Home Assistant Core on Android Tablet

Tags: #<Tag:0x00007fc4173eaf70> #<Tag:0x00007fc4173ead90>

The Home Assistant installation guide recommends using a Raspberry Pi to run the automation server. If you have an old Android tablet or phone lying around, why not make use of it instead? An additional benefit is that the tablet can be used as a wall-mounted UI for Home Assistant - UI and server, all running on one device.

The original guide was written in [this GitHub repository] LINK(https: / /github.com/alexanderhale/home-assistant). I have pasted it here so that it can be collaboratively edited as a Wiki article.

Prerequisites

  • Hardware: tablet or phone running Android
    • This guide uses the Google Nexus 7 (2013) tablet as an example.
  • Software: Android 5.0.0
  • Tools: a computer, and a micro USB cable to connect the tablet to the computer

LineageOS Installation

The Nexus 7 tablet stopped receiving software updates as of Android 5 (Lollipop). Such an old version of Android causes lots of incompatibilities. In addition, an operating system refresh removes old files and apps and speeds the tablet up.

You may be able to install a more recent version of Android, if you’re able to find a ROM for it online, but an easier approach is to install [LineageOS] LINK(https: / /w w w .lineageos.org/), which is a free and open-source Android distribution. The latest version at the time of writing is LineageOS 17.1 (which equates to Android 10). Let’s dive into the steps required to install LineageOS on the tablet.

Backup Files

If you have anything you care about on your Nexus 7 (files, configuration, etc), back it up to another location now. The tablet will be factory reset during the operating system re-install.

Download Files

These files will be required for the LineageOS installation:

  • [Team Win Recovery Project (TWRP)] LINK(https: / /dl.twrp.me/flo/twrp-3.4.0-0-flo.img)
    • The link is to version 3.4.0, but you can select whatever the latest version is.
  • [LineageOS 17.1] LINK(https: / /lineageos.wickenberg.nu/flo)
    • Navigate to Google > flo, then select the most recent build for version 17.1.
  • [addonsu 17.1] LINK(https: / /github.com/alexanderhale/home-assistant/tree/main/docs/tablet_setup/lineage_os/addonsu-17.1-arm.zip)
    • Saved in this repository in case [the source] LINK(https: / /androidfilehost.com/?fid=8889791610682882454) is no longer available.
  • [sysrepart.zip] LINK(https: / /github.com/alexanderhale/home-assistant/tree/main/docs/tablet_setup/lineage_os/sysrepart.zip)
    • Saved in this repository in case [the source] LINK(https: / /forum.xda-developers.com/showpost.php?p=76278047&postcount=19) is no longer available.
  • [GApps] LINK(https: / /opengapps.org/) (optional)
    • select ARM, Android 10.0, nano size

Install TWRP

TWRP is a custom recovery tool, which we can use in place of the default system recovery tools on the device.

TWRP can be installed using the TWRP app, or by connecting the tablet to a computer and using the Android Debug Bridge (ADB). This guide will use ADB - see [this TWRP installation guide] LINK(https: / /w w w .xda-developers.com/how-to-install-twrp/) for more details on both options.

Step 1 - Enable USB Debugging

On the tablet, enable developer options by finding the “About” section in the settings, then repeatedly tapping the build number section. Enter the developer options menu, then toggle USB debugging to on. You can use wireless ADB debugging if you prefer, but file transfers will be slower.

Step 2 - ADB and Fastboot

Install ADB and fastboot on your computer. The LineageOS wiki [describes the process] LINK(https: / /wiki.lineageos.org/adb_fastboot_guide.html) for various operating systems. Once installed, connect the tablet to the computer, then approve the permissions pop-up that appears on the tablet. To confirm that the tablet is accessible via ADB, make sure the device appears when you run adb devices in a terminal on your computer.

