE_TEMPERATURE_REQUEST = 259
PROBE_TEMPERATURE_RESPONSE = 260
PROBE_PRESET_SETTING = 261
ALARM_NOTIFY = 262
HISTORY_REQUEST = 263
HISTORY_RESPONSE = 264
CLEAR_HISTORY = 265
TEMPERATURE_CALIBRATION_SETTING = 273
TEMPERATURE_CALIBRATION_REQUEST = 275
TEMPERATURE_CALIBRATION_RESPONSE = 276
ADVANCE_ALARM_REQUEST = 277
ADVANCE_ALARM_RESPONSE = 278
ADVANCE_ALARM_SETTING = 279
TEMPERATURE_UNIT_REQUEST = 281
TEMPERATURE_UNIT_RESPONSE = 282
TEMPERATURE_UNIT_SETTING = 283
CANCEL_ALARM_REQUEST = 284
CANCEL_ALARM_RESPONSE = 285
COMMON_RESPONSE = 65535
_CC_NAMES = {v: k for k, v in vars(CC).items() if not k.startswith('_')}
_PROBE_SENTINELS = {
0xFFFF: 'NOT_ACTIVE',
0xFFFE: 'TOO_HIGH',
0xFFFD: 'TOO_LOW',
0x0FFF: 'INVALID',
}
_RESP_SECONDARY_KEY = bytes([0x38, 0xA3, 0x50, 0xAD, 0xED, 0x6F, 0x19, 0x76])
_RESP_PROBE_MASKS = [
bytes([_XOR_KEY[2 + i*2] ^ _RESP_SECONDARY_KEY[i*2],
_XOR_KEY[3 + i*2] ^ _RESP_SECONDARY_KEY[i*2 + 1]])
for i in range(4)
]
# Marker 0xD2 frames (raw, post-button-press temperature pushes) use these
# device-specific per-probe masks applied directly to the bytes (no XOR layer).
# Verified empirically against this device's pre-button-press D4 readings.
_D2_PROBE_MASKS = [
bytes([0x4B, 0x94]),
bytes([0x47, 0xAD]),
bytes([0xFC, 0x93]),
bytes([0x3F, 0xDA]),
]
def _unmask_resp_payload(payload_content: bytes) -> bytes:
out = bytearray()
for i, mask in enumerate(_RESP_PROBE_MASKS):
ofs = i * 2
if ofs + 1 >= len(payload_content):
break
out.append(payload_content[ofs] ^ mask[0])
out.append(payload_content[ofs + 1] ^ mask[1])
return bytes(out)
def _unmask_d2_payload(raw_probe_bytes: bytes) -> bytes:
"""Apply D2-specific per-probe masks to raw (non-XOR'd) probe data."""
out = bytearray()
for i, mask in enumerate(_D2_PROBE_MASKS):
ofs = i * 2
if ofs + 1 >= len(raw_probe_bytes):
break
out.append(raw_probe_bytes[ofs] ^ mask[0])
out.append(raw_probe_bytes[ofs + 1] ^ mask[1])
return bytes(out)
NO_ALARM = 0x0100
_alarm_targets: list[int | None] = [None, None, None, None]
PRESET_EMPTY = 0
PRESET_UPPER_TEMP = 1
PRESET_RANGE = 2
WIRE_PROBE_INDEX_BASE = 0
def _build_preset_payload(targets: list[int | None]) -> bytes:
probe = bytearray()
for i in range(4):
t = NO_ALARM if (i >= len(targets) or targets[i] is None) else int(targets[i])
lo, hi = t & 0xFF, (t >> 8) & 0xFF
probe.append(lo ^ _RESP_PROBE_MASKS[i][0])
probe.append(hi ^ _RESP_PROBE_MASKS[i][1])
x0 = 0xDA
for b in probe:
x0 ^= b
return bytes(probe) + bytes([x0, 0x1E, 0x60, 0xA8])
def _le16(value: int) -> bytes:
return struct.pack('<H', int(value) & 0xFFFF)
def _build_probe_alarm_payload(probe: int, lower_c: int | None, upper_c: int | None) -> bytes:
wire_probe = probe - 1
if lower_c is None and upper_c is None:
preset_type = PRESET_EMPTY
l_c = l_f = u_c = u_f = NO_ALARM
elif lower_c == upper_c:
preset_type = PRESET_UPPER_TEMP
u_c = int(upper_c)
u_f = round(u_c * 9 / 5 + 32)
l_c, l_f = u_c, u_f
else:
preset_type = PRESET_RANGE
l_c = int(lower_c)
l_f = round(l_c * 9 / 5 + 32)
u_c = int(upper_c)
u_f = round(u_c * 9 / 5 + 32)
return (
bytes([wire_probe, preset_type])
+ _le16(l_c) + _le16(l_f)
+ _le16(u_c) + _le16(u_f)
+ _le16(0) + bytes([0]) # timer
)
# --- Temperature unit -------------------------------------------------------
def _build_temp_unit_payload(use_fahrenheit: bool) -> bytes:
return bytes([1 if use_fahrenheit else 0])
