Domintell custom component

ridsel · February 28, 2025, 9:26am

Yes, a very friendly lady called me twice. There will be a big announcement in March from domintell in the newsletter. Domintell will soon be available in Home Assistant.

dvanvyve · March 21, 2025, 11:27am

Hi All,

I’m new on Home Assistant. I managed to connect to my DGQG01 (via DETH02) and control DBIR, DDIM, Temp Sensor but I’m facing an issue with the session : whenever I use another device than Home Assistant to access my DETH02, the session got closed and I couldn’t find a way to far to reconnect.

Does anyone already create an automation for this ?

Thanks.

hapasse · March 21, 2025, 1:19pm

Hi,

The DETH02 module only accepts one connection/client at a time.
If “Exclusive session” is not set in parameters of the DETH02 in the Domintell2 software, each time a client connects to the DETH02, it will steal the session to the currently connected client.

If “Exclusive sessions” is enabled, you have to wait a timeout or a LOGOUT of the currently connected slave. A timeout occurs when no command is sent to DETH02 by the client (e.g. Home Assistant or Domintell Pilot) (including “HELLO” heartbeat). If you set session timeout to 0 using the Domintell2 software, You absolutely have to send the LOGOUT command to allow another client to connect to the DETH02

This problem is solved by installing as much DETH02 as you want simultaneous connections or replace it by a DNET01 that accepts up to 8 simultaneous connections. The best is to contact the Domintell support to have the right information.

Best regards.

dvanvyve · March 21, 2025, 2:29pm

Thanks for your feedback,

DNET01 is not compatible with DGQG01 and I have other old modules also not compatible with DGQG03/04.

The new module created by Domintell for HA will only be compatible with DGQG04.

Currently, since I’m using different applications/devices to connect to my DETH02, I have setup a timeout of 1 min and I have disabled the “Exclusive Session”.

But I could indeed add a second DETH02 module dedicated to HA or stop using my other applications.

Thanks.

hapasse · March 21, 2025, 3:04pm

DNET01 is suited for DGQG01 but you have to use “GoldenGate for DGQG01” but "GoldenGate for DGQG01 drops support of very old modules like DTSC01/03, DLCD0x, …

DNET02 is suited for DQGQ02/04.

The new integration created by Domintell for HA is compatible with any installation that has a DGQG01+DNET01, a DGQG02/04 or DGQG02/04+DNET02

Best regards.

dvanvyve · March 21, 2025, 3:44pm

OK,

Good to know. This is not what I understood from Domintell Support Team.

The Issue is linked to my 3 DTSC03. So I cannot use GoldenGate for DGQG01…

The cheapest solution will be to have an extra DETH02 in Exclusive mode for HA.

Thanks

hapasse · March 21, 2025, 4:13pm

Once source code will be released, you could try to implement the UDP suppport and pull request it

dvanvyve · March 21, 2025, 4:15pm

To be tested

Felipe2 · March 22, 2025, 9:25am

Update 3 : I fixed it.
Had to install goldengate1.46, do a firmware update to v30 on the master.
Than a conversion of de DAP file in domitell 1.27 soft

hapasse · March 22, 2025, 1:16pm

Hi,

For users who had the same issue or needs to update the O.S. of the DGQG01 to solve some bugs or you want to replace your DETH02 by a DNET01, the best from my experience, to avoid any lost of data, is:

Please note that if you have DTSC01/03 (any O.S. version) or DTSC02/04 (with O.S. older than 1.24.0), you will not be able to upgrade your installation!

If you do not have your DAP file on your computer, read the application from the DGQG with your current (old) version of Domintell 2 software.
Backup your current DAP in a special directory and do not touch (open) it anymore (elsewhere than in Documents/Domintell2 directory.
Install Domintell2 software version 1.27.09.04 (the best is to install it in electrician mode (check yes at first step of the installer).
Open Domintell2 software version 1.27.09.04. It will create the directory Documents\Domintell2\V1_27_09 .
Copy your DAP file to Documents\Domintell2\V1_27_09. This is very important as opening an old DAP file with a more recent version of a Domintell2 software will migrate/update the DAP file in-place (but don’t worry a backup of the original file is performed to Documents\Domintell2\Backup if you missed some steps before ).
Open your DAP file from Documents/Domintell2/V1_27_09 directory using the Domintell2 software version 1.27.09.04.
Read any warnings/dialogs to be sure nothing has been dropped or reset. Fix them if required. Then, just save it and close the Domintell2 software.
Open GoldenGate for DGQG01 and open the DAP file.
For the first move, update O.S. of the DGQG01 and modules. Please note that DTSC02/04 can not be downgraded!
Send the DAP file to the DGQG01.
Have fun with HA

It is a long time I didn’t do this but I think this is a good/secure way to proceed.

Best regards.

Mabaker · April 1, 2025, 7:16pm

Hi,

Is there any news on the March newsletter from
Domintell? Any more news on Domintell coming to home assistant?

Thanks

hapasse · April 1, 2025, 9:16pm

Hi,

This could be this one but I didn’t test it.

Best regards.