Step 3 - Flash TWRP Image

Run adb reboot bootloader in a terminal on the computer. Wait for the device to boot into bootloader mode, then run fastboot flash recovery <twrp-img-file>, replacing <twrp-img-file> with the path to the TWRP file that you downloaded earlier. Once the flash is complete, run fastboot reboot.

Success! To check that the installation was successful: power off the tablet, then reboot into recovery mode by holding the power and volume down buttons at the same time until the recovery mode screen appears.

[] LINK(https: / /w w w .cleverfiles.com/howto/wp-content/uploads/2018/04/android-recovery-mode.jpg)

Use the volume buttons to scroll to the Recovery option, then press the power button to select it. The TWRP menu should appear.

[] LINK(https: / /upload.wikimedia.org/wikipedia/commons/e/e0/TWRP_3.0.0-0.png)

Install LineageOS

Step 1 - Factory Reset

Confirm that you’ve backed up the tablet. Then, starting from the TWRP home page, navigate to Wipe > Factory Reset, and perform the reset.

Step 2 - Repartition

The existing partitioning of the device leaves little space for loading the OS and GApps images. To check the amount of space, navigate to Wipe > Advanced Wipe > System > Repair or Change File System. Take note of the free space listed on the left of the screen.

Return to the TWRP home screen, then navigate to Install > ADB Sideload. Open a terminal on the computer and run adb sideload sysrepart.zip. Confirm on the tablet that the image was flashed successfully.

Return to Repair or Change File System - the free space should have increased.

Step 3 - Flash New OS

The following files must be loaded in the order listed here. If you don’t need the Google Play store on your device, feel free to skip the GApps step.

From the TWRP home screen, navigate to Install > ADB Sideload. Open a terminal on your computer and run adb sideload <lineage_os_filename>.zip. Confirm on the tablet that the image was flashed successfully.

Without rebooting, select ADB Sideload again, and flash addonsu-17.1-arm.zip in the same way. If you want to install Google Play, select ADB Sideload again, and flash the GApps zip. If the GApps flash fails due to a lack of space in the partition, try again using the pico size when creating the download from the GApps website.

Once the images are flashed, select Clear Cache/Davlik, then select Reboot. The tablet should boot into a fresh installation of LineageOS.

For more information, here are a few threads describing this process:

  • [XDA-Developers Forum] LINK(https: / /forum.xda-developers.com/nexus-7-2013/development/rom-lineageos-17-1-t4038425)
  • [Reddit thread] LINK(https: / /w w w .reddit.com/r/Nexus7/comments/esy39y/install_android_9_lineage_os_160_on_nexus_7_2013/)

Home Assistant Installation

Now that the operating system on the tablet has been swapped to LineageOS, Home Assistant (and related programs) can be installed.

Install F-Droid

[F-Droid] LINK(https: / /w w w .f-droid.org/) is a repository for free apps, analogous to the Google Play store. Head to F-Droid’s website and download the latest .apk file. Once downloaded, a pop-up will appear - hit Install.

If you included GApps in your LineageOS installation, you could skip F-Droid and get Termux (in then next step) from the Google Play store instead. At the time of writing, some of the Termux add-ons are paid in Google Play (but free in F-Droid). You could even install Termux directly from source, if you wanted to avoid repositoiries completely - but this guide will assume that Termux will be downloaded from an app repository.

Install Termux

Most of the Home Assistant installation work will be done on the command line. The most robust UNIX console emulator for Android is Termux. To get Termux, head to F-Droid or Google Play. Search for [Termux] LINK(https: / /f-droid.org/en/packages/com.termux), download it, and install it. While you’re here, download and install [Termux:API] LINK(https: / /f-droid.org/en/packages/com.termux.api/) and [Termux:Boot] LINK(https: / /f-droid.org/en/packages/com.termux.boot) too - we’ll need them later.