# Confirmed from bytesToAdvanceAlarm: response byte[0] is AdvanceAlarmEnable.ENABLE=1
# This is a global (device-wide) alarm, not per-probe.
# ---------------------------------------------------------------------------
def _build_advance_alarm_payload(lower_c: int | None, upper_c: int | None) -> bytes:
if lower_c is None and upper_c is None:
return bytes([0, 0, 0, 0, 0]) # DISABLE
enable = 1
lower = lower_c if lower_c is not None else 0xFFFF
upper = upper_c if upper_c is not None else 0xFFFF
return struct.pack('<B', enable) + _le16(lower) + _le16(upper)
# ---------------------------------------------------------------------------
# Calibration encoding (sign-magnitude, bit15=1→positive, bit15=0→negative)
# ---------------------------------------------------------------------------
def _calibration_value_to_bytes(value: float) -> bytes:
abs_val = int(round(abs(value)))
abs_val = min(abs_val, 0x7FFF)
lo = abs_val & 0xFF
hi = (abs_val >> 8) & 0x7F
if value >= 0:
hi |= 0x80 # bit15 = 1 → positive
return bytes([lo, hi])
def _calibration_bytes_to_value(data: bytes) -> float:
lo = data[0]
hi = data[1]
positive = bool(hi & 0x80)
hi_clean = hi & 0x7F
magnitude = lo | (hi_clean << 8)
return float(magnitude) if positive else -float(magnitude)
def _parse_calibration_response(payload: bytes) -> list[dict]:
calibrations = []
for i in range(4):
ofs = i * 4
if ofs + 3 >= len(payload):
break
c = _calibration_bytes_to_value(payload[ofs:ofs + 2])
f = _calibration_bytes_to_value(payload[ofs + 2:ofs + 4])
calibrations.append({'celsius': c, 'fahrenheit': f})
return calibrations
def _build_calibration_payload(offsets_c: list[float]) -> bytes:
payload = bytearray()
for i in range(4):
oc = offsets_c[i] if i < len(offsets_c) else 0.0
of_ = round(oc * 9 / 5)
payload += _calibration_value_to_bytes(oc)
payload += _calibration_value_to_bytes(float(of_))
return bytes(payload)
def _extract_control_message(data: bytes) -> dict | None:
if len(data) < 4:
return None
command = struct.unpack_from('<H', data, 0)[0]
data_length = struct.unpack_from('<H', data, 2)[0]
decrypted = _xor_crypt(data[4:])
if data_length != len(decrypted):
print(f"[WARN] control frame length mismatch: expected={data_length} got={len(decrypted)}")
return None
flags = decrypted[0]
raw_flags = flags
source = flags & 0x01
need_response = (flags >> 1) & 0x01
rx_tsn = decrypted[1]
payload_content = bytes(decrypted[2:])
return {
'command': command,
'name': _CC_NAMES.get(command, f'0x{command:04X}'),
'flags': raw_flags,
'source': source,
'need_response': need_response,
'rx_tsn': rx_tsn,
'payload_content': payload_content,
}
def _decode_probe(raw: int) -> dict:
sentinel = _PROBE_SENTINELS.get(raw)
if sentinel:
return {'status': sentinel, 'temp_c': None, 'temp_f': None,
'raw': f'0x{raw:04X}'}
temp_c = float(raw)
temp_f = round(temp_c * 9 / 5 + 32, 1)
return {'status': 'ok', 'temp_c': temp_c, 'temp_f': temp_f,
'raw': f'0x{raw:04X}'}
def _parse_probe_temperatures(payload_content: bytes) -> list[dict]:
probes = []
for i in range(0, len(payload_content) - 1, 2):
raw = struct.unpack_from('<H', payload_content, i)[0]
probes.append(_decode_probe(raw))
return probes
def _build_control_frame(command: int, need_response: bool = True,
payload_content: bytes = b'',
token_tsn: int | None = None) -> bytes:
flags = (0 << 0) | ((1 if need_response else 0) << 1)
tx_tsn = token_tsn if token_tsn is not None else _next_tsn()
raw_payload = bytes([flags, tx_tsn]) + payload_content
encrypted = _xor_crypt(raw_payload)
return struct.pack('<HH', command, len(encrypted)) + encrypted
def _command_marker_for_state() -> int:
"""Pick the command marker based on the device's current state.
Marker pattern (XOR 0x50 between normal/button-press states):
- Telemetry: 0x82 (normal) / 0xD2 (button-press) / 0xD4 (XOR push)
- Response: 0x8E (normal) / 0xDE (button-press)
- Command: 0x89 (normal) / 0xD9 (button-press)
"""
if _last_marker in (0xD2, 0xDE):
return 0xD9
return 0x89
def _mask_d9_payload(content: bytes) -> bytes:
"""Mask command payload when sending in button-press (0xD9) mode.
