[Custom Component] TP-Link Router Integration (supports also Mercusys router)

Share your Projects! Custom Integrations
1

Home Assistant component for complete TP-Link and Mercusys routers administration with sensors, button reboot, switches, device tracking and sending SMS.
With configuration via GUI

sensors
sensors906Ă—856 69.7 KB

Components

Events

  • tplink_router_new_device: Fired when a new device appears in your network
  • tplink_router_device_offline: Fired when a device becomes offline
  • tplink_router_device_online: Fired when a device becomes online
  • tplink_router_new_sms: Fired when a new sms received by LTE router

Switches

  • Router Reboot
  • Router data fetching - you may disable router data fetching before accessing the router, so it wont logging your out.
    If you forget to enable it back - it would be automatically enable after 20 minutes
  • 2.4Ghz host wifi Enable/Disable
  • 5Ghz host wifi Enable/Disable
  • 6Ghz host wifi Enable/Disable
  • 2.4Ghz guest wifi Enable/Disable
  • 5Ghz guest wifi Enable/Disable
  • 6Ghz guest wifi Enable/Disable
  • 2.4Ghz IoT wifi network Enable/Disable
  • 5Ghz IoT wifi network Enable/Disable
  • 6Ghz IoT wifi network Enable/Disable

Sensors

  • Total amount of wired clients
  • Total amount of IoT clients
  • Total amount of host wifi clients
  • Total amount of guest wifi clients
  • Total amount of all connected clients
  • CPU used
  • Memory used
  • Connection Type

For LTE Routers

  • LTE Enabled
  • LTE Connection Status
  • LTE Network Type
  • LTE SIM Status
  • LTE Total Statistics
  • LTE Current RX Speed
  • LTE Current TX Speed
  • Unread SMS
  • LTE Signal Level
  • LTE RSRP
  • LTE RSRQ
  • LTE SNR
  • LTE ISP Name

Device Tracker

  • Track clients by MAC address across 2.4Ghz, 5Ghz, 6Ghz guest and main wifi with connection information

Services

  • Send SMS message - Available only for MR LTE routers

Supported routers

TP-LINK router

  • Archer A6 V2.0
  • Archer A7 V5
  • Archer A8 (1.0, 2.20)
  • Archer A9 V6
  • Archer A20 v1.0
  • Archer AX10 v1.0
  • Archer AX12 v1.0
  • Archer AX17 v1.0
  • Archer AX20 (v1.0, v3.0)
  • Archer AX21 (v1.20, v3.0)
  • Archer AX23 (v1.0, v1.2)
  • Archer AX50 v1.0
  • Archer AX53 (v1.0, v2)
  • Archer AX55 (v1.0, V1.60, v4.0)
  • Archer AX58 v1.0
  • Archer AX72 V1
  • Archer AX73 (V1, V2.0)
  • Archer AX75 V1
  • Archer AX90 V1.20
  • Archer AXE75 V1
  • Archer AXE5400 v1.0
  • Archer AXE16000
  • Archer AX1800
  • Archer AX3000 V1
  • Archer AX6000 V1
  • Archer AX11000 V1
  • Archer BE230 v1.0
  • Archer BE400 v1.0
  • Archer BE550 v1.0
  • Archer BE800 v1.0
  • Archer BE805 v1.0
  • Archer BE3600 1.6
  • Archer C1200 (v1.0, v2.0)
  • Archer C2300 (v1.0, v2.0)
  • Archer C6 (v2.0, v3.0, v3.20, 4.0)
  • Archer C6U v1.0
  • Archer C7 (v4.0, v5.0)
  • Archer C24 (1.0, 2.0)
  • Archer C60 v2.0
  • Archer C64 1.0
  • Archer C80 (1.0, 2.20)
  • Archer C5400X V1
  • Archer GX90 v1.0
  • Archer MR200 (v5, v5.3, v6.0)
  • Archer MR550 v1
  • Archer MR600 (v1, v2, v3)
  • Archer NX200 v2.0
  • Archer VR400 v3
  • Archer VR600 v3
  • Archer VR900v
  • Archer VR1200v v1
  • Archer VR2100v v1
  • Archer VX1800v v1.0
  • BE11000 2.0
  • Deco M4 2.0
  • Deco M4R 2.0
  • Deco M5 v3
  • Deco M9 Pro
  • Deco M9 Plus 1.0
  • Deco P7
  • Deco X20
  • Deco X50 v1.3
  • Deco X55 1.0
  • Deco X60 V3
  • Deco X90
  • Deco XE75 (v1.0, v2.0)
  • Deco XE75PRO (v3.0)
  • EX511 v2.0
  • HX510 v1.0
  • NX510v v1.0
  • TD-W9960 (v1, V1.20)
  • TL-MR100 v2.0
  • TL-MR105
  • TL-MR100-Outdoor v1.0
  • TL-MR110-Outdoor v1.0
  • TL-MR150 v2
  • TL-MR6400 (v5, v5.3)
  • TL-MR6500v
  • TL-WA1201 3.0
  • TL-WA3001 v1.0
  • TL-XDR3010 V2
  • TL-WDR3600 V1
  • VX420-G2h v1.1
  • VX800v v1
  • XC220-G3v v2.30