The typing experience on a tablet touch-screen isn’t the most conducive to using a command line. If you have one, connecting a Bluetooth keyboard would be helpful. If not, you could try a modified on-screen keyboard like [Hacker’s Keyboard] LINK(https: / /f-droid.org/en/packages/org.pocketworkstation.pckeyboard/). Later on, we’ll connect to the tablet via SSH, so you can use your computer for configuration and file transfers.

Install Packages

Open up the Termux app. Notice that your home directory is /data/data/com.termux/files/home/, and the etc directory (where packages will be installed) is at /data/data/com.termux/files/usr/etc/. This is different than a standard UNIX operating system.

The package manager in Termux is pkg, which is a wrapper around apt. You can also use the apt command directly, but there’s usually no need to do so.

Here are the packages to install at this stage:

  • python: Home Assistant runs in Python, so the language needs to be installed
  • nano: for viewing and editing files
  • termux-api: to connect with the Termux:API app that is installed on the device
  • make: to allow Makefiles to run
  • libjpeg-turbo: to avoid a bug in a later step due to a missing JPEG package

Install the necessary packages with these commands (confirming with y when requested):

pkg updates
pkg upgrade
pkg install python nano openssh termux-api make libjpeg-turbo

Install Home Assistant

The prerequisites are now in place to install the Home Assistant package from the PyPi Python package repository:

# create a virtual environment (optional, but recommended)
python -m venv hass
source hass/bin/activate

pip install homeassistant

The virtual environment is optional, but recommended - if you don’t use one, the packages will be installed in your “base” environment. Using a virtual environment makes your installation isolated - if you want to update your version of Python or Home Assistant, you could do so in a fresh virtual environment to make sure everything is working properly without impacting your existing installation.

Run

Everything is now in place! With your virtual environment activated, execute hass -v. During this first startup, keep an eye on the output for error messages, which might indicate that something has been configured incorrectly.

If the startup succeeds, head to localhost:8123 in a browser on the tablet - the Home Assistant homepage should appear!

For more information, here is [a Medium post] LINK(https: / /lucacesarano.medium.com/install-home-assistant-hass-on-android-no-root-fb65b2341126) describing this process.

Addressing Setup

Home Assistant is now accessible from other devices which are also connected to your home network. To access Home Assistant, find your tablet’s network IP address (something like http: / /192.168.2.xyz) by running the ipconfig command in Termux, or by logging in to your router’s admin console (usually at http: / /192.168.2.1) and finding your tablet in the list of devices. Then, navigate to that address from another device using port 8123: http: / /192.168.2.xyz:8123. The Home Assistant interface should load, the same way it does for http: / /localhost:8123 on your tablet.

This setup works, but it is not robust. What if your router re-assigns your tablet a new IP address? What if you want to access your Home Assistant setup when you’re away from home? What if you want to connect Home Assistant to an external provider like Google Assistant? These hurdles will be addressed in this section.

Static IP Address

By default, your tablet gets assigned an IP address by your router in a process called [DHCP] LINK(https: / /en.wikipedia.org/wiki/Dynamic_Host_Configuration_Protocol). The ‘D’ in ‘DHCP’ stands for ‘Dynamic’, meaning your tablet’s assigned IP address could get reassigned at any time.

To assign a static IP address, go into the WiFi settings on your tablet, then tap & hold your home network. Select Manage Network Settings > Show Advanced Options. Change the IP Setting from DHCP to Static, and enter the IP address that you want your tablet to have. If the Gateway doesn’t fill in automatically, enter the same value as your IP address, replacing the last section (after the last .) with 1.

[] LINK(https: / /i0.wp.com/thedroidreview.com/wp-content/uploads/2016/03/Set-Static-IP-on-Android.png?fit=900%2C714&ssl=1)

All set! Your tablet will now always receive the same IP address when connected to your home network. This guide will refer to your tablet’s http: / /192.168.2.xyz IP address as the “internal network IP address”.