Mirror of _unmask_de_payload — the device expects the payload XORed
with the D2 probe-1 mask [0x4B, 0x94] applied cyclically.
"""
mask = _D2_PROBE_MASKS[0]
return bytes(b ^ mask[i % len(mask)] for i, b in enumerate(content))
def _build_ticketed_frame(command: int, ticket: int, payload_content: bytes = b'',
marker: int | None = None) -> bytes:
if marker is None:
marker = _command_marker_for_state()
if marker == 0xD9 and payload_content:
# Button-press mode: device expects payload masked like D2/DE frames
payload_content = _mask_d9_payload(payload_content)
raw_payload = bytes([marker, ticket]) + payload_content
return struct.pack('<HH', command, len(raw_payload)) + raw_payload
def _build_outputjs_control_frame(command: int, ticket: int,
payload_content: bytes) -> tuple[bytes, int]:
token_tsn = ticket ^ _XOR_KEY[1]
frame = _build_control_frame(
command,
need_response=True,
payload_content=payload_content,
token_tsn=token_tsn,
)
return frame, token_tsn
def _live_ticket_marker(data: bytes) -> int | None:
if len(data) >= 6 and data[:4] == b'\x04\x01\x0A\x00' and data[4] in (0x82, 0xD4, 0xD2):
return data[4]
return None
async def _next_ticket(timeout: float = 5.0) -> int:
"""Wait for a FRESH ticket from the next live telemetry packet.
The device sends single-use ticket bytes in each live telemetry packet.
Per protocol: each command must use a fresh ticket; reusing the same XX
causes the device to ignore the command. So we drain any stale ticket
sitting in the queue and wait for the next telemetry packet to arrive.
"""
if _ticket_queue is None:
raise TimeoutError("ticket queue is not ready")
# Drain any stale ticket from previous telemetry — we want a fresh one
try:
stale = _ticket_queue.get_nowait()
print(f"TICKET drain stale: 0x{stale:02X}")
except asyncio.QueueEmpty:
pass
try:
return await asyncio.wait_for(_ticket_queue.get(), timeout=timeout)
except asyncio.TimeoutError as e:
raise TimeoutError("timeout waiting for fresh live telemetry ticket") from e
def _offer_ticket(ticket: int):
global _last_ticket, _last_ticket_mono
_last_ticket = ticket
_last_ticket_mono = time.monotonic()
if _ticket_queue is None:
return
try:
_ticket_queue.get_nowait() # drain stale entry (maxsize=1)
except asyncio.QueueEmpty:
pass
_ticket_queue.put_nowait(ticket)
def _unmask_de_payload(content: bytes) -> bytes:
"""Decode payload of 0xDE (post-button-press) responses.
The payload bytes are masked with the same D2 probe-1 mask [0x4B, 0x94]
used for D2 telemetry pushes — applied cyclically across the payload.
Verified empirically: 0x1B ^ 0x4B = 0x50 (80% battery).
"""
mask = _D2_PROBE_MASKS[0]
return bytes(b ^ mask[i % len(mask)] for i, b in enumerate(content))
def _parse_raw_ticket_response(data: bytes) -> dict | None:
# 0x8E = normal raw response marker
# 0xDE = post-button-press raw response marker (parallel to D4/D2 telemetry)
if len(data) < 6 or data[4] not in (0x8E, 0xDE):
return None
command = struct.unpack_from('<H', data, 0)[0]
data_length = struct.unpack_from('<H', data, 2)[0]
payload = data[4:]
if data_length != len(payload):
print(f"[WARN] raw frame length mismatch: expected={data_length} got={len(payload)}")
return None
content = bytes(payload[2:])
if payload[0] == 0xDE:
# Post-button-press responses encode payload with D2 probe-1 mask
content = _unmask_de_payload(content)
msg = {
'command': command,
'name': _CC_NAMES.get(command, f'0x{command:04X}'),
'marker': payload[0],
'ticket': payload[1],
'payload_content': content,
'status': None,
}
if command == CC.COMMON_RESPONSE and len(content) >= 2:
msg['status'] = struct.unpack_from('<H', content, 0)[0]
return msg
def _finish_pending_response(ticket: int, msg: dict):
future = _pending_ticket_responses.get(ticket)
if future and not future.done():
future.set_result(msg)
async def _send_adaptive_control(command: int, payload_content: bytes = b'',
timeout: float = 7.0) -> dict:
"""Send command, adapting frame format based on device state (last marker seen).
If device is in XOR-encrypted mode (0xD4): use encrypted control frames.
Otherwise (0x82, 0xD2, unknown): use raw ticketed frames.