Villersfr2 · April 2, 2025, 1:31pm

yes it is !!! just released today on HACS and will be available tomorrow hi think : [ANNOUNCEMENT] Official Domintell Integration for Home Assistant Now Available via HACS!

hapasse · April 7, 2025, 7:19am

Hi,

By looking some recently closed PR (Pull Request) in HACS/default repository It may not be available in HACS before several weeks/months.

Some are merge within a day but most of them are merged after 7 months without any other activity in the PR. See some examples bellow.

Until then, you will have to install the Domintell integration manually

Some are immediately merged : 2025/02/11 → 2025/02/12

github.com/hacs/default

Adds new integration [unii-security/homeassistant-unii]

master ← rrooggiieerr:unii

opened 02:28PM - 11 Feb 25 UTC

rrooggiieerr

+1 -0

## Checklist - [x] I've read the [publishing documentation](https://hacs.…xyz/docs/publish/start). - [x] I've added the [HACS action](https://hacs.xyz/docs/publish/action) to my repository. - [x] (For integrations only) I've added the [hassfest action](https://developers.home-assistant.io/blog/2020/04/16/hassfest/) to my repository. - [x] The actions are passing without any disabled checks in my repository. - [x] I've added a link to the action run on my repository below in the links section. - [x] I've created a new release of the repository after the validation actions were run successfully. ## Links Link to current release: <https://github.com/unii-security/homeassistant-unii/releases/tag/1.0.0> Link to successful HACS action (without the `ignore` key): <https://github.com/unii-security/homeassistant-unii/actions/runs/11004952581> Link to successful hassfest action (if integration): <https://github.com/unii-security/homeassistant-unii/actions/runs/12307702841>

Some take one month : 2025/01/05 → 2025/02/03

github.com/hacs/default

Adds new template [jazzyisj/speech-helpers-jinja]

master ← jazzyisj:speech-helpers-jinja

opened 02:31AM - 05 Jan 25 UTC

jazzyisj

+1 -0

## Checklist - [X] I've read the [publishing documentation](https://hacs.…xyz/docs/publish/start). - [X] I've added the [HACS action](https://hacs.xyz/docs/publish/action) to my repository. - [ ] (For integrations only) I've added the [hassfest action](https://developers.home-assistant.io/blog/2020/04/16/hassfest/) to my repository. - [X] The actions are passing without any disabled checks in my repository. - [X] I've added a link to the action run on my repository below in the links section. - [X] I've created a new release of the repository after the validation actions were run successfully. ## Links Link to current release: <https://github.com/jazzyisj/speech-helpers-jinja/releases/tag/v0.0.2> Link to successful HACS action (without the `ignore` key): <https://github.com/jazzyisj/speech-helpers-jinja/actions/runs/12615644560/job/35155950561>

Others take 7 months : 2024/09/23 → 2025/03/28

github.com/hacs/default

Adds new integration [jampez77/Yodel]

master ← jampez77:Adds-new-integration-jampez77/Yodel]

opened 03:35PM - 23 Sep 24 UTC

jampez77

+1 -0

## Checklist - [x] I've read the [publishing documentation](https://hacs.…xyz/docs/publish/start). - [x] I've added the [HACS action](https://hacs.xyz/docs/publish/action) to my repository. - [x] (For integrations only) I've added the [hassfest action](https://developers.home-assistant.io/blog/2020/04/16/hassfest/) to my repository. - [x] The actions are passing without any disabled checks in my repository. - [x] I've added a link to the action run on my repository below in the links section. - [x] I've created a new release of the repository after the validation actions were run successfully. ## Links Link to current release: https://github.com/jampez77/Yodel/releases/tag/2024.9.0 Link to successful HACS action (without the `ignore` key): https://github.com/jampez77/Yodel/actions/runs/10997527250 Link to successful hassfest action (if integration): https://github.com/jampez77/Yodel/actions/runs/10997527248

UntriexTv · April 7, 2025, 9:47am

Hello, I am the one that started most of the issues. It can be easily installed by adding repository with the button in readme. It should be working now.
I am running it rigt now and testing if I fing any more issues.

hapasse · April 7, 2025, 10:43am

I am not able to test HACS button in README.md as HACS is not enabled on my box. Thank you for the confirmation

thedoudou · June 26, 2025, 4:38pm

Hi men,

Did someone see the variable into the integration ? I can see all my modules but no variable

David

hapasse · June 29, 2025, 9:47am

Hi thedoudou,

Can you give us more information, please ?
Do you use DGQG01+DNET01, DGQG02/04, DGGQ02/04 + DNET02 ?
Are you sure you did not set up the variables as “Master Only”.

You can also post your DAP file (you should anonymize the name of inputs/outputs/notifications/… and drop your DynDNS information (if any)).

Best regards.

thedoudou · July 2, 2025, 9:17pm

Hi，

i’m using thé DGQG04 without any DNET interface, and my variables have not the Master Only option checked.

David

hapasse · July 9, 2025, 5:55am

Hi thedoudou,

Can you give us the version of the Domintell integration, HA, GoldenGate and if it is possible, your DAP file (do not forget to anonymize name of inputs/outputs by renaming them) because it is working for me.

Best regards
