I took CM000nâs config and adjusted it to my needs. It means I have the custom layout card (just like the one you introduced in 1.0.0), with 2, 3 or 4 columns. I set the horizontal stack of the conditional chips to fill all the columns of the given orientation and resolution, and let the conditional chips fill it justified to the left Ʊ8but this is what not happening). If I put a standard grid card in the conditional horizontal stack I already have, I fear I will have empty-filled-filled-filled for example, if the 1st conditional chip in my list is not activated (for example there are no flowers to water, as it takes the 1st place in my list (see my screenshots here: đ» Lovelace UI âą Minimalist - #2317 by Andras)). Or did I misunderstand your instruction?
Never mind, build a little test setup with the grid card with 8 columns and chips with 4 of those conditional.
It fills up from the right
Although it works a bit differently than the horizontal stack it still leaves some gaps.
Another thing that might work is the state switch card. This is a more advanced conditional card.
Otherwise someone needs to find a solution to trickery the CSS grids with cardmod
Thanks for your time. as weekend is coming, I think I give the state switch card a try, if I can not figure it out, I have to live with the current one and wait for the magic regarding the conditional card. Thanks again.
UPDATE: couldnât wait until weekend However the situation is exactly the same with the state switch card, depending of the number of chips to be displayed, N columns are created and divided into equal parts. First line is with conditional card, second is with switch card, N=3:
If I add âdisplay : flexâ to element.style of hui-horizontal-stack-card in Chromeâs developer tool, I get this (1 step closer, however I have no idea what am I doing here):
How can I permanently add this to the dashboard and how can I fix the shrinkage? Anyone can help?
You should be able to hide the whole row with the same display: none !important
stuff I was doing for the chips
Could somebody help me get different icons for the buttons in the room card ? I want e.g. a different icon on the small buttons on the right when the media player is on/off.
Other question: where can I define my custom templates (not cards or chips) ?
After upgraded to the lastest version, popup light do not open (I have the old UI). Iâm alone ?
There are way more changes then mentioned in the changelog it seemsâŠ
To change the icon color based on entity-state I used this here:
- type: 'custom:button-card'
template: card_generic_swap
entity: input_select.state_trockner
name: Trockner
state:
- value: "Fertig"
styles:
icon:
- color: green
- operator: default
styles:
icon:
- color: red
now I have to use this code snipped:
- type: 'custom:button-card'
template: card_generic_swap
entity: input_select.state_trockner
name: Trockner
custom_fields:
item1:
card:
custom_fields:
item1:
card:
state:
- value: "Fertig"
styles:
icon:
- color: green
- operator: default
styles:
icon:
- color: red
Does anyone know a better way to change the icon-color based on the entity-state?
Hello⊠my light pop up is showing up like this⊠any idea how to fix it? I am using yeelight bulbs if that helps.
Hey guys,
can we add Haptics to all of the cards?
It would look like this:
tap_action:
haptic: light
Or maybe optionally with a variable!?
Hi @benm7 , your design was so beautifull
Iâm a little bug with state-switch which does not show me its content in my âsecurityâ page:
I use your code:
title: "Sécurité"
path: security
visible: false
icon: "mdi:security-home"
cards:
- type: custom:state-switch
entity: alarm_control_panel.alarme
default: disarmed
states:
disarmed:
type: custom:stack-in-card
mode: vertical
keep:
box_shadow: true
margin: true
border_radius: true
background: true
outer_padding: true
style: |
ha-card {
background-color: rgba(var(--color-green),0.7);
border-radius: var(--border-radius);
}
cards:
- type: "custom:layout-card"
layout_type: grid
layout:
grid-template-columns: 24% 76%
margin: 0px 0px 0px 0px
cards:
- type: custom:stack-in-card
mode: vertical
keep:
box_shadow: false
margin: false
border_radius: true
background: false
outer_padding: false
style: |
ha-card {
background-color: rgba(var(--color-green-bg),1.0);
border-radius: var(--border-radius-bar);
box-shadow: none;
}
cards:
- type: horizontal-stack
cards:
- type: 'custom:button-card'
template: chip_back
variables:
ulm_chip_back_path: /ui-lovelace-minimalist/settings
