Zigbee TZ3210 cover switch with HomeAssistant

rytecbe · December 12, 2023, 2:04pm

Hello
I have installed small Zigbee curtain modules model QS-Zigbee-S10-CO4 to open and close my covers at the windows.
If I pair them with Smartlife (Tuya) they are found directly and working very good, I even can calibrate the covers.
But then in HA they are found in the Tuya list but without any entities.
So I had to pair them directly into HA with my Sonoff Zigbee USB dongle. Then I can use them to open and close the covers but they give often a wrong response and then you see for example they are closed in HA but they are open in real. So something is not working fine here.
Anyone had the same issue or know how to resolve this?
Thanks in advance.

Gonzo78 · February 8, 2024, 6:41pm

Hello, i have the same problem with tz3210 cover switches. The state of the devices changes sometimes, so the command to close the cover is not send by automation jobs.
My cover switches are labled “cloud even”

The othee number at the zigbee name is ts130f

There ia already a bug report created for this device ts130f

github.com/zigpy/zha-device-handlers

[BUG] cover _TZ3210_dwytrmda lift percentage is not updated

opened 09:39AM - 22 Oct 23 UTC

tsensei781

Tuya

### Bug description with the device identified as below: "manufacturer": "_T…Z3210_dwytrmda", "model": "TS130F", "class": "zhaquirks.tuya.ts130f.TuyaTS130FTOGP" It seems that the current_position_lift_percentage (id 0x0008) is not updated correctly leading to an unexpected behavior within HA. In my situation this variable is always set to 100 whatever the position of the cover is. ### Steps to reproduce 1. When the cover is open, request in HA to close the cover 2. The covers closed, immediately after HA is showing the correct position and associated commands. 3. Some times after (or if we read the current_position_lift_percentage value), HA is showing the cover as open 4. Up command is not accessible, activating the down command forces a refresh and HA shows the cover as closed ### Expected behavior In the step 3 above, we should expect to always read the same position within HA. ### Screenshots/Video <details><summary>Screenshots/Video</summary> [Paste/upload your media here] </details> ### Device signature <details><summary>Device signature</summary> ```json { "node_descriptor": "NodeDescriptor(logical_type=<LogicalType.Router: 1>, complex_descriptor_available=0, user_descriptor_available=0, reserved=0, aps_flags=0, frequency_band=<FrequencyBand.Freq2400MHz: 8>, mac_capability_flags=<MACCapabilityFlags.FullFunctionDevice|MainsPowered|RxOnWhenIdle|AllocateAddress: 142>, manufacturer_code=4417, maximum_buffer_size=66, maximum_incoming_transfer_size=66, server_mask=10752, maximum_outgoing_transfer_size=66, descriptor_capability_field=<DescriptorCapability.NONE: 0>, *allocate_address=True, *is_alternate_pan_coordinator=False, *is_coordinator=False, *is_end_device=False, *is_full_function_device=True, *is_mains_powered=True, *is_receiver_on_when_idle=True, *is_router=True, *is_security_capable=False)", "endpoints": { "1": { "profile_id": "0x0104", "device_type": "0x0202", "input_clusters": [ "0x0000", "0x0004", "0x0005", "0x0102" ], "output_clusters": [ "0x000a", "0x0019" ] }, "242": { "profile_id": "0xa1e0", "device_type": "0x0061", "input_clusters": [], "output_clusters": [ "0x0021" ] } }, "manufacturer": "_TZ3210_dwytrmda", "model": "TS130F", "class": "zhaquirks.tuya.ts130f.TuyaTS130FTOGP" } ``` </details> ### Diagnostic information <details><summary>Diagnostic information</summary> ```json { "home_assistant": { "installation_type": "Home Assistant Container", "version": "2023.8.4", "dev": false, "hassio": false, "virtualenv": false, "python_version": "3.11.4", "docker": true, "arch": "x86_64", "timezone": "Europe/Paris", "os_name": "Linux", "os_version": "6.2.0-35-generic", "run_as_root": true }, "custom_components": { "pfsense": { "version": "0.1.0", "requirements": [ "mac-vendor-lookup>=0.1.11" ] }, "nest_protect": { "version": "0.4.0b1", "requirements": [] }, "cover_time_based_synced": { "version": "2.0.0", "requirements": [] }, "hacs": { "version": "1.33.0", "requirements": [ "aiogithubapi>=22.10.1" ] } }, "integration_manifest": { "domain": "zha", "name": "Zigbee Home Automation", "after_dependencies": [ "onboarding", "usb" ], "codeowners": [ "@dmulcahey", "@adminiuga", "@puddly" ], "config_flow": true, "dependencies": [ "file_upload" ], "documentation": "https://www.home-assistant.io/integrations/zha", "iot_class": "local_polling", "loggers": [ "aiosqlite", "bellows", "crccheck", "pure_pcapy3", "zhaquirks", "zigpy", "zigpy_deconz", "zigpy_xbee", "zigpy_zigate", "zigpy_znp" ], "requirements": [ "bellows==0.35.9", "pyserial==3.5", "pyserial-asyncio==0.6", "zha-quirks==0.0.102", "zigpy-deconz==0.21.0", "zigpy==0.56.4", "zigpy-xbee==0.18.1", "zigpy-zigate==0.11.0", "zigpy-znp==0.11.4" ], "usb": [ { "vid": "10C4", "pid": "EA60", "description": "*2652*", "known_devices": [ "slae.sh cc2652rb stick" ] }, { "vid": "1A86", "pid": "55D4", "description": "*sonoff*plus*", "known_devices": [ "sonoff zigbee dongle plus v2" ] }, { "vid": "10C4", "pid": "EA60", "description": "*sonoff*plus*", "known_devices": [ "sonoff zigbee dongle plus" ] }, { "vid": "10C4", "pid": "EA60", "description": "*tubeszb*", "known_devices": [ "TubesZB Coordinator" ] }, { "vid": "1A86", "pid": "7523", "description": "*tubeszb*", "known_devices": [ "TubesZB Coordinator" ] }, { "vid": "1A86", "pid": "7523", "description": "*zigstar*", "known_devices": [ "ZigStar Coordinators" ] }, { "vid": "1CF1", "pid": "0030", "description": "*conbee*", "known_devices": [ "Conbee II" ] }, { "vid": "10C4", "pid": "8A2A", "description": "*zigbee*", "known_devices": [ "Nortek HUSBZB-1" ] }, { "vid": "0403", "pid": "6015", "description": "*zigate*", "known_devices": [ "ZiGate+" ] }, { "vid": "10C4", "pid": "EA60", "description": "*zigate*", "known_devices": [ "ZiGate" ] }, { "vid": "10C4", "pid": "8B34", "description": "*bv 2010/10*", "known_devices": [ "Bitron Video AV2010/10" ] } ], "zeroconf": [ { "type": "_esphomelib._tcp.local.", "name": "tube*" }, { "type": "_zigate-zigbee-gateway._tcp.local.", "name": "*zigate*" }, { "type": "_zigstar_gw._tcp.local.", "name": "*zigstar*" }, { "type": "_slzb-06._tcp.local.", "name": "slzb-06*" } ], "is_built_in": true }, "data": { "ieee": "**REDACTED**", "nwk": 26601, "manufacturer": "_TZ3210_dwytrmda", "model": "TS130F", "name": "_TZ3210_dwytrmda TS130F", "quirk_applied": true, "quirk_class": "zhaquirks.tuya.ts130f.TuyaTS130FTOGP", "manufacturer_code": 4417, "power_source": "Mains", "lqi": 33, "rssi": null, "last_seen": "2023-10-22T11:29:41", "available": true, "device_type": "Router", "signature": { "node_descriptor": "NodeDescriptor(logical_type=<LogicalType.Router: 1>, complex_descriptor_available=0, user_descriptor_available=0, reserved=0, aps_flags=0, frequency_band=<FrequencyBand.Freq2400MHz: 8>, mac_capability_flags=<MACCapabilityFlags.FullFunctionDevice|MainsPowered|RxOnWhenIdle|AllocateAddress: 142>, manufacturer_code=4417, maximum_buffer_size=66, maximum_incoming_transfer_size=66, server_mask=10752, maximum_outgoing_transfer_size=66, descriptor_capability_field=<DescriptorCapability.NONE: 0>, *allocate_address=True, *is_alternate_pan_coordinator=False, *is_coordinator=False, *is_end_device=False, *is_full_function_device=True, *is_mains_powered=True, *is_receiver_on_when_idle=True, *is_router=True, *is_security_capable=False)", "endpoints": { "1": { "profile_id": "0x0104", "device_type": "0x0202", "input_clusters": [ "0x0000", "0x0004", "0x0005", "0x0102" ], "output_clusters": [ "0x000a", "0x0019" ] }, "242": { "profile_id": "0xa1e0", "device_type": "0x0061", "input_clusters": [], "output_clusters": [ "0x0021" ] } }, "manufacturer": "_TZ3210_dwytrmda", "model": "TS130F" }, "active_coordinator": false, "entities": [ { "entity_id": "cover.tz3210_dwytrmda_ts130f_cover", "name": "_TZ3210_dwytrmda TS130F" } ], "neighbors": [ { "device_type": "Router", "rx_on_when_idle": "On", "relationship": "Sibling", "extended_pan_id": "**REDACTED**", "ieee": "**REDACTED**", "nwk": "0x3B8F", "permit_joining": "Unknown", "depth": "1", "lqi": "45" }, { "device_type": "Router", "rx_on_when_idle": "On", "relationship": "Sibling", "extended_pan_id": "**REDACTED**", "ieee": "**REDACTED**", "nwk": "0x3D88", "permit_joining": "Unknown", "depth": "1", "lqi": "78" } ], "routes": [], "endpoint_names": [ { "name": "WINDOW_COVERING_DEVICE" }, { "name": "PROXY_BASIC" } ], "user_given_name": null, "device_reg_id": "c9b9f3ce85e85bf5b029ea1901596d8b", "area_id": "cuisine", "cluster_details": { "1": { "device_type": { "name": "WINDOW_COVERING_DEVICE", "id": 514 }, "profile_id": 260, "in_clusters": { "0x0000": { "endpoint_attribute": "basic", "attributes": { "0x0003": { "attribute_name": "hw_version", "value": 1 }, "0x0004": { "attribute_name": "manufacturer", "value": "_TZ3210_dwytrmda" }, "0x0005": { "attribute_name": "model", "value": "TS130F" }, "0x0007": { "attribute_name": "power_source", "value": 1 }, "0xfffe": { "attribute_name": "reporting_status", "value": 0 } }, "unsupported_attributes": { "0x0013": { "attribute_name": "alarm_mask" }, "0x4000": { "attribute_name": "sw_build_id" } } }, "0x0004": { "endpoint_attribute": "groups", "attributes": {}, "unsupported_attributes": {} }, "0x0005": { "endpoint_attribute": "scenes", "attributes": {}, "unsupported_attributes": {} }, "0x0102": { "endpoint_attribute": "window_covering", "attributes": { "0xf001": { "attribute_name": "calibration", "value": 0 }, "0xf003": { "attribute_name": "calibration_time", "value": 172 }, "0x0008": { "attribute_name": "current_position_lift_percentage", "value": 0 }, "0x8000": { "attribute_name": "motor_mode", "value": 0 }, "0xf002": { "attribute_name": "motor_reversal", "value": 0 }, "0xf000": { "attribute_name": "tuya_moving_state", "value": 1 } }, "unsupported_attributes": { "0x0000": { "attribute_name": "window_covering_type" }, "0x0003": { "attribute_name": "current_position_lift" }, "0x0004": { "attribute_name": "current_position_tilt" }, "0x0007": { "attribute_name": "config_status" }, "0x0009": { "attribute_name": "current_position_tilt_percentage" }, "0x0010": { "attribute_name": "installed_open_limit_lift" }, "0x0011": { "attribute_name": "installed_closed_limit_lift" }, "0x0013": { "attribute_name": "installed_closed_limit_tilt" }, "0x0017": { "attribute_name": "window_covering_mode" }, "0x0015": { "attribute_name": "acceleration_time_lift" }, "0x0016": { "attribute_name": "deceleration_time_lift" }, "0x0014": { "attribute_name": "velocity_lift" }, "0x0019": { "attribute_name": "intermediate_setpoints_tilt" } } } }, "out_clusters": { "0x000a": { "endpoint_attribute": "time", "attributes": {}, "unsupported_attributes": {} }, "0x0019": { "endpoint_attribute": "ota", "attributes": { "0x0002": { "attribute_name": "current_file_version", "value": 66 }, "0x0003": { "attribute_name": "current_zigbee_stack_version", "value": 2 }, "0x0004": { "attribute_name": "downloaded_file_version", "value": 4294967295 }, "0x0006": { "attribute_name": "image_upgrade_status", "value": 0 } }, "unsupported_attributes": { "0xfffe": { "attribute_name": "reporting_status" } } } } }, "242": { "device_type": { "name": "PROXY_BASIC", "id": 97 }, "profile_id": 41440, "in_clusters": {}, "out_clusters": { "0x0021": { "endpoint_attribute": "green_power", "attributes": {}, "unsupported_attributes": {} } } } } } } ``` </details> ### Logs <details><summary>Logs</summary> ```python [Paste the logs here] ``` </details> ### Additional information _No response_