Port Forwarding

The configuration above works only when conneceted to your home network, because your home router knows to route requests at http: / /192.168.2.xyz to your tablet. Try it yourself: disconnect your phone from WiFi, connect to data, and navigate to your tablet’s internal network IP address. Nothing loads!

Let’s fix that. Just like your tablet has an IP address, your entire home network also has an IP address. Think of your router as the “front door” of an apartment building - there is a number outside the door telling the mail carrier to deliver mail to the concierge (router) of the building, then it is the concierge’s (router’s) job to distribute the mail to the appropriate apartment number (device, like your tablet) in the building.

[![Internal vs External IP Address] LINK(https: / /raw.githubusercontent.com/alexanderhale/home-assistant/main/docs/images/internal_external_ip.png)] LINK(https: / /troypoint.com/wp-content/uploads/2019/08/internal-vs-external-ip-address-diagram-600x351.png)

To access Home Assistant from outside your home network, we therefore need to know the “building number” (external IP address of your home network) and “apartment number” (port) to which we should send our requests.

To find the IP address of your home network, look in your router’s admin console, or you can go to [whatismyipaddress.com] LINK(https: / /whatismyipaddress.com/) and look for the IPv4 field.

To route requests to the correct device, we need to set up port forwarding. Find the port forwarding configuration area in your router’s admin console and set up a new port forward with the following:

  • External port: 8123
  • Internal port: 8123
  • Internal address: http: / /192.168.2.xyz

When your router receives a request to http: / /<external-ip-address>:8123, it will now send it to http: / /192.168.2.xyz:8123 - the address where our Home Assistant installation is running! Test it out on your phone (while still connected to mobile data).

Great! Home Assistant is accessible from outside your home network. However, two issues remain:

  • The digits of the external IP address are hard to remember, and some external services (like Google Assistant) require a proper hostname.
  • We are accessing Home Assistant via an unencrypted http: / / connection, meaning an intruder could see your username and password.

We’ll resolve those two issues in the next sections.

DNS Routing

When you want to make a Google search, you don’t navigate to 172.217.1.4 - you navigate to google.com. This mapping of human-friendly names to IP addresses is called a “Domain Name System” (DNS).

Registering a domain name - say, myhomeassistant.org - means that you’re reserving the right to route traffic arriving at myhomeassistant.org to a web server owned by you. Most domain names cost money to reserve, but there are some services like [DuckDNS] LINK(https: / /w w w .duckdns.org/) and [No-IP] LINK(https: / /w w w .noip.com/) which offer free domain names. These services make money with their “premium” offerings, which are not required to complete this guide.

One additional feature of domain name services is “dynamic” DNS. The IP address of your router is provided by your internet service provider (ISP), and is liable to change at any time. A dynamic DNS provider takes this change in stride, automatically sending traffic to the updated IP address whenever it changes.

To set up your domain name, create a [No-IP] LINK(https: / /w w w .noip.com) account. Create whatever hostname you’d like - make it something memorable! We’ll call it hass.noip.org for simplicity in this guide. Set “IP / Target” to the external IP address of your network, then save the hostname.

After waiting a few hours for the new DNS record to propogate through name servers (or up to 2 days, according to No-IP’s documentation), navigating to http: / /hass.noip.org:8123 should now bring up your Home Assistant instance. Success!

If you prefer to use DuckDNS or another provider to reserve your hostname, that’s no problem - the steps above should work the same.

One common gotcha: if http: / /hass.noip.org:8123 does not load for you when connected to your local network, but does work when connected to mobile data, it’s likely because your router does not support NAT loopback (also known as NAT Hairpinning). See [Reverse Proxy] LINK(#reverse-proxy) below.

SSL Certificate

When navigating to http: / /hass.noip.org in the previous step, a notice appeared on the left side of your address bar, saying something like “Not Secure!”, with an open padlock logo.

This happens because an http connection is unencrypted - traffic to and from the server is in plain text, and could be read by anybody intercepting the traffic via a “man in the middle” attack. An https connection (where the s stands for “secure”) is a better option.