"""
if _last_marker == 0xD4:
return await _send_outputjs_control(command, payload_content, timeout=timeout)
else:
return await _send_ticketed_control(command, payload_content, timeout=timeout)
async def _send_ticketed_control(command: int, payload_content: bytes = b'',
timeout: float = 5.0) -> dict:
ticket = await _next_ticket(timeout=timeout)
frame = _build_ticketed_frame(command, ticket, payload_content)
loop = asyncio.get_running_loop()
response_future: asyncio.Future[dict] = loop.create_future()
_pending_ticket_responses[ticket] = response_future
print(f"TX ticket=0x{ticket:02X}: {_fmt_hex(frame)}")
try:
await _ble_write(frame)
try:
return await asyncio.wait_for(response_future, timeout=timeout)
except asyncio.TimeoutError as e:
raise TimeoutError(f"timeout waiting for response to ticket 0x{ticket:02X}") from e
finally:
_pending_ticket_responses.pop(ticket, None)
async def _send_outputjs_control(command: int, payload_content: bytes,
timeout: float = 7.0) -> dict:
"""Send a setting command using the XOR-encrypted output.js frame format.
Uses fresh device tickets to ensure command processing even after button presses.
Ticket is XORed with _XOR_KEY[1] to create the tx_tsn used in frame encryption.
"""
ticket = await _next_ticket(timeout=timeout)
frame, token_tsn = _build_outputjs_control_frame(command, ticket, payload_content)
loop = asyncio.get_running_loop()
response_future: asyncio.Future[dict] = loop.create_future()
_pending_ticket_responses[token_tsn] = response_future
print(f"TX outputjs cmd={command} ticket=0x{ticket:02X} tsn=0x{token_tsn:02X}: {_fmt_hex(frame)}")
try:
await _ble_write(frame)
try:
return await asyncio.wait_for(response_future, timeout=timeout)
except asyncio.TimeoutError as e:
raise TimeoutError(f"timeout waiting for response to cmd={command} ticket=0x{ticket:02X}") from e
finally:
_pending_ticket_responses.pop(token_tsn, None)
async def _send_outputjs_alarm_control(payload_content: bytes,
timeout: float = 5.0) -> dict:
ticket = await _next_ticket(timeout=timeout)
frame, token_tsn = _build_outputjs_alarm_frame(ticket, payload_content)
loop = asyncio.get_running_loop()
response_future: asyncio.Future[dict] = loop.create_future()
_pending_ticket_responses[token_tsn] = response_future
_pending_ticket_responses[ticket] = response_future
print(f"TX outputjs-alarm ticket=0x{ticket:02X} tsn=0x{token_tsn:02X}: {_fmt_hex(frame)}")
try:
await _ble_write(frame)
try:
return await asyncio.wait_for(response_future, timeout=timeout)
except asyncio.TimeoutError as e:
raise TimeoutError(f"timeout waiting for COMMON_RESPONSE to ticket 0x{ticket:02X}") from e
finally:
_pending_ticket_responses.pop(token_tsn, None)
_pending_ticket_responses.pop(ticket, None)
async def _ble_write(data: bytes):
for i in range(0, len(data), 20):
await _client.write_gatt_char(WRITE_UUID, data[i:i + 20], response=False)
await asyncio.sleep(0.05)
async def _send_auth_frame(msg_type: int, body: bytes):
header = bytes([msg_type, 0x00]) + struct.pack('<H', len(body))
await _ble_write(header + body)
async def _send_control(command: int, need_response: bool = True,
payload_content: bytes = b''):
if need_response:
# Adapt command format based on device state (last marker seen)
if _last_marker == 0xD4:
# Device in XOR-encrypted mode: use encrypted control frames
await _send_outputjs_control(command, payload_content)
else:
# Device in raw mode (0x82, 0xD2, or unknown): use raw ticketed frames
await _send_ticketed_control(command, payload_content)
return
frame = _build_control_frame(command, need_response, payload_content)
await _ble_write(frame)
def _fmt_hex(data: bytes) -> str:
return ' '.join(
f'\033[32m{b:02X}\033[0m' if i < 4 else f'{b:02X}'
for i, b in enumerate(data)
)
def _fmt_probe(p: dict, label: str) -> str:
if p['status'] != 'ok':
return f"{label}={p['status']}"
return f"{label}={p['temp_c']:.0f}°C({p['temp_f']:.1f}°F)"
def _print_temps(probes: list[dict], tag: str, tsn: int):
now = datetime.now().strftime('%H:%M:%S')
probe_str = ' '.join(_fmt_probe(p, f'P{i+1}') for i, p in enumerate(probes))
print(f"TEMP [{now}] {tag} tsn={tsn:3d} {probe_str}")
def _handle_raw_v5_packet(data: bytes) -> bool:
global _last_push_probes, _calibration_offsets, _last_marker, _last_battery_pct
marker = _live_ticket_marker(data)
if marker is not None:
_last_marker = marker
ticket = data[5]
_offer_ticket(ticket)
print(f"TICKET fresh: marker=0x{marker:02X} ticket=0x{ticket:02X}")
if marker == 0xD4:
# Standard XOR-encrypted PUSH — let _on_notify decrypt it.
return False
if marker == 0xD2:
# Post-button-press push — frame is RAW (no XOR), probe data
# is per-probe masked with device-specific D2 masks.
unmasked = _unmask_d2_payload(data[6:])
probes = _parse_probe_temperatures(unmasked)
_last_push_probes = probes
_print_temps(probes, 'BTN', ticket)
return True
# 0x82 raw push: probe bytes are not encrypted/masked.
probes = _parse_probe_temperatures(data[6:])
_last_push_probes = probes
_print_temps(probes, 'PUSH', ticket)
return True
raw_response = _parse_raw_ticket_response(data)
if raw_response is None:
return False
ticket = raw_response['ticket']
_finish_pending_response(ticket, raw_response)
cmd = raw_response['command']
payload = raw_response['payload_content']
if cmd == CC.BATTERY_LEVEL_RESPONSE:
if payload:
level = payload[0]
display_level = max(0, min(100, level))
label = 'LOW' if display_level < 30 else ('OK' if display_level < 70 else 'FULL')
_last_battery_pct = display_level
if level != display_level:
print(f"BATTERY [RAW] ticket=0x{ticket:02X}: {level}% (raw) -> {display_level}% ({label})")
else:
print(f"BATTERY [RAW] ticket=0x{ticket:02X}: {display_level}% ({label})")
else:
print(f"BATTERY [RAW] ticket=0x{ticket:02X}: (no payload)")
elif cmd == CC.TEMPERATURE_CALIBRATION_RESPONSE:
cals = _parse_calibration_response(payload)
_calibration_offsets = [c['celsius'] for c in cals] + [0.0] * (4 - len(cals))
cal_str = ' '.join(f"P{i+1}={c['celsius']:+.0f}°C" for i, c in enumerate(cals))
print(f"CALIBRATION [RAW] ticket=0x{ticket:02X}: {cal_str}")
elif cmd == CC.ADVANCE_ALARM_RESPONSE:
if len(payload) >= 3:
enabled = payload[0] == 1
cel = payload[1]
fah = payload[2]
print(f"ADVANCE_ALARM [RAW] ticket=0x{ticket:02X}: "
f"enabled={enabled} celsius={cel} fahrenheit={fah}")
else:
print(f"ADVANCE_ALARM [RAW] ticket=0x{ticket:02X}: payload={payload.hex().upper()}")
elif cmd == CC.COMMON_RESPONSE:
print(f"COMMON_RESPONSE [RAW] ticket=0x{ticket:02X}: status={raw_response['status']}")
else:
print(f"CONTROL [RAW] [{raw_response['name']}] ticket=0x{ticket:02X} "
f"payload={payload.hex().upper()}")
return True
and merge the code above with this (I had to divide it into two messages due to length restrictions)
async def _on_notify(sender, data: bytes):
global _last_push_probes, _calibration_offsets, _last_marker, _last_battery_pct
print(f"RX: {_fmt_hex(data)}")
if len(data) < 2:
return
if _handle_raw_v5_packet(data):
return
is_control = (data[1] == 0x01) or (data[0] == 0xFF and data[1] == 0xFF)
if is_control:
msg = _extract_control_message(data)
if msg is None:
return
cmd = msg['command']
is_push = msg['source'] == 1
src = 'PUSH' if is_push else 'RESP'
if cmd == CC.PROBE_TEMPERATURE_RESPONSE:
if is_push:
probes = _parse_probe_temperatures(msg['payload_content'])
_last_push_probes = probes
_print_temps(probes, 'PUSH', msg['rx_tsn'])
else:
# RESP frames (button-press response) use per-probe masking.
unmasked = _unmask_resp_payload(msg['payload_content'])
probes = _parse_probe_temperatures(unmasked)
_last_push_probes = probes
_print_temps(probes, 'RESP', msg['rx_tsn'])
elif cmd == CC.BATTERY_LEVEL_RESPONSE:
if msg['payload_content']:
level = msg['payload_content'][0]
display_level = max(0, min(100, level))
label = 'LOW' if display_level < 30 else ('OK' if display_level < 70 else 'FULL')
_last_battery_pct = display_level
if level != display_level:
print(f"BATTERY [{src}]: {level}% (raw) -> {display_level}% ({label})")
else:
print(f"BATTERY [{src}]: {display_level}% ({label})")
else:
print(f"BATTERY [{src}]: (no payload)")
elif cmd == CC.TEMPERATURE_UNIT_RESPONSE:
unit = 'Fahrenheit' if (msg['payload_content'] and msg['payload_content'][0]) else 'Celsius'
print(f"TEMP_UNIT [{src}]: {unit}")
elif cmd == CC.TEMPERATURE_CALIBRATION_RESPONSE:
cals = _parse_calibration_response(msg['payload_content'])
_calibration_offsets = [c['celsius'] for c in cals] + [0.0] * (4 - len(cals))
cal_str = ' '.join(f"P{i+1}={c['celsius']:+.0f}°C/{c['fahrenheit']:+.0f}°F"
for i, c in enumerate(cals))
print(f"CALIBRATION [{src}]: {cal_str}")
elif cmd == CC.ADVANCE_ALARM_RESPONSE:
p = msg['payload_content']
if len(p) >= 3:
print(f"ADVANCE_ALARM [{src}]: enabled={p[0]==1} celsius={p[1]} fahrenheit={p[2]}")
else:
print(f"ADVANCE_ALARM [{src}]: payload={p.hex().upper()}")
elif cmd == CC.COMMON_RESPONSE:
if len(msg['payload_content']) >= 2:
status = struct.unpack_from('<H', msg['payload_content'])[0]
else:
status = '?'