- type: 'custom:button-card'
template: chip_navigate
variables:
ulm_chip_navigate_path: /ui-lovelace-minimalist/home
ulm_chip_navigate_icon: mdi:home
- type: "custom:button-card"
template:
- "card_title_icon"
name: "Security"
variables:
ulm_card_navigate_title: "Sécurité"
ulm_card_navigate_icon: mdi:shield-off
icon_color: green
background_color: green-bg
armed_away:
type: custom:stack-in-card
mode: vertical
keep:
box_shadow: true
margin: true
border_radius: true
background: true
outer_padding: true
style: |
ha-card {
background-color: rgba(var(--color-red),0.7);
border-radius: var(--border-radius);
}
cards:
- type: "custom:layout-card"
layout_type: grid
layout:
grid-template-columns: 24% 76%
margin: 0px 0px 0px 0px
cards:
- type: custom:stack-in-card
mode: vertical
keep:
box_shadow: false
margin: false
border_radius: true
background: false
outer_padding: false
style: |
ha-card {
background-color: rgba(var(--color-red-bg),1.0);
border-radius: var(--border-radius-bar);
box-shadow: none;
}
cards:
- type: horizontal-stack
cards:
- type: 'custom:button-card'
template: chip_back
variables:
ulm_chip_back_path: /ui-lovelace-minimalist/settings
- type: 'custom:button-card'
template: chip_navigate
variables:
ulm_chip_navigate_path: /ui-lovelace-minimalist/home
ulm_chip_navigate_icon: mdi:home
- type: "custom:button-card"
template:
- "card_title_icon"
name: "Security"
variables:
ulm_card_navigate_title: "Sécurité"
ulm_card_navigate_icon: mdi:shield-lock
icon_color: red
background_color: red-bg
- type: "custom:button-card"
template: "card_title_fixed_small"
name: "SystÚme de sécurité"
Have you the same issue?
For information I tried with different version of state-switch.
Thanks in advance for your help
Hi there!
Sorry its not entirely clear to me what the issue might be. Does it work without the state-switch? You may also have different state options for your alarm to what I have, so perhaps check the entity state options for your alarm to make sure they match.
How do i implement conditional cards or especially chips?
I do not see that info in the docs.
Thank you all for your help.
After updating to the current version I got the same problem. With 0.9 it works like a charm.
There is some progress to add names and icons to variables for all cards in the upcoming release
Morning team! Feel I maybe missing something here, I use the following for my light -
- type: "custom:button-card"
template: card_light
entity: light.yeelight_color_0x52e8ea7
variables:
ulm_card_light_enable_popup: true
ulm_card_light_enable_slider: true
ulm_card_light_enable_color: true
ulm_card_light_force_background_color: true
I then hold the light name or icon for a second and release and I donât get the swanky looking popup as per these screenshots - Light Popup - UI Lovelace Minimalist
I just get your generic actions -
Hopefully this is something really similar but any ideas?
Check your custom_actions settings. And add popup to the actions you want.
https://ui-lovelace-minimalist.github.io/UI/setup/custom_actions/
Good Morning!
Maybe someone can help me with my âpopupâ problems. Everything worked perfectly a while ago. Somehow all of the button-card popups stopped working.
eg.
- type: custom:button-card
template: card_light
entity: light.badhauptlicht
variables:
ulm_card_light_enable_slider: true
ulm_card_light_enable_color: true
ulm_card_light_force_background_color: true
ulm_card_light_name: Hauptlicht
ulm_card_light_enable_popup: true
ulm_card_light_enable_popup_tap: true
this does not show up any popup at all at the moment. It just shows the more-info dialog instead.
But this one for example works perfectly:
- type: 'custom:button-card'
template: chip_icon_label
label: WiFi
icon: mdi:wifi
tap_action:
action: call-service
service: browser_mod.popup
service_data:
large: false
hide_header: false
card:
type: picture
image: /local/frame.png
show_state: false
show_name: false
title: Scannen zum Verbinden
I have a few more popups that show up âoriginalâ Home Assistant Cards, that work perfectly. It just seems that all of the button-card popups from the Minimalist Integration just simply stopped working. Of coure everything (Minimalist, Browser Mod, HomeAssistant itself) is up to date.
Appreciate your help!
See the post directly above yours to find a fix
Double popup posts I do have mine set to popup in the above yaml, but sometimes it will do nothing and sometimes it will do the above No major one really can still live without but always nice to have the snazzy looking things eh!