To allow connections via https, your server first needs a TLS/SSL certificate, which:

  1. Specifies the owner of the certificate, and includes the domain that content signed with this certificate should be coming from (preventing another server from spoofing this server).
  2. Provides a public key, which anybody wishing to communicate with a server can use to encrypt their traffic.

The certificate is issued by a Certificate Authority, which is an authoratitive body that has been trusted to issue certificates. Just like with domains, there are free and paid Certificate Authorities from which certificates can be issued. We’ll be using [LetsEncrypt] LINK(https: / /letsencrypt.org/), which is a free option.

To receive a certificate from LetsEncrypt, you must prove that you “control” the domain - that is, traffic to hass.noip.org goes to your server, and not somebody else’s. This prevents you from generating a certificate for a server that does not belong to you.

LetsEncrypt provides the handy certbot tool for proving you own a domain, but it is not available in Termux, so some extra steps are required.

Option 1 - Complete the HTTP-01 Challenge Elsewhere

  1. Set up a new port forward on your router, which routes traffic to port 80 of your external IP address to port 80 of your computer’s internal IP address.
  2. Install [Apache] LINK(https: / /httpd.apache.org/) on your computer.
  3. Run [certbot] LINK(https: / /certbot.eff.org/) in standalone mode to complete the HTTP-01 challenge.
  4. Remove the port forward on your router.

Option 2 - Complete the DNS-01 Challenge

See [this blog post] LINK(https: / /w w w .splitbrain.org/blog/2017-08/10-homeassistant_duckdns_letsencrypt) for instructions.

Once the certificate files are generated (fullchain.pem and privkey.pem), transfer them to your tablet via ADB and place them somewhere accessible. Update your Home Assistant configuration with the paths to the files.

http:
  ssl_certificate: /path/to/fullchain.pem
  ssl_key: /path/to/privkey.pem

More information details on this process are available in this [instructional blog post] LINK(https: / /community.home-assistant.io/t/installing-tls-ssl-using-lets-encrypt/196975).

Reverse Proxy

Most ISP-provided routers don’t support NAT loopback, which means that the domain name configured above will give a certificate error when accessing it from within the home network. That certificate error can be ignored in the browser, but not in the Home Assistant companion app.

There are a few options to get around this:

  • New Router: the most obvious solution, but it is not free, and might not be possible depending on your ISP.
  • Split-Brain DNS: setting up a DNS server which handles the routing of traffic on your home network. This could be a good option, but personally I’m wary of relying on the Nexus 7 tablet for DNS resolution of all my home traffic.
  • Reverse Proxy: the approach used in this guide.

A [reverse proxy] LINK(https: / /en.wikipedia.org/wiki/Reverse_proxy) is a layer placed in front of a web server to handle incoming traffic. When behind a reverse proxy, all traffic arriving at the web server is coming from one source - the proxy - simplifying the configuration required at the web server.

We’ll be using [NGINX] LINK(https: / /w w w .nginx.com/) as our proxy server. Install it on the tablet with pkg install nginx. We’ll also need OpenSSL: pkg install openssl.

Navigate to ~/../usr/etc/nginx/ssl/, then execute openssl dhparam -out dhparams.pem 2048. You may need to execute this command as root - if that’s the case, you can prepend su to that command, or execute it in a root shell via ADB.