msg['status'] = status
print(f"COMMON_RESPONSE [{src}]: status={status}")
else:
print(f"CONTROL [{src}] [{msg['name']}] tsn={msg['rx_tsn']} "
f"payload={msg['payload_content'].hex().upper()}")
# Resolve any pending GET/SET request future regardless of response type.
# The device echoes our tx_tsn back as rx_tsn, but the same logical
# ticket is also tracked under (tsn ^ XOR_KEY[1]).
_finish_pending_response(msg['rx_tsn'], msg)
_finish_pending_response(msg['rx_tsn'] ^ _XOR_KEY[1], msg)
return
cmd = data[0]
if cmd == 0x01 and data[1] == 0x00:
try:
body = data[4:].decode('ascii', errors='ignore').strip('\x00')
device_uuid = _aes_decrypt(body)
confirm = _aes_encrypt(f"{APP_UUID}_{device_uuid}").encode()
await _send_auth_frame(0x02, confirm)
print("AUTH: challenge response sent")
except Exception as e:
print(f"AUTH error: {e}")
return
if cmd == 0x03:
print("AUTH: accepted")
await _client.write_gatt_char(WRITE_UUID, bytes([0x21, 0x00, 0x00, 0x00]),
response=False)
asyncio.create_task(_initial_probe_request())
return
if cmd in (0x1D, 0x22):
return
print(f"UNKNOWN cmd=0x{cmd:02X} data={data.hex().upper()}")
async def _on_notify2(sender, data: bytes):
print(f"RX2: {_fmt_hex(data)}")
_handle_raw_v5_packet(data)
async def _poll_loop():
while True:
await asyncio.sleep(POLL_INTERVAL)
if _client and _client.is_connected:
if time.monotonic() - _last_ticket_mono < POLL_INTERVAL * 2:
continue
try:
await _send_control(CC.PROBE_TEMPERATURE_REQUEST, need_response=True)
except TimeoutError as e:
print(f"Probe temperature request skipped: {e}")
async def _initial_probe_request():
await asyncio.sleep(0.5)
if not (_client and _client.is_connected):
return
try:
await _send_control(CC.PROBE_TEMPERATURE_REQUEST, need_response=True)
print("Probe temperature requested")
except TimeoutError as e:
print(f"Initial probe temperature request skipped: {e}")
await asyncio.sleep(0.5)
for cmd, label in [
(CC.BATTERY_LEVEL_REQUEST, "Battery level"),
(CC.TEMPERATURE_UNIT_REQUEST, "Temperature unit"),
(CC.TEMPERATURE_CALIBRATION_REQUEST, "Calibration"),
]:
if not (_client and _client.is_connected):
break
try:
await _send_control(cmd, need_response=True)
print(f"{label} requested")
except TimeoutError as e:
print(f"{label} request skipped: {e}")
await asyncio.sleep(0.3)
print()
# ---------------------------------------------------------------------------
# High-level command functions
# ---------------------------------------------------------------------------
async def set_probe_alarm(probe: int, temp_c: int | None):
await _set_probe_preset(probe, temp_c, temp_c)
async def set_probe_range_alarm(probe: int, lower_c: int, upper_c: int):
await _set_probe_preset(probe, lower_c, upper_c)
async def _set_probe_preset(probe: int, lower_c: int | None, upper_c: int | None):
if not (1 <= probe <= 4):
print(f"Error: probe must be 1-4, got {probe}")
return
if lower_c is not None and not (0 <= lower_c <= 300):
print(f"Error: lower temp {lower_c} out of range")
return
if upper_c is not None and not (0 <= upper_c <= 300):
print(f"Error: upper temp {upper_c} out of range")
return
_alarm_targets[probe - 1] = upper_c
payload = _build_probe_alarm_payload(probe, lower_c, upper_c)
if lower_c == upper_c:
label = f"{upper_c}°C" if upper_c is not None else "disabled"
else:
label = f"{lower_c}–{upper_c}°C"
try:
response = await _send_adaptive_control(CC.PROBE_PRESET_SETTING, payload, timeout=7.0)
except TimeoutError as e:
print(f"ALARM P{probe}: {e}")
return
if response.get('command') != CC.COMMON_RESPONSE:
name = response.get('name', f"0x{response.get('command', 0):04X}")
print(f"ALARM P{probe}: unexpected response {name}; status={response.get('status')}")
return
status = response.get('status')