MERCUSYS routers

  • MR47BE v1.0
  • MR50G 1.0
  • H60XR 1.0
  • H47BE 2.0
  • Halo H80X 1.0
  • Halo H3000x 1.0

Please let me know if you have tested integration with any other model. Open an issue with info about router’s model, hardware and firmware versions.

11 Likes
2

TP-Link Archer AX10 support confirmed

3

I have made a research.
These routers also should be supported, but I can’t test the integration completely with them.

If you have one of them, could you test this component please and let me know?

Models:

  • AD7200 V2
  • Archer A6 (V2 and V3)
  • Archer A7 V5
  • Archer A9 V6
  • Archer A10 (V1 and V2)
  • Archer A20 (V1, V3)
  • Archer AX50 V1
  • Archer AX3000 (V1, V2)
  • Archer AX6000 V1
  • Archer C6 V4
  • Archer C7 (V4 and V5)
  • Archer C8 (V3 and V4)
  • Archer C9 (V4 and V5)
  • Archer C59 V2
  • Archer C90 V6
  • Archer C900 V1
  • Archer C1200 (V2, V3)
  • Archer C1900 V2
  • Archer C2300 (V1, V2)
  • Archer C4000 (V2 and V3)
  • Archer C5400 V2
  • Archer C5400X V1
  • TL-WR1043N V5
4

Hi,
Is it possible to allow block device connected to wifi? Or can you add?

5

Hi
I will check

6

v1.0.0 Released

Changelog

  • Added https connection support
  • Added CPU used sensor
  • Added Memory used sensor
7

v1.2.4 Released

Changelog

  • Fixed Archer C6 v2.0 support
  • Added Archer C7 v5.0 support
8

Greetings, I have installed the HACS repo, and went to install the integration for my Archer AX10000 and got the following error message:

Expecting value: line 1 column 1 (char 0)

Any thoughts as to what could have caused this?

9

Working for me on Archer AX3000 - thanks for setting this up!

It would be great if this could expose the IoT Wi-Fi network client numbers too (for each of the 2.4 GHz and 5 GHz networks).

10

Hi, @AlexandrErohin , love your work on this.

Can confirm that the TP-Link Archer AX73 - V1 is working. Very happy with it :clap:

Just 2 questions:

  • is it possible to change the standard scan interval 30 sec. to a smaller size? For
    instance 15 sec. after installation?
  • after setup I want to be able to logout from the router, because the TP-Link AX 73 only allows 1 admin login.
    Thanks in advance.
1 Like
11

Could you get the full error log? Like this one Archer A7 V5 setup failed · Issue #10 · AlexandrErohin/home-assistant-tplink-router · GitHub

12

Thank you for the info! What version of you AX3000 V1 or V2 ?
Could you make a screenshot of IoT Network in the router UI - I cannot find it

13

Thank you for the info about Archer AX73 V1 support!
About questions

  • Unfortunately, it can only change in setup window. You need to delete integration and configure it again. In the future release it would be added changing the system options
  • To get updates from the router - the integration on every updates - logs in → gets updates → logs out.
    So by default it logs in and logs out every 30 seconds. If you want to log in in UI - you would be logged out from UI when the integration makes its next update.
14

Okay that’s clear. So I’ll change the settings after a new install.
Thanks for the quick response! :facepunch:

15

It is AX3000 V1.

This is what the IoT Network UI looks like:

Screenshot 2023-12-18 172844
Screenshot 2023-12-18 1728441069Ă—987 55 KB

16

wow your AX3000 V1 looks like AX3000 V2

Unfortunately, my router doesnt have IoT Network - so I cannot add it to the integration.
It would be great if you could add it to the client GitHub - AlexandrErohin/TP-Link-Archer-C6U: Python package for API access and management for TP-Link Router and then I add to the home assistant component

17

Hmm, the sticker on the bottom says “v1.6”, so I assume that’s V1. It is this model, not this model.

I can try to add it, might take some time.

18

Could you check your links - it looks like links are the same

19

Oops, edited my post.

1 Like
20

Thank you!

Vorks on my Archer AX55.

1 Like