Create the file ~/../usr/etc/nginx/nginx.conf, then enter the config below. Replace hass.noip.org with your domain name.

worker_processes 	1;

events {
	worker_connections 	1024;
}

http {
	include 		mime.types;
	default_type	application/octet-stream;

	sendfile	on;

	keepalive_timeout	65;

	map $http_upgrade $connection_upgrade {
		default 	upgrade;
		''			close;
	}

	server {
		server_name		hass.noip.org;

		listen [::]:8080 default_server ipv6only=off;
		return 301 https: / /$host$request_uri;
	}

	server {
		server_name 	hass.noip.org;

		ssl_certificate			/data/data/com.termux/files/home/certificates/fullchain.pem;
		ssl_certificate_key 	/data/data/com.termux/files/home/certificates/privkey.pem;
		ssl_dhparam				/data/data/com.termux/files/usr/etc/nginx/ssl/dhparams.pem;

		listen [::]:8443 ssl default_server ipv6only=off http2;
		add_header Strict-Transport-Security "max-age=31536000; includeSubdomains";

		ssl_protocols TLSv1.2;
		ssl_ciphers "EECDH+AESGCM:EDH+AESGCM:AES256+EECDH:AES256+EDH:!aNULL:!eNULL:!EXPORT:!DES:!MD5:!PSK:!RC4"
		ssl_prefer_server_ciphers on;
		ssl_session_cache shared:SSL:10m;

		proxy_buffering off;

		location / {
			proxy_pass http: / /127.0.0.1:8123;
			proxy_set_header Host $host;
			proxy_redirect http: / / https: / /;
			proxy_http_version 1.1;
			proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
			proxy_set_header Upgrade $http_upgrade;
			proxy_set_header Connection $connection_upgrade
		}
	}
}

All traffic to Home Assistant should be routed through the proxy - to configure this, head to ~/.homeassistant/configuration.yml and change the http section:

http:
	server_host: 127.0.0.1  # optional: only permit traffic from localhost (i.e. from the reverse proxy)
	use_x_forwarded_for: true
	trusted_proxies: 127.0.0.1

Finally, in your router, remove the port forwarding rule at port 8123 and add two new rules:

  • for HTTP traffic: external port: 80, internal port: 80, internal IP address: your tablet
  • for HTTPS traffic: external port: 443, internal port: 443, internal IP address: your tablet

Start nginx by running nginx in Termux. Home Assistant should now be accessible via https: / /hass.noip.org from outside your network and http: / /192.186.2.xyz:8123 from your internal network. In the Home Assistant companion app, you can add those two addresses and it will automatically transition between them.

For additional information, [here’s a guide] LINK(https: / /community.home-assistant.io/t/reverse-proxy-using-nginx/196954) on the subject.

Remote SSH Access

Let’s set up SSH access to the tablet so that you can access the command line remotely.

Here are the steps:

  1. On the Termux command line, install OpenSSH: pkg install openssh.
  2. On the Termux command line, generate an OpenSSH key pair: ssh-keygen
    • This will will create ~/.ssh/id_rsa and ~/.ssh/id_rsa.pub.
    • On the tablet, place the contents of ~/.ssh/id_rsa.pub in ~/.ssh/authorized_keys, change the permissions of ~/.ssh/authorized_keys to 600, and ensure the permissions of ~/.ssh are 700.
    • Copy ~/.ssh/id_rsa to the computer via ADB, and add it to your SSH client of choice.
  3. On the Termux command line, execute sshd.

You should now be able to access the tablet from your computer: ssh 192.168.2.xyz -p 8022.

To access the tablet via SSH from outside your home network, add a new entry in your router’s port forwarding settings that routes incoming traffic at port 22 to your tablet’s IP address at port 8022. Notice that this allows SSH access via the default port: ssh hass.noip.org.

Some formatting issues may come up in the terminal when accessing the tablet via SSH. Executing export TERM=xterm-256color in your remote terminal (after logging in via SSH) should resolve those issues.

For more information, check out [this article] LINK(https: / /glow.li/posts/run-an-ssh-server-on-your-android-with-termux/).

Startup at Reboot

If the tablet ever restarts, a sequence of startup commands can be put in place so that Home Assistant starts up automatically upon reboot. Install the Termux:boot application from Google Play or F-Droid. Once installed, launch the app once - this will configure Termux to launch when the system starts after a reboot.