if status == 0:
print(f"PROBE ALARM SET P{probe}: {label}")
else:
print(f"PROBE ALARM P{probe}: {label} rejected, status={status}")
async def set_temp_unit(use_fahrenheit: bool):
payload = bytes([1 if use_fahrenheit else 0])
label = "Fahrenheit" if use_fahrenheit else "Celsius"
try:
response = await _send_adaptive_control(CC.TEMPERATURE_UNIT_SETTING, payload, timeout=7.0)
except TimeoutError as e:
print(f"UNIT: {e}")
return
# Accept either a COMMON_RESPONSE (status) or a TEMPERATURE_UNIT_RESPONSE
resp_cmd = response.get('command')
if resp_cmd == CC.COMMON_RESPONSE:
status = response.get('status')
if status == 0:
print(f"UNIT SET: {label}")
else:
print(f"UNIT: {label} rejected, status={status}")
return
if resp_cmd == CC.TEMPERATURE_UNIT_RESPONSE:
p = response.get('payload_content') or b''
unit = 'Fahrenheit' if (len(p) >= 1 and p[0]) else 'Celsius'
print(f"UNIT SET (response): {unit}")
return
print(f"UNIT: unexpected response {response.get('name')}")
async def set_range_alarm(lower_c: int | None, upper_c: int | None):
payload = _build_advance_alarm_payload(lower_c, upper_c)
if lower_c is None and upper_c is None:
label = "disabled"
else:
lo_str = f"{lower_c}°C" if lower_c is not None else "none"
hi_str = f"{upper_c}°C" if upper_c is not None else "none"
label = f"{lo_str}–{hi_str}"
try:
response = await _send_adaptive_control(
CC.ADVANCE_ALARM_SETTING, payload, timeout=7.0)
except TimeoutError as e:
print(f"RANGE_ALARM: {e}")
return
if response.get('command') != CC.COMMON_RESPONSE:
print(f"RANGE_ALARM: unexpected response {response.get('name')}")
return
status = response.get('status')
if status == 0:
print(f"RANGE_ALARM SET: {label}")
else:
print(f"RANGE_ALARM: {label} rejected, status={status}")
async def set_probe_calibration(probe: int, offset_c: float):
if not (1 <= probe <= 4):
raise ValueError(f"probe must be 1-4, got {probe}")
if not (-15 <= offset_c <= 15):
raise ValueError(f"calibration offset must be -15..+15 °C, got {offset_c}")
_calibration_offsets[probe - 1] = offset_c
payload = _build_calibration_payload(_calibration_offsets)
try:
response = await _send_adaptive_control(
CC.TEMPERATURE_CALIBRATION_SETTING, payload, timeout=7.0)
except TimeoutError as e:
print(f"CALIBRATION: {e}")
return
if response.get('command') != CC.COMMON_RESPONSE:
print(f"CALIBRATION P{probe}: unexpected response {response.get('name')}")
return
status = response.get('status')
if status == 0:
print(f"CALIBRATION SET P{probe}: {offset_c:+.1f}°C")
else:
print(f"CALIBRATION P{probe}: {offset_c:+.1f}°C rejected, status={status}")
async def request_battery():
try:
await _send_control(CC.BATTERY_LEVEL_REQUEST, need_response=True)
except TimeoutError as e:
print(f"BATTERY request skipped: {e}")
# ---------------------------------------------------------------------------
# Input loop
# ---------------------------------------------------------------------------
_HELP = """\
Commands:
<temp> target alarm probe 1 (°C, 0-300)
<probe>:<temp> target alarm for probe 1-4
<probe>:off disable target alarm for probe
<probe>:<lo>-<hi> per-probe range alarm (e.g. 1:20-30)
<probe>:cal:<off> set calibration offset °C (e.g. 2:cal:-3)
<probe>:cal:0 clear calibration for probe
unit:C / unit:F set temperature display unit
battery request battery level
exit exit the script
help show this help\
"""
async def _input_loop():
global _awaiting_input
loop = asyncio.get_event_loop()
print(_HELP)
while True:
try:
_awaiting_input = True
sys.stdout.write("cmd> ")
sys.stdout.flush()
line = await loop.run_in_executor(None, input)
_awaiting_input = False
except Exception:
_awaiting_input = False
break
line = line.strip()
if line.lower() == 'exit':
print("Exiting...")
_exit_event.set()
break
if not line:
continue
if line.lower() == 'help':
print(_HELP)
continue
# battery
if line.lower() == 'battery':
if _client and _client.is_connected:
await request_battery()
else:
print("Not connected")
continue
# unit:C / unit:F
if line.lower().startswith('unit:'):
unit_str = line[5:].strip().upper()
if unit_str not in ('C', 'F'):
print("Usage: unit:C or unit:F")
continue
if _client and _client.is_connected:
await set_temp_unit(unit_str == 'F')
else:
print("Not connected")
continue
# off as alias for 1:off
if line.lower() == 'off':
line = '1:off'
# probe-prefixed commands
if ':' in line:
parts = line.split(':', 2)
try:
probe = int(parts[0].strip())
except ValueError:
print("Usage: <probe>:<cmd> (probe = 1-4)")
continue
if not (1 <= probe <= 4):
print("Probe must be 1-4")
continue
rhs = parts[1].strip()
# calibration: <probe>:cal:<offset>
if rhs.startswith('cal:'):
offset_str = rhs[4:].strip()
try:
offset_c = float(offset_str)
except ValueError:
print("Offset must be a number (e.g. 2:cal:-3)")
continue
if _client and _client.is_connected:
await set_probe_calibration(probe, offset_c)
else:
_calibration_offsets[probe - 1] = offset_c
print(f"CALIBRATION P{probe} queued: {offset_c:+.1f}°C (not connected yet)")
continue
# target alarm off: <probe>:off
if rhs.lower() == 'off':
temp = None
if _client and _client.is_connected:
await set_probe_alarm(probe, temp)
else:
_alarm_targets[probe - 1] = temp
print(f"ALARM P{probe} queued: disabled (not connected yet)")
continue
# per-probe range alarm: <probe>:<lo>-<hi>
if '-' in rhs:
try:
lo_s, hi_s = rhs.split('-', 1)
lower_c, upper_c = int(lo_s.strip()), int(hi_s.strip())
if not (0 <= lower_c <= 300 and 0 <= upper_c <= 300):
raise ValueError
if lower_c >= upper_c:
print(f"Lower ({lower_c}) must be less than upper ({upper_c})")
continue
except ValueError:
print("Usage: <probe>:<lo>-<hi> (e.g. 1:20-30)")
continue
if _client and _client.is_connected:
await set_probe_range_alarm(probe, lower_c, upper_c)
else:
print("Not connected")
continue
# target alarm: <probe>:<temp>
try:
temp = int(rhs)
if not (0 <= temp <= 300):
print(f"Temperature must be 0-300°C (got {temp})")
continue
except ValueError:
print("Usage: <probe>:<temp> or <probe>:off or <probe>:cal:<offset> or <probe>:<lo>-<hi>")
continue
if _client and _client.is_connected:
await set_probe_alarm(probe, temp)
else:
_alarm_targets[probe - 1] = temp
print(f"ALARM P{probe} queued: {temp}°C (not connected yet)")
continue
# plain <temp> → probe 1 target alarm
try:
temp = int(line)
if not (0 <= temp <= 300):
print(f"Temperature must be 0-300°C (got {temp})")
continue
except ValueError:
print("Unknown command. Type 'help' for usage.")
continue
if _client and _client.is_connected:
await set_probe_alarm(1, temp)
else:
_alarm_targets[0] = temp
print(f"ALARM P1 queued: {temp}°C (not connected yet)")
async def main():
global _client, _tx_tsn, _last_push_probes, _ticket_queue, _last_ticket, _exit_event
print(f"BMT01 version 2026-05-06 — connecting to {MAC}")
print(f"XOR key (MD5 raw bytes): {_XOR_KEY.hex()}\n")
_ticket_queue = asyncio.Queue(maxsize=1)
_exit_event = asyncio.Event()
input_task = asyncio.create_task(_input_loop())
while True:
_tx_tsn = 0
_last_push_probes = None
_last_ticket = None
_pending_ticket_responses.clear()
while _ticket_queue is not None:
try:
_ticket_queue.get_nowait()
except asyncio.QueueEmpty:
break
try:
client = BleakClient(MAC, timeout=20)
try:
await client.connect(timeout=20)
except Exception as e:
raise
_client = client
print("Connected")
try:
await client.start_notify(NOTIFY_UUID, _on_notify)
try:
await client.start_notify(NOTIFY_UUID2, _on_notify2)
print("bbb3 subscribed")
except Exception:
pass
await _send_auth_frame(0x00, _aes_encrypt(APP_UUID).encode())
print("AUTH: request sent\n")
poll_task = asyncio.create_task(_poll_loop())
try:
while client.is_connected:
if _exit_event.is_set():
print("Exit requested — stopping notifications...")
try:
await client.stop_notify(NOTIFY_UUID)
except Exception:
pass
try:
await client.stop_notify(NOTIFY_UUID2)
except Exception:
pass
break
await asyncio.sleep(1)
finally:
poll_task.cancel()
finally:
# ensure we disconnect and clear client reference before continuing
try:
if client.is_connected:
await client.disconnect()
except Exception:
pass
_client = None
# If exit requested, do not attempt to reconnect — return cleanly
if _exit_event.is_set():
print("Exiting — clean shutdown.")
return
print("Disconnected — reconnecting in 3 s...")
await asyncio.sleep(3)
except BleakError as e:
print(f"BLE error: {e} — retry in 5 s...")
await asyncio.sleep(5)
except KeyboardInterrupt:
input_task.cancel()
print("\nStopped.")
return
if _exit_event.is_set():
input_task.cancel()
print("\nClosed.")
return
if __name__ == "__main__":
asyncio.run(main())