The sequence of commands to execute on startup can be placed in a file in ~/.termux/boot/. Here’s an example boot sequence:

#! /data/data/com.termux/files/usr/bin/sh

# prevent system from sleeping
termux-wake-lock

# enable remote access
sshd

# start reverse proxy (in the background by default)
nginx

# start MQTT in the background
mosquitto -d

# start home assistant in the background
source ~/hass/bin/activate
hass --daemon
deactivate

# start node-red
node-red

Configuring Home Assistant

The setup of Home Assistant on the Nexus 7 tablet is now complete! Everything beyond the steps above is “normal” Home Assistant configuration. Refer to the [Home Assistant documentation] LINK(https: / /w w w .home-assistant.io/docs/) and [community forum] LINK(https: / /community.home-assistant.io/) as resources.

The remainder of this guide will cover the installation of extensions to Home Assistant, because there are some particularities about the Nexus 7 tablet.

Node-RED Installation

[Node-RED] LINK(https: / /nodered.org/) is a visual automation suite, in which you can create automations beyond the complexity available with the basic Home Assistant tools. As the name suggests, Node-RED is build upon NodeJS.

[AppDaemon] LINK(https: / /github.com/AppDaemon/appdaemon) is a similar tool which allows for the creation of automations in code, but there are several issues with the compatibility of AppDaemon on Termux in LineageOS. Feel free to give the installation of AppDaemon a whirl, but this guide will use Node-RED.

Install the required packages on the tablet, then start Node-RED.

pkg install nodejs
npm install node-red
npm install node-red-contrib-home-assistant-websocket
node-red

See the [Node-RED documentation] LINK(https: / /nodered.org/docs/getting-started/android) or [this guide] LINK(https: / /dev.to/anthrogan/running-node-red-on-android-4fgi) to troubleshoot any issues installation.

Connect Home Assistant to Node-RED

When using Home Assistant Core, the Node-RED connection must be installed manually from [this repository] LINK(https: / /github.com/zachowj/hass-node-red). In case the process changes with newer versions of the connection, I have not copied the setup instructions here. See the README in that repository for instructions.

After installing the connection, an Access Token must be created in Home Assistant to allow Node-RED access. Follow the instructions in [this guide] LINK(https: / /zachowj.github.io/node-red-contrib-home-assistant-websocket/guide/#generate-access-token), namely:

  • Open Home Assistant in your web browser or in the companion app.
  • Click your username in the sidebar.
  • Scroll down to the Long-Lived Access Token section, and create a token.
  • Copy the token so you can use it in the next step.

Connect Node-RED to Home Assistant

The default port for Node-RED is 1880. If you want to access Node-RED from outside your home network then you can set up a port-forward, but this isn’t recommended because Node-RED doesn’t require a username or password. Access Node-RED by navigating to http: / /192.168.2.xyz:1880.

To configure Node-RED to recognize your Home Assistant server, place any Home Assistant node on the working area and enter its edit menu. Next to Server, click the edit pencil to add a new server, and follow the instructions in the UI. See [this post] LINK(https: / /zachowj.github.io/node-red-contrib-home-assistant-websocket/guide/) for more detailed instructions.

All set! You can now create complex automation flows in Node-RED.

Google Assistant integration with Home Assistant

All of the elements are now in place to complete the integration of Google Assistant with Home Assistant. The process is well-documented and liable to change if Google changes its authentication procedure, so I will not re-write it. Follow the “Manual Setup” section of the [Google Assistant integration documentation] LINK(https: / /w w w .home-assistant.io/integrations/google_assistant/).

Once the setup is complete, all your Google Home devices will appear in Home Assistant, and you can start using them for automations.

Mosquitto MQTT Installation

[MQTT] LINK(https: / /en.wikipedia.org/wiki/MQTT) is a messaging protocol for IoT devices. It’s useful for passing around the data from sensors: for example, sensors that monitor a [laundry machine] LINK(https: / /w w w .home-assistant.io/blog/2015/08/26/laundry-automation-with-moteino-mqtt-and-home-assistant/) to sound an alarm when the laundry is complete.

The [Mosquitto MQTT broker] LINK(https: / /mosquitto.org/) is compatible with Home Assistant, and lightweight enough to install on the same Nexus 7 tablet that is running Home Assistant. Install it with pkg install mosquitto, then you can start the broker with the mosquitto command. To hook it up with Home Assistant, add the following to configuration.yaml:

mqtt:
  broker: 127.0.0.1

You can now configure your sensors to pass their data to the IP address of your tablet. For more configuration information, see the [Home Assistant page on MQTT] LINK(https: / /w w w .home-assistant.io/integrations/mqtt/).

Conclusion

That’s it, that’s all! This guide has focused on the configuration process, because it’s unique to the Nexus 7 tablet. From here on out, it’s in your hands: the process of creating automations on the tablet is identical to creating automations on any other Home Assistant installation.

If there is a step you think I missed, or a snag you ran into during the installation process, please free to contribute an edit - let’s keep this guide up to date so it remains useful as time goes on.

Thank you for reading!

3 Likes

Apologies for the broken links - I wasn’t allowed to add a certain number of images or links because my account is new. If anybody has permissions to do so, they can fix the links with these CTRL+Rs:

  • “] LINK(” -> “](”
  • ": / / " -> “://”
  • "w w w " -> “www”

thanks for detailed explanation, this was very helpful for me

I’m stuck at the SSL certificate stage. Trying to follow the instructions on the splitbrain blog, I get the following error when trying to run the dehydrated script:

ERROR: This script requires an openssl binary.

Any ideas how to fix this? Trying to install openssl says it’s already the newest version

I didn’t configure split brain DNS for my setup, so no specific solutions for you - but that error message is probably being raised by this line in the dehydrated library.

I see openssl when I run apt list --installed, but running openssl version tells me that it is not installed and to install openssl-tools. You could maybe try installing that to see if it resolves the issue? Otherwise, you could try to find the value in the ${OPENSSL} variable in the dehydrated library.

1 Like

installing openssl-tools worked - thanks!

Only issue now, is that home assistant doesn’t want to start when I have the http config in configuration.yaml, but there are no errors in the log. Commenting it out let’s home assistant start just fine.

Not sure what the issue is, any ideas?

Ignore my last post, turns out it was working fine, but I needed to access it with https and the DNS address, rather than the normal local URL with the internal IP

Thanks Alex for this very detailed guide
I’m trying to install on a Samasung Galaxy tab 2 GT-P5110
I installed Lineage 13.0, then F-droid, but I cannot install Termux as there is no compatible version. is there an alternative, or is it just that my old tab is really tooooo old ?

can you try downloading apk and installing manually? Lineage 13 is not old enough :slight_smile:

yes, and it worked :slight_smile: thanks
unfortunately, home assistant installation generated soooo many errors.
I’m afraid my tab is too old :frowning:

Perhaps you could use a RPi 4 as the HA server and combine it with the tablet as a wall mounted console?

that’s an interesting possibility

I’d say that’s the base case for any tablet that’s too old to run the Home Assistant server - regardless of how old, it should be possible to install the companion app and using it as a wall-mounted UI.

Is there a way to install add-ons. There a lot of options not available with the core version like Hacs.

Thanks

HACs is not an add-on and can be installed on core.

can you please give me idea how. I have zero skills on termux and linux in general

https://hacs.xyz/docs/installation/prerequisites

You start there and read, then click next, then scroll down to the instructions which matches your install.

Shameless to say I need step by step instruction. Is this installation a Home assistant container or Home assistant Core?

Look at the thread title, what does it say? :wink: It is HomeAssistant Core. :slight_smile: But don’t worry, you will get there! :wink:

Thank you. I did it. I can now control my Sonoff devices
